ACELERON ESSENTIAL User manual

ESSENTIAL
12V 100Ah Li-ion
USER GUIDE
2021-05 V01

Accelerating access
to energy storage
Truly committed to a circular economic model, Aceleron
exists to bring sustainability and innovation to the
Tech industry by revolutionising the linear economy’s
traditional battery manufacturing methods, with our
next-gen advanced storage.
At the core of our products is our Patented Circa™
Platform. The state-of-the-art assembly technology
is engineered for the future, making our products the
world’s 1st Serviceable, Upgradeable and Recyclable
Lithium Iron Phosphate batteries. Designed with their
applications’ lifespan in mind, our energy storage
solutions allow partner service providers to easily take
apart, repair and enhance the batteries, giving them
a new extended life.
Aceleron aspires to accelerate access to cleaner energy
storage around the world and futureproof the tech-
nology to significantly increase battery life, optimise
material use and reduce waste. With our advanced
clean technology we strive to help positively impact
the environment, economy and society.
Our mission is to accelerate
the global shift to cleaner energy
usage by creating storage technology
that is more accessible to all.
“”
ABOUT ACELERON
Aceleron Ltd,
22 Gas Street, Birmingham B1 2JT
tel: [phone]
[email protected]
www.aceleronenergy.com
1

Contents
Technical Specifications
How to Register Your Product
Aceleron Warranty: Energy Storage Products
Safety Measures and Guidelines
3
5
6
9
CONTENTS
2

Technical Specications
12V 100Ah LiFePO4
12V 100Ah SPECS
OPERATING CONDITIONS
Nominal Voltage 12.8 V
Nominal Capacity 110 Ah
Total Energy 1.4 kWh
Impedance 5 mΩ
Self-Discharge ~3% per month
Cycle life at 100% DoD @ 0.2C 5,000 cycles
Series Connection 4
Parallel Connection 10
CHARGE
Charge/Discharge Efficiency >97% @ 0.5C
Recommended Charge Current 40 A
Peak Charge Current 100 A
PCM Charge Current Cut-Off 110 A
Fully Charged Voltage 14.4 V
DISCHARGE
Standard Continuous Discharge 60 A (20+min)
Maximum Continuous Discharge
Current 110 A (10 min)
Peak Discharge Current 200 A (1 min)
PCM Discharge Current Cut-Off 220 A (3 seconds)
Max Solar Recommended Low
Voltage Disconnect 10.5 V
Short Circuit Protection 200-500μs
3
IMPORTANT:
Please ensure the charger used with the product is
IEC/UL and CE certified.
For lower power charging of 1-49 amps Lithium Iron
Phosphate, AGM or Gel Lead Acid chargers are suitable.
For higher power charging of 50-100 amps the charger
must be designed for Lithium Iron Phosphate with a
max cut-off voltage of 14.6V.
This battery is not rated to be charged at more than
100 amps.
This battery is not compatible with chargers designed
for flooded lead acid batteries (over 14.6V).
Using chargers that are not designed within the
parameters outlined above will present safety risks.

12V 110Ah SPECS
4
BATTERY MANAGEMENT
BMS Type Passive
BMS Location Internal
Balance Current per Cell 50 mA
Overcharge / Discharge Current 220 A
TEMPERATURE
Storage Temperature 15 to 30ºC
Recommended Storage Time at 25ºC 1 year
Discharge Temperature Range 15 to 30ºC
Charge Temperature Range 0 to 45ºC
SAFETY
Transportation Classification UN3480, Class 9
Battery Certification CE, UN38.3,
RoHS, IEC 62619
UN Certification (Cells) UN38.3
MECHANICAL
Chemistry Cylindrical – LiFePO4
Case Dimensions L330xW170xH240 (mm)
Weight Circa 15 kg
Terminal Type M8 female thread brass
Casing Type V0 Plastic Case
This information is for technical reference only and should not be
used as a basis for product guarantee or warranty.

How to register
your product
Step 1.
Type in the serial number
Locate your product’s Serial Number on the Rating label
at the back of your battery. Go to www.portal.aceleron.
energy/warranty and enter the serial number.
...or, use your device’s camera to scan the code
Go to www.portal.aceleron.energy/warranty and use
the camera icon to scan the code and populate
the Serial Number automatically.
REGISTRATION
5
Step 2.
Once you have entered the correct Serial Number, click continue
and follow the instructions to complete the process.
Code

Aceleron warranty:
energy storage products
WARRANTY CONDITIONS
6
Aceleron Limited (“Aceleron”) offers a limited warranty against
each Aceleron branded Li-ion battery (“Product”) listed below
and sold by Aceleron Limited, or any of its authorised distributors
or dealers, to be free of defects for a period of 10 years (“the
Warranty Period”) from the date of sale as determined by either
the customer’s sale receipt,the shipping invoice and/or the
battery serial number, with proof of purchase. The warranty is
non-transferrable.
Which products qualify for this warranty?
This warranty applies to the following lithium-ion products
manufactured by or on behalf of Aceleron Limited:
• ESSENTIAL Li-Ion BATTERIES, each a “Product”
What the warranty covers?
Subject to the restrictions and conditions below and within the
Warranty Period, Aceleron warrants that your Product:
• will be free from defects in material and workmanship;and
• shall maintain an energy capacity of not less than 60% of its
described energy capacity (expressed in kWh)
The “Warranty Period” shall be whichever occurs sooner of:
• 3,000 Cycles of use of the Product as recorded by the
Product. A Cycle is defined as a charge and discharge to
at least 65% of the Product’s capacity; or
• In respect of the Battery Management System (BMS) part
of the product; 4 years from the date of purchase, and
• In respect of all other parts of the Product; 10 years from
the from the date of purchase.
In relation to Products acknowledged to be defective by
Aceleron, the warranty covers the repair or replacement of
Products or defective parts, or a discount to purchase a new
Product or parts, in each case as described in the section
entitled ‘What we offer if your Product is defective’ below.
What you must do to benefit from the warranty?
To qualify for this warranty, you must:
• be the end user of the Product and have put the Product into
use for the first time. This warranty does not apply to any
subsequent owner of the Product (for example, if the Product
is secondhand), and

