Acnodes RMC 7189 User manual

661 Brea Canyon Rd., Suite 3
Walnut, CA 91789
tel: [phone], fax: [phone]
© Copyright 2009 Acnodes, Inc.
All rights reserved. Product description and product specifications
are subject to change without notice. For latest product information,
please visit Acnodes’ web site at www.acnodes.com.
RMC 7189
1U Rackmount System
User Manual
RMC7189:1URackmountComputer comeswith
IntelXeonX5600/E5600/L5600 seriesprocessor
IntelXeonX5500/E5500/L5500seriesprocessor

661 Brea Canyon Rd., Suite 3
Walnut, CA 91789
tel: [phone], fax: [phone]
© Copyright 2005 Acnodes, Inc.
All rights reserved. Product description and product specifications
are subject to change without notice. For latest product information,
please visit Acnodes’ web site at www.acnodes.com.
RMC 7189
1U Rackmount System
The information in this User's Manual has been carefully reviewed and is believed to be accurate. The vendor assumes
no responsibility for any inaccuracies that may be contained in this document, makes no commitment to update or to
keep current the information in this manual, or to notify any person or organization of the updates. Please Note:
For the most up-to-date version of this manual, please see our web site at www.supermicro.com.
Acnodes Corporation, reserves the right to make changes to the product described in this manual at any time
and without notice. This product, including software, if any, and documentation may not, in whole or in part, be
copied, photocopied, reproduced, translated or reduced to any medium or machine without prior written consent.
IN NO EVENTWILLSUPERMICRO BE LIABLE FOR DIRECT, INDIRECT, SPECIAL, INCIDENTAL, SPECULATIVE
OR CONSEQUENTIAL DAMAGESARISING FROMTHE USE OR INABILITY TO USE THIS PRODUCT OR DOCU-
MENTATION, EVEN IFADVISED OF THE POSSIBILITY OF SUCH DAMAGES. IN PARTICULAR, ACNODES
SHALLNOT HAVE LIABILITY FORANYHARDWARE, SOFTWARE, OR DATASTORED OR USED WITHTHE
PRODUCT, INCLUDINGTHE COSTS OF REPAIRING, REPLACING, INTEGRATING, INSTALLING OR RECOVER-
ING SUCH HARDWARE, SOFTWARE, OR DATA.
Any disputes arising between manufacturer and customer shall be governed by the laws of Santa Clara County in the
State of California, USA. The State of California, County of Santa Clara shall be the exclusive venue for the resolu-
tion of any such disputes. Acnodes 's total liability for all claims will not exceed the price paid for the hardware
product.
FCC Statement: This equipment has been tested and found to comply with the limits for a ClassA digital device
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses,
and can radiate radio frequency energy and, if not installed and used in accordance with the manufacturer's instruc-
tion manual, may cause harmful interference with radio communications. Operation of this equipment in a residential
area is likely to cause harmful interference, in which case you will be required to correct the interference at your own
expense.
California Best Management Practices Regulations for Perchlorate Materials: This Perchlorate warning applies
only to products containing CR (Manganese Dioxide) Lithium coin cells. "Perchlorate Material-special handling may
apply. See www.dtsc.ca.gov/hazardouswaste/perchlorate"
WARNING: Handling of lead solder materials used in this product may expose you to lead,
a chemical known to the State of California to cause birth defects and other reproductive
harm.
Manual Revision 1.0
Release Date:April 26, 2010
Unless you request and receive written permission fromAcnodes Corporation., you may not copy any part of this
document.
Information in this document is subject to change without notice. Other products and companies referred to herein
are trademarks or registered trademarks of their respective companies or mark holders.
Copyright © 2009 byAcnodes Corporation.All rights reserved.
Printed in the United States ofAmerica

