USER MANUAL
metone.com
GAS—1060
Direct Nitrogen Dioxide Analyzer
US EPA Designated Equivalent Method
Version 3.0

Met One Instruments is now part of the Acoem Group. The Met One
range of gas analyzers was originally developed by Acoem under
the brand name Ecotech Serinus®.
For the purposes of expediting the availability of Met One gas
analyzers to Met One customers around the world; Met One
Instruments have chosen to use the original Ecotech Serinus®
operating manual.
Although the name of the Met One instrument is dierent, the
analyzer itself has remained unchanged and meets the strictest
quality and performance requirements expected of Met One
equipment. All the information presented in this manual is current,
including analyzer specications and operating principles.
Met One will update this manual to reflect the new branding
convention in due course.

Introduction
Page 3
Table of Contents
Manufacturer’s Statement ..............................................................................................................................................11
Notice ..............................................................................................................................................................................11
Safety Requirements .......................................................................................................................................................12
Warranty..........................................................................................................................................................................12
Service & Repairs .............................................................................................................................................................13
CE Mark Declaration of Conformity .................................................................................................................................14
Claims for Damaged Shipments and Shipping Discrepancies ..........................................................................................15
Internationally Recognised Symbols on Ecotech Equipment...........................................................................................16
Manual Revision History ..................................................................................................................................................17
1. Introduction....................................................................................................................................19
1.1 Description ..........................................................................................................................................................19
1.2 Specifications ......................................................................................................................................................19
1.2.1 Measurement ......................................................................................................................................19
1.2.2 Precision/Accuracy ..............................................................................................................................19
1.2.3 Calibration ...........................................................................................................................................20
1.2.4 Power ................................................................................................................................................20
1.2.5 Operating Conditions...........................................................................................................................20
1.2.6 Communications..................................................................................................................................20
1.2.7 Physical Dimensions.............................................................................................................................21
1.3Nomenclature .....................................................................................................................................................21
1.4 Background/Theory.............................................................................................................................................22
1.4.1 Measurement Theory ..........................................................................................................................23
1.5 Instrument Description .......................................................................................................................................24
1.5.1 Calibration Valve Manifold ..................................................................................................................24
1.5.2 Background Scrubber DAU ..................................................................................................................24
1.5.3 Sample Filter Holder ............................................................................................................................24
1.5.4 Sample DFU .........................................................................................................................................25
1.5.5 Dryer ................................................................................................................................................25
1.5.6 Pressure Sensor PCA............................................................................................................................25
1.5.7 Interface PCA .......................................................................................................................................25
1.5.8 Measurement Cell Assembly ...............................................................................................................25
1.5.9 Pneumatic Tubing ................................................................................................................................26
1.5.10 Main Controller PCA ............................................................................................................................26
1.5.11 Power Supply .......................................................................................................................................26
1.5.12 On/Off Switch ......................................................................................................................................26
1.5.13 Communications..................................................................................................................................27
2. Installation......................................................................................................................................29
2.1 Initial Check.........................................................................................................................................................29
2.2 Installation Notes ................................................................................................................................................30
2.3 Instrument Set-Up...............................................................................................................................................31
2.3.1 Pneumatic Connections .......................................................................................................................31
2.3.2 Power Connections..............................................................................................................................32
2.3.3 Communications Connections .............................................................................................................32

