Acer Predator PO3-600 Installation and operation manual

Table of Contents -
1
Predator PO3-600
User’s Guide

-Upgrading your Computer
2
© 2018. All Rights Reserved.
Desktop Computer Covers:
Tower models
This revision: April 2018 V1.00
Important
This manual contains proprietary information that is protected by
copyright laws. The information contained in this manual is
subject to change without notice. Images provided herein are for
reference only and may contain information or features that do not
apply to your computer. Acer Group shall not be liable for technical
or editorial errors or omissions contained in thismanual.

Table of Contents -
3
Table of Contents
1. UPGRADING YOUR COMPUTER...............5
Installation precautions ..............................5
ESD precautions ..........................................5
Required tools ..............................................5
Pre-installation instructions ....................6
Post-installation instructions ..................6
System Upgrade ...........................................7
Removing the left side system cover ....7
Installing the left side system cover ......8
Hard drives ....................................................9
Removing the 3.5-inch hard drives .......9
Installing the 3.5-inch hard drives .......12
Memory ........................................................ 14
Memory configuration guidelines .......14
Removing a memory module ................15
Installing a memory module ..................16
Graphic board ............................................. 17
Removing the Graphic board ................17
Installing the Graphic board ..................20
M.2 SSD module ......................................... 22
Removing the M.2 SSD module ............22
Installing the M.2 SSD module .............25
2PREDATORSENSE.................................. 29
PredatorSense features ............................ 29

-Upgrading your Computer
4
Upgrading your Computer
In this section, you will find:
•Instructions on how to replace a hardware component

Upgrading your Computer -
5
1. UPGRADING YOUR COMPUTER
Installation precautions
Before you install any computer component, we recommend
that you read the following sections. These sections contain
important ESD precautions along with pre-installation and
post-installation instructions.
ESD precautions
Electrostatic discharge (ESD) can damage your processor,
disk drives, expansion boards, and other components.
Always observe the following precautions before you install a
computer component:
1. Do not remove a component from its protective
packaging until you are ready to install it.
2. Wear a wrist grounding strap and attach it to a metal
part of the computer before handling components. If a
wrist strap is not available, maintain contact with the
computer throughout any procedure requiring ESD
protection.
Required tools
In performing the component replacement process, you will
need the following tools:
•Philips screwdriver
•Hex screwdriver
•Flat screwdriver
•Scissors
Note
The screws for the different components vary in size. During the
disassembly process, group the screws with their corresponding
components to avoid mismatches when putting back thecomponents.

-Upgrading your Computer
6
Pre-installation instructions
Always observe the following before you install any
component:
1. Make sure that the ODD and card reader slot is empty.
2. Turn off the power to the computer and all peripherals.
3. Unplug the power cord from the computer.
4. Unplug the network cable and all connected peripheral
devices from the computer.
5. Place the computer on a flat, steady surface.
6. Open your computer according to the instructions on
Removing the rear system cover on page 7 and
Removing the left side system cover on page 9.
7. See the following sections for specific instructions on
the component you wish to install.
Post-installation instructions
Observe the following after installing a computer component:
1. See to it that the components are installed according to
the step-by- step instructions in their respective
sections.
2. Replace any expansion boards or peripherals that you
removed earlier.
3. Replace the system covers. See Installing the left side
system cover on page 10 and Installing the rear
system cover on page 8.
4. Connect the necessary cables.
5. Turn on your computer.
Warning
Not turning off the computer properly before you start installing the
components may cause serious damage. Do not attempt the
procedures described in the following sections unless you are a
qualified service technician.

Upgrading your Computer -
7
System Upgrade
Removing the left side system cover
1. Before you proceed, make sure that you have turned
off your computer and all peripherals connected to it.
Read the Pre- installation instructions on page 6.
2. Remove the two screws that secure the system cover
to the computer.
3. Slide the cover toward the back of the computer and
pull away from the side of the computer.
4. Set the cover aside for re-installation later.

-Upgrading your Computer
8
Installing the left side system cover
1. Align the cover to the sides of the computer and slide
the cover toward the front of the computer.
2. Secure the cover with two screws.
3. Observe the Post-installation instructions on page 6.

