Acnodes APS911 Series User manual

APS911X
15” / 19” Panel Mount LCD
S t a i n l e s s S t e e l C h a s s i s
F u l ly I P 65 R a t ed E n c lo s u re
Industrial
Monitors
User Manual
All rights reserved. Product description and product specifications are subject to change without notice.
For lastest product information, please visit Acnodes’ website at www.acnodes.com
14628 Central Ave. Chino, CA91710 Tel: [phone] Fax: [phone]
© Copyright 2015 Acnodes Corp.

Warning!
Disclaimer
This information in this document is subject to change without notice. In no event shall Acnodes Corp. be
liable for damages of any kind, whether incidental or consequential, arising from either the use or misuse
of information in this document or in any related materials.
Electric Shock Hazard –Do not operate the machine with its back cover removed. There are
dangerous high voltages inside.
This equipment generates, uses and can radiate radio frequency energy and if not installed and
used in accordance with the instructions manual, it may cause interference to radio communications.
It has been tested and found to comply with the limits for a Class Acomputing device pursuant to
FCC Rules, which are designed to provide reasonable protection against such interference when
operated in a commercial environment. Operation of this equipment in a residential area is likely
to cause interference in which case the user at his own expense will be required to take whatever
measures may be required to correct the interference.

Table of Contents
Warning!…………………………………………………………………………….……..….2
Disclaimer………………………………………………………………….…………………2
Chapter 1 Getting Started
1.1 Specifications…………………………………………....……………...….5
1.2 Dimensions…………………………………...………………………….…6
1.3 Brief Description. ................................................................................ 8
1.4 Display Mode……………………………………………………………….9
Chapter 2 OSD
2.1 Front Panel Controls……………………………………………….……….10
2.2 OSD Controls…………………..………………………………………….11
2.3 Main Menu…..………..……………………………………………………..12
2.4 AD Board OSD Functions…….………………...………………….………14
Chapter 3 Installation
3.1 Windows 2000/XP Driver Installation…………………………………….15
3.2 Configuring PenMount Windows 2000/XP Driver………………………19
3.3 Uninstall PenMount Windows 2000/XP Driver………………………….29
Chapter 4 Software
4.1 Software Functions………………………………………………………..30
4.2 Software Function Descriptions……………………………………….…31
Appendix A: Board Description & Specifications………………….41
Figures
Figure 1.1: Dimensions of APS9115.….………………………………………..6
Figure 1.2: Dimensions of APS9119.………………………………………….7
Figure 1.3: Front View of the APS911X…..………….……………………….8

Figure 1.4: Rear View of the APS911X.…………….………………………….8
Figure A: VESA-mounting………………………….……………………….….40
Appendix
VESA-mounting…………………………………………………………..40

Chapter 1 Getting Started
1.1 Specifications
Model No.
Specs
APS9115
APS9119
Display Type
15”TFTLCD
19”TFTLCD
Max. Resolution
1024x768
1280x1024
Max. Color
16.7M
Luminance (cd/m²)
300
350
Viewing Angle (H/V)
150/140
170/160
Backlight Lifetime
50,000 Hours
On Screen Display
Control
On the rear side
External I/O Port
Default:
1 x VGA Input
1 x DC
Optional:
Touch I/O
Power Input
DC 11~32V
Touch Screen Type
Resistive Touch
Construction
Stainless Steel Enclosure
IP Rating
IP 65
Mounting
VESA75x75 Mount
VESA100x100 Mount
Dimensions (WxHxD)
399x324x53 mm
470x388.6x60 mm
Net Weight
6.8kgs
9.9kgs
Operating Temperature
0~50℃
Storage Temperature
-20~60℃
Storage Humidity
10~90% @40℃(non-condensing)
Certificate
CE / FCC Class A

