INSTALLATION, OPERATION AND MAINTENANCE INSTRUCTIONS
FREEZE RESISTANT WALL MOUNTED EMERGENCY EYE/FACEWASH
TECHNICAL ASSISTANCE TOLL FREE TELEPHONE NUMBER
1.800.591.9360
TECHNICAL ASSISTANCE FAX: [phone]
ACORN SAFETY
P.O. BOX 3527
CITY OF INDUSTRY, CA 91744-0527
UNITED STATES OF AMERICA
Manual #7109-516-001
MODELS: S0420-FRV / S0440-FRV
NOTES TO THE INSTALLER:
1. Please leave this documentation with the owner of the fixture when finished.
2. Please read this entire booklet before beginning the installation.
3. Check your installation for compliance with plumbing, electrical, ANSI Z358.1 and other
applicable codes.
Acorn Safety a division of Acorn Engineering Company™
Revised: 06/01/2022

Installation & Operation Manual
PRELIMINARY STEPS
1. Read the installation instructions prior to beginning the installation.
2. Separate parts from packaging and verify all necessary parts are accounted for and undamaged. Obtain missing or
damaged parts from Acorn Safety prior to beginning installation.
3. Flush water supply lines prior to installation. This will remove unwanted debris from the lines and prevent unwanted
blockages in the safety equipment.
4. In order to comply with ANSI Z358.1, the safety equipment must be inspected periodically. An inspection tag is provided for
documentation purposes.
5. All employees at risk of contamination should be informed and trained in the use of this and any other safety equipment.
The signage provided should be posted appropriately in close proximity to this equipment.
Acorn Safety a division of Acorn Engineering Company™
Page 2 of 5 Revised: 06/01/2022
Manual #7109-516-001
S0420-FRV & S0440-FRV
ROUGH-IN
*325
8"
(829)
11
4"
OD
TAILPIECE
51
4"
(133)
*331
4"
(845)
SUPPLY
*373
4"
(959)
*39"
(991)
EYE/FACE
DISCHARGE
85
8"
(219)
1/2" NPT
SUPPLY
* 325
8"
(829)
REF
1"
(25)
FINISHED
FLOOR
MOUNTING DETAIL
1/4" NPT DRAIN
DOWN VALVE
Ø113
4"
(298)
141
2"
(368)
STRAINER
8"
(203)
REF.
FINISHED
WALL
4x Ø 3/8" (10)
MTG HOLES
GENERAL NOTES:
1. ALL DIMENSIONS ARE IN INCHES (MM).
*2. DIMENSIONS SHOWN ARE FOR REFERENCE FOR NORMAL ADULT HEIGHT. ANSI Z358. 1
REQUIRE NOZZLES TO BE BETEWEEN 33" AND 45" ABOVE THE FLOOR.
41
8"
(105)
Ø1/2" (13) ACTIVATION
ROD OPENING
FINISHED
FLOOR
Ø7/8" (22) OPENING
FOR 1/2" SUPPLY
*293
4"
(756)
47
8"
(124)

Installation & Operation Manual
Page 3 of 5
Acorn Safety a division of Acorn Engineering Company™
INSTALLATION INSTRUCTIONS:
Supplies required: (not provided by Acorn)
1. Wall fastener anchors, washers and bolts for eyewash
assembly.
(Machine threads or lag bolts based on construction.)
2. Pipe sealant or Teflon tape for sealing water
connections.
IMPORTANT: FLUSH WATER SUPPLY LINES PRIOR
TO CONNECTION TO SAFETY EQUIPMENT.
NOTES:
— Top of spray nozzles must be between 33”- 45” from
finished floor in order to meet ANSI Z358.1
— Use hand tools and wrenches in a manner which will
prevent marring finished surfaces. Strap wrenches or
tools with plastic jaw linings are highly recommended.
— Refer to Rough-in for location of supply and drain lines.
— Fragments of Teflon tape or pipe sealant residue can
interfere with the proper operation of this unit. Ensure
pipe sealant methods do not cause contamination in the
system.
STEP ONE: MOUNTING
1. Position assembly on wall at appropriate height and in
proximity to the supply and drain lines.
2. While holding the assembly level against the wall, mark
position of mounting bolt holes.
3. Remove assembly and install appropriate anchors into
wall to receive 3/8” diameter bolts (supplied by others).
4. Re-position assembly against wall and install 3/8” bolts
to secure the assembly to the wall.
5. Assemble activation rod to valve bracket and secure
with nut. See detail “A”.
6. Assemble activation paddle to activation rod and secure
with provided screws. See Detail “B”
STEP TWO: SUPPLY LINE
1. Install water line (Supplied by others), in a position, to
align with ½” ball valve as shown in Rough- in.
2. Make connection to ½” NPTF ball valve with appropriate
fittings (Supplied by others)
3. Open water supply.
4. Test for leaks, proper operation and flow.
STEP THREE: SIGNAGE & INSPECTION
1. Position sign with clear visibility, in close proximity to
safety equipment and mark mounting hole locations.
2. Select appropriate ¼” anchors, screws and washers
(Supplied by others) to install signage.
3. Attach inspection tag supplied, with plastic zip tie.
NOTE:
REFER TO ANSI 2358.1 FOR SIGNAGE AND LIGHTING
REQUIREMENTS.
DETAIL "A" DETAIL "B"
Revised: 06/01/2022
Manual #7109-516-001
DETAIL "A"
DETAIL "B"
MOUNTING
SCREWS(PROVIDED
BY INSTALLER)
MOUNTING
HARDWARE
(DETERMINED
AND PROVIDED
BY INSTALLER)
1-1/4" OD
TAILPIECE

