Acorn DC-360 User manual

Model: DC-360
Instruction Manual
Attention:
This appliance is not intended for use by persons (including children)
with reduced physical, sensory or mental capabilities or lack of
experience and knowledge unless they have been given supervision or
instruction concerning use of the appliance by a person responsible for
their safety. Children should be supervised to ensure that they do not
play with the appliance.

1
CONTENTS:
1. Safety Precaution .................................................................
2. Fan Structure Drawing (Hugger/Flush Mount) ………………....
3. Fan Structure Drawing (Wall Mount) ……………..………………...
4. Method of Installation –Hugger/Flush Mount
a) Installation of Hanger Bracket ……..................................
b) Installation of Canopy …………………………………………………
c) Pre-fix the Fan ……………………………………………………………
d) Wiring of Fan ………………….…………………….……………………
e) Installation of Fan ……………………………………..……………….
5. Method of Installation –Wall Mount
a) Installation of Hanger Bracket ……..................................
b) Installation of Downrod …..……………………………….………..
c) Hanging of Fan ………………………………………….……………….
d) Wiring of Fan ………………….……………………….…………………
e) Installation of Canopy …………………………………………………
6. Installation of Fan Blades ………………………………………………….
7. Remote Control Manual (Wiring Diagram) ……………………….
8. Remote Control Manual (Button Function) ……….………………
9. Maintenance Tips ………………………………………........................
10. Troubleshooting ….................................................................
11. Notes ………………....................................................................
Page 2
Page 3
Page 4
Page 5
Page 5
Page 6
Page 7
Page 7
Page 8
Page 8
Page 9
Page 9
Page 10
Page 10
Page 11
Page 12
Page 13
Page 14
Page 15

2
SAFETY PRECAUTION:
TO REDUCE THE RISK OF PERSONAL INJURY, DO NOT BEND THE
BLADES BRACKETS DURING ASSEMBLY OR AFTER INSTALLATION.
DO NOT INSERT ANY OBJECTS IN THE PATH OF THE BLADES.
TO REDUCE THE RISK OF SHOCK, THIS FAN MUST BE INSTALLED
WITH AN ISOLATION WALL CONTROL / SWITCH.
WARNING
IMPORTANT: PLEASE READ BEFORE INSTALLATION
1. The installation work must be carried out by a qualified wiring installer.
2. Turn off the Electrical Main Switch at the circuit breaker fuse box.
3. Using power supply 220 –240V~/50Hz.
4. When mounting the fan, to ensure the safety cable is loop across the
ceiling mounting ‘J’ hook.
5. The ceiling fan & wall fan must be mounted so that the blades are more
than 2.3 meters above the floor.
6. Do not insert any objects in the path of the blades.
7. When all electrical connections are done, store all wires neatly.
8. Make sure all screws and connections are tightly screwed and secured.
9. The supply wires live and neutral must be connected to a double pole
switch having a contact of at least 3mm in all poles.

3
FAN STRUCTURE DRAWING (Hugger / Flush Mount):

4
FAN STRUCTURE DRAWING (Wall Mount):

5
METHOD OF INSTALLATION –HUGGER / FLUSH MOUNT
1) To use Four Expansion Setscrew to install the hanger bracket firmly (fig 1).
2) Install the ‘J’ hook onto the concrete ceiling and fasten firmly. Note the
place of ‘J’ hook as (fig 2).
fig 3
fig 1
1) Remove the two setscrews, three screws and reinforced piece as (fig 3).
2) Install the canopy to the main body with the three screws and reinforced
piece as (fig 4).
3) Keep the two setscrews which will not be used.
INSTALLATION OF CANOPY:
fig 4
fig 2
INSTALLATION OF HANGER BRACKET:

6
PRE-FIX THE FAN:
fig 5
1) Remove the Two screws from the hanger bracket (fig 5). It will be used on
step ‘INSTALLATION OF FAN’.
2) Attach the safety wire cord to the expansion ‘J’ hook for safety purposes.
Tighten the nuts firmly (fig 5).

7
WIRING OF FAN:
fig 7
fig 6
INSTALLATION OF FAN:
1) Total three groups of wires from the
top of the main body:
•White, Blue wires with small
connector - for Synchronous Motor
•Black(L1), Red (L2), Brown (L3)
wires with big connector - for fan
•Green/Yellow - ground wire
2) Plug the connector from the main body into the remote control receiver:
big connector to big socket & small connector to small socket.
3) Connect remote control receiver wires to AC wires: White to Neutral,
Black to Live, Green/Yellow to Ground.
4) Earth wire is longer than safety cord by 60mm and more. When the
failure of the suspension system occurs, the current carrying conductor
taut before the earthling conductor and the body of the fan assembly is
still effectively earthed.
1) Unscrew the two screws from the
hanger bracket out by ½ (fig 7).
2) Aligned and insert the canopy ‘L’
shape groove to the hanger bracket
screws, twist until it held tight.
3) Fix back the two screws which were
removed earlier during step ‘PRE-FIX
THE FAN’ to the hanger bracket hole
and tighten all the four screws firmly
(fig 7).