Serinus 60 User Manual 3.0
Page 4
2.3.4 Instrument Set-Up............................................................................................................................... 33
2.4 Transporting/Storage.......................................................................................................................................... 33
3. Operation....................................................................................................................................... 37
3.1 Warm-Up ............................................................................................................................................................ 37
3.2 Measurement ..................................................................................................................................................... 37
3.3 General Operation Information.......................................................................................................................... 37
3.3.1 Keypad & Display................................................................................................................................. 37
3.3.2 Home Screen....................................................................................................................................... 39
3.4 Menus & Screens ................................................................................................................................................ 40
3.4.1 Quick Menu......................................................................................................................................... 41
3.4.2 Main Menu.......................................................................................................................................... 41
3.4.3 Analyser State Menu........................................................................................................................... 42
3.4.4 Status Menu ........................................................................................................................................ 42
3.4.5 Temperature Menu............................................................................................................................. 43
3.4.6 Pressure & Flow Menu ........................................................................................................................ 44
3.4.7 Voltage Menu...................................................................................................................................... 44
3.4.8 General Settings Menu........................................................................................................................ 44
3.4.9 Measurement Settings Menu.............................................................................................................. 45
3.4.10 Calibration Menu ................................................................................................................................ 46
3.4.11 Pressure Calibration Menu.................................................................................................................. 48
3.4.12 Service Menu....................................................................................................................................... 48
3.4.13 Diagnostics Menu................................................................................................................................ 49
3.4.14 Digital Pots Menu................................................................................................................................ 49
3.4.15 Internal Pump Menu (Option)............................................................................................................. 50
3.4.16 Valve Menu ......................................................................................................................................... 50
3.4.17 Tests Menu.......................................................................................................................................... 51
3.4.18 Digital Input Test Menu....................................................................................................................... 51
3.4.19 Digital Output Test Menu.................................................................................................................... 52
3.4.20 Calculation Factors Menu.................................................................................................................... 52
3.4.21 Communications Menu....................................................................................................................... 53
3.4.22 Data Logging Menu ............................................................................................................................. 53
3.4.23 Serial Communication Menu............................................................................................................... 53
3.4.24 Analog Input Menu ............................................................................................................................. 54
3.4.25 Analog Output Menu........................................................................................................................... 54
3.4.26 Digital Input Menu .............................................................................................................................. 56
3.4.27 Digital Output Menu ........................................................................................................................... 56
3.4.28 Network Menu .................................................................................................................................... 57
3.4.29 Bluetooth Menu .................................................................................................................................. 58
3.4.30 Advanced Menu .................................................................................................................................. 59
3.4.31 Hardware Menu .................................................................................................................................. 59
3.4.32 Parameter Display Menu..................................................................................................................... 60
4. Communications............................................................................................................................ 61
4.1 RS232 Communication........................................................................................................................................ 61
4.2 USB Communication ........................................................................................................................................... 62
4.3 TCP/IP Network Communication (optional) ....................................................................................................... 63
4.3.1 Network Setup .................................................................................................................................... 64
4.3.2 Port Forwarding on Remote Modem/Router Setup............................................................................ 64
4.3.3 Setup Airodis to Communicate with Serinus....................................................................................... 65
4.4 Digital/Analog Communication........................................................................................................................... 66

Introduction
Page 5
4.4.1 Analog Outputs....................................................................................................................................66
4.4.2 Analog Inputs.......................................................................................................................................68
4.4.3 Digital Status Inputs.............................................................................................................................68
4.4.4 Digital Status Outputs..........................................................................................................................68
4.5 Logging Data........................................................................................................................................................69
4.5.1 Configure Instrument Internal Logging................................................................................................69
4.6 Using Airodis Software to Download Data ..........................................................................................................70
4.6.1 Connecting the Instrument to Your PC ................................................................................................70
4.6.2 Installing Airodis ..................................................................................................................................73
4.6.3 Configuring Airodis ..............................................................................................................................73
4.7 Serinus Remote App/Bluetooth ..........................................................................................................................79
4.7.1 Installation...........................................................................................................................................79
4.7.2 Connecting to the Instrument .............................................................................................................80
4.7.3 Instrument Control ..............................................................................................................................81
4.7.4 Real-Time Plot......................................................................................................................................82
4.7.5 Download.............................................................................................................................................84
4.7.6 Get Parameters....................................................................................................................................84
4.7.7 Preferences..........................................................................................................................................85
5. Calibration ......................................................................................................................................87
5.1 Overview .............................................................................................................................................................87
5.2 Pressure Calibration ............................................................................................................................................89
5.2.1 Full Pressure Calibration ......................................................................................................................89
5.2.2 Ambient Point Pressure Calibration.....................................................................................................90
5.3 Pressure Calibration (Internal Pump Option Only)..............................................................................................91
5.4 Zero Calibration...................................................................................................................................................91
5.4.1 Calibration Port....................................................................................................................................92
5.4.2 Sample Port .........................................................................................................................................92
5.4.3 Internal Zero (Sample Port) .................................................................................................................93
5.5 Span Calibration ..................................................................................................................................................93
5.5.1 Calibration Port....................................................................................................................................93
5.5.2 Sample Port .........................................................................................................................................94
5.5.3 Manual Instrument Gain and Offset Adjustments...............................................................................94
5.6 Precision Check ...................................................................................................................................................95
5.7 Multipoint Precision Check .................................................................................................................................95
5.8 High Pressure Zero/Span Valve ...........................................................................................................................97
5.8.1 Single Pressurised Calibration Option..................................................................................................98
5.8.2 Dual Pressurised Calibration Option..................................................................................................100
6. Service ..........................................................................................................................................103
6.1 Maintenance Tools............................................................................................................................................103
6.2 Maintenance Schedule......................................................................................................................................104
6.3 Maintenance Procedures ..................................................................................................................................106
6.3.1 Background Scrubber DAU check ......................................................................................................106
6.3.2 Particulate Filter Replacement ..........................................................................................................107
6.3.3 Clean Fan Filter ..................................................................................................................................107
6.3.4 Sample DFU Replacement .................................................................................................................108
6.3.5 Background Scrubber DAU Replacement ..........................................................................................108
6.3.6 Leak Check .........................................................................................................................................109