Installation & Operation Manual
Page 4 of 5
Acorn Safety a division of Acorn Engineering Company™
OPERATION INSTRUCTIONS:
Employees who work with hazardous materials should
become familiar with the location and operation of the
nearest emergency plumbing fixture. Emergency plumbing
fixtures stations are simple to use and require hands free
operation once the station is activated. Regular instruction
regarding proper care and use will increase confidence
that the units are accessible and function properly.
The route and area surrounding the Eye/Face Wash
should be clear and unobstructed; the sooner eyes are
flushed, the less likelihood of damage. Eye/Face Wash
stations should be located in close proximity to the hazard
and take no more than 10 seconds to reach. In the case of
sever eye contamination the victim may require assistance
to the Eye/Face station and help flushing their eyes.
Safety plumbing fixture equipment should be operated
weekly for a period long enough to verify operation, clear
the supply line of any sediment build-up and minimize
microbial contamination due to sitting water.
1. To start the Eye/Face, push activation paddle from the
horizontal to vertical fully “ON” position. Flushing should
start, popping the spray nozzle caps open.
2. Lower both eyes into flow. Both eyes should be flushed
to prevent contamination from one eye from being
delivered to unaffected eye. Personnel who wear
contact lenses should remove them immediately prior to
or during the flush to prevent the contamination from
remaining against the cornea possibly causing
unnecessary damage or pain.
3. Using thumb and forefingers, fully open eyelids and
flush eyes thoroughly for approximately 15 minutes or
until medical personnel arrive. Be prepared to let the
doctor know what type of contamination has entered the
eye.
4. When finished return the push paddle to the horizontal
or fully “OFF” position. Flushing fluid should stop. Once
flushing fluid has stopped flowing, return spray nozzle
lids to the closed position to protect from airborne
contaminates.
MAINTENANCE GUIDE:
Maintain and inspect in accordance with ANSI Z358.1
1. Check for obvious signs of wear, broken or defective
equipment. Re-paint if necessary. Replace missing or
defective equipment such as broken push paddles,
missing signs and inspection tags.
2. Remove strainer and washout any debris collected
–replace as required.
3. Operate Eye/Face Wash nozzles using the push paddle
to place ball valve in the fully “ON” position checking for
smooth operation of valve push paddle mechanism at
the same time ensuring that the Eye/Face spray nozzle
caps pop off immediately when actuated. If the ball
valve does not operate smoothly check the actuating
assembly for binding or missing parts. If the Eye/Face
spray nozzle caps do not pop off immediately when
actuated check for correct supply inlet pressure.
4. While in operation, inspect spray nozzles for clogs or
debris correct or replace as required.
5. Return push paddle to vertical or fully “OFF” position
and swing back to stand by position. To prevent
Eye/Face Wash spray nozzles from becoming
contaminated, always close nozzle lids after each
use.
Revised: 06/01/2022
Manual #7109-516-001

Installation & Operation Manual
PARTS LIST
Page 5 of 5
Acorn Safety a division of Acorn Engineering Company™
Revised: 06/01/2022
Manual #7109-516-001
17
11
12
19
14
13
16
15
20
18
1
2
3
4
5
6
7
9
10
8
ITEM PART NUMBER DESCRIPTION ITEM PART NUMBER DESCRIPTION
7101-104-001 EYE/FACEWASH NOZZLE
97000-020-199 JAM NUT
7101-058-001 FACEWASH NOZZLE W S/S LID
10 7100-113-001 1-1/4OD x 2.75 CHROME TAILPIECE ASSY
7101-003-001 YOKE STEM ASSEMBLY
11 7100-140-001 STRAINER ASSY
7101-003-002 YOKE STEM ASSY S0430-CS1-SSE
12 7100-314-000 1/2"-14 NPT GALV. TEE MxFxF
37100-108-000 BOWL STRAINER 13 7101-001-000 1/2 BALL VALVE, CHROME PLATED BRASS
7101-005-000 PLASTIC BOWL
14 7101-231-199 1/2"NPTM x 1/4"NPTF DRAIN DOWN VALVE
7101-008-000 S/S BOWL
15 7101-224-199 FRV ACTIVATION VALVE BRACKET
7101-046-000 PLASTIC BOWL GASKET
16 0304-007-000 5/16"-18UNC ZINC PLATED HEX NUT W/NYLOCK
7101-048-000 S/S BOWL GASKET
17 7101-700-022 3/8" X 17.19" NPT PIPE, YELLOW
7101-054-022 DRAIN CASTING, YELLOW
18 7101-040-003 FRV ACTIVATION ROD ASSY
7101-054-199 DRAIN CASTING, UNPAINTED
19 2725-501-000 INVERTED UMBRELLA DIAPRAGM
77101-006-199 WALL MOUNTING BRACKET 20 7100-402-000 SAFETY EYEWASH PLACARD
87100-401-000 INSPECTION TAG
