Acnodes RM 6193 User manual

RM 6193
8U 19” Rack Mount High brightness
LCD Monitor
User’s Manual
Rev 1.0

RM 6193 User manual
Acnodes Corporation, www.acnodes.com, [e-mail] 2
Packing List
The complete RM 6193 package consist of:
Rack mount 19” TFT LCD display x 1
6' VGA cable (male to male) x 1
Auto switch power adapter x 1
User manual x 1
AC Power cord x 1
Check to make sure that the unit was not damaged in shipping. If you encounter a problem, contact
your dealer.
Please read this manual thoroughly, and follow the installation and operation procedures carefully to
prevent any damage to the product, and/or any of the devices that connect to it.

RM 6193 User manual
Acnodes Corporation, www.acnodes.com, [e-mail] 3
Safety Instructions
1. Please read these safety instructions carefully.
2. Please keep this User’s Manual for later reference.
3. Please disconnect this equipment from AC outlet before cleaning. Don’t use liquid or sprayed
detergent for cleaning. Use moisture sheet or clothe for cleaning.
4. For pluggable equipment, the socked-outlet shall be installed near the equipment and shall be
easily accessible.
5. Please keep this equipment from humidity.
6. Lay this equipment on a reliable surface when install. A drop or fall could cause injury.
7. Do not leave this equipment in an environment unconditioned, storage temperature above 600C,
it may damage the equipment.
8. The opening on the enclosure is for air convection hence the equipment from overheating. DO
NOT COVER THE OPENING.
9. Make sure the voltage of the power source connect the equipment to the power outlet.
10. Please keep the power cord such a way that people can not step on it. Do not place anything over
power cord. The power cord must rate for the voltage and current marked on the product’s electrical
ratings label. The voltage and current rating of the cord should be greater than the voltage and the
current rating marked on the product.
11. All cautions and warning on the equipment should be noted.
12. If the equipment is not in use for long time, disconnect the equipment from mains to avoid being
damaged by transient over-voltage.
13. Never pour any liquid into ventilation openings; this could cause fire or electrical shock.
14. Never open the equipment. For safety reason, qualified service personnel should only open the
equipment.
15. If one of the following situations arises, get the equipment checked by service personnel.
The Power Cord or plug is damaged.
Liquid has penetrated into the equipment.
The equipment has been exposed to moisture.
The equipment has not worked well or you can not get it work according to User’s Manual.
The equipment has dropped and damaged.
If the equipment has obvious signs or breakage.

RM 6193 User manual
Acnodes Corporation, www.acnodes.com, [e-mail] 4
Index of Contents
Packing List ...............................................................................................................2
Safety Instructions .....................................................................................................3
Index of Contents ......................................................................................................4
1. General Information ............................................................................................5
1.1 Overview ..................................................................................................5
1.2 Product Specification ...............................................................................6
2. Rack Mount Installation.......................................................................................7
3. OSD Menu ..........................................................................................................8
3.1 OSD Menu Membrane Switch ................................................................8
3.2 On Screen Display Menu .........................................................................9
4. Connecttion Diagram ........................................................................................11
4.1 Video Connection Diagram ....................................................................11
4.2 Touch Screen Connection Diagram.......................................................12
5. Touch Screen Specification ..............................................................................13
6. DC Input power Supply (option)........................................................................14
7. Trouble shooting .............................................................................................15

RM 6193 User manual
Acnodes Corporation, www.acnodes.com, [e-mail] 5
1. General Information
1.1 Overview
The RM6193 is a 8U rack mount LCD monitor with 19” 800-nit 1280 x 1024 TFT LCD
monitor and rugged metal black color front bezel. This monitor comes with a standard
15-pin VGA video input and front access OSD membrane switch. Optional Video-input
for S-video / BNC / RCA connector and USB or PS/2 type resistive-type touch. RM
6193 comes with an external 110/220VAC power adapter, 24/48 VDC power input is
available for customer’s application.
1. 19” 1280 x 1204 high brightness TFT LCD monitor
2. Membrane OSD Menu switch
3. External 110/220VAC power adapter with bracket

RM 6193 User manual
Acnodes Corporation, www.acnodes.com, [e-mail] 6
1.2 Product Specification
Model name
RM 6193
Dimension 480 x 76 x 354.8mm/18.9 x 3" x 14inches
Net Weight 8 Kg / 18 lbs
Display Size 19 inches
Panel Type Active Matrix TFT LCD
Resolution
Capabilities
Maximum Resolution up to 1280 x 11024
Viewing Angle
(CR>10)
Right-Left view 160°(Typ)
Up-Down View 160°(Typ)
Contrast Ratio 700:1
Brightness White 800 cd/m² (Center 1 point Typ)
Tr Response
Time (ms)
1.3 ms
Supported Colors 16.7M Colors (6-bit with FRC)
Display Area
(mm)
376 x 301
VGA Signal Input Analog RGB, 0.7Vp-p
Sync. Type Separate H/V, Composite, SOG
Resolution 640 x 350, 70 Hz
720 x 400, 70 Hz
640 x 480, 60/ 72/ 75 Hz
800 x 600, 60/ 70/ 72/ 75 Hz
1024 x 768, 60/ 70/ 72/ 75 Hz
1152 x 864, 60/ 70/ 75 Hz
1280 x 1024, 60/ 70/ 75 Hz
Cables 1 x 6’ D-sub VGA male to male Cable
Plug & Play DDC EDID 1.3
Power Source Auto-sensing 100 to 240VAC, 50 / 60Hz
Power
Consumption
Max. 40 Watt, Standby 5 Watt
Temperature
Operate 0 ~ 50°C / 32 ~ 122°F
Storage -20 ~ 60°C / -4 ~ 140°F
Humidity 10% ~ 90% RH
Shock
Vibration
10G acceleration (11ms duration)
5~500Hz 1G RMS random vibration
Chassis
Construction
Heavy duty steel materials
Certification CE / FCC, ROHs Compliance