661 Brea Canyon Rd., Suite 3
Walnut, CA 91789
tel: [phone], fax: [phone]
© Copyright 2009 Acnodes, Inc.
All rights reserved. Product description and product specifications
are subject to change without notice. For latest product information,
please visit Acnodes’ web site at www.acnodes.com.
RMC 7189
1U Rackmount System
Preface
About This Manual
This manual is written for professional system integrators and PC technicians. It provides information
for the installation and use of theAcnodes RMC7189. Installation and maintainance should be per-
formed by experienced technicians only.
Manual Organization
Chapter 1: Introduction
The first chapter provides a checklist of the main components included with the server system and
describes the main features of the embedded board and the RMC7189 chassis.
Chapter 2: Server Installation
This chapter describes the steps necessary to install theAcnodes RMC7189 into a rack and check
out the server configuration prior to powering up the system. If your server was ordered without the
processor and memory components, this chapter will refer you to the appropriate sections of the
manual for their installation.
Chapter 3: System Interface
Refer to this chapter for details on the system interface, which includes the functions and information
provided by the control panel on the chassis as well as other LEDs located throughout the system.
Chapter 4: System Safety
You should thoroughly familiarize yourself with this chapter for a general overview of safety precautions
that should be followed when installing and servicing theAcnodes RMC7189.

661 Brea Canyon Rd., Suite 3
Walnut, CA 91789
tel: [phone], fax: [phone]
© Copyright 2005 Acnodes, Inc.
All rights reserved. Product description and product specifications
are subject to change without notice. For latest product information,
please visit Acnodes’ web site at www.acnodes.com.
RMC 7189
1U Rackmount System
Chapter 5: Advanced Motherboard Setup
Chapter 5 provides detailed information on the embedded board, including the locations and
functions of connectors, headers and jumpers. Refer to this chapter when adding or removing
processors or main memory and when reconfiguring the motherboard.
Chapter 6: Advanced Chassis Setup
Refer to Chapter 6 for detailed information on the RMC7189 1U rackmount server chassis.You
should follow the procedures given in this chapter when in- stalling, removing or reconfiguring
drives and when replacing system power supply units and cooling fans.
Chapter 7: BIOS
The BIOS chapter includes an introduction to BIOS and provides detailed informa- tion on run-
ning the CMOS Setup Utility.
Appendix A: POST Error Beep Codes
Appendix B: Installing the Windows OS
Appendix C: System Specifications

661 Brea Canyon Rd., Suite 3
Walnut, CA 91789
tel: [phone], fax: [phone]
© Copyright 2009 Acnodes, Inc.
All rights reserved. Product description and product specifications
are subject to change without notice. For latest product information,
please visit Acnodes’ web site at www.acnodes.com.
RMC 7189
1U Rackmount System
Table of Contents
CHAPTER 1 INTRODUCTION
1-1 Overview..........................................................................................................1
1-2 ServerboardFeatures.....................................................................................2
Processor........................................................................................................2
Memory.............................................................................................................2
UIO.....................................................................................................................2
SATA..................................................................................................................2
PCIExpansionSlots....................................................................................... 2
OnboardControllers/Ports...............................................................................2
GraphicsController............................................................................................2
OtherFeatures...................................................................................................2
1-3 ServerChassis Features ................................................................................ 4
SystemPower................................................................................................. 4
PCIExpansionSlots........................................................................................4
ControlPanel................................................................................................... 4
I/OBackplane....................................................................................................4
CoolingSystem...............................................................................................4
CHAPTER 2 INSTALLATION
2-1 Overview............................................................................................................5
2-2 UnpackingtheSystem .................................................................................... 5
2-3 Preparingfor Setup ......................................................................................... 5
ChoosingaSetupLocation.............................................................................5
RackPrecautions..............................................................................................5
ServerPrecautions............................................................................................5
RackMountingConsiderations.......................................................................7
AmbientOperatingTemperature.....................................................................7

