Dell™ PowerVault™ 100
Getting Started Guide
With Your System
Guide de mise en route
Primeiros passos com o sistema
Procedimientos iniciales con el sistema

Dell™ PowerVault™ 100 Systems
Getting Started With
Your System
Model MVT01

Notes, Notices, and Cautions
NOTE: A NOTE indicates important information that helps you make better use of
your computer.
NOTICE: A NOTICE indicates either potential damage to hardware or loss of data
and tells you how to avoid the problem.
CAUTION: A CAUTION indicates a potential for property damage, personal injury,
or death.
____________________
Information in this document is subject to change without notice.
© 2007 Dell Inc. All rights reserved.
Reproduction in any manner whatsoever without the written permission of Dell Inc. is strictly forbidden.
Trademarks used in this text: Dell, the DELL logo, and PowerVault, are trademarks of Dell Inc.;
Intel Core and Core 2 Duo are trademarks and Intel, Pentium and Celeron are registered trademarks
of Intel Corporation in the U.S. and other countries; Microsoft, Windows and Windows Storage Server
are either trademarks or registered trademarks of Microsoft Corporation in the United States and/or
other countries.
Other trademarks and trade names may be used in this document to refer to either the entities claiming
the marks and names or their products. Dell Inc. disclaims any proprietary interest in trademarks and
trade names other than its own.
Model MVT01
August 2007 P/N JU892 Rev. A00

Contents 3
Contents
System Features . . . . . . . . . . . . . . . . . . . . . . 5
Supported Operating Systems . . . . . . . . . . . . . . . 7
Other Information You May Need . . . . . . . . . . . . . 7
Obtaining Technical Assistance . . . . . . . . . . . . . 8
Installation and Configuration. . . . . . . . . . . . . . . 8
Unpacking the System . . . . . . . . . . . . . . . . 8
Connecting the Keyboard, Mouse, and Monitor . . . 9
Connecting the Power . . . . . . . . . . . . . . . . 9
Turning on the System . . . . . . . . . . . . . . . 10
Complete the 0perating System Setup. . . . . . . . . . 10
Technical Specifications . . . . . . . . . . . . . . . . 11
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

4Contents

Getting Started With Your System 5
System Features
This section describes the major hardware and software features of your
system. It also provides information about other documents you may need
when setting up your system and how to obtain technical assistance.
Major hardware and software features of your system include:
• One of the following processors:
–Intel
®
Core™ 2 Duo
– Intel Celeron
®
D, 300 sequence
– Intel Pentium
®
4, 600 sequence
NOTE: Use the System Setup program to view processor information.
See ”Using the System Setup Program” in your Hardware Owner’s Manual.
• A minimum of 512 MB of 533-MHz or 667-MHz DDRII SDRAM memory,
upgradable to a maximum of 8 GB by installing combinations of 512-MB,
1-GB, or 2-GB unbuffered ECC memory modules in four memory module
sockets on the system board, single or dual rank.
• The following expansion slots:
– One PCIe x1 (3.3-V) slot
– One PCIe x8 (3.3-V) slot
– One 32-bit, 33-MHz PCI (5-V) slot
– Two 64-bit, 133-MHz PCI-X (3.3-V) slots
• An integrated Gigabit Ethernet NIC, capable of supporting 10-Mbps,
100-Mbps, or 1000-Mbps data rates, with support for IPMI 1.5 and
Wake-on-LAN.
• Four USB 2.0-compliant connectors (two on the front and two on the back)
capable of supporting a diskette drive, CD-ROM drive, keyboard, mouse,
or USB flash drive.
• An integrated ATI ES1000 SVGA video controller supporting true-color
graphics in the following resolutions: 640 x 480, 800 x 600, 1024 x 768,
1280 x 1024, and 1600 x 1200.
• Systems management circuitry that monitors critical system voltages and
fan speeds. The systems management circuitry works in conjunction with
the systems management software.

6Getting Started With Your System
• Standard baseboard management controller with serial access.
• Back-panel connectors include PS/2 mouse and keyboard, serial, video,
two USB connectors, and one NIC connector.
• One 3.5-inch CD, DVD, or combination CD-RW/DVD in a peripheral
drive bay.
NOTE: DVD devices are data only.
• Support for the following internal hard-drive configurations:
– Up to four internal, 1-inch, SATA hard drives with integrated drive
controllers.
– Up to four internal, 1-inch, Serial-Attached SCSI (SAS) hard drives
with an optional SAS controller card or backplane.
NOTE: Hot-plug capability is supported only when SATA or SAS drives are
connected to the optional SAS controller card or backplane.
• Optional Dell Remote Access Card (DRAC 4) for remote systems
management. This option requires a dedicated PCI slot.
• One 420-W power supply.
For more information about specific features, see “Technical Specifications”
on page 11.
The following software is included with your system:
• A System Setup program for quickly viewing and changing system
configuration information. For more information on this program, see
“Using the System Setup Program” in the
Hardware Owner’s Manual .
• Enhanced security features, including a system password and a setup
password, available through the System Setup program.
• System diagnostics for evaluating system components and devices.
For information about using the system diagnostics, see “Running the
System Diagnostics” in your
Hardware Owner’s Manual .
• Video drivers for displaying many popular application programs in high-
resolution modes.
• SATA or SAS device drivers that allow the operating system to
communicate with devices attached to the integrated SATA or SAS
subsystem. For more information about these drivers, see “Installing
Drives” in your
Hardware Owner’s Manual .
• Systems management software and documentation CDs.