Serinus 60 User Manual 3.0
Page 6
6.3.7 Clean Pneumatics.............................................................................................................................. 111
6.3.8 Pressure Sensor Check ...................................................................................................................... 111
6.4 Bootloader........................................................................................................................................................ 113
6.4.1 Display Help Screen........................................................................................................................... 113
6.4.2 Communications Port Test................................................................................................................ 113
6.4.3 Updating Firmware ........................................................................................................................... 114
6.4.4 Erase All Settings ............................................................................................................................... 114
6.4.5 Start Analyser.................................................................................................................................... 114
7. Troubleshooting........................................................................................................................... 115
7.1 Leak Check ........................................................................................................................................................ 117
7.2 Flow Fault ......................................................................................................................................................... 118
7.3 Noisy/Unstable Readings.................................................................................................................................. 119
7.4 Flow Block Temperature Failure ....................................................................................................................... 120
7.5 Measurement Cell Temperature Failure........................................................................................................... 121
7.6 USB Memory Stick Failure................................................................................................................................. 122
7.7 Ecotech Service Support Files ........................................................................................................................... 123
8. Optional Extras............................................................................................................................. 125
8.1 Dual Sample Filter (PN: E020100)..................................................................................................................... 125
8.2 Internal Pump (PN: E020124) ........................................................................................................................... 125
8.2.1 Hardware Setup ................................................................................................................................ 125
8.2.2 Pressure Calibration .......................................................................................................................... 126
8.2.3 Pump control..................................................................................................................................... 126
8.3 Rack Mount Kit (PN: E020116).......................................................................................................................... 126
8.4 High Pressure Zero/Span Valves ....................................................................................................................... 130
9. Parts List....................................................................................................................................... 131
9.1 Serinus Accessories Kit...................................................................................................................................... 131
9.2 Maintenance Kit................................................................................................................................................ 131
9.3 Consumables .................................................................................................................................................... 132
9.4 Instrument Parts List......................................................................................................................................... 132
9.5 Plumbing Schematic –(PN: D020060) .............................................................................................................. 134
9.6 Block Wiring Schematic –(PN: D020111) ......................................................................................................... 135
9.7 Measurement Cell Side Section –(PN: H015000)............................................................................................. 136
9.8 Calibration Valve Manifold Assembly Exploded View –(PN: H010013-01) ...................................................... 138
9.9 Valve Assembly Exploded View –(PN: H010042) ............................................................................................. 139
9.10 High Pressure Valve Exploded View –(PN: H050043) ...................................................................................... 140
List of Figures
Figure 1 –Simple Pneumatic Diagram................................................................................................... 23
Figure 2 –Internal Components Diagram ............................................................................................. 24
Figure 3 –Ecotech Tygon Tubing........................................................................................................... 26
Figure 4 –Opening the Instrument ....................................................................................................... 29

