Acer Aspire 4930 Series User manual

Aspire 4930 Series
Quick Guide

Changes may be made periodically to the information in this publication without obligation
to notify any person of such revisions or changes. Such changes will be incorporated in new
editions of this manual or supplementary documents and publications. This company makes
no representations or warranties, either expressed or implied, with respect to the contents
hereof and specifically disclaims the implied warranties of merchantability or fitness for a
particular purpose.
Record the model number, serial number, purchase date and place of purchase information in
the space provided below. The serial number and model number are recorded on the label
affixed to your computer. All correspondence concerning your unit should include the serial
number, model number and purchase information.
No part of this publication may be reproduced, stored in a retrieval system, or transmitted, in
any form or by any means, electronically, mechanically, by photocopy, recording or otherwise,
without the prior written permission of Acer Incorporated.
Model number: __________________________________
Serial number: ___________________________________
Date of purchase: ________________________________
Place of purchase: ________________________________
Copyright © 2008. Acer Incorporated.
All Rights Reserved.
Aspire 4930 Series Quick Guide
Original Issue: 04/2008
Aspire 4930 Series Notebook PC
Acer and the Acer logo are registered trademarks of Acer Incorporated. Other companies'
product names or trademarks are used herein for identification purposes only and belong to
their respective companies.

3
Federal Communications Comission
Declaration of Conformity
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) This device may not cause harmful interference, and (2) This device must
accept any interference received, including interference that may cause undesired
operation.
The following local manufacturer/importer is responsible for this declaration:
Product name: Notebook PC
Model number: JAL90
Machine type: Aspire 4930
SKU number: Aspire 4930-xxxxx ("x" = 0 - 9, a - z, or A - Z)
Name of responsible party: Acer America Corporation
Address of responsible party: 333 West San Carlos St. San Jose, CA 95110 USA
Contact person: Acer Representitive
Tel: [phone]
Fax: [phone]

4
CE Declaration of Conformity
We,
Acer Computer (Shanghai) Limited
3F, No. 168 Xizang medium road, Huangpu District,
Shanghai, China
Contact Person: Mr. Easy Lai
Tel: [phone], Fax: [phone]
E-mail: eas[email protected]w
Hereby declare that:
Is compliant with the essential requirements and other relevant provisions of the following
EC directives, and that all the necessary steps have been taken and are in force to assure
that production units of the same product will continue comply with the requirements.
EMC Directive 2004/108/EC as attested by conformity with the following harmonized
standards:
•EN55022:1998 + A1:2000 + A2:2003, AS/NZS CISPR22:2002, Class B
•EN55024:1998 + A1:2001 + A2:2003
•EN55013:2001 + A1:2003 + A2:2005 (Applied to product with TV function)
•EN55020:2007 (Applied to product with TV function)
•EN61000-3-2:2000 + A2:2005, Class D
•EN61000-3-3:1995 + A1:2001 + A2:2005
Low Voltage Directive 2006/95/EC as attested by conformity with the following harmonized
standard:
•EN60950-1:2001 + A11:2004
•EN60065:2002 (Applied to product with TV function)
Council Decision 98/482/EC (CTR21) for pan- European single terminal connection to the
Public Switched Telephone Network (PSTN).
RoHS Directive 2002/95/EC on the Restriction of the Use of certain Hazardous Substances in
Electrical and Electronic Equipment.
R&TTE Directive 1999/5/EC as attested by conformity with the followingharmonized
standard:
CE Issued Date: 29 February 2008
Product: Notebook PC Trade Name: Acer
Model Number: JAL90 Machine Type: Aspire 4930
SKU Number: Aspire 4930 -xxxxx ("x" = 0~9, a ~ z, or A ~ Z)
•Article 3.1(a) Health and Safety
•EN60950-1:2001+ A11:2004
•EN50371:2002
•Article 3.1(b) EMC
•EN301 489-1 V1.4.1
•EN301 489-3 V1.4.1
•EN301 489-17 V1.2.1
•Article 3.2 Spectrum Usages
•EN300 220-3 V1.1.1
•EN300 328 V1.6.1
•EN300 440-2 V1.1.2
•EN301 893 V1.2.3
Acer Computer (Shanghai) Limited
Easy Lai / Director Date
29 Feb 2008

