ACER K-12 BUYER’S GUIDE TERM 4 2009
Valid till 30 November 2009
Technology to Enhance
Your Learning Experience
Aspire One Pro
All Day Computing
• Intel® Atom™ Processor N270
1.6Ghz 533Mhz
• Geniune Windows Vista Business
with XP Pro Downgrade Media
• 10.1” SWVGA Widescreen
• 2GB DDR2-667 Memory
• 160GB Hard Drive
• 3 Year Pickup Repair Return Warranty
From $699
ex GST
Privilege Points: 20
Aspire 1820PT
Preorder now - Available 15/11/2009
• Intel® Core™ 2 Duo SU7300
1.3GHz, 3MB Cache, 800MHz FSB
• Windows Vista® Home Premium
• 11.6” WXGAG Widescreen Touch
• 2GB DDR3 Memory
• 250GB Hard Drive
• 3 Year NBD Onsite Warranty
TOUCH | DRAW
$1419
ex GST
Privilege Points: 20
Veriton X480G
Special offer - Available while stocks last
• Intel Core®2 Duo E7500 Processor
• 2.93GHz, 3MB Cache, 1066MHz FSB
• Geniune Windows Vista Business
with XP Pro Downgrade Media
• 2GB DDR3 Memory
• 160GB SATA 7200RPM Hard Drive
• Onboard Intel GMA X4500 Graphics
• 3 Year NBD Onsite Warranty
$689
ex GST
Privilege Points: 10
*Price Excludes Monitor & Speakers
11.6”
10.1”
1/3 Size
of standard tower PC

Aspire One 11.6” Screen
ex GST
Privilege Points: 20
K-12 Buyer’s Guide TERM 4 2009
1
Up to 8 hours battery life^
How would you like to get 8+ hours battery life – a whole working day - with just one charge? Well now you can thanks to
carefully chosen low power consuming components such as the recently introduced Intel® ultra-low voltage (ULV) processors
technology and LED-backlit displays. The low energy consumption of the innovative Intel ULV processors means you get incredibly
long battery life without a reduction in performance. Intel’s ULV technology offers the high performance we have come to expect
from notebooks based on Intel® technology in new ultra-thin, ultra light, highly desirable designs.
ex GST
Aspire 1810T-732G25n TravelMate8471Aspire 1410-232G25n
$859
ex GST
Privilege Points: 20
ex GST
Privilege Points: 20
ex GST
Privilege Points: 20
$1179 $1349
• Intel® Core™2 Duo SU7300
• 1.3GHz, 3MB Cache, 800MHz FSB
• Windows Vista Business + XP Media
• 14” WXGA LED Widescreen
• 2GB DDR3-1066 Memory
• 320GB 5400rpm SATA Hard Drive
• DVD Super Multi
• Intel® Wireless WiFi Link 1000
Mini PCIe 802.11b/g/Draft-N1
• Built-in Bluetooth
• Crystal Eye Webcam
• Long Life 6-cell Battery
• Bio-Metric Finger Print Reader
• MS Office Ready
• 3 Year NBD Onsite Warranty
NEW - Acer TravelMate 1820PT NEW - Acer TravelMate 1820PT NEW - Acer
FROM FROM FROM
14.1”
Touch me
Multi-touch all day computing
Aspire 1820PT powered by Intel® Centrino®2 Processor Technology
Touch
&
Rotate
Reserve yours now
available from 15/11/09
11.6”
• Intel® Core™2 Duo SU7300
• 1.3GHz, 3MB Cache, 800MHz FSB
• Windows Vista Business + XP Media
• 11.6” WXGAG HD Widescreen
• 2GB DDR2-667 Memory
• 250GB 5400rpm SATA Hard Drive
• Intel® Wireless WiFi Link 1000
Mini PCIe 802.11b/g/Draft-N1
• Built-in Bluetooth
• Crystal Eye Webcam
• Long Life 6-cell Battery
• 3 Year NBD Onsite Warranty
• Intel® ULV Celeron™ Processor SU2300
• 1.2GHz, 1MB Cache, 800MHz FSB
• Windows Vista® Home Premium
• 11.6” WXGAG HD Widescreen
• 2GB DDR2-667 Memory
• 250GB 5400rpm SATA Hard Drive
• Intel® Wireless WiFi Link 1000
Mini PCIe 802.11b/g/Draft-N1
• Built-in Bluetooth
• Crystal Eye Webcam
• Long Life 6-cell Battery
• 3 Year NBD Onsite Warranty
more than
8 hours battery life*
Multi-touch
• Experience everything that Windows 7 has to offer including the
all new feature of our Multi-Touch display.
