Acorn AC-268 User manual

Model: AC-268
Instruction Manual
Attention:
This appliance is not intended for use by persons (including Children)
with reduced physical, sensory or mental capabilities or lack of
experience and knowledge unless they have been given supervision or
instruction concerning use of the appliance by a person responsible for
their safety. Children should be supervised to ensure that they do not
play with the appliance.

1
CONTENTS:
1. Safety Precaution ...................................................
2. Fan Structure Drawing ...........................................
3. Installation of Hanger Hook …................................
4. Installation of Fan Blades …………………...................
5. Installation of Down Rod / Hanger Ball .................
6. Hanging of Ceiling Fan ...........................................
7. Wiring of Ceiling Fan …...........................................
8. Installation of Canopy ............................................
9. Installation of Lightkit ………………..……………….........
10.Maintenance Tips ..................................................
11.Troubleshooting .....................................................
12. Notes …………………………………………………………………
Page 2
Page 3
Page 4
Page 4
Page 5
Page 5
Page 6
Page 6
Page 7
Page 8
Page 9
Page 10

SAFETY PRECAUTION:
2
TO REDUCE THE RISK OF PERSONAL INJURY, DO NOT BEND THE
BLADES BRACKETS DURING ASSEMBLY OR AFTER INSTALLATION.
DO NOT INSERT ANY OBJECTS IN THE PATH OF THE BLADES.
TO REDUCE THE RISK OF SHOCK, THIS FAN MUST BE INSTALLED
WITH AN ISOLATION WALL CONTROL / SWITCH.
WARNING
IMPORTANT: PLEASE READ BEFORE INSTALLATION
1. The installation work must be carried out by a qualified wiring installer.
2. Turn off the Electrical Main Switch at the circuit breaker fuse box.
3. Using power supply 220 –240V~/50Hz.
4. When mounting the fan, to ensure the safety cable is loop across the
ceiling mounting ‘J’ hook.
5. The ceiling mounting hook must be able to withhold a min. of 35
pounds.
6. The ceiling fan must be mounted at a min. height of 2.3meters of
clearance from the floor.
7. Do not insert any objects in the path of the blades.
8. When all electrical connections are done, store all wires neatly.
9. Make sure all screws and connections are tightly screwed and secured.
10. The supply wires live and neutral must be connected to a double pole
switch having a contact of at least 3mm in all poles.

FAN STRUCTURE DRAWING:
3

4
INSTALLATION OF HANGER HOOK:
INSTALLATION OF FAN BLADES:
1) Install blade to blade bracket
using the supplied screws. Start
a screw into the bracket, repeat
for the two remaining screws.
(fig 3)
2) Tighten each screw securely.
3) Remove the three resistance
pieces and six screws off the
motor. (fig 4)
4) Assemble and attach the blade
bracket to the motor holes,
install with the six screws. (fig 4)
5) Tighten each screw securely onto
the motor. (fig 6)
6) Finished as fig 5.
fig 4
fig 3
fig 5
1) For Wood Ceiling: Install the hanger hook firmly onto the wood ceiling
with two screws (fig 1).
2) For Concrete Ceiling: To use two expansion setscrew to install the
hanger hook onto the concrete ceiling and fasten firmly (fig 2).
fig 1 fig 2

5
INSTALLATION OF DOWNROD / HANGER BALL:
HANGING OF CEILING FAN:
1) Remove the ‘R’ pin and Cross pin
from the downrod. Thread the
wires through the downrod,
insert the downrod into the
connector. (fig 6)
2) Loosen the two setscrews in the
downrod support. Install back
the Cross pin and secured with
the ‘R’ pin. (fig 7)
3) The ‘R’ pin must be properly
installed to prevent the Cross pin
from working loose. (fig 7)
fig 6
fig 7
1) Carefully lift the fan and
assembly into hanger hook which
is attached to the outlet box.
2) Ensure the hanger wheel is fix on
the hanger hook securely.
Attach the safety wire (cord) to
the expansion ‘J’ hook for safety
purposes. Tighten the nuts
firmly. (fig 8)
fig 8

6
WIRING OF CEILING FAN:
INSTALLATION OF CANOPY:
1) Total four colors of wires
connected from the top of the
motor:
* White –neutral wire
* Blue –live wire for lightkits
* Green –ground wire
* Red –live wire for fan
fig 9
2. Connect fan wires to ceiling wires: White to Neutral, Red to Live, Green
to Ground. If you opt for lightkit, then connect the Blue to Live. If not,
cap the Blue wire off with a connector.
3. After connecting the wires, spread them apart so that the Green & White
wires are on one side and the Red wire is on the other side (fig 9).
4. Earth wire is longer than safety cord by 60mm and more. When the
failure of the suspension system occurs, the current carrying conductor
taut before the earthling conductor and the body of the fan assembly is
still effectively earthed.
5. Place the remote receiver inside the canopy (refer to the remote control
manual for remote receiver installation).
1) After wiring done, lift up the
canopy towards the ceiling
and tighten with screw firmly
(fig 10).
fig 10

7
INSTALLATION OF LIGHTKITS:
1) Carefully attach the acrylic
light cover to the lightkit
and twist clockwise until its
secured tightly by the tabs.
(fig 11)
2) The finished products as
fig 12.
fig 11
fig 12

8
MAINTENANCE TIPS:
1. Because of the fan’s natural movement, some connections may be loose.
To check the support connections, brackets and blades attachments 2
times a year. Make sure they are all secured (It is not necessary to
dismantle the entire fan from ceiling).
2. Clean your fan periodically to help maintain its appearance over the
years. Do not use water when cleaning, use only a soft brush or lint-free
cloth to avoid scratching the finish. The plating is coated with a lacquer to
minimize the ratio of discoloration or tarnishing which would damage the
motor or the wood or possibly cause an electric shock.
3. You can apply a light coat of furniture varnishing to the wood for
additional protection and enhance its beauty. Surface scratched mark can
be touch-up with a light coat of shoe polish.
4. There is no need to oil your fan. The motor is created with lubricated
sealed ball bearings.
WARNING
MAKE SURE THE POWER IS SWITCH OFF AT THE ELECTRICAL
PANEL BOX BEFORE YOU ATTEMPT TO ANY REPAIRS (REFER TO
THIS SECTION), MAKING ELECTRICAL CONNECTIONS.

9
MAINTENANCE TIPS:
PLEASE CHECK THE FOLLOWING BEFORE LODGING A SERVICE REPORT
PROBLEM REASON SOLUTION
Fan not
moving
1) Main cables not
connected.
2) Check the line wires.
1) Check mains & sub circuit
breakers or fuse.
2) Check the line wires
connections to the fan &
switch housing.
Fan noisy 1) Housing screw
loose.
2) Wire nut
connections rattles
against each other.
3) Canopy touches the
ceiling.
1) Tighten all screws.
2) Separate & store neatly all
the wire nut connections.
3) Check & ensure the canopy is
not touching or too close to
the ceiling.
Remote
Control
not
working
1) Remote & receiver
code set differently.
2) Battery not
installed.
3) Weak battery.
1) Check & ensure both codes
are matching.
2) Install the remote control
battery.
3) Change new battery.

NOTES:
10
DRAWING SHOWING THE ASSEMBLY OF WIRES THROUGH
FAN MOTOR SHAFT FOR DECORATIVE CEILING FAN
