ACONATIC AN-SP159 User manual
NO.3
Features:
Quality 2.1 speaker system with built-in amplifier
Full audio spectrum performances, ideal for your favourite entertainment
from Mp3, Mp4, CD/DVD movies and digital playbacks
Specially designed woofer cabinet for bass and resolution
Comes with wired remote control and 3.5 stereo connection
NO.1
Operation explanation:
~220V/60Hz
3"x 2 + 6.5" subwoofer
80W(RMS)
Remote control 1 pc
User manual 1 pc
Audio input cord 1 pc
FM ANT 1 pc
W280xH353xD277.5(mm)
W120xH1020xD118(mm)
Package contents:
Subwoofer cabinet 1 pc
Satellite speakers 2 pcs
2.1CH MULTIMEDIA SPEAKER SYSTEM
AN-SP159
DEAR CUSTOMER:
Thank you to buy the product !
Prior to first use, please read the manual carefully.
6. Previous: In USB mode, short-press to play previous song;
In BT mode, short-press to play previous song;
In FM mode, short-press to play previous FM station in memory;
7. VOL- :volume down；
8. 0-9 buttons : In USB mode ,press the number key to play the corresponding
song in USB;
In FM mode, press numbers to get the corresponding radio station, if there’re
stations in memory, also can press the number key to select in sequence
9. MUTE: activate or deactivate mute.
10. LED: short-press to cycle select “LED1、LED2、LED3、LED4、LED 5、
LED6 or LEDF ( means light off)”，long-presscan turn off light directly；
11. MEMORY：in FM mode, long press this button to enter into the automatic
search mode, product can search and save the effective stations automatically,
when manually scanning, short press this button to enter into the manually-saving
mode, the FM station number will flash. At this time, press the prev. or next button
to select the station number without the table. Press the MEMORY button again
to confirm the storage and save the station at that location;
12. MIC VOL : Karaoke volume adjustment;
14. NEXT: In USB mode, short-press to play next song;
In BT mode, short-press to play next song;
In FM mode, short-press to play next FM station in memory；
*Bluetooth connection method: switch to BT mode, open your bluetooth device,
search for the device name "AN-SP161" and connect, there’s one beep sound
when paring is successful;
NO.2
1. ST-BY
2. SOURCE
3. TONE
4. MIC ECHO
5. VOL+
6. PREVIOUS
7. VOL-
8. 0~9
9. MUTE
10. LED
11. MEMORY
12.MIC VOL
13. PLAY/PAUSE
14. NEXT
VOL+
LED
TONE MEMORY
VOL-
SOURCE
(1)
(2)
(5)
(3)
(4)
(6)
(8)
(7)
(9)
(10)
(11)
(12)
(14)
(13)
1. ST-BY : Standby & release standby; short press in standby mode, product
be power-on, short-press again, product be Standby again;
2. SOURCE: switch the input mode; when power-on, short press to select the
input mode (AU =AUX,DU =DVD,F =FM,UD=USB, BL=Bluetooth)last two
digitals of display shows the volume level; under USB mode, it will shows
the playing time, too;
3. “ TONE ”means you can choose “TREBLE” “BASS”and “LOUD” ,“ VOL+/- ”
means you can increase or decrease volume of “TREBLE” “BASS”and “LOUD”.
4. MIC ECHO: Karaoke reverberation adjustment;
5. VOL+ :volume up；
MIC
ECH O
MIC
VOL
NO.6
R
System connection diagram
L
* Do not leave objects generating magnetism near the speakers.
SPEAKER TERMINALS
Connect the satellite and center speaker to the output terminals as
shown in the figure.
Connect the 3.5" stereo cable to the input of the subwoofer,Connect the
3.5 stereo input jack into output of the audio sources,such as MP3,MP4,
walkman,computer etc.
NO.7
In use please pay attention to the following items:
*if the remote control cannot function, it is because the battery of
remote control has been used up. thank you.
1. /SOURCE
4. 5.VOL+/- 6. /SCAN
2.LED 3.
45
6
1.Switch on the unit, it will be in standby state with LED display showing
" --- ".Press the key “ ” , it's turned into Aux input mode with
display showing "BT 18".("BT" means BT mode,"18 " means the present
volume is 18dB,volume range is 0~30dB). Long press the key 3~5 seconds,
the unit will be back to standby state.
2.Press the “SOURCE” key to choose the input modes by the cycle order
of “AUX-DVD-USB/SD-FM”. Meanwhile the LED display indicates “Au18”.
“Du18”. “Ud18”. “87.5”.
3. In FM mode, short press the key “ ”, “ ” to search channels step by
step(each time 0.1 MHz). Long press the key 3~5 seconds, the unit will
do automatic cycle search and play the channel after getting the signal.
4. In USB mode, press the key “ ”,“ ” to skip to previous or next song.
5. In USB mode, press “ ” you can pause and play control ,
In FM mode press “ ”. Automatic search and storage of radio
channels
6. Knob operation: turn right/left to increase/decrease the volume based
on the key volume control.
7.Rotary volume knob to increase or decrease the volume. The current
channel won't change when operahing it; the volume level will increase/
decrease from 00 to 30 as user operating it.
NO.4
Front panel
/SCAN
/SCAN
1 2 3
/SOURCE
Rear panel
(1)
(2)
(3)
(5)
(4)
1. ANTENNA
2. AUX Input
3. DVD Input
4. Output R/L
Connect the satellite speakers.
5. AC IN : AC Power cord
MIC
side panel
NO.5