WARRANTY CONDITIONS
• provide proof of purchase, and
• report and faults to the Aceleron within 14 days of the defect
becoming apparent.
You must ensure that the Product is only used for its intended
purpose(s), and must ensure that it is used, stored, and main-
tained in accordance with any instructions supplied with the
Product or otherwise communicated by Aceleron from time to time.
What we will do if your Product is defective?
• The “Warranty Start Date” means the date on which you
purchased the Product as shown in the proof of purchase
• For the Li-Ion Cells within the Product:
- For up to 4 years from the Warranty Start Date Aceleron
will repair or replace the cells with an equivalent product
which may be new or refurbished. Prorated repair or
replacement thereafter.
• For the Battery Management System (BMS) within the Product:
- For up to 4 years from the Warranty Start Date Aceleron
will repair or replace the BMS with an equivalent product
which may be new or refurbished.
• For all other parts:
- For up to 10 years from the Warranty Start Date Aceleron
will repair or replace the defective part with an equivalent
part which may be new or refurbished.
What’s not covered?
The warranty does not cover the following items:
• Claims in respect of any other damage or loss suffered
including, without limitation, downtime, loss of production,
the hiring of replacement equipment, or loss of business
or profits.
• Damage caused by, or resulting from, non-standard or
incorrect operation or by failing to comply with the usage
instructions provided with your Product or otherwise
communicated by Aceleron from time to time.
• Damage caused by neglect, accident or other factors
beyond our control (e.g. fire, flooding or storms).
• Damage caused by inappropriate storage conditions;
exposure to extreme hot or cold temperatures, fire or
freezing, water damage or others as shown in the usage
instructions of the Product.
• Damage caused by a failure to report a fault to Aceleron.
• Damage caused by unauthorised modifications of the
Product.
• Damage as a result of transport, handling, impact or collision.
• Damage subject to peak loads greater than shown in the
usage instructions of the Product.
7

WARRANTY CONDITIONS
8
What to do in the event of a warranty claim?
• You must report all warranty claims to Aceleron prior to
the expiry of the Warranty Period and within 14 days of
the defect becoming apparent.
• You must report warranty claims to Aceleron email at
[email protected]
Other points to note
• If you are a consumer (as defined in the Consumer Rights
Act 2015), nothing in this warranty shall limit your
statutory rights.
• Work carried out under the warranty does not extend the
Warranty Period. In particular, no additional warranty is
offered in relation to any part replaced during work carried
out under warranty.
• Any Products or components which are retained by Aceleron
following their replacement in connection with a warranty
become the property of Aceleron.

SAFETY MEASURES
circuits, too deep discharges and too high charge
currents. Use insulated tools. Do not wear any
metallic items such as watches, bracelets, etc. In
case of fire, you must use a type D, foam or CO2 fire
extinguisher.
Too deep discharges damage the Li-ion battery
seriously and can even be dangerous. Use of external
fuse is recommended.
Li-ion Batteries are heavy. If involved in an accident
they can become a projectile! Ensure adequate and
secure mounting and always use suitable handling
equipment for transportation. Handle with care
because Li-ion Batteries are sensitive to mechanical
shock.
If charged after the Li-ion battery was discharged
below the Discharge cut-off voltage, or when the
Li-ion battery is damaged or overcharged, the Li- ion
battery can release a harmful mixture of gasses such
as phosphate.
Non-compliance with operating instructions, repairs
made with other than original parts, or repairs made
without authorization render the warranty void.
9
Safety measures
and guidelines
GENERAL RULES
Observe these instructions and keep them located
near the Li-ion Battery for future reference.
Work on the Li-ion Battery should be carried out
by qualified personnel only.
Never try to open or dismantle the Li-ion Battery.
Electrolyte is very corrosive. In normal working
conditions contact with the electrolyte is impossible.
If the battery casing is damaged do not touch the
exposed electrolyte or powder because it is corrosive.
Any uncovered battery material such as electrolyte
or powder on the skin or in the eyes must be flushed
with plenty of clean water immediately. Then seek
medical assistance. Spillages on clothing should be
rinsed out with water.
Explosion and fire hazard. Terminals of the Li-ion
Battery are always a live; therefore do not place
items or tools on the Li-ion Battery. Avoid short
9

SAFETY MEASURES
10
CARE AND MAINTENANCE
Do not use water, solvents or polishes to clean the
product. Do not use abrasive materials to wipe the
product. Wipe clean with a dry cloth.
Do not use, store or charge in wet, damp or moist
environments.
Keep the product out of the reach of children.
Check for any visible signs of wear, damage or defects
before use.
Only use a charger with correct rating for the product.
Do not use a damaged charger.
After heavy use or in high temperatures the product
may become warm. Allow the product to cool for 30
minutes before charging.
DISPOSAL
Please note that Lithium-Ion batteries must be disposed
of in an environmentally responsible manner and in
accordance with local regulations.These batteries
contain toxic chemicals and pose a danger to the
environment, as they may cause heavy contamination
and water pollution if discarded in an irresponsible
manner.
This symbol indicates that waste electrical or electronic
equipment (WEEE) may not be disposed of together
with household waste. By separating WEEE and
batteries, you will help reduce the volume of waste
sent for incineration or landfills and minimize any
potential negative impact on human health and
environment. For proper disposal, contact your local
recycling or hazardous waste facility.