661 Brea Canyon Rd., Suite 3
Walnut, CA 91789
tel: [phone], fax: [phone]
© Copyright 2005 Acnodes, Inc.
All rights reserved. Product description and product specifications
are subject to change without notice. For latest product information,
please visit Acnodes’ web site at www.acnodes.com.
RMC 7189
1U Rackmount System
ReducedAirflow...............................................................................................7
MechanicalLoading.........................................................................................7
CircuitOverloading............................................................................................7
ReliableGround.................................................................................................7
2-4 Installingthe System in to aRack......................................................................8
IdentifyingtheSectionsoftheRackRails......................................................12
InnerRails........................................................................................................ 12
OuterRails....................................................................................................... 12
Installingthe Server into aTelcoRack...........................................................12
2-5 Checking the Serverboard Setup ...................................................................12
2-6 Checking the Drive Bay Setup........................................................................ 14
CHAPTER 3 System Interface
3-1 Overview..........................................................................................................16
3-2 ControlPanelButtons ..................................................................................... 16
Reset...............................................................................................................16
Power..............................................................................................................16
UID.....................................................................................................................16
3-3 ControlPanel LEDs ........................................................................................ 17
UniversalInformationLED...............................................................................17
NIC2.................................................................................................................17
NIC1.................................................................................................................17
HDD..................................................................................................................17
Power...............................................................................................................18
3-4 HardDrive Carrier LEDs..................................................................................19
CHAPTER 4 SYSTEM SAFETY
4-1 ElectricalSafety Precautions .......................................................................... 19
4-2 GeneralSafety Precautions ............................................................................ 20

661 Brea Canyon Rd., Suite 3
Walnut, CA 91789
tel: [phone], fax: [phone]
© Copyright 2009 Acnodes, Inc.
All rights reserved. Product description and product specifications
are subject to change without notice. For latest product information,
please visit Acnodes’ web site at www.acnodes.com.
RMC 7189
1U Rackmount System
4-3 ESDPrecautions............................................................................................. 21
4-4 OperatingPrecautions .................................................................................... 22
CHAPTER 5 ADVANCED MOTHERBOARD SETUP
5-1 Handlingthe Serverboard ................................................................................ 23
Precautions......................................................................................................23
Unpacking...........................................................................................................23
5-2 ProcessorandHeatsink Installation.................................................................23
InstallingLGA1366Processors.........................................................................23
InstallingtheHeatsink.........................................................................................24
RemovingtheHeatsink.......................................................................................24
5-3 ConnectingCables.............................................................................................24
ConnectingDataCables....................................................................................24
ConnectingPowerCables.................................................................................25
ConnectingtheControlPanel .......................................................................... 25
5-4 I/OPorts............................................................................................................. 26
5-5 InstallingMemory................................................................................................27
5-6 AddingPCI Cards ............................................................................................. 30
5-7 ServerboardDetails ......................................................................................... 31
ServerboardQuickReference...........................................................................34
5-8 ConnectorDefinitions ....................................................................................... 35
5-9 JumperSettings..................................................................................................35
5-10 OnboardIndicators..............................................................................................36
5-11 SATAPort Connections......................................................................................37
5-12 InstallingSoftware................................................................................................38
DoctorIII................................................................................................................39

661 Brea Canyon Rd., Suite 3
Walnut, CA 91789
tel: [phone], fax: [phone]
© Copyright 2005 Acnodes, Inc.
All rights reserved. Product description and product specifications
are subject to change without notice. For latest product information,
please visit Acnodes’ web site at www.acnodes.com.
RMC 7189
1U Rackmount System
CHAPTER 6 ADVANCED CHASSIS SETUP
6-1 Static-Sensitive Devices.....................................................................................50
Precautions.........................................................................................................50
6-2 ControlPanel...................................................................................................... 51
6-3 SystemCooling....................................................................................................52
SystemFanFailure...............................................................................................52
6-4 DriveBay Installation/Removal ........................................................................... 53
AccessingtheDriveBays.....................................................................................53
HardDriveInstallation...........................................................................................55
DVDDriveInstallation...........................................................................................55
6-5 PowerSupply....................................................................................................... 56
RMC7185...............................................................................................................56
CHAPTER 7 BIOS
7-1 Introduction........................................................................................................56
StartingBIOSSetup Utility................................................................................56
HowTo Change the Configuration Data.........................................................56
Startthe Setup Utility.........................................................................................57
7-2 MainSetup........................................................................................................ 57
7-3 AdvancedSetup Configurations...................................................................... 59
7-4 SecuritySettings.............................................................................................. 78
7-5 BootConfiguration............................................................................................79
7-6 ExitOptions......................................................................................................80
Appendix A POST Error Beep Codes
Appendix B Installing the Windows
Appendix C System Specifications

