Acer Aspire 7100 System User manual

Aspire 7100
System
Service Guide
Service guide files and updates are available
on AIPG/CSD web, For more information,
please refer to service CD kit
or http://csd.acer.com.tw

II
Copyright
Copyright 1998 by Acer Incorporated. All rights reserved. Nopart of this
publication may be reproduced, transmitted, transcribed, stored in a retrieval
system, or translated into any language or computer language, in any form or by
any means, electronic, mechanical, magnetic, optical, chemical, manual or
otherwise, without the prior written permission of Acer Incorporated.
Disclaimer
Acer Incorporated makes no representations or warranties, either expressed or
implied, with respect to the contents hereof and specifically disclaims any
warranties of merchantability or fitness for any particular purpose. Any Acer
Incorporated software described in this manual is sold or licensed "as is".
Should the programs prove defective following their purchase, the buyer (and
not Acer Incorporated, its distributor, or its dealer) assumes the entire cost of all
necessary servicing, repair, and any incidental or consequential damages
resulting from any defect in the software. Further, Acer Incorporated reserves
the right to revise this publication and tomake changes from timeto timein the
contents hereof without obligation of Acer Incorporated to notify any person of
such revision or changes.
Acer is a registered trademark of Acer Corporation.
Intel is a registered trademark of Intel Corporation.
Pentium and Pentium II are trademarks of Intel Corporation.
Other brand and product names are trademarks and/or registered trademarks of
their respective holders.

III
Conventions
The following are the conventions used in this manual:
Text entered by user Represents text input by the user.
Screen messages Denotes actual messages that appear
onscreen.
, , , etc. Represent the actual keys that you have to
press on the keyboard.
NOTE Gives bits and pieces of additional
information related to the current topic.
WARNING Alerts you to any damage that might result
from doing or not doing specific actions.
CAUTION Gives precautionary measures to avoid
possible hardware or software problems.
IMPORTANT Reminds you to do specific actions relevant
to the accomplishment of procedures.

IV
Preface
Before using this information and the product it supports, please read the
following general information!
1. This Service Guide provides you with all technical information relating to the
BASIC CONFIGURATION decided for Acer's "global" product offering. To
better fit local market requirements and enhance product competitiveness,
your regional office MAY have decided to extend the functionality of a
machine (eg. add-on card, modem, and extra memory capability). These
LOCALIZED FEATURES will NOT be covered in this generic service guide.
When this case arises, you should contact your regional offices or the
responsible personnel/channel to provide you with further technical details.
2. Please note WHEN ORDERING FRU PARTS, that you should check the
most up-to-date information available on your regional web or channel. For
whatever reasons a part number change is made, it will not be noted in the
printed Service Guide. For ACER-AUTHORIZED SERVICE PROVIDERS,
your Acer office may have a DIFFERENT part number code to those given in
the FRU list of this printed Service Guide. You MUST use the list provided by
your regional Acer office to order FRU parts for repair and service of
customer machines..

Table of Contents
V
Chapter 1 System Introductions 1
Hardware Specifications and Configurations.............................. 2
Processor......................................................................... 2
BIOS................................................................................ 2
BIOS Hotkey List.............................................................. 3
System Memory ............................................................... 3
DIMM Combinations......................................................... 4
Cache Memory................................................................. 4
Audio Interface................................................................. 5
IDE Interface.................................................................... 5
Diskette drive Interface..................................................... 5
Parallel Port ..................................................................... 6
Serial Port........................................................................ 6
Memory Address Map....................................................... 7
PCI INTx# and IDSEL Assignment Map............................. 7
PCI Slot IRQ Routing Map................................................ 7
I/O Address Map .............................................................. 8
PIIX4E GPIO (General Purpose I/O) PIN Definitions.......... 9
IRQ Assignment Map........................................................ 9
DRQ Assignment Map.................................................... 10
System Board Major Chips ............................................. 10
Power Management................................................................ 11
Power Saving Mode Phenomenon List............................ 11
Environmental Requirements.................................................. 11
Chapter 2 System Utilities 13
Entering Setup ....................................................................... 14
System Information................................................................. 16
Processor....................................................................... 17
Processor Speed............................................................ 17
Internal Cache................................................................ 17
External Cache............................................................... 17
Floppy Drive A................................................................ 17
Floppy Drive B................................................................ 17
IDE Primary Channel Master........................................... 17
IDE Primary Channel Slave............................................. 17
IDE Secondary Channel Master...................................... 17
IDE Secondary Channel Slave........................................ 17