Introduction
Page 7
Figure 5 –Instrument Back Panel ..........................................................................................................31
Figure 6 –Installation of USB Memory Stick..........................................................................................34
Figure 7 –Switching the Battery On/Off................................................................................................35
Figure 8 –Front Panel ............................................................................................................................38
Figure 9 –Home Screen .........................................................................................................................39
Figure 10 –Communication Ports..........................................................................................................61
Figure 11 –Multidrop RS232 Cable Example.........................................................................................62
Figure 12 –Example of Typical Network Setups....................................................................................63
Figure 13 –Example of Network Menu Setup .......................................................................................64
Figure 14 –Port Forwarding Example....................................................................................................65
Figure 15 –LAN Network Set-Up (Airodis).............................................................................................65
Figure 16 –WAN Network Set-Up (Airodis)...........................................................................................66
Figure 17 –25 Pin Rear Panel PCA (Default Jumpers Highlighted) ........................................................68
Figure 18 –External 25 pin I/O Individual Pin Descriptions...................................................................69
Figure 19 –Installing Driver Software (Device Manager) ......................................................................70
Figure 20 –Update Driver Popup...........................................................................................................71
Figure 21 –Update Driver Popup (Directory Location)..........................................................................71
Figure 22 –Installing Driver Confirmation Prompt ................................................................................72
Figure 23 –Successful Driver Installation ..............................................................................................72
Figure 24 –Airodis Workspace Manager ...............................................................................................74
Figure 25 –Adding a New Station..........................................................................................................74
Figure 26 –New Station Connection......................................................................................................75
Figure 27 –Station Configuration ..........................................................................................................76
Figure 28 –Error Status Notification......................................................................................................76
Figure 29 –Downloading Data...............................................................................................................77
Figure 30 –Download Data Status.........................................................................................................77
Figure 31 –Data Visibility.......................................................................................................................78
Figure 32 –Exporting Data.....................................................................................................................78
Figure 33 –Data Download Complete ...................................................................................................79
Figure 34 –Downloading the App from Google Play Store ...................................................................80
Figure 35 –Bluetooth Pairing Request...................................................................................................80
Figure 36 –Showing or Hiding the NumPad ..........................................................................................81
Figure 37 –Switching Analysers.............................................................................................................82
Figure 38 –Real-Time Plot .....................................................................................................................83
Figure 39 –Plot of Downloaded Data ....................................................................................................84
Figure 40 –Directory Settings................................................................................................................85
Figure 41 –Logs Format.........................................................................................................................85
Figure 42 –Colour Theme Settings ........................................................................................................86
Figure 43 –Example of a Calibration System.........................................................................................87
Figure 44 –Setting the Ambient Set Point.............................................................................................90
Figure 45 –Multipoint Calibration Results Example..............................................................................97
Figure 46 –Single High Pressure Calibration Option .............................................................................98
Figure 47 –Dual High Pressure Calibration Option..............................................................................100

Serinus 60 User Manual 3.0
Page 8
Figure 48 –Minifit Extraction Tool –(T030001).................................................................................. 103
Figure 49 –Orifice/Sintered Filter Removal Tool –(H010046) ........................................................... 103
Figure 50 –Leak Test Jig –(H050069) ................................................................................................. 104
Figure 51 –Air Monitoring Test Equipment Kit (AMTEK) –Customisable .......................................... 104
Figure 52 –Removing the Plunger ...................................................................................................... 107
Figure 53 –Removing the Fan Filter.................................................................................................... 108
Figure 54 –Sample DFU....................................................................................................................... 108
Figure 55 –Background DAU............................................................................................................... 109
Figure 56 –Test Point Location ........................................................................................................... 112
Figure 57 –Typical Test Point Reading of Internal Pump Pressure Sensor......................................... 112
Figure 58 –Typical Test Point Reading of Measurement Cell Pressure Sensor .................................. 113
Figure 59 –Leak Check Troubleshooting Flow Chart .......................................................................... 117
Figure 60 –Zero Flow Fault Troubleshooting Flow Chart ................................................................... 118
Figure 61 –Noisy or Unstable Readings Troubleshooting Flow Chart ................................................ 119
Figure 62 –Flow Block Temp failure Troubleshooting Flow Chart...................................................... 120
Figure 63 –Measurement Cell Temperature Failure Troubleshooting Flow Chart ............................ 121
Figure 64 –USB Memory Stick Failure ................................................................................................ 122
Figure 65 –USB Memory Stick File Structure...................................................................................... 124
Figure 66 –Dual Filter Option Installed............................................................................................... 125
Figure 67 –Separate Rack Slides ......................................................................................................... 127
Figure 68 –Assemble Inner Slide on Chassis....................................................................................... 127
Figure 69 –Rack Mount Ears Fitted to Instrument ............................................................................. 128
Figure 70 –Attach Rack Mount Adaptors to Outer Slides................................................................... 128
Figure 71 –Test Fit the Rack Slide Assembly into Your Rack .............................................................. 129
Figure 72 –Attach Slides to Front of Rack........................................................................................... 129
Figure 73 –Slide Clips.......................................................................................................................... 130