• In clamshell mode benet from the versatility of point-n-click, drag-n-
drop, and application launch onscreen. Switch to tablet mode and enjoy
enhanced Internet browsing, album viewing and document reading.
• Benet from improved readability and touch control with magnied
browsing support, intuitive handwriting, annotation and note taking.
The future is Touch!
11.6”
11.6”
PLANT
1 Tree
with every
notebook purchased
more than
8 ho urs ba t te ry life *
more than
8 ho urs ba t te ry life *
more than
8 ho urs ba t te ry life *
• Free upgrade to Windows 7 • Free upgrade to Windows 7 • Free upgrade to Windows 7
1Disclaimer: Your computer’s battery life may vary depending on product specications, computer settings, and applications or features launched. The listed battery life is for individual battery packs tested with MobileMark
2007 in productivity test mode and with wireless connection on. All batteries’ maximum capacity will diminish with time and use. Battery life indicated is with Acer PowerSmart Manager enabled. 2007 test results for the
Acer TravelMate 8000. Battery life will vary based on your conguration. The MobileMark2007 benchmark does not include DVD playback. See http://www.acer.com.au for more information.
ex GST
Privilege Points: 20
$1419*

TravelDapter Car
Airplane Adapter
ex GST$179
$1490
ex GST
Not what you’re after? Call your Reseller for more trolley options
K-12 Buyer’s Guide TERM 4 2009
2
Laptop Locker to Secure
Notebooks & Netbooks.
The Laptop Locker is a secure, user friendly and compact trolley
designed for storing and charging up to 14 laptops. The power
boards supplied for recharging are overload protected and
ample provision has been made in the design for tidy cable
management.
• Compatible for storage of both Notebooks and Netbooks.1
• Unique Double sliding locking bar for security and ease of use.
• High Quality soft rubber pivot castors for easy maneuverability.
• Rear section for cable management, storage of transformers
and overload protected power boards.
• Anchor point to secure to oor.
• Injection Molded plastic inserts to support and protect your
Notebooks.
1Mini PC adapter kit available at extra cost.
NOTEBOOK ACCESSORIES - boost performance in your school
Acer TravelSlim Polyester Case
Acer EasyPort IV - Port Replicator
For:
EX5630
TM4730
Acer Optical Mouse
Notebook AC Adaptor
All acer notebook models
Aspire One External USB
Optical Drive
Notebook AC Adaptor
AspireOne model Only
Shintaro Cable Lock
with Key
AspireOne Li-lon Battery - 6 Cell
(Available in white and black)
Notebook Memory - 1GB DDR2
SDRAM 667MHz
Notebook Memory - 2GB DDR2
SDRAM 667MHz
Li-Ion Battery - 8 Cell
(EX5630)
Acer TravelSure Koskin Case
Acer TravelTuff Polyester Case
support up to 14” notebook
TargusSlam Backpack
ex GST$45
ex GST$129
ex GST$81
ex GST$49
ex GST$54 ex GST$99
ex GST$20
ex GST$64
ex GST$89
ex GST$149
ex GST$90
ex GST$19
ex GST$159
ex GST$119
Aspire 11.6” Hard Case
ex GST$59
Acer USB Keyboard
ex GST$18

PMS: 329
PLANT
1 Million
“Planting 1 Million Trees"
This special edition of the Acer K12 Buyers Guide is dedicated to a noble cause of planting
one million trees in Australia.
