auna 10033254 User manual

14
EN
Techncal Data 14
Safety Instructions 15
Device Description 17
Operation 18
BT Connection 21
Troubleshooting 21
Disposal Considerations 22
CONTENTS
Dear Customer,
Congratulations on purchasing this equipment.
Please read this manual carefully and take
care of the following hints to avoid damages.
Any failure caused by ignoring the mentioned
items and cautions mentioned in the instruction
manual are not covered by our warranty and
any liability. Scan the QR code to get access to
the latest user manual and other information
about the product.

15
EN
TECHNCAL DATA
Artikelnummer 10033254
Power supply
Net adapter
Built-in battery
100-240 V~ 50/60 Hz
12 V 5 A
RMS power 35 W
Max power output 100 W
Connections
AUX-IN
Microphone input
USB
3.5 mm
6.3 mm
5 V; 1 A
UHF microphone
Frequency 863.1 MHz
BT
Operation range up to 10 metres
Compatible BT prole A2DP

16
EN
SAFETY INSTRUCTIONS
• Read the manual prior to using the product. Take all precautions to
avoid re and/or electrical shock. Repairs must only be carried out by a
qualied technician in order to avoid electrical shock. Keep the manual
for future reference.
• Prior to using the product, please ask advice from a specialist. When the
product is switched on for the rst time, some smell may occur. This is
normal and will disappear after a while.
• The product contains voltage carrying parts. Therefore do NOT open the
housing.
• Do not place metal objects or pour liquids into the product. This may
cause electrical shock and malfunction.
• Do not place the product near heat sources such as radiators, etc.
• Do not place the product on a vibrating surface. Do not cover the
ventilation holes.
• The product is not suitable for continuous use.
• Be careful with the mains lead and do not damage it. A faulty or
damaged mains lead can cause electrical shock and malfunction.
• When unplugging the product from a mains outlet, always pull the plug,
never the lead.
• Do not plug or unplug the product with wet hands.
• If the plug and/or the mains lead are damaged, they need to be
replaced by a qualied technician.
• If the product is damaged to such an extent that internal parts are
visible, do NOT plug the product into a mains outlet and DO NOT
switch the unit on. Contact your dealer. Do NOT connect the product to
a rheostat or dimmer.
• To avoid re and shock hazard, do not expose the product to rain and
moisture.
• All repairs should be carried out by a qualied technician only.
• Connect the product to an earthed mains outlet (220-240 V AC/50 Hz)
protected by a 10-16 A fuse.
• During a thunderstorm or if the product will not be used for a longer
period of time, unplug it from the mains. The rule is: Unplug it from the
mains when not in use.
• If the product has not been used for a longer period of time,
condensation may occur. Let the unit reach room temperature before
you switch it on. Never use the product in humid rooms or outdoors.
• To prevent accidents in companies, you must follow the applicable
guide lines and follow the instructions.
• Do not repeatedly switch the product on and o. This shortens the life
time.
• Keep the product out of the reach of children. Do not leave the product
unattended.
• Do not use cleaning sprays to clean switches. The residues of these
sprays cause deposits of dust and grease. In case of malfunction,

17
EN
always seek advice from a specialist.
• Do not force the controls.
• If this product is with speaker inside which can cause magnetic eld.
• Keep the product at least 60 cm away from computer or TV.
• If the product has built-in lead-acid rechargeable battery. Please
recharge the battery every 3 months if you are not going to use the unit
for a long period of time. Or the battery may be damaged.
• If the battery is damaged please replace with same specications
battery. And dispose the damaged battery environment friendly.
• If the product has fallen, always have it checked by a qualied
technician before you switch the product on again.
• Do not use chemicals to clean the unit. They damage the varnish. Only
clean the product with a dry cloth.
• Keep away from electronic equipment that may cause interference.
• Only use original spares for repairs, otherwise serious damage and/or
dangerous radiation may occur.
• Switch the product o prior to unplugging it from the mains and/ or
other equipment. Unplug all leads and cables prior to moving the
product.
• Make sure that the mains lead cannot be damaged when people walk
on it. Check the mains lead before every use for damages and faults!
• The mains voltage is 220-240 V AC/50 Hz. Check if power outlet match.
• If you travel, make sure that the mains voltage of the country is suitable
for this product.
• Keep the original packing material so that you can transport the product
in safe conditions.
Designated use
• This device is for the transmission of speech and singing. It is solely
designed and may only be used for this purpose. It may only be used in
the manner described in this manual.
• This appliance is not intended for use by persons (including children)
with reduced physical, sensory or mental capabilities, or lack of
experience and knowledge, unless they have been given supervision or
instruction concerning use of the appliance by a person responsible for
their safety.
• The microphone system includes microphones with an integrated
transmitter, which serve wireless transmission to the receiving unit. The
systems operate within the UHF range (863.1 MHz & 864.5MHz). The
transmission range is 50 m and depends on the local conditions. The
appliance are designed for indoor use only.