Introduction
Page 9
List of Tables
Table 1 –Manual Revision History.........................................................................................................17
Table 2 –Measurements Times .............................................................................................................37
Table 3 –Digital Output States ..............................................................................................................57
Table 4 –Analog Outputs.......................................................................................................................66
Table 5 –New Station Setup ..................................................................................................................75
Table 6 –Maintenance Schedule .........................................................................................................104
Table 7 –Troubleshoot List..................................................................................................................115
Table 8 –Included Parts (Rack Mount Kit)...........................................................................................126
Table 9 –Serinus Accessories Kit (PN: H010136).................................................................................131
Table 10 –Annual Maintenance Kit –(PN: E020203-01) .....................................................................131
Table 11 –Consumables.......................................................................................................................132
Table 12 –Spare Parts List ...................................................................................................................132
Table 13 –Packet Format.....................................................................................................................141
Table 14 –Example: Primary Gas Request...........................................................................................141
Table 15 –Example: Primary Gas Response ........................................................................................142
Table 16 –Example: Primary Gas Response (continued).....................................................................142
Table 17 –List of Errors........................................................................................................................142
Table 18 –Example: Get IEEE Response data ......................................................................................143
Table 19 –Advanced Protocol Parameter List .....................................................................................144
Table 20 –Bayern-Hessen Data ...........................................................................................................157
Table 21 –Block Check Operation .......................................................................................................158
Table 22 –Status Bit Map ....................................................................................................................159
Table 23 –Failure Bit Map (Positive Logic) ..........................................................................................160
Table 24 –Modbus Error Codes...........................................................................................................163

Serinus 60 User Manual 3.0
Page 10
This page is intentionally blank.

Introduction
Page 11
Manufacturer’s Statement
Thank you for selecting the Ecotech Serinus 60 Nitrogen Dioxide Analyser.
The Serinus series is the next generation of Ecotech designed and manufactured gas analysers. The
Serinus 60 will perform NO2measurements over a range of 0-1 ppm with a lower detectable limit of
0.04 ppb.
This User Manual provides a complete product description including operating instructions,
calibration and maintenance requirements for the Serinus 60. Reference should also be made to the
relevant local standards which should be used in conjunction with this manual. Some of these
standards are listed in this manual.
If, after reading this manual you have any questions or you are still unsure or unclear on any part of
the Serinus 60, please do not hesitate to contact Ecotech or your local Ecotech distributor.
Please help the environment and recycle the pages of this manual when
you have finished using it.
Notice
The information contained in this manual is subject to change without notice. Ecotech reserves the
right to make changes to equipment construction, design, specifications and /or procedures without
notification.
Copyright © 2016. All rights reserved. Reproduction of this manual, in any form, is prohibited
without the written consent of Ecotech Pty Ltd.
CAUTION
Hazardous voltages exist within the instrument. Do not remove or modify any of
the internal components or electrical connections whilst the mains power is on.
Ensure the mains power lead is maintained in a safe working condition.
The instruments lid should be closed during normal operation to comply with
EMC regulations.

Serinus 60 User Manual 3.0
Page 12
Safety Requirements
To reduce the risk of personal injury caused by electrical shock, follow all safety notices and warnings
in this documentation.
If the equipment is used for purposes not specified by Ecotech, the protection provided by this
equipment may be impaired.
Replacement of any part should only be carried out by qualified personnel, using only parts specified
by Ecotech as these parts meet stringent Ecotech quality assurance standards. Always disconnect the
power source before removing or replacing any components.
Warranty
This product has been manufactured in an ISO 9001/ISO 14001 facility with care and attention to
quality.
The product is subject to a 24-month warranty on parts and labour from date of shipment. The
warranty period commences when the product is shipped from the factory. Lamps, filters and other
consumable items are not covered by this warranty.
Each instrument is subjected to a vigorous testing procedure prior to despatch and will be
accompanied with a parameter list and a multipoint precision check, thereby enabling the
instrument to be installed and ready for use without any further testing.

