Acer MATE User manual

Air Monitor MATE

Fan Speed Timer
Fan Speed
Short Touch: Manual Speed 1 > Manual Speed 2 > Manual Speed 3 > Automatic Control
Long Touch: Stop
When switching to manual speed, the timer will be set to 30 minutes by default.
After 30 minutes, the controller will switch to automatic mode.
Timer
In manual mode, each press on the button corresponds to 1hr increment. Once the time
exceeds 6hr, the decide would be in always on mode, and the device would display 24hr.
Touch Button Description-I

Main Page
Switch Button
Setting Button
Sub Pages
Switch Button
Sub Page Switch Button
Press the button to display detailed information
related to the Main page.
Setting Button
In the settings page, press the button to
switch and configure options.
Main Page Switch Button
There are 5 main pages. Press this button to switch main page sequentially.
Default Main Page > Sensor Page > Ventilation Equipment Page > Settings > About
Touch Button Description-II

Phoneix
Connectors
Coin Battery
for clock
Stand Temperature &
Humidity Sensor
Phoneix Connectors
※NO1-NO3 can be used for controlling fan speed in order. Only one of NO1-NO3 can be
switched on at a time.
※NO4 can be used to turn on a relay switch for further controlling a dehumidifier,
compressor, or valve.
※AO: Analog Output
GND
A+B-A+B-1 2
GND
DCin
DCout
1 2 3 4 AO
Normal Open Slave Ain PowerMaster

Switch for
touch lock
RS485 120ohm
MODBUS ID: A0-AF
USB Type C
Power Connnector
Screw hole for
Wall Mount Plate
Dip switch
LORA Version
ON: Turn on LORA communication and turn off RS485 slave function.

Ambient
Light Sensor
Wi-Fi
Green LED
Wi-Fi
Red LED
Wi-Fi
Reset
Wi-Fi Status Red Green
Waiting for provisioning ON OFF
Connecting to access point OFF Slow flashing
Connecting to cloud server OFF Fast flashing
Connected to cloud server OFF ON
Communication Error to Sensor Slow flashing Slow flashing
Description of Wi-Fi LED Light
※Wi-Fi Reset: Long press reset button to switch Wi-Fi to provision waiting mode.

Set up cloud connection and connect to ventilation equipment
※Launch Acer Air Monitor Pro APP
※Click "+" to add Acer AMM Smart Environmental Monitor and Controller. Follow the steps
indicated on APP to complete the settings.
※To connect to a ventilation equipment, please click an AMM device then click "+" to select an
equipment. Follow the steps indicated on APP to complete the settings.
<Notice> Scan right QR Code to download the APP.
Air Monitor Pro
INDOOR
IAQ
Air Monitor Pro
INDOOR
IAQ
58 AMM012
Air Quality: Moderate
2021/03/09 16:34:11
Dry contact RS485
AUTO
1
AUTO
2
AUTO
1
IAQ
Filter in good condition The Filter needs to be replaced
OFF
ANALYSIS CONTROL SETTINGOVERVIEW
Ventilator/Purier
Schedule
Sun Mon Tue Wed Thu Fri Sat
Automatic Mode

ON
OFF
ANALYSIS CONTROL SETTINGOVERVIEW
Ventilator/Purier
Schedule
Sun Mon Tue Wed Thu Fri Sat
Automatic Mode
Apply
啟動設備
01:00
02:00
03:00
04:00
05:00
06:00
07:00
08:00
09:00
10:00
Sun Mon Tu e Wed Thu Fri Sat
Schedule setting
※Click a AMM device, click Control, then click "Ventilator/Purifier".
※Click "Schedule"
※On schedule setting page,
click on the table column corresponding to each hour to turn it on or off.
<Notice>
When the schedule control is enabled, AMM will switch to automatic control mode over time.
When the schedule is set to ON, the automatic control is started.
When the schedule is set to OFF, it turns to the off mode.
SETTINGCONTROL
Ventilator/Purier
Schedule
Sun Mon Tue Wed Thu Fri Sat
Automatic Mode
AOFF
ＭODE TIMER
Schedule
預約設備啟動時間
Automatic rule setting
AMM自動規則設定
SETTINGCONTROL

智慧空氣品質偵測器
INDOOR
Air Monitor Pro
58 智慧空氣品質偵測器
信號強度: -93dB
2021-03-09 16:34:11
溫度
28
濕度
65
揮發物質
0.23
PM10
7
照度
5
二氧化碳
3000
甲醛
0.01
PM2.5
15
尚未配對
請輸入認證號碼
此號碼會顯示在AMM面板
Air Monitor Pro
58 Air Monitor Pro
RSSI: -93dB
2021-03-09 16:34:11
Temp.
28
Himi.
65
TVOC
0.23
PM10
7
illum
5
CO2
830
HCHO
0.01
PM2.5
15
尚未配對
<Notice>
Please turn on Bluetooth on your smartphone.
The 4-digit number will disappear after 5 seconds automatically. Please complete the pairing
process in time.
Bluetooth Remote Control
※Launch APP
※Click manual icon then click "Scan Bluetooth air
quality broadcasts"
※Select the AMM that has strongest signal. The LCD display on
the corresponding AMM device will show a 4-digit number.
※Input the 4-digit number on APP to complete paring process,
and then you can perform remote control functions.
Air Monitor Pro
Device Center
App Settings
Map View
Account
Scan Bluetooth air quality broadcasts
About this app
Product Introduction
Knowledge Center