5
First things first
We would like to thank you for making an Acer notebook your choice for
meeting your mobile computing needs.
Your guides
To help you use your Acer notebook, we have designed a set of guides:
First off, the Just for Starters...poster helps you get started with setting up your
computer.
The printed Aspire Series Generic User Guide contains useful information
applying to all models in the Aspire product series. It covers basic topics such as
Acer’s Empowering Technology, using the keyboard, audio, etc. Please
understand that due to its nature, the Generic User Guide as well as the
AcerSystem User’s Guide mentioned below will occasionally refer to functions
or features which are only contained in certain models of the series, but not
necessarily in the model you purchased. Such instances are marked in the text
with language such as "only for certain models".
The printed Quick Guide introduces you to the basic features and functions of
your new computer. For more on how your computer can help you to be more
productive, please refer to the AcerSystem User's Guide. This guide contains
detailed information on such subjects as system utilities, data recovery,
expansion options and troubleshooting. In addition it contains warranty
information and the general regulations and safety notices for your notebook.
It is available in Portable Document Format (PDF) and comes preloaded on your
notebook. Follow these steps to access it:
1 Click on Start, All Programs, AcerSystem.
2 Click on AcerSystem User's Guide.
Note: Viewing the file requires Adobe Reader. If Adobe Reader is not
installed on your computer, clicking on AcerSystem User's Guide will run the
Adobe Reader setup program first. Follow the instructions on the screen to
complete the installation. For instructions on how to use Adobe Reader,
access the Help and Support menu.

6
English
Your Acer notebook tour
After setting up your computer as illustrated in the Just for Starters... poster,
let us show you around your new Acer notebook.
Front view
#Icon Item Description
1 Acer PureZone Two internal stereo microphones for sound
recording.

7
English
2 Acer Crystal Eye Web camera for video communication.
3 Display screen Also called Liquid-Crystal Display (LCD),
displays computer output.
4 Status indicators Light-Emitting Diodes (LEDs) that light up
to show the status of the computer's
functions and components.
5 Empowering key Lanuch Acer Empowering Technology
6 Easy-launch
buttons
Buttons for launching frequently used
programs.
7 Palmrest Comfortable support area for your hands
when you use the computer.
8 Touchpad Touch-sensitive pointing device which
functions like a computer mouse.
9 Click buttons (left,
center* and right)
The left and right buttons function like the
left and right mouse buttons. *The center
button serves as Acer Bio-Protection
fingerprint reader supporting Acer
FingerNav 4-way control function (only for
certain models).
10 Status indicators Light-Emitting Diodes (LEDs) that light up
to show the status of the computer's
functions and components.
11 Keyboard For entering data into your computer.
12 Speakers Left and right speakers deliver stereo audio
output.
13 Acer MediaTouch
keys
For use with Acer Arcade and other media
playing programs.
14 Power button Turns the computer on and off.
#Icon Item Description

8
English
Closed front view
#Icon Item Description
1 CIR receiver Receives signals from a remote
control.
2 5-in-1 card reader Accepts Secure Digital (SD),
MultiMediaCard (MMC), Memory
Stick (MS), Memory Stick PRO (MS
PRO), xD-Picture Card (xD).
3 Latch Locks and releases the lid.

9
English
Left view
#Icon Item Description
1 Acer EasyPort IV
connector
Connects to Acer EasyPort IV.
2 Ethernet (RJ-45)
port
Connects to an Ethernet 10/100/1000-
based network.
3 External display
(VGA) port
Connects to a display device
(e.g., external monitor, LCD projector).
4 HDMI Connects to a television or display device
with HDMI input.
5 USB 2.0 ports Connect to USB 2.0 devices (e.g., USB
mouse, USB camera) (only for certain
models).
6 Line-in jack Accepts audio line-in devices (e.g., audio
CD player, stereo walkman).
7 Microphone-in
jack
Accepts input from external
microphones.
8 Headphones/
speaker/line-out
jack with
S/PDIF support
Connects to audio line-out devices (e.g.,
speakers, headphones).
9 Unlimited volume
control wheel
Adjust the volume of the audio-out.
10 ExpressCard/54
slot
Accepts one ExpressCard/54 module.

10
English
Right view
#Icon Item Description
1 Kensington lock slot Connects to a Kensington-compatible
computer security lock.
2 Optical drive Internal optical drive; accepts CDs or
DVDs .
3 Optical disk access
indicator
Lights up when the optical drive is
active.
4 Optical drive eject
button
Ejects the optical disk from the drive.
5 Emergency eject
hole
Ejects the optical drive tray when the
computer is turned off.
Note: Insert a paper clip to the
emergency eject hole to eject the optical
drive tray when the computer is off.
6 Modem (RJ-11) port Connects to a phone line.
7 USB 2.0 port Connect to USB 2.0 devices (e.g., USB
mouse, USB camera).
8 DC-in jack Connects to an AC adapter.