Introduction
Page 13
Service & Repairs
Our qualified and experienced technicians are available to provide fast and friendly service between
the hours of 8:30am –5:00pm AEST Monday to Friday. Please contact either your local distributor or
Ecotech regarding any questions you have about your instrument.
Service Guidelines
This manual is designed to provide the necessary information for the setup, operation, testing,
maintenance and troubleshooting of your instrument.
Should you still require support after consulting the documentation, we encourage you to contact
your local distributor for support.
To contact Ecotech directly, please e-mail our Technical Support Services group at
[email protected]m or to speak with someone directly:
Please dial 1300 364 946 if calling from within Australia.
Please dial [phone] if calling from outside of Australia.
Please contact Ecotech and obtain a Return Material Authorisation (RMA) number before sending
any equipment back to the factory. This allows us to track and schedule service work and to expedite
customer service. Please include this RMA number when you return equipment, preferably both
inside and outside the shipping packaging. This will ensure you receive prompt service.
When shipping instrumentation, please also include the following information:
Name and phone number
Company name
Shipping address
Quantity of items being returned
Model number/s or a description of each item
Serial number/s of each item (if applicable)
A description of the problem and any fault-finding completed
Original sales order or invoice number related to the equipment
Shipping Address:
Attention Service Department
Ecotech Pty Ltd
1492 Ferntree Gully Road,
Knoxfield, VIC, Australia 3180.

Serinus 60 User Manual 3.0
Page 14
CE Mark Declaration of Conformity
This declaration applies to the Serinus 60 Nitrogen Dioxide Analyser as manufactured by Ecotech Pty.
Ltd. of 1492 Ferntree Gully Rd, Knoxfield, VIC Australia 3180. The instrument to which this
declaration relates is in conformity with the following European Union Directives:
Council Directive of 15 December 2004 on the approximation of the laws of Member States
relating to electromagnetic compatibility (2004/108/EC)
The following standard was applied:
EN 61326-1:2013 Electrical equipment for measurement, control and laboratory use –EMC
requirements –Part 1: General requirements.
Immunity Requirements EN 61326-1
IEC-61000-4-2 Electrostatic discharge immunity
IEC-61000-4-3 Radiated RF immunity
IEC-61000-4-4 Electrical fast transient burst immunity
IEC-61000-4-5 Surge immunity
IEC-61000-4-6 Conducted RF immunity
IEC-61000-4-11 Voltage dips and interruption immunity
Electromagnetic Compatibility EN 61326-1
CISPR-11 Radiated RF emission measurements
CISPR-11 Mains terminal RF emission measurements
IEC-61000-3-3 Mains terminal voltage fluctuation measurements
IEC-61000-3-2 Power frequency harmonic measurements
Council Directive of 12 December 2006 on the harmonisation of the laws of Member States relating
to electrical equipment designed for use within certain voltage limits (2006/95/EC)
The following standard was applied:
EN 61010-1:2013 Safety requirements for electrical equipment, for measurement control and
laboratory use (3rd edition) –Part 1: General requirements
For protection against:
Electric shock or burn
Mechanical Hazards
Excessive temperature
Spread of fire from the equipment
Effects of fluids and fluid pressure
Effects of radiation, including laser
sources, sonic and ultrasonic pressure
Liberated gases, explosion and implosion

Introduction
Page 15
Claims for Damaged Shipments and Shipping Discrepancies
Damaged Shipments
Inspect all instruments thoroughly on receipt. Check materials in the container/s against the
enclosed packing list. If the contents are damaged and/or the instrument fails to operate properly,
notify the carrier and Ecotech immediately.
The following documents are necessary to support claims:
Original freight bill and bill of lading
Original invoice or photocopy of original invoice
Copy of packing list
Photographs of damaged equipment and container
You may want to keep a copy of these documents for your records.
Please refer to the instrument name, model number, serial number, sales order number and your
purchase order number on all claims.
You should also:
Contact you freight forwarder for an insurance claim
Retain packing material for insurance inspection
Shipping Discrepancies
Check all packages against the packing list immediately on receipt. If a shortage or other discrepancy
is found, notify the carrier and Ecotech immediately. Ecotech will not be responsible for shortages
against the packing list unless they are reported within seven days.
Contact Details
Head Office
1492 Ferntree Gully Road, Knoxfield, VIC Australia 3180
Phone: [phone] Fax: [phone]
Email: [e-mail]
Service: [email protected]
Support: [e-mail]
www.ecotech.com

