Ace USB-EX100 User manual

USB-EX100
USB Extender Over CAT5
User Manual
Made in Taiwan
ACE PLUS CORP.
Page 1 of 6
JAN 06 /2011
Headquarters :
9F.-2, No.190, Sec. 2, Zhongxing Rd., Xindian Dist., New Taipei City 231, Taiwan
Tel : [phone]
Fax : [phone]
E-Mail: [email protected]
Technical Support: [email protected]
http://www.ace-plus.com
http://www.ace-plus.tw

Safety and Notice
The USB-EX100 USB Extender Over CAT5 has been tested for conformance to safety regulations and requirements,
and has been certified for international use. However, like all electronicequipments, the USB-EX100 should be used with
care. Please read and follow the safety instructions to protect yourself from possible injury and to minimize the risk of
damage to the unit.
zFollow all instructions and warnings marked on this unit.
zDo not attempt to service this unit yourself, except where explained in this manual.
zProvide proper ventilation and air circulation and do not use near water.
zKeep objects that might damage the device and assure that the placement of this unitis on a stable surface.
zUse only the power adapter and power cords and connection cables designed for this unit.
zDo not use liquid or aerosol cleaners to clean this unit.Always unplug the power to the device before cleaning.
ACE PLUS CORP.
Page 2 of 6
JAN 06 /2011
Headquarters :
9F.-2, No.190, Sec. 2, Zhongxing Rd., Xindian Dist., New Taipei City 231, Taiwan
Tel : [phone]
Fax : [phone]
E-Mail: [email protected]
Technical Support: [email protected]
http://www.ace-plus.com
http://www.ace-plus.tw

The USB-EX100 USB Extender over CAT5 makes USB equipped device accessible over CAT5. Peripheral devices can be
managed and monitored via LAN cable. USB-EX100 helps you extend USB peripheral device up to 330feet.The extender
consistsof two units,local and remote unit. The local unit connects to the PC and the remote unit connect to the peripheral
device, such as USB printers, USB camera, USB Storage devices, USB Card-Readers,and more.
Features
zExtend any USB peripheral device up to 330ft.
zUse standard CAT5/CAT6
zUSB Compatibility: USB 1.0, 1.1, 2.0 (USB 2.0 devices operate at 12 Mbps)
zEasy to setup
Introduction
ACE PLUS CORP.
Page 3 of 6
JAN 06 /2011
Headquarters :
9F.-2, No.190, Sec. 2, Zhongxing Rd., Xindian Dist., New Taipei City 231, Taiwan
Tel : [phone]
Fax : [phone]
E-Mail: [email protected]
Technical Support: [email protected]
http://www.ace-plus.com
http://www.ace-plus.tw

Specifications & Package Contents
Model Name USB-EX100
Technical USB-EX100-TX USB-EX100-RX
Role of usage Local of Extender Remote of Extender
USB USB 2.0 high speed compliant USB 2.0 high speed compliant
LAN 10/100Mbp/Auto-sensing/Auto-crossover 10/100Mbp/Auto-sensing/Auto-crossover
ESD protection Human body model— ±19kV [air-gap
dischar
g
e
]
& ±12kV
[
contact dischar
g
e
]
Human body model— ±19kV [air-gap
dischar
g
e
]
& ±12kV
[
con
t
act dischar
g
e
]
Input TypeA RJ45
Output RJ45 TypeA
Mechanical
Housing Metal enclosure
Dimensions (L
x W x H)
Model 40 x 65 x 26mm [1.5”x2.5”x1.0”]
Packa
g
e 270 x 175 x 80mm
[
10.6” x 6.9” x 3.1”
]
Carton 450 x 370 x 300mm [1’6” x 1’3” x 1’]
Weight Model 300g [1.1 lbs]
Package 480g [1.7 lbs]
Fixedness Wall-mounting case with screws
Power Supply 5V 0.85ADC
Power consumption
Operation temperature 0~40°C [32~104°F]
Storage temperature -20~60°C [-4~140°F]
Relative humidity 20~90% RH [no condensation]
Package Contents 1x USB-EX100 1x User Manual
1x 5V 2Ainterlocked wall wart power adapter
ACE PLUS CORP.
Page 4 of 6
JAN 06 /2011
Headquarters :
9F.-2, No.190, Sec. 2, Zhongxing Rd., Xindian Dist., New Taipei City 231, Taiwan
Tel : [phone]
Fax : [phone]
E-Mail: [email protected]
Technical Support: [email protected]
http://www.ace-plus.com
http://www.ace-plus.tw

Hardware Installation
1. Connect your PC USB port to USB-EX100 TX USB input
2. Connect CAT output port of USB-EX100TX and CAT input port of USB-EX100 RX
3. Connect +5V Power to USB-EX100 RX
4. Connect USB devices to USB-EX100. RX
5. Run the USB2.0 Lan Extender software.
6. USB 2.0 Extender status icon will show the USB peripheral exist or not.
Software Installation
1. Install Driver
2. Install USB_LAN_Extenderl software
3 Power off PC.
Installation
Notice
SoftwareInstall
ACE PLUS CORP.
Page 5 of 6
JAN 06 /2011
Headquarters :
9F.-2, No.190, Sec. 2, Zhongxing Rd., Xindian Dist., New Taipei City 231, Taiwan
Tel : [phone]
Fax : [phone]
E-Mail: [email protected]
Technical Support: [email protected]
http://www.ace-plus.com
http://www.ace-plus.tw

The SELLER warrants the USB-EX100 4 Port USB Hub over Ethernet to be free from defects in the material and
workmanship for 1 year from the date of purchase from the SELLER or an authorized dealer. Should this product fail to be in
good working order within 1 year warranty period, The SELLER, at its option, repair or replace the unit, provided that the
unit has not been subjected to accident, disaster, abuse or any unauthorized modifications including static discharge and
power surge. This warranty is offered by the SELLER for its BUYER with direct transaction only. This warranty is void if the
warranty seal on the metal housing is broken.
Unit that fails under conditions other than those covered will be repaired at the current price ofparts and labor in effect
at the time of repair. Such repairs are warranted for 90 days from the day of reshipment to the BUYER. If the unit is
delivered by mail, customers agree to insure the unit or assume the risk of loss or damage in transit. Under no
circumstances will a unit be accepted without a return authorization number.
The warranty is in lieu of all other warranties expressed or implied, including without limitations, any other implied
warranty or fitness or merchantability for any particular purpose, all of which are expressly disclaimed.
Proof of sale may be required in order to claim warranty. Customers outside Taiwan are responsible for shipping
charges to and from the SELLER. Cables and power adapters are limited to a 30 day warranty and must be free from any
markings, scratches, and neatly coiled.
The content of this manual has been carefully checked and is believed to be accurate. However, The SELLER
assumes no responsibility for any inaccuracies that may be contained in this manual. The SELLER will NOT be liable for
direct, indirect, incidental, special, or consequential damages resulting from any defect or omission in this manual, even if
advised of the possibility of such damages. Also, the technical information contained herein regarding the USB-EX100
features and specifications is subject to change without further notice.
LimitedWarranty