58 AMM012
Air Quality: Moderate
2021/03/09 16:34:11
Dry contact RS485
AUTO
1
AUTO
2
AUTO
1
IAQ
Filter in good condition The Filter needs to be replaced
<Notice>
Please contact business window for LORA relative functions.
LORA Conguration
※Please login the cloud account into LoRa Master device for setting the connection.
※Once the setting is completed, you can use the APP to access the AMM.
Air Monitor Pro
IAQ
Air Monitor Pro
成功連線
後方WiFi燈號為綠燈
裝置名稱
AMM010

FEDERAL COMMUNICATIONS COMMISSION INTERFERENCE STATEMENT
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio
communications.
However, there is no guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television reception, which can
be determined by turning the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from thatto which the receiver
is connected.
-Consult the dealer or an experienced radio/ TV technician for help.
CAUTION:
Any changes or modifications not expressly approved by the grantee of this device could
void the user's authority to operate the equipment.This device complies with Part 15 of the
FCC Rules. Operation is subject to the following two conditions: (1) this device may not
cause harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
RF exposure warning This equipment must be installed and operated in accordance with
provided instructions and the antenna (s) used for this transmitter must be installed to
provide a separation distance of at least 20 cm from all persons and must not be co-located
or operating in conjunction with any other antenna or transmitter. End-users and installers
must be provide with antenna installation instructions and transmitter operating conditions
for satisfying RF exposure compliance.

Category Item Specification
Power
USB Type C Power Input DC 5V 2A
DC-in Power Input DC 9-24V 2A
DC-Out Power Output DC 5V
Display TFT LCD 320x240 16bit color display
Touch Button 5 x Capacitive Touch Button
Air Quality Light
Full color breathing light
Green: Good；Yellow: Moderate；
Orange: Unhealthy for Sensitive Group
Red: Unhealthy；Purple: Very Unhealthy
RTC Backup Battery CR1220 3V Coin Battery
Human-Machine
Interface
CO2
Method: NDIR (Non-Dispersion Infrared)
Range: 0-10,000ppm
Resolution: 1ppm
Temperature
Method: Semiconductor
Range: 0-100°C
Resolution: 0.1°C
Relative Humidity
Particulate Matter
Method: Semiconductor
Range: 0-100%
Resolution: 0.1%
Method: Laser Scattering
Range: 0-1,000μg/m3
Sensor <Note 1>

Formaldehyde Sensor Method: Electrochemical Sensor
Range: 0-1.600ppm
Total Volatile Organic
Compound Sensor
Method: Semiconductor
Range: 0-10ppm
Resolution: 0.1°C
Ambient Light Sensor
Method: Dual Diode Semiconductor
Range: 0-10,000Lux
Resolution: 1Lux
Sensor <Note 1>
Wireless Network 2.4GHz, IEEE802.11 b, g, n
Low Power Bluetooth BLE 2.4GHz
Wired Communication MODBUS-RTU protocol over RS-485；
9600bps 8n1
LORA 920MHz Peer to Peer Communication
SD-Card Slot Micro SDCARD 32GB, FAT32 File System
RS-485 MODBUS-RTU protocol over RS-485 Master
9600bps 8n1
Analog 0-10V output control
Digital 4 port Normal Open Control Point
Communication
<Note 2>
Storage
Control
Category Item Specification
<Note 1> The sensor is equipped according to the product model, and the sensor needs
to be calibrated regularly.
<Note 2> The communication function is optional according to the product model.

Barb hanger (L) 1
1
1
4
2
1
Barb hanger (R)
Double box wall mount plate
Salad head screws
Gecko screw group
Hexagon socket screws
1
2
Lock the barb rack to the back cover with salad
head screws.
1
Lock the wall mount plate on the double box with
self-tapping screws.
※Self-tapping screws are placed in the gecko
screw group.
2
Align the barb hanger with the rectangular hole on
the wall mount. Past down fixed and lock with
hexagon socket screws.
3
3

<Notice>
※This product contains a coin / button cell battery. If the coin / button cell battery is swallowed,
it can cause severe internal burns in just 2 hours and can lead to death.
※Keep new and used batteries away from children.
※ If the battery compartment does not close securely, stop using the product and keep it away
from children.
※ If you think batteries might have been swallowed or placed inside any part of the body, seek
immediate medical attention.

© 2021 Acer Inc. All Rights Reserved.
