Acer Aspire AS5745-5425 User manual

Buyers Guide | BTS 2010
Acer
®
Aspire AS5745-5425 Notebook
Acer
®
Confidential v1.0 - May 4, 2010
Wa -Mart

Acer® Aspire AS5745-5425 Notebook
Multimedia Powerhouse
Selling Points
Product Messaging
1
Turbo Charged Mobile Performance Taglines
Multimedia Powerhouse
Model Acer
®
Aspire AS5745-5425 Notebook
Positioning Statement
MSRP $698.00
On-Shelf Date June 20, 2010
High Level Specifications
2
High-Definition Multimedia Fun
 Intel® Core™ i3-350M Processor
(2.26GHz, 3MB L2 cache)
 Windows® 7 Home Premium 64-bit
 15.6" HD Widescreen CineCrystal™ LED-backlit Display

Mobile Intel® HM55 Express Chipset

4096MB DDR3 Dual-Channel 1066MHz Memory
Packaging and Documentation
 Intel® Graphics Media Accelerator HD

Hardware Items
Dolby Home Theater® V3 delivers audio that's true to the
original source, so you hear every detail. And with 5.1 channel
output you can enjoy intuitive surround sound through any pair
of speakers, or set of headphones.
Enjoy multimedia fun on-the-go with the Acer Aspire AS5745-
5425 Notebook providing advanced performance, amazing
mobility and stunning entertainment in a stylish thin and light
design. Enjoy HD media content and experience home theater
enjoyment like never before with stunning Blu-ray Disc™
technology, Dolby sound and a 15.6-inch 16:9 HD display. With
the latest Intel Core i3 processing performance, convenience
features and amazing connectivity you can conquer the most
demanding applications and keep in touch with friends, work and
the latest, while mobile.
Enjoy today's best HD entertainment on the cinematic 15.6" HD
widescreen LED-backlit display (true 16:9). HDMI port easily
extends the view to a TV via a single cable delivering crisp high-
quality visuals and high-fidelity audio.
Windows® 7 Home Premium makes it easy to enjoy and share
your favorite TV shows, photos, videos, and music.
Connect to the Internet anywhere, anytime. 802.11b/g/n Wi-Fi
CERTIFIED™ conveniently delivers rapid and reliable wireless
connectivity from your home, at work or on-the-go.
Smart performance starts here with the new Intel® Core™ i3
processor. Serving as the perfect threshold for a fast and
responsive computing, it features 4-way multi-tasking power
allowing each core to work on tasks simultaneously.
 320GB 5400RPM SATA Hard Drive
Hardware Items
 4X Blu-ray Disc™/DVD-Super Multi double-layer drive 6-Cell Lithium-Ion (4400 mAh) Battery
 Multi-in-1 Digital Media Card Reader AC Power Adapter
 802.11b/g/n Wi-Fi CERTIFIED™ AC Power Cord
 10/100/1000 Gigabit Ethernet LAN (RJ-45 port)
 Built-in HD Webcam (1280 x 1024 Resolution)
Documentation
 Two Built-in Stereo Speakers Setup Poster

Dolby Home Theater®Audio Enhancement
3
Packed with Extra Features & Travels Light Wireless Setup Card

High Definition Audio Support Registration/ Limited Warranty Card
 4 - USB 2.0 Ports COA Label for Microsoft
®
Installed software
 1 - HDMI™ Port McAfee® Internet Security Suite Trial (60-day trial)
 Multi-Gesture Touchpad
 Programmable Key
Online Documentation

6-Cell Lithium-Ion (4400 mAh) User's Guide
 5.72 lbs. | 2.6 kg. (system unit only)

One-year International Travelers Limited Warranty
Page 2 v1.0 - May 4, 2010
1.3 Megapixel HD webcam presents vivid images even in low
light situations so you can go face-to-face in online chats and
easily take still pictures and videos to share.
of speakers, or set of headphones.
Prepare to be stunned by the clarity of Blu-ray™ High-
Definition - experience interactive features from a Blu-ray Disc
movie and extraordinary HD detail (up to 1080p when connected
to a 1080p display via HDMI). The Blu-ray/DVD optical drive
also lets you burn CDs and DVDs of your favorite music, photos
and files.
This Acer Aspire 15.6"" Notebook is loaded with features while
being amazingly thin and light making it easy to take to the
coffee shop, on a plane, to class or just around the house. The
durable design sports a stylish black matte cover with a discrete
textile pattern that stays clean from fingerprints.
Smart controls like the Easy-launch P-key let you open your
favorite or most used program with a single touch.
Acer
®
Confidential
ADedicated Numeric Keypad makes number key-in's quick
and streamlines productivity.