Getting Started With Your System 7
Supported Operating Systems
Your system supports the following operating system:
• Microsoft
®
Windows Storage Server™ 2003 R2 Express Edition (x64)
• Microsoft
Windows Storage Server 2003 R2 Workgroup Edition (x64)
Other Information You May Need
CAUTION: The Product Information Guide provides important safety and
regulatory information. Warranty information may be included within this
document or as a separate document.
• The Hardware Owner’s Manual provides information about system
features and describes how to troubleshoot the system and install or
replace system components. The
Hardware Owner’s Manual is available
on the CDs that came with your system or on
support.dell.com .
• CDs included with your system provide documentation and tools
for configuring and managing your system.
• Systems management software documentation describes the features,
requirements, installation, and basic operation of the software.
• Operating system documentation describes how to install (if necessary),
configure, and use the operating system software.
• Documentation for any components you purchased separately provides
information necessary to configure and install these options.
• Updates are sometimes included with the system to describe changes
to the system, software, and/or documentation.
NOTE: Always check for updates on support.dell.com and read the updates
first because they often supersede information in other documents.
• Release notes or readme files may be included to provide last-minute
updates to the system or documentation or advanced technical reference
material intended for experienced users or technicians.

8Getting Started With Your System
Obtaining Technical Assistance
If you do not understand a procedure in this guide or if the system does not
perform as expected, see your Hardware Owner’s Manual.
Dell
™ Enterprise Training and Certification is available; see
www.dell.com/training for more information. This service may not be offered
in all locations.
Installation and Configuration
CAUTION: Before performing the following procedure, read and follow the safety
instructions and important regulatory information in your Product Information Guide.
This section describes the steps to set up your system for the first time.
CAUTION: Installing the feet on a stand-alone tower system is necessary to provide
a stable foundation for the system. Failure to install the feet poses the risk of having
the system tip over, possibly causing bodily injury or damage to the system.
CAUTION: Whenever you need to lift the system, get others to assist you. To avoid
injury, do not attempt to lift the system by yourself.
Unpacking the System
Unpack your system and identify each item.
Keep all shipping materials in case you need them later.
See the documentation included with your system on installing the
system stabilizer feet.

Getting Started With Your System 9
Connecting the Keyboard, Mouse, and Monitor
Connect the keyboard, mouse, and monitor (optional).
The connectors on the back of your system have icons indicating
which cable to plug into each connector. Be sure to tighten the screws
(if any) on the monitor's cable connector.
Connecting the Power
Connect the system’s power cable(s) to the system.
Plug the other end of the cable into a grounded electrical outlet or a
separate power source such as an uninterrupted power supply (UPS)
or a power distribution unit (PDU).

10 Getting Started With Your System
Turning on the System
Turn on the system and monitor (optional).
Press the power button on the system and the monitor. The power
indicators should light. Adjust the monitor’s controls until the displayed
image is satisfactory.
Complete the 0perating System Setup
If you purchased a preinstalled operating system, see the operating system
documentation that ships with your system. To install an operating system for
the first time, see the
Quick Installation Guide . Be sure the operating system is
installed before installing hardware or software not purchased with the system.

Getting Started With Your System 11
Technical Specifications
Processor
Processor type Intel Core
2 Duo processor
or
Intel Celeron®D, 300 sequence
or
Intel Pentium
®
4, 600 sequence
Expansion Buses
Bus type PCIe, PCI-X, PCI
Expansion slots
PCIe One 3.3-V, x1
One 3.3-V, x8
PCI-X Two full-height, full-length, 3.3-V,
64-bit, 133-MHz
PCI One 5-V, 32-bit, 33-MHz
Memory
Architecture 72-bit ECC unbuffered DDR2 533/667
MHz SDRAM DIMMs, single- or dual-
channel
Memory module sockets Four 240-pin
Memory module capacities 512 MB, 1 GB, or 2 GB
Minimum RAM 512 MB (one 512-MB module)
Maximum RAM 8 GB