18
EN
DEVICE DESCRIPTION
Connections
Front panel
Rear panel
* not included

19
EN
Front Panel
Controls
1 Microphone input with volume control: This mono input
accepts a 1/ 4" (6.35 mm) input such as a microphone, guitar,
or other musical instrument. (Such as the use wireless
microphones, just turn on the wireless microphone power
switch, then adjust the microphone volume can be. The
frequency of the wireless microphone is 795.85MHz.).
2 AUX input: This stereo 1/8" (3.5 mm) input can be used to
connect a CD player, MP3 player, or other audio source.
3 TREBLE CONTROL: This adjusts the treble frequencies,
Use this control to attain a bright and lively sound for your
instrument.
4 BASS CONTROL: This adjusts the bass frequencies, Use this
control to get the best sounding bass response for your
instrument.
5 MASTER CONTROL: This adjusts the unit's main mix volume,
which includes the Microphone input,
Auxiliary input, MP3 and the audio of a paired BT device.
6 BATTERY LEVEL: While the unit is powered ON, that Blue light
is lit. the Red lights indicate the power in the low-battery that
need to charge. when Green light is lit, that unit is plugged in
and charge the battery.
CHANNEL 1
MICROPHONE VOLUME AUX IN TREBLE BASS VOLUME FLASH
CHANNEL 2 TONES MASTER BATTERY
PREVIOUS
USB SD/MMC CARD
NEXT
METER
MODE REPEATPLAY
PAUSE
ON
0 10 0 10-10 +10 -10 +10
1 2 3 4 5
6
7 8 9
10 12 13 14
11
11

20
EN
7FLASH: Press this button to cycle through dierent screen
eects.
• Moving transverse lights (non-reactive to music)
• Square lights wipe (non-reactive to music)
• Transverse lights wipe (non-reactive to music)
• Diagonal Light wipe (non-reac tive to music)
• Wavy Line (non-reac tive to music)
• Shimmering lights (non-reac tive to music)
• Pulsating bars (reac tive to music)
• O (no lights)
8 USB INTERFACE:
• Use this socket to connect your pen drive or external disk
to the unit using USB interface.
(Note: Mobile disk memory must be less than 64GB.)
• Connect your device's charge cable here to charge it. USB
charging only functions when the unit power is turned on.
9 SD CARD READER: Use this socket to connect your memory
card to the unit by SD card.
(Note: SD card memory must be less than 64GB.)
10 PREVIOUS BUTTON: Press to move the input to the previous
track in MP3 & BT mode, hold for a few seconds to search
backwards within the current track ( not included BT mode).
11 PLAY/PAUSE BUTTON: Press once to begin playing, Press
again to pause. ( USB priority)
12 NEXT BUTTON: Press to move the input to the next track in
MP3 & BT mode. hold for a few seconds
to search forwards within the current track( not included BT
mode).
13 MODE BUTTON: Press once to change the current access
device of the unit.
(USB interface - SD card reader - BLUE TOOTH) the unit
priority read USB interface, SD card reader
14 REPEAT BUTTON: There are 2 preset repeat modes. Press once
to repeat single, that "REP." will be lit at bottom right corner
of the screen. Press it again and unit will be on repeat all, that
"REP." will be put out.

21
EN
15 POWER SWITCH
Note: that while the unit is connected to a power source, it does not
need to be powered on to charge the battery. If the battery cannot
be continue to use, please contact Supplier open the hatch for
changing battery. Battery specications for 12VDC 5.0AH.
16 POWER CABLE INPUT (IEC): Insert the included power cable
here to charge the unit. that the unit can run o the power
adapter while it simultaneously charges the battery. The
charge indicator is lit when the battery is charging.
17 FUSE FOR AC POWER: Use this fuse to protect the unit & EXT.
power supply.

22
EN
GETTING STARTED
Battery charging
This device is equipped with a with a rechargeable battery. The batty will be
charged automatically as soon as the device is connected to power. After
recharging, the device switches to trickle charging. However, do not leave
the device constantly connected to a socket. Turning o the device via
remote control switches it to standby mode, which consumes more power
than switching it completely o at the panel of the appliance.
ATTENTION: Before rst use, fully charge the battery for at least 8
hours. Only after having charged the battery for 3 times, the battery
reaches its full capacity.
Charge the battery before and after each usage for a lasting battery
performance.
When the unit is turned o using the remote control, it is still in standby
mode and consumes more power than when turned o completely.
Be sure to fully charge the unit's internal battery before using it for the rst
time on the move (without AC power).
Connect the device to an ordinary wall socket via power adapter. The
charging time is about 5.8 hours. The state of charge is indicated by the LED
on the back. The LED will got out when the batty is fully charged.
Microphone Use
Unscrew the battery cover on the lower part of the microphone. Insert 2
batteries and mind the polarity.
Set the volume to the minimum. Power the system on so that the power
LED lights up. Switch the microphone on and set the volume control to the
desired position.
Check for microphone feedback (howling). Reduce the treble signal. If the
problem still occurs, reduce the speakers or move the audio system. Do not
hold the microphone near the speakers.

23
EN
BT CONNECTION
1. Turn on your BT device.
2. Power on the unit. If you have previously connected to another BT
device,the unit will reconnect.
3. Navigate to your BT device's setup screen, nd "Moving-80.2" speaker"
and connect.
(Note: If your BT device prompts for a pairing code, enter "0000".)
4. To disconnect pairing while the BT icon is lit solid, press the mode
button.
5. To connect to another BT device, repeat step 3.
TROUBLESHOOTING
Problem Solution
Distorted sound Try lowering the volume control
of your sound source, musical
instrument,
or microphone. Also, try to
reduce the overall volume of the
unit using the Master Volume
knob.
Too much bass Try adjusting the tone or EQ
control on your sound source to
lower the bass
level. This will allow you to play
the music louder before clipping
distortion occurs.
High-pitched whistling nose
when using the microphone.
This is probably feedback. Point
the microphone away from the
speaker.