Table of Contents
VI
Total Memory..................................................................18
Serial Port.......................................................................18
Parallel Port....................................................................18
USB Mouse.....................................................................18
Product Information.................................................................19
Product Name.................................................................19
System S/N.....................................................................19
Main Board ID.................................................................19
Main Board S/N...............................................................19
System BIOS Version......................................................19
DMI BIOS Version...........................................................19
Disk Drives..............................................................................20
Floppy Drives..................................................................20
LS-120 drive as...............................................................21
IDE Drives ......................................................................21
Onboard Peripherals ...............................................................26
Serial Port.......................................................................26
Parallel Port....................................................................27
Onboard Device Settings.........................................................28
Floppy Disk Controller .....................................................28
IDE Controller .................................................................28
USB Mouse Controller.....................................................28
USB Host Controller........................................................28
USB Legacy Mode..........................................................29
Onboard Audio Chip........................................................29
Power Management ................................................................30
Power Management Mode...............................................30
Power Switch < 4 sec......................................................31
System Wake-Up Event...................................................31
Boot Options...........................................................................32
Boot Sequence................................................................32
First Hard Disk Drive.......................................................32
Primary Display Adapter..................................................32
Fast Boot........................................................................33
Silent Boot ......................................................................33
Num Lock After Boot .......................................................33
Memory Test...................................................................33
Configuration Table.........................................................33
Date and Time........................................................................34
Date................................................................................34
Time...............................................................................34

Table of Contents
VII
System Security ..................................................................... 35
Setup Password............................................................. 35
Power-on Password ....................................................... 38
Disk Drive Control........................................................... 38
Advanced Options.................................................................. 39
Memory/Cache Options.................................................. 40
PnP/PCI Options ............................................................ 42
Load Default Settings ............................................................. 44
Abort Settings Change............................................................ 45
Exit Setup .............................................................................. 46
Chapter 3 Removal and Replacement 47
Removing/Installing the DIMM................................................. 48
Removing a DIMM.......................................................... 48
Installing a DIMM............................................................ 48
Removing/Installing the Processor .......................................... 49
Removing the P2 with SECC Type Processor from the System
Board............................................................................. 49
Removing the P2 with SECC Type Processor Fan-sink.... 50
Installing the P2 with SECC Type Processor Fan-sink ..... 51
Installing the P2 with SECC Package Type Processor into the
System Board................................................................. 53
Removing the Housing Cover.................................................. 55
Remove the door............................................................ 56
Diskette Drive/CD-ROM BEL ASS’Y................................ 57
Remove the Upper cover ................................................ 58
Remove the Front panel ................................................. 59
Removing the Hard Disk Drive........................................ 60
Remove the Right panel ................................................. 61
Removing the CD-ROM Drive................................................. 62
Removing the Diskette Drivemodule....................................... 63
Removing the Power Supply................................................... 64
Removing the RTC Battery..................................................... 65
Removing the System board................................................... 65
Chapter 4 Troubleshooting 67
Power-On Self-Test (POST).................................................... 67
POST Error Messages List ..................................................... 68
Error Symptoms List............................................................... 71
Undetermined Problems ......................................................... 77

Table of Contents
VIII
Chapter 5 Jumper and Connector Information 79
Jumpers and Connectors.........................................................80
Jumper and Connector Locations.....................................80
Jumper Settings..............................................................81
Onboard Connectors.......................................................82
IDE Hard Disk Support ............................................................83
Video Function........................................................................83
Audio Function........................................................................83
USB........................................................................................84
Hardware Monitoring Function.................................................84
Modem Ring-in Function..........................................................84
Wake-on LAN Function ...........................................................84
Chapter 6 FRU (Field Replaceable Unit) List 85
Appendix A Model Number and Configurations 93
Appendix B Test Compatible Components List 95
Microsoft®Windows®98 (En/Jp) Environment Test ..................96
Microsoft®Windows®NT 4.0 Workstation Environment Test....97
IBM®OS/2 Warp 4.0 Environment Test....................................97
Novell®Netware®3.12 & 4.11 Environment Test ......................98
SCO UNIX Environment Test...................................................99
Appendix C Online Support Information 101
Index 103