Serinus 60 User Manual 3.0
Page 16
Internationally Recognised Symbols on Ecotech Equipment
Protective conductor terminal
IEC 60417-5017
Alternating current
IEC 60417-5032
Caution, hot surface
IEC 60417-5041
Caution, risk of danger.
Refer to accompanying documents
ISO 7000-0434
Caution, risk of electric shock
ISO 3864-5036

Introduction
Page 17
Manual Revision History
Manual PN: M010060
Current revision: 3.0
Date released: 7 March 2016
Description: User Manual for the Serinus 60 Nitrogen Dioxide Analyser
This manual is the full user manual for the Serinus 60 Nitrogen Dioxide Analyser. This manual
contains all relevant information on theory, specifications, installation, operation, maintenance and
calibration. Any information that cannot be found within this manual can be obtained by contacting
Ecotech.
This manual uses cross reference links extensively throughout this manual. The hot keys below will
greatly reduce the amount of time scrolling between references:
You can access the links by pressing the following:
>CTRL + LEFT MOUSE CLICK: Move to the link location
You can switch between links by pressing the following:
>ALT + LEFT ARROW KEY: Returns you to previous Link
>ALT + RIGHT ARROW KEY: Swaps back
Table 1 –Manual Revision History
Edition
Date
Summary
3.0
March 2016
Initial release

Serinus 60 User Manual 3.0
Page 18
This page is intentionally blank.

Introduction
Page 19
1. Introduction
1.1 Description
The Serinus 60 Nitrogen Dioxide Analyser (NO2) utilizes cavity attenuated phase shift spectroscopy
detection to perform continuous analysis of nitrogen dioxide.
The Serinus 60 can measure to a sensitivity of 20 ppt with a range of 0-1 ppm. The measurement of
this gas is performed with the following main sub-components:
Particulate filters
Sample dryer
Measurement cell (temperature controlled)
Light source (Blue LED) and Photo Detector
Interface PCA
A microprocessor programmed with Serinus firmware monitors the detector response and many
other parameters. The concentrations are automatically corrected for gas temperature and pressure
changes and when using gravimetric units (e.g. μg/m³) is referenced to 0°C, 20°C or 25°C at 1
atmosphere. This allows the Serinus 60 to provide readings in the relevant units for your
requirements. This section will describe the specifications of the instrument as well as the main
components and techniques used to obtain stable gas concentration readings.
1.2 Specifications
1.2.1 Measurement
Range
0-1 ppm autoranging
Lower detectable limit: 0.04 ppb, with no filter active
Noise: < 0.02 ppb
1.2.2 Precision/Accuracy
Precision
0.04 ppb otherwise 0.5 % of reading, whichever is greater
Linearity
±4 % of full scale
Response Time
30 seconds

Serinus 60 User Manual 3.0
Page 20
Sample Flow Rate
0.5 slpm
1.2.3 Calibration
Zero Drift
Temperature dependant: 0.1 ppb per °C
24 hours: < 0.4 ppb
7 days: < 1.0 ppb
Span Drift
Temperature dependant: 0.1 % per °C
7 days: < 1.0 % of reading
1.2.4 Power
Operating voltage
100-240 VAC, 50 to 60 Hz (autoranging)
Power Consumption
88 VA max (typical at start up)
65 VA after warm up
1.2.5 Operating Conditions
Ambient Temperature Range
0 °C to 40 °C (32 °F to 104 °F)
Sample Pressure Dependence
5 % change in pressure produces less than a 1 % change in reading
Maximum altitude: 3000 m above sea level
1.2.6 Communications
Analog Output
Menu selectable current output of 0-20 mA, 2-20 mA or 4-20 mA.
Voltage output of 0 to 5 V, with menu selectable zero offset of 0 V, 0.25 V or 0.5 V.
Voltage output of 0 to 10 V (configured using jumpers (JP3) on rear panel PCA).
Range: 0 to full scale from 0-0.05 ppm to 0-1 ppm.
