LCD WORKSTATION LW910
10.4” TFT INDUSTRIAL 250NIT METAL HOUSING
SPECIFICATIONS
Chassis
4U height, 19" EIA Rack mounting
Construction
Heavy-duty steel
Front Panel
Plastic made front panel with window and key-lock
switch
LCD Panel
Screen size: 6.4” high brightness TFT LCD:
Resolution: 640 x 480
Brightness: 300 cd/m2
Colors: 18 bits
LCD MTBF: 50,000 hours
Backlight MTBF: 25,000 hours
Interface: DB-15 VGA
Main System
SBC: Single Board Computer with built-in VGA/LAN
ATX M/B: Standard ATX M/B
CPU:
Socket 370 Type, Pentium-III Processor
Socket 478 Type, P-4 Processor
Drive Bays
1 x 3.5" & 3 x 5.25" horizontal open drive bay
1 x 3.5" hidden driver bay
SystemFan
Two8cmballbearingcoolingfans
CardClamp
Designedwithanti-vibrationcardclamptokeeping system
stable
Backplane
Selection14 slotbackplane
(4-ISA, 6-PCI, 2-SBC, 1-ISA/PCI or 1-ISA, 11-PCI, 1-
SBC, 1-SBC/PCI)
PowerSupply
300W PS/2 size ATX P/S, optional for 12/24/48 DC P/S
Frontpanelinterface
Systempowerswitch
OSD(on screendisplay) controlbuttons
Color
White(PANTONE413C)
Dimensions (W x H x D)
431mmx176mm x480mm
17"x 8.7" x 18.9"
Weights
35lbs
Environmental
Operatingtemperature: 0o ~ 50oC
Relativehumidity:5~85%,non-condensing
Vibration: 5~17Hz,0.1"double amplitudedisplacement
17 ~ 640Hz, 1.5G acceleration peak to peak
Shock:10Gpeakaccelerationpeak to peak (11ms)
Shock:10Gpeakaccelerationpeak to peak (11ms)
FEATURES
4Urack mountdesignin depthof18.9”
6.4"300nit 640X480 TFT LCDpanel
Selectionof Pentium-III andP-4 Processor withSBC
3-5.25”and 1-3.5” horizontal opendriverbay,1-3.5” hidden driver
Selectionof14 slot back plane or7slot ATX M/B
ORDER INFORMATION
LCDWorkstation LW-910/X
6.4"TFTLCD 14-slot/ATXindustrialworkstation
Xsystemboard Code: B=SBC, ATX=ATXM/B

ACNODE.COM
[email protected]
