RMC 7130
1U Rackmount System
Installing the System into a Rack
(Rackhardwareoptional)
Thissectionprovidesinformationon installingtheAcnodesRMC7130intoarack unit. If the system has
alreadybeen mounted into arack, you can skipahead to Sections 2-5and 2-6.
Basic Installation Procedure
TheRMC7130server comes with two rackmountingbrackets, which are located oneachside at the
frontofthechassis. Tomountthesystemintoa rack, simply screw these bracketsdirectlytothefrontof
therack(twoscrews for each bracket).
Installing with Rackmount Kit
Thissectionisonlyfor customers that have the optional rackmountkit(CSE-PT8).Each of these as-
sembliesconsistof two sections: an inner railthatsecures to the chassis andanouter rail that secures
directlytothe rack itself (seeFigure 2-1).
Thisisaguideline for installingtheunitinto a rack with the optionalrackkit.Youshouldalsorefer to the
installationinstructionsthatcamewiththerackunityouareusing.Beawarethattherearea variety of
rackunitsonthemarket,whichmaymeantheassemblyprocedurewill differslightly.

661 Brea Canyon Rd., Suite 3
Walnut, CA 91789
tel: [phone], fax: [phone]
© Copyright 2009 Acnodes, Inc.
All rights reserved. Product description and product specifications
are subject to change without notice. For latest product information,
please visit Acnodes’ web site at www.acnodes.com.
RMC 7130
1U Rackmount System
Installing the Chassis Rails
Thetworail sections must be detachedfromeach other prior to installation:depressthe locking tab on
theinnerrail to release it fromitslocked position then pull thetwo rails completely apart. Dothisfor both
theleft and right side rack rail assemblies.
Positionthefixed chassis rail sections youjustremoved along the sideofthe chassis making sure the
threescrewholeslineup.Note that these two rails are left/rightspecific.Screwtherailsecurely to the
side of the chassis (see Figure
2-2).Repeatthis procedure for the otherrailon the other side of thechassis.You willalsoneed to attach
therailbracketswheninstalling into a telco rack.
Locking Tabs: Both chassis rails havea locking tab,whichserves two functions. The first isto lock the
serverintoplacewheninstalledandpushedfullyintotherack,whichisitsnormal position. Secondly,
thesetabs also lock the server in place when fully extended from the rack. This prevents the server from
comingcompletely out of the rack when you pull it out for servicing.
Installing the Rack Rails
Determinewhereyou want to place theserverin the rack (see RackandServer Precautions in Section 2-
3). Position the fixed rack rail/sliding rail guide assemblies at the desired location in the rack, keeping the
slidingrailguide facing the insideofthe rack. Screw the assemblysecurely to the rack usingthe brackets
provided.Attachtheotherassembly to the other side oftherack,making sure that both are attheexact
sameheightandwith the rail guides facinginward.

661 Brea Canyon Rd., Suite 3
Walnut, CA 91789
tel: [phone], fax: [phone]
© Copyright 2005 Acnodes, Inc.
All rights reserved. Product description and product specifications
are subject to change without notice. For latest product information,
please visit Acnodes’ web site at www.acnodes.com.
RMC 7130
1U Rackmount System
Installing the Server into the Rack
You should now have rails attachedto boththechassisandtherackunit.The next step is to installthe
serverintothe rack. Do this byliningup the rear ofthechassis rails with the frontofthe rack rails. Slidethe
chassisrailsinto the rack rails, keepingthepressure even on bothsides(you may have to depressthe
lockingtabswhen inserting). See Figure 2-3.
Whentheserverhasbeenpushedcompletelyintotherack,youshouldhearthelockingtabs"click".

661 Brea Canyon Rd., Suite 3
Walnut, CA 91789
tel: [phone], fax: [phone]
© Copyright 2009 Acnodes, Inc.
All rights reserved. Product description and product specifications
are subject to change without notice. For latest product information,
please visit Acnodes’ web site at www.acnodes.com.
RMC 7130
1U Rackmount System
Installing the Server into a Telco Rack
Toinstall the server into aTelcotype rack, use two L-shapedbracketsoneitherside of the chassis (four
total).First,determinehowfartheserverwillextendoutthe front of the rack. Larger chassis should be
positionedtobalancetheweight between front and back. If abezelisincludedon your server,removeit.
Thenattachthetwo front brackets to each side ofthechassis,then the two rear brackets positionedwith
justenoughspace to accommodate the widthofthe rack. Finish by slidingthechassis into the rack and
tighteningthebrackets to the rack.SeeFigure 2-5.

661 Brea Canyon Rd., Suite 3
Walnut, CA 91789
tel: [phone], fax: [phone]
© Copyright 2005 Acnodes, Inc.
All rights reserved. Product description and product specifications
are subject to change without notice. For latest product information,
please visit Acnodes’ web site at www.acnodes.com.
RMC 7130
1U Rackmount System

661 Brea Canyon Rd., Suite 3
Walnut, CA 91789
tel: [phone], fax: [phone]
© Copyright 2009 Acnodes, Inc.
All rights reserved. Product description and product specifications
are subject to change without notice. For latest product information,
please visit Acnodes’ web site at www.acnodes.com.
RMC 7130
1U Rackmount System
Checking the Motherboard Setup
AfteryouinstalltheRMC7130 in the rack, you will needtoopentheunit to make sure the motherboard is
properlyinstalled and all the connections have been made.
AccessingtheInside of the System (Figure 2-7)
1. Graspthetwohandles on either side and pull theunitstraightout until it locks (you willheara"click").
2. Removethe screws from the lipsoneitherside of the chassistop cover, located atthe front of the
chassis.

661 Brea Canyon Rd., Suite 3
Walnut, CA 91789
tel: [phone], fax: [phone]
© Copyright 2005 Acnodes, Inc.
All rights reserved. Product description and product specifications
are subject to change without notice. For latest product information,
please visit Acnodes’ web site at www.acnodes.com.
RMC 7130
1U Rackmount System
3. Next,depressthetwo buttons on the top ofthechassisto release the top cover whilepushingthecover
awayfrom you untilitstops.You can thenlift
thetopcover from the chassis togainfull access to the insideof the server.
Checking the Components
1. You may have one processor alreadyinstalledinto the system board.Theprocessorshould have its
ownheatsinkattached.SeeChapter5 for instruc- tions on processor installation.
2. Your system mayhavecomewithsystemmemoryalreadyinstalled.MakesureallDIMMsarefully
seatedin their slots. For detailsonadding system memory,referto Chapter 5.
3. Ifdesired,you can install anadd-on card to thesystem.See Chapter 5 fordetails on installing aPCI
add-oncard.
4. Makesure all powerand data cables areproperly connected andnot block- ing the airflow. See Chap-
ter5 for detailsoncable connections.Also, check the air sealsfor damage. The airseals are locatedunder
theblowerfanandbeneath the frame cross section thatseparatesthedrivebay area from the
motherboardareaofthe chassis.