RM 6193 User manual
Acnodes Corporation, www.acnodes.com, [e-mail] 7
2. Rack mount Installation
1. Find the property position and size to screw rack mount front bezel onto the
server rack mount first.
2. Lift & push the rack mount monitor into the rack cabinet, and screw between
bracket and rack mount monitor with screws.

RM 6193 User manual
Acnodes Corporation, www.acnodes.com, [e-mail] 8
3. OSD Menu
3.1 OSD Menu Membrane Switch

RM 6193 User manual
Acnodes Corporation, www.acnodes.com, [e-mail] 9
3.2 On screen Display menu
BRIGHTNESS / CONTRAST
Brightness: Adjust background black level of the screen image.
Contrast: Adjust the difference between the image background (black level)
and the foreground (white level).
AUTO ADJUST
Auto Adjust: Fine tunes the video signal to eliminate waviness and distortion. A
"Adjusting" message is displayed during the process.
Auto Tune: Optimize phase, clock, position and size. An "Adjusting" message is
displayed during the process.
PHASE/CLOCK
Phase / Clock: To enter into the phase & clock sub menu
H/V POSITION
H/V Position: Align the screen image left or right and up or down.
MISC
Information: Display the current resolution, refresh rate and frequency
information on the screen.
OSD Timer
Set the time duration in seconds that the OSD is visible after the last button is
pressed. The factory default is 10 seconds.

RM 6193 User manual
Acnodes Corporation, www.acnodes.com, [e-mail] 10
Color
Select the screen color - 5500K, 6500K & 9500K. The factory default is 9500K.
Language
Select the language in which the OSD menu is displayed -
English, Chinese (中文), Japanese (日本語), German, French, Spanish, Italian
RESET
Restore the settings to factory defaults.

RM 6193 User manual
Acnodes Corporation, www.acnodes.com, [e-mail] 11
4. Connecton Diagram
The RM6193 comes with a standard 15-pin VGA video input and external
110/220VAC power adapter.
Optional Video-input for S-video / BNC / RCA connector and USB or PS/2 type
resistive-type touch.
4.1 Video-input Connection Diagram
15-pin D-sub VGA
15-pin D-sub VGA and DVI-D
15-pin D-sub VGA, S-video and RCA
15-pin D-sub VGA, S-video and BNC

RM 6193 User manual
Acnodes Corporation, www.acnodes.com, [e-mail] 12
4.2 Touch Screen Connection Diagram
15-pin D-sub VGA and USB-type touch screen
15-pin D-sub VGA and Serial-type touch screen

RM 6193 User manual
Acnodes Corporation, www.acnodes.com, [e-mail] 13
5. Touch Screen Specification
Touch screen
type
Resistive-type
Interface USB or PS/2
Optical
transmittance
82%±5%
Surface hardness ≥3H (JIS K5400)
Operating system Windows 98 / 2000 / ME / XP / NT / CE,
DOS, Linux
Touch screen
type
Capacitive-type
Interface USB or PS/2
Optical
transmittance
88%
Surface hardness Mohs’ hardness rating: 6
Operating system Windows 98 / 2000 / ME / XP / NT / CE,
DOS, Linux
Remarks
■USB touch screen package includes an extra 6ft USB cable, quick reference guideline and
CD disc
■Serial touch screen package includes an extra 6ft serial cable, quick reference guideline and
CD disc
■For detailed information, please refer to the attached CD disc
■As the touch screen unit is not made of toughened glass, please handle it carefully.

RM 6193 User manual
Acnodes Corporation, www.acnodes.com, [e-mail] 14
6. DC Input Power Supply (Option)

RM 6193 User manual
Acnodes Corporation, www.acnodes.com, [e-mail] 15
7. Trouble shooting
1. How do I adjust the resolution?
To change monitor resolution, click Start -> Control Panel -> Display. Select Setting
tab to adjust the monitor resolution in Desktop Area. The available resolutions, "640
x 480", "800 x 600", "1024 x 768", "1152 x 864", "1280 x 1024", are deter- mined by
the display card in your computer.
2. Is interference signal appeared on LCD normal when shutting down the
computer ?
In rare cases, interference may appear on the monitor. This may be caused by
signal rate of VGA card and is considered normal. The image quality can be
improved by adjusting the phase or pixel rate automatically or manually.
3. The membrane button power light is not ON
Press the power On / Off on LCD membrane button to check if the monitor is in the
ON mode. Check the power cord is properly connected to the LCD keyboard
drawer and power outlet.
4. Screen image is not centered or sized properly
Press the button for two seconds to automatically adjust the image. Adjust the
H-position and V-position settings via On-screen menu.