12 Getting Started With Your System
Drives
Hard Drives
SATA Up to four internal, 1-inch-high (3.5-inch
form factor) drives connected to
integrated drive controller or RAID
controller card (non-hot plug) or SAS
backplane (hot plug)
SAS Up to four internal, 1-inch-high (3.5-inch
form factor) drives connected to optional
SAS backplane (hot-plug) or SAS
controller card (non-hot plug)
NOTE: Mixing of SATA and SAS drives is
not supported
Optical drive One IDE CD, DVD, or combination
CD-RW/DVD
NOTE: DVD devices are data only.
Diskette drive One optional 3.5-inch, 1.44-MB
Tape drive One optional IDE in optical drive bay
Connectors
Externally accessible
Back
NIC One RJ-45 (for integrated 1-Gigabit NIC)
PS/2-style keyboard 6-pin mini-DIN
PS/2-compatible mouse 6-pin mini-DIN
Serial 9-pin, DTE, 16550-compatible
USB Two 4-pin, USB 2.0-compliant
Video 15-pin VGA
Front
Video 15-pin VGA
USB Two 4-pin, USB 2.0-compliant

Getting Started With Your System 13
Internally accessible
IDE channel 40-pin
SATA channels Two 7-pin
Video
Video type Integrated ATI ES1000 SVGA
controller
Video memory 16 MB
Power
AC power supply
Wattage 420 W
Voltage 100–240 VAC, 50/60 Hz
Heat dissipation 2275 BTU/hr maximum
Maximum inrush current Under typical line conditions and over the
entire system ambient operating range,
the inrush current may reach 55 A for
10 ms or less or 25 A at 150 ms or less.
System battery CR 2032 3.0-V lithium ion coin cell
Physical
Height 43.9 cm (17.3 in)
Width 19.8 cm (7.8 in)
Depth 50.0 cm (19.7 in)
Weight 19.1 kg (42 lb)
Connectors (continued)

14 Getting Started With Your System
Environmental
NOTE: For additional information about environmental measurements for specific
system configurations, see www.dell.com/environmental_datasheets.
Temperature
Operating 10° to 35°C (50° to 95°F)
Storage –40° to 65°C (–40° to 149°F)
Relative humidity
Operating 20% to 80% (noncondensing)
Storage 5% to 95% (noncondensing)
Maximum vibration
Operating 0.26 G (half-sine wave) at a sweep of
3 to 200 MHz for 15 minutes
Storage 0.5 G at 3–200 Hz for 15 min
Maximum shock
Operating Six consecutively executed shock pulses
in the positive and negative x, y, and z
axes (one pulse on each side of the
system) of 36 G for up to 2.6 ms
Storage Six consecutively executed shock pulses
in the positive and negative x, y, and z
axes (one pulse on each side of the
system) of 71 G for up to 2 ms
Altitude
Operating –16 to 3048 m (–50 to 10,000 ft)
Storage –16 to 10,668 m (–50 to 35,000 ft)

Index 15
Index
D
drives, 12
E
environmental specifications, 14
expansion buses, 11
M
memory, 11
P
physical specifications, 13
power, 13
R
remote access card
optional, 6
S
system features
USB, 5
T
technical assistance, 8
technical specifications, 11
drives, 12
environmental, 14
expansion buses, 11
memory, 11
physical, 13
power, 13
video, 13
V
video, 13
W
warranty, 7

16 Index

Systèmes Dell™
PowerVault™ 100
Guide de mise en route
Modèle MVT01

Remarques, avis et précautions
REMARQUE : Une REMARQUE indique des informations importantes
qui vous aident à mieux utiliser votre ordinateur.
AVIS : Un AVIS vous avertit d'un risque de dommage matériel ou
de perte de données et vous indique comment éviter le problème.
PRÉCAUTION : Une PRÉCAUTION indique un risque potentiel
d'endommagement du matériel, de blessure corporelle ou de mort.
____________________
Les informations contenues dans ce document peuvent être modifiées sans préavis.
© 2007 Dell Inc. Tous droits réservés.
La reproduction de ce document de quelque manière que ce soit sans l'autorisation écrite de Dell Inc.
est strictement interdite.
Marques utilisées dans ce document : Dell, le logo DELL et PowerVault sont des marques de Dell Inc. ;
Intel Core and Core 2 Duo sont des marques de Intel, Pentium et Celeron sont des marques
déposées de Intel Corporation aux Etats-Unis et dans d’autres mays ; Microsoft, Windows,
et Windows Storage Server sont des marques ou des marques déposées de Microsoft Corporation
aux États-Unis et/ou dans d'autres pays.
Tous les autres noms de marques et marques commerciales utilisés dans ce document se rapportent
aux sociétés propriétaires des marques et des noms de ces produits. Dell Inc. décline tout intérêt
dans l'utilisation des marques déposées et des noms de marques ne lui appartenant pas.
Modèle MVT01
Août 2007 N/P JU892 Rév. A00