1.2 Dimensions
Figure 1.1: Dimensions of APS9115

Figure 1.2: Dimensions of APS9119

1.3 Brief Description of the APS911X
The APS9115/9119 is a total IP65 Stainless Steel Enclosure LCD Display, which comes with a 15 inch
(luminance of 300 cd/m²) / 19 inch (luminance of 350 cd/m²) TFT LCD. APS9115 comes with viewing
angle of 150 (H) degrees and 140 (V) degrees, APS9119 comes with viewing angle of 170 (H)
degrees and 160 (V) degrees, and more outstanding features, thus giving you the best in monitoring
and control applications
The front panel of the display monitor is sealed with gasket for NEMA 4/IP 65 rating when it is
panel-mounted in a NEMA rated cabinet or enclosure. It can also be VESA 100-mounted. It is optional
to be equipped with a resistive touch screen.
Figure 1.3: Front View of APS9119 (Left)/ APS9115 (Right)
Figure 1.4: Rear View of APS911X

1.4 Display Mode
Display Mode
Hori. Sync (KHz)
Vert. Sync. (Hz)
VGA 640 x 480
31
60
38
72
38
75
SVGA 800 x 600
35
56
38
60
48
72
47
75
XGA 1024 x 768
48
60
56
70
60
75
SXGA
1152 x 864
68
75
1280 x 1024
64
60
80
75

Chapter 2
2.1 Front Panel OSD Functions
Auto Adjust Up/Left Down/Right Power
Menu/Entry PowerIndicator
Power switch: To turn ON or OFF the power
Shift the icon to the right side or shift it up
Shift the icon to the left side or shift it down
Menu: To enter OSD menu for related icon and item.
Auto Button: One-touch auto adjustment
1.) Getting into Burn-in Mode
Before setting into a burn-in mode, first disconnect the AC power cord. Then press (don‟t let them go)
the buttons until the AC power cord is connected and the “RGB” appears on the top left corner
of your screen. Now it can be put into the burn-in mode for changing colors.
2.) Getting Out of Burn-in Mode
Before getting out of the burn-in mode, please first disconnect the AC power cord. Then press the
button (If not workable, press the button and don‟t let them go) until the AC power cord is
connected. Please don‟t let your fingers go until the AC power cord is connected again and the
wording of “RGB”appears on the top left corner of your screen, and wait for 3 seconds. Under the
non-signal entry situation, if is seen, exit is thus successfully made.
Cable Not Connected

2.2 OSD Controls
To make any adjustment, select the following:
1. Press (Menu) to show the OSD menu or disable the OSD menu.
2. Select the icon that you wish to adjust with the ( /or +/-) key in the menu.
3. Press (Menu) and then choose the item with the ( /or +/-) key.
4. Press (Menu) and then adjust the quality with the ( /or +/-) key.
1.) If the “RGB” is still on the top left corner of the screen, press to enter “Miscellaneous”and
choose “Reset”, and then Yes, and press . When the screen goes black, disconnect power
and repeat the above steps.
2.) If the “RGB”is not found, disconnect the AC power cord first. Then press the buttons
(don‟t let them go) until the AC power cord is connected, and wait for 2 to 3 seconds. When
“RGB” appears, repeat the above steps.
3.) Functions of OSD Keys

2.3 Main Menu
In the Main menu, there are the following items:
•Color
•Image Setting
•Position
•OSD Menu
•Language
•Misc
•Exit
For Color, check out the following:
•Contrast
•Brightness
•Color Adjust
•Color Temp
•Back
For Image setting, check out the following:
•Clock
•Phase
•Gamma
•Sharpness
•Back

In the Position, there are the following:
•H. Position
•V. Position
•Back
In the OSD menu, there are:
•OSD H. Pos.
•OSD V. Pos.
•OSD Timer
•Back
In the Language menu, there are:
•English
•Frances
•Germany
•Spanish
•Traditional Chinese
•Simplified Chinese
•Japanese
In the Misc menu, there are:
•Signal Source
Select VGA: Analogue VGA Input
Select DVI: Digital DVI-D Input
Select AV: Composite Video Input
Select SV: S-Video Video Input
•Reset
•Back