Scientists have warned us that the current carbon emission levels are causing global warming. The
issue of climate change is real, not only for our generation but also for the generations to come.
At Acer we don’t pretend we can solve the world’s problems, but by taking the position of a
corporate citizen we aim to make a positive impact and a small contribution to the environment. Acer
is interested in reducing carbon emissions, in particular those emitted by computing devices.
Planting trees is an effective way to reverse the effects of carbon dioxide emissions through
photosynthesis. Revegetation is also an integral part of any global climate change program. On
average, 1.4 tonnes of timber contain 1 tonne of carbon. These largely continue to be stored in the
timber even after havesting.
Acer is committed to do our part for the environment. Since 2008, we have successfully
planted more than 31,000 trees, this equates to offsetting more than 5,000
tonnes of carbon dioxide. Our goal now is pure and simple, we want to
accelerate our tree plantation process, and with your help, Acer will plant
a million trees within the next 2 years. To kick start this effort, for every
purchase of a system in this “Green” edition of the Acer K12 Buyers Guide
Acer will plant up to 10 trees in Australia.
Please support us in our goal and at the same time enjoy Acer’s award
winning range of products at great value prices.
For more information on carbon footprint and our tree planting efforts, please visit the website of Acer’s
environmental partner: Trees For Life – www.carbonneutral.com.au

Standard Series
17” 4:3 V173BMD
19” 4:3 V193BMD
19” wide V193WB
23” wide X233HB
27” wide B273HU
3 Years Pick Up and Return Warranty**
ex GST
$170
$209
$175
$239
$529
17” 19” 23” wide
All Monitors Privilege Points: 5
27” wide
K-12 Buyer’s Guide TERM 1 2009
K-12 Buyer’s Guide TERM 4 2009
4
• Intel® Atom Processor N280
1.66GHz, 512K Cache, 667MHz FSB
• Geniune Windows Vista® Business with
Windows XP Professional Downgrade Media
• 2GB DDR2 Memory
• 160GB 5400RPM Hard Drive
• Onboard Gigabit Ethernet
• Wireless 802.11b/g/Draft-N
• 3 Year NBD Warranty
• Intel® Celeron Dual Core Processor E3200
2.4GHz, 1MB Cache, 800MHz FSB
• Geniune Windows Vista® Business with
Windows XP Professional Downgrade Media
• 2GB DDR3 Memory
• 160GB SATA 7200RPM Hard Drive
• Slim DVD Super Multi (Dual Layer)
• Onboard Intel® GMA X4500 Graphics
• 3 Year NBD Warranty
• Intel® CoreTM2 Duo Processor E8500
3.16GHz, 6MB Cache, 1333MHz FSB
• Geniune Windows Vista® Business with
Windows XP Professional Downgrade Media
• 2GB DDR3 Memory
• 320GB 7200RPM Hard Drive
• Onboard Intel GMA X4500 Graphics
• 3 Year NBD Warranty
PLANT
2 Trees
with every
desktop purchased
Veriton Hornet N260G Veriton L480G Veriton S670G with Intel vPro
ex GST
Privilege Points: 10 ex GST Privilege Points: 10
ex GST
Privilege Points: 10
$829* $649* $749*
Price Excludes Monitor Price Excludes MonitorPrice Excludes Monitor and Speakers
True Small Form Factor PC
Veriton X480G powered by Intel®CoreTM2 Duo
ex GST
Privilege Points: 10
$689*
• Intel® CoreTM2 Duo Processor E7500
2.93GHz, 3MB Cache, 1066MHz FSB
• Geniune Windows Vista Business
With XP Professional Downgrade Media
• 2GB DDR3 Memory
• 160GB SATA 7200RPM Hard Drive
• Optional Optical Device
• Onboard Intel GMA X4500 Graphics Controller
• 3 Year NBD Warranty
The Veriton X480G desktop PC offers a choice of powerful Intel®
processors and up to 8 GB of DDR3 memory to handle the most
challenging office tasks. This compact PC also packs a host of
Acer software applications for convenient system management
and dependable security. To top it off, the Veriton X480G has
passed rigorous certification tests to cut your costs, while caring
for the environment.
