Ace EX-G049 User manual

EX-G049
1x8 HDMI 1.3 Distribution Amplifier
User Manual
ACE PLUS CORP.
Headquarters :
9F-2., No. 190 Sec. 2 Jung Shing Rd.,Hsin-dian,
Taipei, Taiwan 231
TEL: [phone]
FAX: [phone]
Website: www.ace-plus.com
Page 1 of 7

Safety and Notice
The EX-G049 1x8 HDMI 1.3 Distribution Amplifier has been tested for conformance to safety
regulations and requirements, and has been certified for international use. However, like all electronic
equipments, the EX-G049 should be used with care. Please read and follow the safety instructions to
protect yourself from possible injury and to minimize the risk of damage to the unit.
zFollow all instructions and warnings marked on this unit.
zDo not attempt to service this unit yourself, except where explained in this manual.
zProvide proper ventilation and air circulation and do not use near water.
zKeep objects that might damage the device and assure that the placement of this unit is on a
stable surface.
zUse only the power adapter and power cords and connection cables designed for this unit.
zDo not use liquid or aerosol cleaners to clean this unit. Always unplug the power to the device
before cleaning.
Introduction
The EX-G049 1x8 HDMI 1.3 Distribution Amplifier provides the most cost effective and
advanced HDMI 1.3 splitter solution on the market, by which the high definition video and high quality
audio can be transmitted to 8 different locations without losing quality. With built-in USB firmware
update mechanism, the compatibility among countless HDMI sources and receivers can be further
guaranteed. With 12 bit deep color video and high definition audio support, EX-G081 is suitable for
high quality A/V broadcasting, digital signage and education applications!
ACE PLUS CORP.
Headquarters :
9F-2., No. 190 Sec. 2 Jung Shing Rd.,Hsin-dian,
Taipei, Taiwan 231
TEL: [phone]
FAX: [phone]
Website: www.ace-plus.com
Page 2of 7

Features
zHDMI 1.3c and DVI 1.0 compliant
zHDCP 1.2 compliant
zWide Frequency Range: 25MHz~225MHz
zVideo bandwidth: 6.75GBPS
zSupports conversion of HDMI signaling to DVI
zResolution up to 1080p or WUXGA
zAutomatic EDID learning
zSupports xvYCC
zSupports CEC (not bypassing)*
zSupports Dolby Digital, DTS-HD and Dolby True HD audio
zUSB firmware update for expanding compatibility
zEasy installation
Automatic EDID learning will detect all the connected HDMI equipped monitors and analyze
all the content of EDID. The EDID with minimal resolution support will be the reference EDID
for incoming HDMI source players.
*Depends on models
ACE PLUS CORP.
Headquarters :
9F-2., No. 190 Sec. 2 Jung Shing Rd.,Hsin-dian,
Taipei, Taiwan 231
TEL: [phone]
FAX: [phone]
Website: www.ace-plus.com
Page 3of 7

Specifications & Package Contents
Model Name EX-G049
Technical
HDMI compliance HDMI 1.3c [Deep Color, xvYCC color space supported]
DVI compliance DVI 1.1
HDCP compliance Yes
Video bandwidth Single-link 225MHz [6.75Gbps]
Video support Up to WUXGA [1920x1200@60Hz] & UXGA [1600x1200@60Hz]
Transmission length
1920x1200@60Hz: 30m (100ft)
[CAT5e]
1024x768@60Hz: 60m (200ft)
[CAT5e]
1920x1200@60Hz: 15m (100ft)
[CAT5e]
1024x768@60Hz: 25m (200ft)
[CAT5e]
Audio support DTS-HD Master Audio, Dolby TrueHD
Dolby Digital, DTS, DVD-Audio, LPCM, SACD, MPCM
ESD protection
[1] Human body model — ±15kV [air-gap discharge] & ±8kV [contact
discharge]
[2] Core chipset — ±2kV
PCB stack-up 4-layer board [impedance control — differential 100Ω; single 50Ω]
USB firmware
updatable YES
Input TMDS signal 1.2 Volts [peak-to-peak]
Input DDC signal 5 Volts [peak-to-peak, TTL]
Input 1x HDMI [7.1ch audio & video]
Output 8x HDMI [7.1ch audio & video]
HDMI connector Type A [19-pin female]
Mechanical
Housing Metal
Dimensions (L x W x H)
Model: mm []
Package: mm []
Carton: 495 x 440 x 380mm [1’7.5”x1’5.3”x1’3”]
Weight EX-G049: 630g [1.4 lbs] / Package: 997g [2.2 lbs]
Fixedness Wall-mounting case with screws upon request
Power supply 5V 4A DC
Power consumption 10 Watts [max]
Operation temperature 0~40°C [32~104°F]
Storage temperature -20~60°C [-4~140°F]
Relative humidity 20~90% RH [no condensation]
Package Contents 1x EX-G049 1x 5V power adapter 1x User Manual
ACE PLUS CORP.
Headquarters :
9F-2., No. 190 Sec. 2 Jung Shing Rd.,Hsin-dian,
Taipei, Taiwan 231
TEL: [phone]
FAX: [phone]
Website: www.ace-plus.com
Page 4of 7