Upgrading your Computer -
9
Hard drives
The computer supports installation of one 3.5-inch SATA
hard drives in the internal HDD cage.
Removing the 3.5-inch hard drives
1. Perform Pre-installation instructions on page 6.
2. Remove the four screws that secure the HDD bracket
to the computer.

-Upgrading your Computer
10
3. Rotating the HDD bracket and pull away from the side
of computer (1) (2).
4. Disconnect the power and data cables from the hard
drives.
2
1
2

Upgrading your Computer -
11
5. Remove the four screws that secure the hard drives to
the bracket.

-Upgrading your Computer
12
Installing the 3.5-inch hard drives
1. Remove the new hard drive from their packaging.
2. Insert the new hard drive into the bracket and secure
the new hard drive with four screws.
3. Connect the power and data cables to the hard drive.

Upgrading your Computer -
13
4. Insert the HDD bracket into the side of computer (1) (2)
and rotating the bracket to fix.
5. Secure the HDD bracket with four screws.
6. Observe the Post-installation instructions on page 6.
1
2
1

-Upgrading your Computer
14
Memory
The computer has four DDR4 U-DIMM slots that support up
to 64 GB maximum system memory.
Memory configuration guidelines
Toensure data integrity, use only Acer-approved DDR4 2400 MHz
or DDR4 2666 MHZ type memory modules.
Memory modules must be installed starting with DIMM3 slot.
Always handle memory modules by its edges.
When installing memory modules, populate the DIMM slots
according to the table below.
Size
DIMM1
DIMM2
DIMM3
DIMM4
4GB
4GB
N/A
N/A
N/A
8GB
4GB
4GB
N/A
N/A
12GB
4GB
4GB
4GB
N/A
16GB
4GB
4GB
4GB
4GB
8GB
8GB
N/A
N/A
N/A
16GB
8GB
8GB
N/A
N/A
24GB
8GB
8GB
8GB
N/A
32GB
8GB
8GB
8GB
8GB
16GB
16GB
N/A
N/A
N/A
32GB
16GB
16GB
N/A
N/A
48GB
16GB
16GB
16GB
N/A
64GB
16GB
16GB
16GB
16GB
DIMM4
DIMM3
DIMM2
DIMM1

Upgrading your Computer -
15
Removing a memory module
1.Perform Pre-installation instructions on page 6.
2.Press outward the holding clips on both sides of the
DIMM slot outward to release the memory module (1).
3.Gently pull the memory module upward to remove it from
the DIMM slot (2).
4.Repeat steps 5~6 to remove the other memory modules.
1
2

-Upgrading your Computer
16
Installing a memory module
1. Select an empty DIMM slot.
2. Remove the new memory module from its packaging,
handling it by the edges.
3. Align then insert the memory module into the DIMM
slot (1).
4. Insert the memory to the slot until the retaining clips
snap inward (2).
The module is keyed so it can only be inserted in one
direction. If the module does not fit, make sure that the
notch in the module lines up with the tab in the
memory slot.
5. Repeat steps 1~4 to install the other memory modules.
6. Observe the Post-installation instructions on page 6.
Note
DIMM slots on the mainboard must be installed only in certain configurations.
Numbers next to DIMM slots correspond to installation sequence.
Be sure to install the memory module in DIMM1 slot followed by DIMM2 slot.
2
1

Upgrading your Computer -
17
Graphic board
The computer contains one or two Graphic boards installed in
the PCIe x16 slots. The detail configuration will be differed by
different models.
Removing the Graphic board
1. Perform Pre-installation instructions on page 6.
2. Remove the 3.5-inch hard drives. See removing the
3.5-inch hard drives.
3. Disconnect the power cables from the Graphic board.
4. Remove the screw that secure the Graphic boards to
the chassis.

-Upgrading your Computer
18
5. Rotating the latch bracket and graphic board hold
module to release.
6. Release the latch that secures the graphic board to the
mainboard.

Upgrading your Computer -
19
7. Detach the Graphic board from the PCIe x16 slot.

-Upgrading your Computer
20
Installing the Graphic board
1. Remove the new graphic board from its packaging.
2. Insert the Graphic boards into the PCIe x16 slot and
push it until it latches into place.
[Note] For replace/upgrade graphic board, please check
the specification of graphic board & power supply first in
order to make sure the graphic board and power supply
could work.
3. Rotating the latch bracket (1) and graphic board hold
module (2) to lock.
2
1
