KDS 5178
17” 1280 x 1024 / 1152 X 900 LCD
SUN-keys keyboard touch pad
8 port KVM switch
» Specifications
» Features
Cables:
8 x 6' cable for VGA / Keyboard /Track ball
Optional for 10' or 15' USB KVM cable
Optional for 6' Daisy Chain cable
Drawer Design:
High load-rating slide rail with angle bracket
extension up to 31.1” depth, Optional Extension bracket to
36" depth
System Serurity:
2 x Thumb-lock screws on the front panel for system
serurity
Power Supply:
110/220VAC power supply, Optional for 48VDC power input
Color:
Black
Operation Temperature:
0ºC to 50ºC
Weight:
35 lb
Safty:
FCC, CE
Dimension:
19"(W) x 23.63"(D) x 1.75"(H)
» Ordering Guide
» Options
CD-6U: 6’ USB KVM cable
CD-10U: 10’ USB KVM cable
CD-15U: 15’ USB KVM cable
Material:
Heavy-duty steel
Keyboard and topuch pad (USB-type):
116 keys Cherry keyboard
Sun keys:
STOP, HELP, AGAIN PROPS, UNDO, FIND, OPEN COPY, CUT,
PASTE and FRONT
3-buttons touch pad
LCD Panel:
Size: 17"
Resolution: 1280 x 1024
Brightness (cd/m^): 300nit
Contrast Ratio: 500 : 1
Response time: Tr=5ms/ Tf=20ms
Pixel pitch: 0.264mm (H) x 0.264mm (W)
Frame Rate: 60Hz
Viewing Angle: 160° Horizontal and 160° Vertical
Backlighs: 4 CCFTs
Colors: 16.7M colors
MTBF: 30,000 hours
KVM Switch:
8 x D-sub 15-ping proprietory USB KVM switch ports
Connector type: proprietary DB-15 KVM connector
1 x local coneector port (2 x USB & 1 VGA port)
Bypassing the built-in LCD and keyboard/touchpad through
the rear local console port
1 x Daisy chain port
Connector type: proprietary DB-15 KVM connector
Cascades level: 8 levels, up to 128 servers
built-in microprocessor to emulation for each port boots up
processor
Input VGA resolution: 1,920 x 1,440
Auto Scan Mode: monitoring your server at interval 5 to 99s
Supprt hot-pluggable cable, OSD and built-in KVM switch
buttons
Multi-platform: Suns, PCs, IBMs, HPs, Compaq & DELL
KVM switch Connectors:
8 x D-Sub 15 pin KVM port (female)
1 x D-sub 15 pin for cascades port
1 x Local connector (1 x VGA, 2 x USB)
» 1U compact design, only 23.6" depth
» 17" 1280 x 1024 LCD monitor
» OSD (On Screen Display) function
» 116 keys SUN keyboard
» 3-buttons Touch pad
» 8 port KVM switch
» 110/220VAC power supply
KDS 5178:
1U, 17" 1280x1024 TFT LCD, 8 ports KVM switch 116-keys
SUN keyboard 3-buttons touch pad, Black color