Acer® Aspire AS5745-5425 Notebook
Detailed Product Specifications
Processor
Intel®Core™ i3-350M Processor
Windows
®
7 Home Premium 64-bit
(2.26GHz, 3MB L2 cache)
(1)
Productivity
Display 4 - USB 2.0 Ports Acer Backup Manager, Acer ePower Management & Acer eRecovery Management
15.6" HD Widescreen CineCrystal™ LED-backlit Display 1 - HDMI™ Port Microsoft
®
Works 9 with Office Home and Student 2007 Trial
(7)
1366x768 resolution; 16:9 aspect ratio 1 - VGA Port Adobe
®
Flash®Player 10 & Adobe® Reader® 9.1
Chipset 1 - Headphone/Speaker/Line-out Jack eSobi™
Mobile Intel
®
HM55 Express Chipset with S/PDIF Support Google Toolbar™
Memory 1 - Microphone-in Jack Norton®Online Backup
4096MB DDR3 Dual-Channel 1066MHz Memory
(2)
1 - Ethernet (RJ-45) Port Security
Upgradable to 8GB 1 - DC-in Jack for AC Adapter McAfee
®
Internet Security Suite 2009 Trial
(6)
Video 1 - Kensington Lock Slot MyWinLocker®
Intel
®
Graphics Media Accelerator HD
(3)
Multimedia
Webcam Acer Arcade™Deluxe
Built-in HD Webcam (1280 x 1024 Resolution) NTI Media Maker
™
Audio Convenience Features Gaming
Two Built-in Stereo Speakers WildTangent®Demo Games
(8)
Communication & ISP
Acer Crystal Eye
Easy-Launch Keys: Microsoft
®
Silverlight™
Programmable Key Skype™
Dedicated Numeric Keypad
Windows Live™ Essentials - Wave 3.2
Software
with 128MB of dedicated system memory, supporting Microsoft®
DirectX® 10
3
rd
Generation Dolby Home Theater
®
Audio Enhancement,
featuring Dolby
®
Digital Live, Dolby Pro Logic
®
IIx, Dolby
®
Headphone, Dolby
®
Natural Bass, Dolby
®
Sound Space
Expander, Dolby
®
Audio Optimization, Dolby
®
High Frequency
Enhancer Technologies
Interfaces
Multi-gesture touchpad pointing device,
featuring Acer FingerNav 4-way control
function gesture support
Black with discrete textile pattern
Case Design
Dedicated Numeric Keypad
Windows Live™ Essentials - Wave 3.2
High Definition Audio Support
(Mail, Photo Gallery, Live™ Messenger, Movie Maker, Writer)
Built-in Microphone 6-Cell Lithium-Ion (4400 mAh)
Hard Drive Battery Life
320GB 5400RPM SATA Hard Drive
(3)
Up to 3.5-hours Battery Life
(4)
Optical Drive Dimensions (System)
4X Blu-ray Disc™/DVD-Super Multi double-layer drive 14.96 (W) x 9.84 (D) x 1.0/1.34 (H) inches
Read: 24X CD-ROM, 24X CD-R, 24X CD-RW, 8X DVD-ROM, 379 (W) x 250 (D) x 25.5/34.1 (H) mm
8X DVD±R, 8X DVD-ROM DL (double-layer), Dimensions (Box)
6X DVD±R DL, 8X DVD±RW, 5X DVD-RAM 18.1 (L) x 3.9 (W) x 11.7 (H) inches
4X BD-ROM, 4X BD-R, 2X BD-RE, 4X BD-ROM DL, 461 (L) x 100 (W) x 297 (H) mm
4X BD-R DL, 2X BD-RE DL Weights (4) Battery life varies depending on product specifications, computer settings and applications or features launched.
Write: 24X CD-R, 16X CD-RW, 8X DVD±R, 6X DVD±RW 5.72 lbs. | 2.6 kg. (system unit only)
5X DVD-RAM, 4X DVD±R DL Approximately 10.1 lbs. | 4.57 kg. (box)
Digital Media Card Reader Pallet Quantity
Multi-in-1 Digital Media Card Reader 72 units per pallet
Limited Warranty
(6) Internet access required. First 60-days of live updates included, subscriptions required post 60-days.
Communications UPC
10/100/1000 Gigabit Ethernet LAN (RJ-45 port) 884483194636 (8) Additional fees and conditions may apply
802.11b/g/n Wi-Fi CERTIFIED™Part Number
LX.PTW02.039
Page 3 v1.0 - May 4, 2010Acer®Confidential
(3) 1 GB is 1 billion bytes. Actual formatted capacity is less and may vary depending on preloaded materials and
operating environment. Acer eRecovery Management utilizes up to 8 GB (10 GB with Microsoft® Works with
Office Home and Student 2007 Trial) of the stated hard disk capacity as dedicated backup space.
(2) Shared system memory may be allocated to support integrated graphics depending on system memory size and
other factors. Actual system memory available to the operating system will be reduced by the amount of shard
system memory utilized by the graphics solution and resources required by the operating environment.
(1) Overall system performance is based on several PC attributes. GHZ, processor clock speed, is one of the
attributes.
© 2010 Acer Inc. All rights reserved. Acer, the Acer logo, and Aspire are registered trademarks of Acer Inc. Other trademarks, registered trademarks, and/or service marks, indicated or
otherwise, are the property of their respective owners. Microsoft and Windows are registered trademarks of Microsoft Corporation.
One-year International Travelers Limited
Warranty (ITW)
(5)
Enhancer Technologies
Battery Type
Secure Digital™ (SD) Card, MultiMediaCard (MMC), Memory
Stick™ (MS), Memory Stick PRO™ (MS PRO), xD-Picture
Card™ (xD)
(5) For a free copy of the standard limited warranty end
‐
users should see a reseller where Acer products are sold
or write to Acer America Corporation, Warranty Department, P.O. Box 6137, Temple, TX 76503. TFT displays
commonly exhibit a small number of discolored dots, so‐called “nonconforming pixels.” This phenomenon is a
limitation of TFT LCD technology, not a product defect and, as such, is not covered by the limited warranty or by
the upgrade programs. For International travelers warranty Valid only in countries where Acer has an authorized
repair facility. For a list of those countries go to http://global.acer.com/support/itw.htm. or call 800
‐
816
‐
2237.
Services and response times may vary in countries outside the U.S. and Canada
(7) 60-day trial, option to purchase full-version of the Office software will be made after the 60-day trial. All files
created during the trial will remain on the PC system regardless of full version purchase.
Page 3
v1.0 - May 4, 2010
Acer
Confidential