11
English
Rear view
#Item Description
1 Ventilation slots Enable the computer to stay cool, even after
prolonged use.

12
English
Base view
#Icon Item Description
1 Battery bay Houses the computer's battery pack.
2 Battery release latch Releases the battery for removal.
3 Memory compartment Houses the computer's main memory.
4 Hard disk bay Houses the computer's hard disk (secured
with screws).
5 Battery lock Locks the battery in position.
6 Ventilation slots and
cooling fan
Enable the computer to stay cool, even
after prolonged use.
Note: Do not cover or obstruct the
opening of the fan.

13
English
Specifications
Operating
system
•Windows Vista™
Platform •Intel®Centrino®2 processor technology, featuring:
•Intel
®Core™2 Duo processor*
• Mobile Intel®PM45/GM45 Express Chipset*
•Intel
®Wireless WiFi Link 5100/5300, 5150/5350*
System memory •Dual-Channel DDR2 SDRAM support
•Up to 2 GB of DDR2 667 MHz memory, upgradeable
to 4 GB using two soDIMM modules*
TV-tuner •Digital TV-tuner supporting DVB-T*
Display •14.1" WXGA 1280 x 800
Graphics •Mobile Intel®GM45 Express Chipset
•NVIDIA GeForce 9300M GS / 9600M GT*
Storage
subsystem
•2.5" hard disk drive
•Optical drive options:
•Blu-rayDisc
™/DVD-Super Multi double-layer
drive
• DVD-Super Multi double-layer drive
•5-in-1 card reader
Audio •Dolby-certified surround sound system with two
built-in stereo speakers and one subwoofer
supporting low-frequency effects
•S/PDIF (Sony/Philips Digital Interface) support for
digital speakers
•Acer PureZone technolgy with two built-in stereo
microphones
Dimensions
and weight
•340.4 (W) x 247 (D) x 22.9/42.3 (H) mm
(13.4 x 9.7 x 0.9/1.6 inches)
•2.4 kg (5.29 lbs.)
Communication Acer Video Conference, featuring:
• Integrated Acer Crystal Eye webcam
• Acer Video Conference Manager software
• Acer PureZone technology
• Optional Acer Xpress VoIP phone
•WLAN: Intel®Wireless WiFi Link 5100/5300*
•WiFIi®/WiMAX™: Intel®Wireless WiFi Link 5150/
5350*
•WPAN: Bluetooth®2.0+EDR (Enhanced Data Rate)
•LAN: Gigabit Ethernet; Wake-on-LAN ready
•Modem: 56K ITU V.92

14
English
Privacy control •Acer Bio-Protection fingerprint solution
•BIOS user, supervisor, HDD passwords
•Kensington lock slot
Power
subsystem
•ACPI 3.0
•48.8 W 4400 mAh*
•3-pin 90 W AC adapter*
•3-pin 65 W AC adapter*
•Engergy Star 4.0
Special keys and
controls
•88-/89-/93-key keyboard
•Touchpad pointing device
•Empowering Key
•Easy-launch buttons: WLAN, Internet, email,
Bluetooth, Acer Arcade™
•Acer MediaTouch keys: play/pause, stop, previous,
next and record keys
•Volume wheel
•Acer Media Center remote control*
Environment •Temperature:
• Operating: 5 °C to 35 °C
• Non-operating: -20 °C to 65 °C
•Humidity (non-condensing):
• Operating: 20% to 80%
• Non-operating: 20% to 80%
I/O interface •Acer EasyPort IV connector
•ExpressCard™/54 slot
•5-in-1 card reader (SD/MMC/MS/MS PRO/xD)
•3 USB 2.0 ports
•HDMI™port with HDCP support*
•Consumer infrared (CIR) port
•External display (VGA) port
•Headphones/speaker/line-out port with S/PDIF
support*
•Microphone-in jack
•Line-in jack
•Ethernet (RJ-45) port
•Modem (RJ-11) port
•DC-in jack for AC adapter
Environment •Temperature:
• Operating: 5 °C to 35 °C
• Non-operating: -20 °C to 65 °C
•Humidity (non-condensing):
• Operating: 20% to 80%
• Non-operating: 20% to 80%

15
English
Note: "*" "Only for certain models"
Note: The specifications listed above are for reference only. The
exact configuration of your PC depends on the model purchased.