Cable Not Connected
2.4 AD Board OSD Functions
2.) Getting into Burn-in Mode
Before setting into a burn-in mode, first disconnect the AC power cord. Then press (don‟t let them go)
the buttons until the AC power cord is connected and the “RGB” appears on the top left corner
of your screen. Now it can be put into the burn-in mode for changing colors.
2.) Getting Out of Burn-in Mode
Before getting out of the burn-in mode, please first disconnect the AC power cord. Then press the
button (If not workable, press the button and don‟t let them go) until the AC power cord is
connected. Please don‟t let your fingers go until the AC power cord is connected again and the
wording of “RGB”appears on the top left corner of your screen, and wait for 3 second. Under the
non-signal entry situation, if is seen, exit is thus successfully made.
When the Burn-in Mode is Unable to Eradicate…
4.) If the “RGB” is still on the top left corner of the screen, press to enter “Miscellaneous”and
choose “Reset”, and then Yes, and press . When the screen goes black, disconnect power and
repeat the above steps.
5.) If the “RGB”is not found, disconnect the AC power cord first. Then press the buttons
(don‟t let them go) until the AC power cord is connected, and wait for 2 to 3 seconds. When
“RGB” appears, repeat the above steps.
6.) Functions of OSD Keys
Auto Adjust Up/Left Down/Right Power
Menu/Entry PowerIndicator

Chapter 3
3.1 Windows 2000/XP Driver Installation for 9036 Control Board
Before installing the Windows 2000/XP driver software, you must have the Windows
2000/XP system installed and running on your computer. You must also have the 9036
PenMount Serial Interface controller board installed. Contents of the PenMount
Windows 2000/XP driver folder are listed below:
DMC9000.inf
DMC9000.sys
DMC9000.cat
SETUP.EXE
If you have an older version of the PenMount Windows 2000/XP driver installed in your
system, please remove it first. Follow the steps below to install the PenMount Windows
2000/XP driver.
1. When the system first detects the controller board, a screen appears that shows
“Unknown Device”. Do not use this hardware wizard. Press Cancel.

2. Insert the PenMount Driver CD-ROM. Go to the Windows 2000-XP Driver folder.
Click setup.exe.
3. The screen displays the installation wizard for the PenMount software. Click “Next”.

4. A License Agreement appears. Click “I accept…” and “Next”.
5. The “Ready to Install the Program”screen appears. Select “Install”.

6. The next screen is “Hardware Installation”. Select “Continue Anyway”.
7. The “InstallShield Wizard Completed”appears. Click “Finish”.

3.2 Configuring the PenMount Windows 2000/XP Driver
Upon rebooting, the computer automatically finds the new 9036 controller board. The
touch screen is connected but not calibrated. Follow the procedures below to carry out
calibration.
1. After installation, click the PenMount Monitor icon “PM” in the menu bar.
2. When the PenMount Control Panel appears, click “Calibrate”.
PenMount Control Panel
The functions of the PenMount Control Panel are Calibrate, Draw, Multiple Monitors,
Option, and About, which are explained in the following sections.
Calibrate
This function offers two ways to calibrate your touch screen. “Standard Calibration”
adjusts most touch screens. “Advanced Calibration” adjusts aging touch screens.
Standard Calibration Click this button and arrows appear pointing to red
squares. Use your finger or stylus to touch the red
squares in sequence. After the fifth red point
calibration is complete. To skip, press ‘ESC’.
Advanced Calibration Advanced Calibration uses 4, 9, 16 or 25 points to
effectively calibrate touch panel linearity of aged
touch screens. Click this button and touch the red
squares in sequence with a stylus. To skip, press
‘ESC’.

NOTE: The older the touch screen is, the more Advanced Mode calibration points you need
for an accurate calibration. Use a stylus during Advanced Calibration for greater
accuracy.