661 Brea Canyon Rd., Suite 3
Walnut, CA 91789
tel: [phone], fax: [phone]
© Copyright 2009 Acnodes, Inc.
All rights reserved. Product description and product specifications
are subject to change without notice. For latest product information,
please visit Acnodes’ web site at www.acnodes.com.
RMC 7189
1U Rackmount System
CHAPTER 1 INTRODUCTION
1.1 Overview
TheAcnodes RMC7189 is a high-end single processor, 1U rack- mount server. The RMC7189 is
comprised of two main subsystems: the RMC7189 chassis and the embedded board. Please refer to
our web site for informa- tion on operating systems that have been certified for use with the RMC7189.
In addition to the mainboard and chassis, various hardware components may have been included with
the RMC7189, as listed below.
o One slim DVD-ROM drive
o One mini USB to SATAadapter
o Four sets of 4-cm counter-rotating fans
o One air shroud
o One DVD-ROM drive cable
o One internal USB cable for DVD drive
o Two passive CPU heatsinks
o Riser Cards: (see Section 5-6 for details) One RSC-R1UU-UE16 for PCI-E card
o Hard DriveAccessories
One SAS/SATAbackplane
Two SAS/SATA iPASS cables
Eight SAS/SATA drive carriers
o One rackmount kit
o One CD containing drivers and utilities
oAcnodesRMC7189 User's Manual

661 Brea Canyon Rd., Suite 3
Walnut, CA 91789
tel: [phone], fax: [phone]
© Copyright 2005 Acnodes, Inc.
All rights reserved. Product description and product specifications
are subject to change without notice. For latest product information,
please visit Acnodes’ web site at www.acnodes.com.
RMC 7189
1U Rackmount System
1-2 Serverboard Features
At the heart of theAcnodes RMC7189 lies the embedded system, a dual processor serverboard
based on the Intel® IOH-36D + ICH10R chipset. Below are the main features of the embedded system
(See Figure 1-1 for a block diagram of the chipset).
Processor
The RMC7189 supports single or dual two Intel® 5500 Series processors in LGA1366 sockets.
Please refer to our web site for a complete listing of supported processors
Memory
The RMC7189 has 240-pin DIMM sockets that can support up to 96 GB of regis- tered ECC DDR3-
1333/1066/800 SDRAM. Please refer to Chapter 5 for installing memory.
UIO
The RMC7189 is a specially-designed serverboard that featuresAcnodes's UIO (Universal I/O) tech-
nology. UIO serverboards have a PCI Express x8 slot that can support any one of several types of UIO
card types to add SAS ports, additional LAN ports, etc. to the serverboard. This allows the user to
tailor the serverboard to their own needs.
Note: the server does not come with a UIO card installed.
Onboard SATA
An on-chip (ICH10R) SATAcontroller is integrated into the RMC7189 to provide a six-port, 3 Gb/sec
SATAsubsystem, which is RAID 0, 1, 5 and 10 supported. The SATAdrives are hot-swappable units.
Note: You must have RAID set up to enable the hot-swap capability of the SATAdrives. Documentation
on RAID setup guidelines can be found on our web site.
Onboard Controllers/Ports
An onboard IDE controller supports one floppy drive. Onboard I/O backpanel ports include one COM
port, a VGA port, two USB ports, PS/2 mouse and keyboard ports and two Gigabit LAN (NIC) ports.
Graphics Controller
The RMC7189 features an integrated Matrox G200eW graphics chip, which includes 8 MB of DDR2
memory.