NEW
1/3Size
of standard tower PC

WHY ACER DATA PROJECTOR?
Acer Projectors extend productivity potential without going over budget. They are easy to use, come in attractive
design, and feature the latest technologies for superior usability
Plug and play connectivity | Empowering Technology for simple set up and use | DLP™ technology | Slim, compact design
• Native Resolution XGA (1024 x 768)
• Contrast Ratio 2700:1
• Brightness 2700 ANSI Lumens
• Acer Eco Projection Technology
• 3x Colour-Wheel Rotation Speed
• Digital Connectivity via HDMI Port
• ECO Mode • Includes Free Carry Bag
• 2 Years Return to Base Warranty**
• Native Resolution SVGA (800 x 600)
• Contrast Ratio 4000:1
• Brightness 2500 ANSI Lumens
• Analog RGB/Component Video (D-sub)
• Composite Video (RCA)
• S-Video (Mini-DIN)
• Includes Free Carry Bag
• 2 Years Return to Base Warranty**
• Native Resolution SVGA (858 x 600)
• Contrast Ratio 2000:1
• Lightweight: 0.55 kg
• LED Lamp Life 20000 Hours
• Kensington Lock Support
• Acer Instant Pack Technology
• 2 Years Return to Base Warranty**
Acer P1266P Projector
$899
ex GST
Acer K10 Projector (0.55kg)
$689
ex GST
Acer X1161 Projector
$579
ex GST
K-12 Buyer’s Guide TERM 4 2009
5
Enhanced Viewing Experience!
獎項名稱(與COMPUTEX結合)
僅Logo與年份
• Full HD 1920x1080 Resolution
• High 80,000:1 Contrast Ratio (ACM)
• Ultra-fast 2ms GTG response rate
• Multi-Touch Features
- Cicular-motion scrolling
- Up/down scrolling
- Pinch-action zoom
- Image rotation
- Page ip
Multitouch Monitor
Touch screen technology provides a fast and
intuitive interface simplifying user interaction
Zoom Flip Rotate Up/Down
Multi-touch
ex GST
Privilege Points: 10
$689*
TOUCH
Acer T230H lets you enjoy all the
touch qualities of Windows® 7.
Rotate images, ip pages, pinch,
and draw on the multi-touch
screen with simple hand gestures.
Advanced HDMI™ connectivity
delivers the highest-quality video
and audio currently available.
16:9 wide
The 16:9 widescreen LCD
monitor unlocks new multitasking
possibilities to increase
productivity, and delivers a
fabulous multimedia experience.
ergonomics++
productivity++
Scroll, search, zoom, and
rotate with one touch within a
comfortable work position. Work
with increased speed today.
ACER T230
NEW

There’s more to our commitment to schools than just providing the highest quality
desktops, notebooks, LCD monitors, data projectors and enterprise solutions.
Acer is pleased to announce the Acer Privilege Program, a program designed to reward
schools, from kindergarten through to year 12, for purchasing Acer products.
Based on the quantity of Acer products purchased through Acer Authorised
Education Resellers, schools can earn points, which can be used to
claim merchandise from our Redemption Catalogue. The more
points you have the more you can reward your school.
Simply log onto www.acer.com.au/privilege
It’s that easy.
Get Privileged Now!
Acer Privilege ProgramAcer Privilege Program

Thinking about Virtualising?
Less can denitely run more. New Windows Server 2008 changes the game with innovations
that give your servers legs of steel, no matter the workload. When you have a server that
runs faster, longer, more securely, and with less downtime, it can transform your day, your
department, and your whole school. Just give it your command, and get on with your day.
