Product Launch:
Acer V203H
Sustainable, Solid Vision

V203H - Value Series
Sustainable, Solid Vision
The V203H is a solid 16:9 format display which brings to
the home a perfect balance between best value
performance and technical features. Displaying 6%
more viewable area then a standard 19” Widescreen
16:10 format cut for a broader view of your media which
is optimized by Windows Vista.
The smart High definition EcoDisplay renders a healthy
pixel per inch of 91.8% for comfortable viewing with no
strain plus consuming 50% less power! The V203H is a
brilliant display reproducing crisp data and media over a
cinematic format with the added benefits of a higher
resolution performance.

Product Overview
Left view Front view Right view
Side view Rear view I/O ports
Model Name: V203H
Color: Dark gray with black square base
Size: 51 cm (20”) 16:9
Native Resolution: 1600x900@60Hz
Response Time: 5 ms
Brightness: 250 nits (cd/m2)
Contrast Ratio: 50,000:1 (ACM)
Viewing Angle: 170° (H), 160° (V)
Input: Analog, Analog, optional DVI with HDCP support
In Addition: Optional Multimedia

Features Summary
•Acer EcoDisplay management
The Acer V203H is EcoDisplay-Ready,
complying with Acer's commitment to carry
out product design and materials
management distinctly meant to reduce
environmental impact. EcoDisplay-ready
LCD monitors have achieved
environmentally friendly design status in
the following ways:
o Capacity for product recycling
o Proper management of restricted
substances
o Power-saving design, featuring
two lamps
o Product thinness and minimalist
packaging design
•Power-saving design
Acer LCD monitors use two CCFL lamps
instead of four. The two-lamp design
results in a simplified connector and
inverter power board design, cutting power
consumption by 50 percent.
energy.
•High resolution over a wider viewing
area
The efficient 51 cm (20”) 16:9 widescreen
has a viewing area which can display 6%
more content then a 19” Widescreen and
with a better resolution then a standard 20”
widescreen with 16:10 format.
•Brilliant color with crisp results
The generous contrast ratio of 50,000:1
creates crisp images and detailed data
results.
•Acer eColor Management —
The acer Empowering Technology enables
users to fine-tune and personalize the
display settings by redefining the color
precision according to the work mode
whether data, media, cinema or images.
•Acer eDisplay Management
Acer eDisplay Management is a powerful
display tool enabling advanced color
calibration and display management for
previewing and adjusting all settings
enabling winning results!
•Widescreen enjoyment and
productivity
The spacious widescreen display optimizes
viewing pleasure.
o Widescreen multitasking at
work
o Dual widescreen displays with
widescreen notebooks
o Widescreen entertainment and
gaming

Specifications
Model V203HQ
Product name V203HQ
Display Type Flat screen / TFT
Dimensions (mm) 476.4x353.8x195
Net Weight (kg) 4.1
Colour Darkgrey
Panel Technology TN+Film
Size cm/ Inch 51 cm (20”) 16:9
Display Size (mm) 410x230mm
Pixel Pitch (mm) 0.3
Resolution 1600x900@60Hz
Frequency 30-80KHz/ 55-75Hz
PPI 92
Rsp time (ms) 5
Contrast 50'000:1
Brightness (cd/m2) 250
H/V° CR 10:1 170°/160°
Colors (M) 16.7
Panel Specifications
NTSC (%) 72
Input Signal Analog (optional DVI w/
HDCP)
Speaker Optional 2x1 W
VESA Wall Mounting 100x100
Kensington Support Yes
Tilt -5°~15°
Swivel degrees No
Hgt Adj (mm) No
Pivot degrees No
Off/Standby (W) 0.33
Sleep (W) 0.47
System Specifications
EnergyStar On (W) 18.9
Service & Support 3 Years bring in-Service
Certificates CE, TÜV GS, TCO03, ISO
13406-2
Pallet Qty / Size 90/115x108x219.2
Other
Container 20"/40" 950/2090