Panel Descriptions
Rear Panel
1. HDMI OUT: Distributed HDMI outputs
2. HDMI IN: HDMI input source
3. USB IN: For firmware update use only
4. Power Indicator: When power on, the LED will blink.
5. DC IN: 5V 4A
When the connected HDMI equipped monitor is verified as HDMI and HDCP compliant, the
corresponding green LED will blink.
1
2
1
3
4
5
ACE PLUS CORP.
Headquarters :
9F-2., No. 190 Sec. 2 Jung Shing Rd.,Hsin-dian,
Taipei, Taiwan 231
TEL: [phone]
FAX: [phone]
Website: www.ace-plus.com
Page 5of 7

Hardware Installation
Broadcasts HDMI signal to 8 HDMI displays!
1.Switch off all devices, including monitors.
2.Connect to the receivers.
3.Connect an HDMI source (such as a Blu-ray Disc player) to the HDMI In.
4.Plug in 5V DC power supply.
5.Power on the HDMI monitors.
6.Power on the HDMI source. HDMI
EX-G076B
EX-G076A
EX-G049
HDMI source
HDMI cable
HDTV
HDTV
HDMI cable
ACE PLUS CORP.
Headquarters :
9F-2., No. 190 Sec. 2 Jung Shing Rd.,Hsin-dian,
Taipei, Taiwan 231
TEL: [phone]
FAX: [phone]
Website: www.ace-plus.com
Page 6of 7

Notice
1. While connecting a new monitor to the splitter, experiencing a short period of time no display may
be expected. Automatic EDID learning will analyze the newly connected monitor to see if the EDID
for the HDMI input is necessary to update!
2. For long range high definition HDMI transmission applications, please adopt CAT-5 cable based
HDMI extenders.
Limited Warranty
The SELLER warrants the EX-G049 1x8 HDMI 1.3 Distribution Amplifier to be free from defects
in the material and workmanship for 1 year from the date of purchase from the SELLER or an
authorized dealer. Should this product fail to be in good working order within 1 year warranty period,
The SELLER, at its option, repair or replace the unit, provided that the unit has not been subjected to
accident, disaster, abuse or any unauthorized modifications including static discharge and power
surges.
Unit that fails under conditions other than those covered will be repaired at the current price of
parts and labor in effect at the time of repair. Such repairs are warranted for 90 days from the day of
reshipment to the BUYER. If the unit is delivered by mail, customers agree to insure the unit or
assume the risk of loss or damage in transit. Under no circumstances will a unit be accepted without a
return authorization number.
The warranty is in lieu of all other warranties expressed or implied, including without limitations,
any other implied warranty or fitness or merchantability for any particular purpose, all of which are
expressly disclaimed.
Proof of sale may be required in order to claim warranty. Customers outside Taiwan are
responsible for shipping charges to and from the SELLER. Cables are limited to a 30 day warranty and
cable must be free from any markings, scratches, and neatly coiled.
The content of this manual has been carefully checked and is believed to be accurate. However,
The SELLER assumes no responsibility for any inaccuracies that may be contained in this manual.
The SELLER will NOT be liable for direct, indirect, incidental, special, or consequential damages
resulting from any defect or omission in this manual, even if advised of the possibility of such damages.
Also, the technical information contained herein regarding the EX-G049 features and specifications is
subject to change without further notice.