K-12 Buyer’s Guide TERM 4 2009
6
PLANT
10 Trees
with every
server purchased
Altos G540 M2
• Intel® Xeon® Processor E5504
• 4GB Registered DDR3 RAM (2 x 2GB)
• 2 x 750GB SATA 3.5” Hotswap Hard Drive 7200 RPM
• DVD Super Multi (Dual Layer)
• Integrated software SATA RAID Controller (RAID 0, 1, 10)
• Integrated remote management with remote KVM capability
• Integrated Dual Port Gigabit Ethernet
• 610W Hotswap Power Supply
• Acer EasyBUILD
• 3 Years Next Business Day Onsite Warranty with 24x7 Hotline Support **
The Altos G540 M2 is a 5U pedestal server that boasts a complete package for cost-effective usage. Featuring the
latest Intel® processor technology, fast DDR3 memory and large storage capacity, the Altos G540 M2 can serve web
applications, e-mail, FTP and other heavy-loading programs with ease. With reliable security, assured availability,
maximised productivity, intuitive manageability, efcient serviceability and a strong commitment to environment-
friendly operation, Altos G540 M2 servers are a benecial addition to your school.
All Altos G540 M2 servers include EasyBUILD™, a user-friendly interface that allows rapid server provisioning
through cloning, an enhanced post-setup guide for installing applications or utilities, and an easy-to-use resource
kit disc with software documentation. EasyBUILD™ helps set up a group of identical servers to get software and
services running in less time.
Altos Servers – Solutions for all environments
$1969ex GST
Privilege Points: 40
• Intel® Xeon® Processor E5504
• 4GB Registered DDR3 RAM (2 x 2GB)
• 2 x 750GB SATA 3.5” Hotswap Hard Drive
7200 RPM
• DVD Super Multi (Dual Layer)
• Integrated software SATA RAID Controller
(RAID 0, 1, 10)
• Integrated remote management
with remote KVM capability
• Integrated Dual Port Gigabit Ethernet
• 750W Hotswap Power Supply
• Acer EasyBUILD
• 3 Years Next Business Day Onsite Warranty
with 24x7 Hotline Support **
Altos R720 M2
$2279
ex GST
Privilege Points: 40
• Intel® Xeon® Processor E5504
• 4GB Registered DDR3 RAM (2 x 2GB)
• 2 x 250GB SATA 2.5” Hotswap Hard Drive
5400 RPM
• DVD Super Multi (Dual Layer)
• Integrated software SATA RAID Controller
(RAID 0, 1, 10)
• Integrated remote management
with remote KVM capability
• Integrated Dual Port Gigabit Ethernet
• 650W Hotswap Power Supply
• Acer EasyBUILD
• 3 Years Next Business Day Onsite Warranty
with 24x7 Hotline Support **
Altos R520 M2
$2229
ex GST
Privilege Points: 40
• Intel® Pentium® Processor E5300
• 2GB Unbuffered DDR2-800 ECC RAM (1 x 2GB)
• 2 x 320GB SATA 3.5” Easy-Swap Hard Drive
7200 RPM
• DVD Super Multi (Dual Layer)
• 3.5” Floppy Disk Drive
• Integrated software SATA RAID Controller
(RAID 0, 1, 10)
• Integrated Gigabit Ethernet
• Acer EasyBUILD
• 3 Years Next Business Day Onsite Warranty
with 24x7 Hotline Support **
Altos G330 Mk2
$759
ex GST
Privilege Points: 40

Contact your nearest authorised education reseller
NSW
• Ethan Group
Phone: [phone]
• PCS Australia Pty ltd
Phone: [phone]
• Sterling IT
Phone: [phone]
• SuperIt
Phone: [phone]
• Winthrop Australia
Phone: [phone]
WA
• Bizquip Solutions
Phone: [phone]
• JH Computer Services
Phone: [phone]
• Winthrop Australia
Phone: [phone]
SA
• ASI Solutions SA
Phone: [phone]
• Corporate Express Australia
Phone: [phone]
• Datacom Systems SA Pty Ltd
Phone: [phone]
• Green Triangle Electronics
Phone: [phone]
• SUBNET
Phone: [phone]
QLD
• Computer Alliance
Phone: [phone]
• BES Information Technology
Phone: [phone]
• Brilliant Technologies
Phone: [phone]
• e-Computing Pty Ltd
Phone: [phone]
• Rosh Tech (Townsville) Pty Ltd
Phone: [phone]
VIC
• Learning with Technologies
Phone: [phone]
• PerfecktCom
Phone [phone]
•Trident Computer Services
Phone: [phone]
•Winthrop Australia
Phone: [phone]
•Ofce Everything
Phone: [phone]
TAS