8
fig 8
1) Use four Expansion Setscrew to install
the hanger bracket to the wall firmly
(fig 8).
Note: The hanger bracket must be
vertical to the floor.
METHOD OF INSTALLATION –WALL MOUNT
INSTALLATION OF HANGER BRACKET:
fig 9
1) Remove the ‘R’ pin, nut and cross pin from the downrod.
2) Install the canopy and decorative cover through the downrod then thread
the wires through the downrod, insert the downrod into the coupler as
(fig 9).
3) Install back the cross pin, nut and secured with the ‘R’ pin. The ‘R’ pin
must be properly installed to prevent the cross pin from working loose.
Tighten the two setscrews on the coupler (fig 10).
INSTALLATION OF DOWNROD:
fig 10

9
HANGING OF FAN:
fig 11
3) Install back the cross pin, nut and secured with the ‘R’ pin. The ‘R’ pin
must be properly installed to prevent the cross pin from working loose.
Tighten the screws on the coupler through the downrod. Tighten the two
setscrew on the coupler (fig 11).
WIRING OF FAN:
fig 12
1) Connect the motor wires, receiver wires and AC wires, follow step
‘WIRING OF FAN’ on page 7.
1) Remove the ‘R’ pin, nut and
cross pin from the coupler
on the hanger bracket.
2) Thread the wires through
the coupler and insert the
downrod into the coupler
(fig 11).

10
INSTALLATION OF CANOPY:
fig 13 fig 14
1) Remove the two screws from the hanger bracket and unscrew the other
two screws from the hanger bracket out by ½. (fig 13)
2) Align and insert the canopy ‘L’ shape groove onto the hanger bracket
screws, twist until its held tight.
3) Install back the two screws which were removed on step (1) to the hanger
bracket hole and tighten all the four screws firmly. (fig 14)
INSTALLATION OF FAN BLADES:
1) Remove the nut from the motor.
2) Insert the fan blades and nut to the
motor shaft pin. Tighten the nut
firmly (fig 15).
3) Install and tighten the blade cap.
fig 15

11
REMOTE CONTROL MANUAL (Wiring Diagram):
1. This manual is to use for the controller of fan.
2. Disconnect power supply before wiring.
3. Install the Receiver inside the canopy of fan to ensure proper protection.
Adopt RF wireless digit emission technique, biunique controlled, coincident code rate
is less than one millionth.
Receiver can be controlled by any angles of the Emitter in prescriptive space and
unrestricted by direction.

12
REMOTE CONTROL MANUAL (Button Function):
Model: DC-FC989RS
(Emitter)
Fan OFF Button
360° Revolve Angle Control
(doublepresstochangedirection)
Natural Wind
Fan Speed
Timer
Light ON Button
Light OFF Button
LED Indicated Light
1.5V Battery x 2pcs
1
2
3
4
5
6
7
8
9
(notapplicable
forthismodel)
IMPORTANT:
1. Insert two size AAA alkaline batteries by matching and on the
batteries to the diagram inside the battery compartment of the remote
control.
2. Steps to pair the Emitter and Receiver:
i. Turn ‘ON’ the supply power.
ii. Within 30 seconds, press and hold the Emitter button ‘ ‘ for 5
seconds until hearing a long ‘beep’ sound.
iii. Pairing successfully (learning mode is not acceptable after turn ‘ON’
the supply power for more than 30 seconds).
3. When the Emitter cannot control the Receiver, check surrounding for any
existence of similar remote control products. Some interference might
occur when similar radio waves being transmitted.
4. Replace the batteries when found low in voltage as it will affected the
sensitivity of the Emitter.
5. Always remove the batteries from the Emitter when leaving unused for
long period of time.
-
+

13
MAINTENANCE TIPS:
1. Because of the fan’s natural movement, some connections may be loose.
To check the support connections, brackets and blades attachments 2
times a year. Make sure they are all secured (It is not necessary to
dismantle the entire fan from ceiling).
2. Clean your fan periodically to help maintain its appearance over the
years. Do not use water when cleaning, use only a soft brush or lint-free
cloth to avoid scratching the finish. The plating is coated with a lacquer to
minimize the ratio of discoloration or tarnishing which would damage the
motor or the wood or possibly cause an electric shock.
3. You can apply a light coat of furniture varnishing to the wood for
additional protection and enhance its beauty. Surface scratched mark can
be touch-up with a light coat of shoe polish.
4. There is no need to oil your fan. The motor is created with lubricated
sealed ball bearings.
5. User are advised to contact the fan supplier to conduct regular
examination of the fan suspension system at least once in every two
years.
WARNING
MAKE SURE THE POWER IS SWITCH OFF AT THE ELECTRICAL
PANEL BOX BEFORE YOU ATTEMPT TO ANY REPAIRS (REFER TO
THIS SECTION), MAKING ELECTRICAL CONNECTIONS.

14
TROUBLESHOOTING:
PLEASE CHECK THE FOLLOWING BEFORE LODGING A SERVICE REPORT
PROBLEM REASON SOLUTION
Fan not
moving
1) Main cables not
connected.
2) Check the line wires.
1) Check mains & sub circuit
breakers or fuse.
2) Check the line wires
connections to the fan &
switch housing.
Fan noisy 1) Housing screw
loose.
2) Wire nut
connections rattles
against each other.
3) Canopy touches the
ceiling.
1) Tighten all screws.
2) Separate & store neatly all
the wire nut connections.
3) Check & ensure the canopy is
not touching or too close to
the ceiling.
Remote
control
not
working
1) Remote & receiver
pairing out.
2) Battery not
installed.
3) Battery weak
1) Pairing required –follow
page 12, clause 2.
2) Install the remote control
battery.
3) Change new battery.

15
NOTES:
DRAWING SHOWING THE ASSEMBLY OF WIRES THROUGH
FAN MOTOR SHAFT FOR DECORATIVE CEILING FAN