661 Brea Canyon Rd., Suite 3
Walnut, CA 91789
tel: [phone], fax: [phone]
© Copyright 2009 Acnodes, Inc.
All rights reserved. Product description and product specifications
are subject to change without notice. For latest product information,
please visit Acnodes’ web site at www.acnodes.com.
RMC 7189
1U Rackmount System
Other Features
Other onboard features that promote system health include voltage monitors, a chassis intrusion
header, auto-switching voltage regulators, chassis and CPU overheat sensors, virus protection
and BIOS rescue.
1-3 Server Chassis Features
The RMC7189 features eight 2.5" hard drive bays and high-efficiency power supplies. The
RMC7189 is built upon the embedded system chassis while the RMC7189 is built upon the embed-
ded system chassis. Details on the chassis and on servicing procedures can be found in Chapter
6.The following is a general outline of the main features of both chassis.
System Power
The RMC7189 features a redundant 650W power supply consisting of two power modules. The
system does not need to be shut down when replacing or removing a single power supply module.
The RMC7189 features a single 560W power supply module. The system must be shut down when
replacing or removing this power supply module.
PCI Expansion Slots
Ariser card on the right side of the chassis can sup- portAOC-PG-i2+ add-on card to provide two
Gb LAN ports. The left side supports a UIO card and one PCI-E x16 card. These two systems can
support four SAS/ SATAdrives with an optional UIO SAS card.
See page 5-10 for details. (Right and left refer to the side when viewed from the front of the system.
Control Panel
The SC113 control panel provides important system monitoring and control informa- tion. LEDs
indicate power on, network activity, hard disk drive activity and a UID (Universal Information) LED.
Also present are a main power button, a system reset button and a UID button.
I/O Backplane
The RMC7189 is a 1U rackmount chassis. Its I/O backplane provides three standard size PCI slots,
one COM port, one VGA port, two USB ports, PS/2 mouse and keyboard ports, two Ethernet (LAN)
ports, one dedicated IPMI LAN port and a UID LED.

661 Brea Canyon Rd., Suite 3
Walnut, CA 91789
tel: [phone], fax: [phone]
© Copyright 2005 Acnodes, Inc.
All rights reserved. Product description and product specifications
are subject to change without notice. For latest product information,
please visit Acnodes’ web site at www.acnodes.com.
RMC 7189
1U Rackmount System
Cooling System
The RMC7189 chassis' revolutionary cooling design has been optimized to provide sufficient cooling
for dual CPU configurations. The chassis includes an air shroud and four 4-cm counter-rotating fans
located in the middle of the chassis. There is a "Fan Speed Control Mode" in BIOS that allows chas-
sis fan speed to be determined by system temperature.

661 Brea Canyon Rd., Suite 3
Walnut, CA 91789
tel: [phone], fax: [phone]
© Copyright 2009 Acnodes, Inc.
All rights reserved. Product description and product specifications
are subject to change without notice. For latest product information,
please visit Acnodes’ web site at www.acnodes.com.
RMC 7189
1U Rackmount System
CHAPTER 2 INSTALLATION
2-1 Overview
This chapter provides a quick setup checklist to get yourAcnodes RMC7189 and running. Following
the steps in the order given should enable you to have the system operational within a minimal amount
of time. This quick setup assumes that your RMC7189 system has come to you with the processor and
memory preinstalled. If your system is not already fully integrated with a motherboard, processor,
system memory etc., please turn to the chapter or section noted in each step for details on installing
specific components.
2-2 Unpacking the System
You should inspect the box theAcnodes RMC7189 was shipped in and note if it was damaged in any
way. If the server itself shows damage, you should file a damage claim with the carrier who delivered it.
Decide on a suitable location for the rack unit that will hold theAcnodes RMC7189. It should be situ-
ated in a clean, dust-free area that is well ventilated.Avoid areas where heat, electrical noise and
electromagnetic fields are generated. You will also need it placed near a grounded power outlet. Read
the Rack and Server Precautions in the next section.
2-3 Preparing for Setup
The box the RMC7189 was shipped in should include two sets of rail assemblies, two rail mounting
brackets and the mounting screws you will need to install the system into the rack. Follow the steps in
the order given to complete the installation process in a minimum amount of time. Please read this
section in its entirety before you begin the installation procedure outlined in the sections that follow.
Choosing a Setup Location