• ComputerCORP (Hobart)
Phone: [phone]
• ComputerCORP (Launceston)
Phone: [phone]
• IRIS Computing (Hobart)
Phone: [phone]
• IRIS Computing (Launceston)
Phone: [phone]
ACT
• Dataex
Phone: [phone]
Acer and the Acer logo are registered trademarks of Acer Incorporated. Copyright 2009 Acer. All rights reserved. Celeron, Celeron Inside, Centrino, Centrino Logo, Core Inside, Intel, Intel Logo, Intel Core, Intel Inside, Intel Inside Logo,
Intel vPro, Pentium, Pentium Inside, Xeon, Xeon Inside are trademarks or registered trademarks of Intel Corporation or its subsidiaries in the United States and other countries. Microsoft, Windows, the Windows logo, and Windows
Vista are either registered trademarks or trademarks of Microsoft Corporation in the United States and/or other countries. *Pictures are for illustrative purposes only. **Terms and conditions apply – warranty locations available
on website www.acer.com.au. Advance Exchange Warranty - In the event of a HDD failure a replacement drive will be shipped direct to the customer. In the event a system replacement is required, the replacement will
be shipped to the customer and the faulty unit will need to be returned once migration is completed. Only available through the Acer Authorised Resellers listed above. All efforts have been made to check for errors
in typography and photography; however inadvertent errors may occur for which Acer may not be responsible. All prices indicated are ex GST. Offers available while stocks last. No Cashback applies to all models
featured. Prices are valid until 30/11/2009 or while stocks last.
Version Date: 15/10/09
Hitachi Simple Modular Storage SMS100
The Hitachi Simple Modular Storage, SMS100, is a simple and reliable entry level SAN that offers
enterprise-class storage and data protection features. The SMS100 is ideal for small schools that need a
reliable and highly available storage system that is easy to install, manage and integrate with Microsoft®
Windows and other common applications.
Key Features
• Hitachi SMS100 2U Storage Array
• iSCSI or Fibre Channel connectivity
• Dual Active Controllers for performance and redundancy
• Available in 6, 8 and 12 Disk congurations
• High Speed SAS or High Capacity SATA Disks available
• RAID 6 for maximum data availability
• 3 Years Advance Exchange Warranty**
STORAGE SOLUTION
Adaptable Modular Storage AMS2000 Family
The AMS2000 family of storage arrays feature Dynamic Load Balancing Controllers, which provide integrated,
automated hardware-based front to-back-end I/O load balancing; Full-Duplex, Point-to-Point SAS Architecture,
which eliminates loop arbitration for better performance; Intermix of SAS and SATA HDDs in the same
enclosure; and a new management interface, which was designed for use by small to large schools without
storage expertise and is common with the SMS100.
Key Features
• Hitachi AMS2000 Storage Array
• iSCSI or Fibre Channel host connectivity
• Dual Active Controllers for performance and redundancy
• Highly scalable from 5 to 480 HDDs
• High Speed SAS or High Capacity SATA Disks available
• Dynamic Storage Provisioning
• Supports RAID Levels 1, 5, 6 and 10
• On-Site support and maintenance
• Includes Hi-Track call-home monitoring
Enterprise
Solutions
Group
Acer have a dedicated
Enterprise Solutions
Group, a team of highly
skilled solutions experts
who are available to
help you identify and
scope your storage
requirements, design a
solution to meet your
needs and even to install
the solution which they
have designed. You will
be given a single point of
contact within the ESG
team from start to nish
so you don’t have to
worry about dealing with
a different person every
time you call.
ex GST
Privilege Points: 40
From $11539*
ex GST
Privilege Points: 60
From $21169*