Chapter 1
Chapter 1 1
System Introductions
This product is a Pentium II processor-based IBM PC/AT compatible system
with PCI/AGP bus.
It supports:
❑Intel Pentium II processor
❑3 * 168 pin DIMM sockets ( maximum up to 384MB)
❑Power management features
❑Processor SMM (System Management Mode), STOP clock control
❑ACPI compliant BIOS
❑API (Application Program Interface) feature
❑ATA compliant hard disk power saving feature
❑Onboard PCI master enhanced local bus IDE (Embedded in Intel 82371EB
(PIIX4E) chipset)
❑PIO mode 4
❑Ultra DMA/33
❑
Onboard serial ports - 2 high speed NS16C550 compatible UARTs with 16
byte FIFOs
❑Onboard parallel port - SPP, EPP and ECP (IEEE 1284 compliant)
❑Onboard diskette drive interface - 1.2MB/1.44MB/2.88MB & 3 mode diskette
drive
❑PS/2 keyboard
❑PS/2 mouse
❑Plug-and-Play (PnP) features
❑2 USB connector
❑Onboard Slot1 (PCI bus.
❑Support Wake-on LAN.
❑2 PCI slots + 1ISA/1PCI shared slot + 1 AGP slot
❑Software shutdown for Windows 95/98
❑Hardware Monitor function (SMB bus/ISA bus)

2 System Introductions
Hardware Specifications and Configurations
Processor
Item Specification
Type Intel Pentium II .
Slot Slot 11
Speed Pentium II processor: 333/350/400/450 MHz
Minimum operating speed 0 MHz
Voltage Processor voltage can be detected by the
system without setting any jumper.
BIOS
Item Specification
BIOS code programmer Acer
BIOS version V3.2
BIOS ROM type Bulk mode flash ROM
BIOS ROM model number ATMEL AT29C020
BIOS ROM size 256KB
BIOS ROM package 32-pin DIP package
Support protocol PCI 2.1, APM1.2, DMI 2.00.1, E-IDE, ACPI
1.0,
ESCD 1.03, ANSI ATA 3.0, PnP 1a,
Bootable CD-ROM 1.0, ATAPI
Boot from CD-ROM feature Yes
Supports LS-120 drive Yes
Supports BIOS boot block feature Yes
BIOS password control Check/bypass by switch (S1-2) setting
Acer logo display control during POST Enable/disable by switch (S1-3) setting
NOTE The BIOS can be overwritten/upgraded using the “AFLASH” utility
(AFLASH.EXE).
1Slot 1 defines the mechanical and electrical specification for Pentium II processor slot.
It is defined and developed by Intel.

Chapter 1 3
BIOS Hotkey List
Hotkey Function Description
+ + Enter BIOS Setup Utility Press while the system is
booting to enter BIOS Setup
Utility.
+ R
Enable hidden page of
BIOS Setup Utility Press in BIOS Setup Utility main menu screen, the
Advanced Options menu then
appears.
The items shown in the
Advanced Options menu are:
Memory/Cache Options
PnP/PCI Options
Chipset Options
System Memory
This section lists the system memory specifications and the possible
combinations of memory modules.
Item Specification
Onboard embedded memory size 0MB
Memory socket number 3 sockets (3 banks)
Supported memory size per socket 8MB / 16MB / 32MB / 64MB / 128MB
Supported maximum memory size 384MB (128MB x 3)
Supported memory type SDRAM
Supported memory speed 2100MHz (PC100) (for Local Bus speed
100MHz or 66 MHz)
66MHz (for Local Bus speed 66MHz)
Supported memory voltage 3.3 V
Supported memory module package 168-pin DIMM
Supported parity check feature No
Support for Error Correction Code (ECC)
feature. Yes
Memorymodule combinations You can install memory modules in any
combinations as long as they match the
above specifications.
2Thedefault is 100MHz.

4 System Introductions
DIMM Combinations
DIMM1 DIMM2 DIMM3 TOTAL DIMM1 DIMM2 DIMM3 TOTAL
16M 0 0 16M 16M 16M 16M 48M
32M 0 0 32M 16M 16M 32M 64M
64M 0 0 64M 16M 16M 64M 96M
128M 0 0 128M 16M 16M 128M 160M
16M 16M 0 32M 32M 32M 32M 96M
16M 32M 0 48M 32M 32M 64M 128M
16M 64M 0 80M 32M 32M 128M 192M
16M 128M 0 144M 64M 64M 16M 144M
64M 16M 0 80M 64M 64M 32M 160M
64M 32M 0 96M 64M 64M 64M 192M
64M 64M 0 128M 64M 64M 128M 256M
64M 128M 0 192M 128M 128M 16M 272M
128M 16M 0 144M 128M 128M 32M 288M
128M 32M 0 160M 128M 128M 64M 320M
128M 64M 0 192M 128M 128M 128M 384M
128M 128M 0 256M
Cache Memory
Item Specification
First-Level Cache Configurations
Cache function control Enable/disable by BIOS Setup
Second-Level Cache Configurations
The information below is only applicable to systems installed with a Pentium II
processor installed.
Tag RAM location On Pentium II processor
L2 Cache RAM location On Pentium II processor
L2 Cache RAM type PBSRAM (Pipelined-burst Synchronous RAM)
L2 Cache RAM size Depends on Processor type
L2 Cache RAM speed One-half the processor core clock frequency
L2 Cache function control Enable/disable by BIOS Setup
L2 Cache scheme Fixed in write-back

Chapter 1 5
Audio Interface
Item Specification
Audio controller ESS solo 1
Audio controller resident bus PCI bus
Audio function control Enable/disable by BIOS Setup
Mono or stereo Stereo
Resolution 16 bits
Compatibility Compliant to Microsoft Windows Sound
System, Sound Blaster Pro standard, and
Microsoft PC’98 and WHQL audio
requirement.
Music synthesizer Yes, internal FM synthesizer
Sampling rate 48 KHz (max.)
MPU-401 UART support Yes
Microphone jack Supported
On audio-I/O board (connect via CN6)
Headphone jack Supported
On audio-I/O board (connect via CN6)
Joystick port Supported
On audio-I/O board (connect via CN6)
Fully DOS games compatibility TDMA/DDMA/PCPCI
IDE Interface
Item Specification
IDE controller Inside of Intel 82371EB(PIIX4E)
IDE controller resident bus PCI bus
Number of IDE channel 2 (CN10 and CN11)
Supports IDE interface E-IDE (up to PIO mode-4 and Ultra DMA
/33), ANSIS ATA rev.3.0
ATAPI
Supported LS-120 Yes
Supported bootable CD-ROM Yes
Diskette drive Interface
Item Specification
Diskette drive controller FDC37C707
Diskette drive controller resident bus ISA bus
Supported diskette drive formats 1.2MB, 1.44MB, 2.88MB and 3-mode format

6 System Introductions
Parallel Port
Item Specification
Parallel port controller FDC37C707
Parallel port controller resident bus ISA bus
Number of parallel ports 1
ECP/EPP support Yes
Connector type 25-pin D-type female connector
Parallel port function control Enable/disable by BIOS Setup
Optional ECP DMA channel
(in BIOS Setup) DMA channel 1 DMA channel 3
Optional parallel port I/O address
(via BIOS Setup) 3BCh 378h
278h
Optional parallel port IRQ
(via BIOS Setup) IRQ5 IRQ7
Serial Port
Item Specification
Serial port controller FDC37C707
Serial port controller resident bus ISA bus
Number of serial ports 2
Serial port locations CN4
16550 UART support Yes
Connector type 9-pin D-type female connector
Optional serial port I/O address
(via BIOS Setup) 3F8h 2F8h
3E8h
2E8h
Optional serial port IRQ
(via BIOS Setup) COM1: IRQ 4 COM2: IRQ 3

Chapter 1 7
Memory Address Map
Address Size Function
000000 - 07FFFF 512 Kbytes Host Memory
080000 - 09FFFF 128 Kbytes Host/PCI Memory
0A0000 - 0BFFFF 128 Kbytes PCI/ISA Video Buffer
Memory
0C0000 - 0C7FFF 32 Kbytes Video BIOS Memory
0C8000 - 0DFFFF 96 Kbytes ISA Card BIOS & Buffer
Memory
0E0000 - 0EFFFF 64 Kbytes BIOS Extension
Memory
Setup and Post
Memory
PCI Development BIOS
0F0000 - 0FFFFF 64 Kbytes System BIOS Memory
100000 - UPPER LIMIT Main Memory
UPPER LIMIT - 4GBytes PCI Memory
PCI INTx# and IDSEL Assignment Map
PCI INTx # PCI Devices Device IDSEL : ADxx
INTA# PCI-Slot1 AD27
INTB# PCI-Slot2 AD24
INTC# PCI-Slot3/ESS Solo1 AD25/AD22
INTD# USB AD18
PCI Slot IRQ Routing Map
PCI INTX# INTA INTB INTC INTD Bus Mastering
PCI slot 1 Route 1 Route 2 Route 3 Route 4 Enabled
PCI slot 2 Route 2 Route 3 Route 4 Route 1 Enabled
PCI slot 3 Route 3 Route 4 Route 1 Route 2 Enabled

8 System Introductions
I/O Address Map
Hex Range Devices
000-00F
020-021
040-043
060-060
061-061
070-071
081-08F
0A0-0A1
0C0-0DF
0F0-0FF
170-177
1F0-1F7
278-27F
2F8-2FF
378-37F
3F0-3F5
3F6-3F6
3F7-3F7
3F8-3FF
0CF8
0CFC
778-77A
DMA Controller-1
Interrupt Controller-1
System Timer
Keyboard Controller 8742
System Speaker
CMOS RAM Address and Real Time Clock
DMA Controller-2
Interrupt Controller-2
DMA Controller-2
Math Co-Processor
Secondary IDE
Primary IDE
Parallel Port 2
Serial Asynchronous Port 2
Parallel Port 1
Floppy Disk Controller
Secondary IDE
Primary IDE
Serial Asynchronous Port 1
Configuration Address Register
Configuration Data Register
Parallel Port 1

Chapter 1 9
PIIX4E GPIO (General Purpose I/O) PIN Definitions
Item Description
GPO28 FANOFFJ 0: Turn off the fan
1: Turn on the fan
GPO29 BIOSA17 0:
GPO24 DISS0I01 0: Disabled
1: Enabled
GPI1 GPI1 Reserved
GPI20 CHKPSW 0: Bypass
1: Check password
GPO27 PWRLED 0: Suspend
1: Normal
IRQ Assignment Map
IRQx System Devices Add-On-Card Devices
IRQ0 Timer Not applicable
IRQ1 Keyboard Not applicable
IRQ2 Cascade Interrupt Control Not applicable
IRQ3 Serial Alternate Reserved
IRQ4 Serial Primary Reserved
IRQ5 Parallel port (Alternate) Reserved
IRQ6 Floppy Diskette Reserved
IRQ7 Parallel Port Reserved
IRQ8 Real Time Clock Not applicable
IRQ9 Free Reserved
IRQ10 Unused Reserved
IRQ11 Free Reserved
IRQ12 PS/2 Mouse Reserved
IRQ13 Math Coprocessor Exception Not applicable
IRQ14 Hard disk drive Reserved
IRQ15 Hard disk drive Reserved

10 System Introductions
DRQ Assignment Map
DRQx System Devices Add-On-Card Devices
DRQ0 Reserved Reserved
DRQ1 Reserved Reserved
DRQ2 Floppy Diskette Not applicable
DRQ3 Reserved Reserved
DRQ4 Cascade Not applicable
DRQ5 Reserved Reserved
DRQ6 Reserved Reserved
DRQ7 Reserved Reserved
System Board Major Chips
Item Controller
System core logic Intel 443BX / Intel 82371EB(PIIX4E)
Super I/O controller FDC37M707
Audio controller ESS Solo1
Hard disk drive controller Built-in Intel 82371EB(PIIX4E)
Keyboard controller Built-in FDC37M707
RTC Built-in Intel 82371EB(PIIX4E)

Chapter 1 11
Power Management
Power Saving Mode Phenomenon List
Power Saving Mode Phenomenon
IDE Hard Disk Standby
mode Hard disk drive is in standby mode (spindle turned-off)
Monitor Power Saving
mode Monitor is in suspend mode (V-sync.=0Hz).
System Standby mode Power LED illuminate in amber color
Hard disk drive is in standby mode (spindle turned-off)
Monitor is in off mode (V-sync. and H-sync. =0Hz).
System Suspend mode Power LED illuminate in amber color
Hard disk drive is in standby mode (spindle turned-off)
Monitor is in off mode (V-sync. and H-sync. =0Hz).
Processor fan turns off
NOTE The VGA BIOS should support DPMS (Desktop Power Management
System) for the standby and suspend mode function call. When the
Display Standby Timer expires, the system BIOS will execute the DPMS
service routines.
Environmental Requirements
Item Specifications
Temperature
Operating +10 ~ +35°C
Non-operating -20 ~ +60°C
Humidity
Operating 20% to 80% RH
Non-operating 20% to 80% RH
Vibration
Operating (unpacked) 5 ~ 18 Hz: 0.015 mm
18 ~ 250 Hz: 0.25 G
Non-operating (packed) 5 ~ 27.1 Hz: 0.6 G
27.1 ~ 50 Hz: 0.016 mm
50 ~ 500 Hz: 2 G

Chapter 2
Chapter 2 13
System Utilities
Most systems are already configured by the manufacturer or the dealer. There
is no need to run Setup when starting the computer unless you get a Run Setup
message.
The Setup program loads configuration values into the battery-pack nonvolatile
memory called CMOS RAM. This memory area is not a part of the system
RAM.
NOTE If you repeatedly receive Run Setup messages, the battery may be
defective. In this case, the system cannot retain configuration values in
CMOS. You may try to replace the RTC battery to solve this problem.
Before you run Setup, make sure that you have saved all open files. The
system reboots immediately after you exit Setup.
