ACP MCS10DSE User manual

Refer to Product Safety Manual for Safety Statements
Complete Owner’s Manual available online
Quick Start Reference Guide
Oven Wall Clearances
A—Allow at least 2” (5.1 cm) of clearance
around top of oven. Proper air ow around
oven cools electrical components. With
restricted air ow, oven may not operate
properly and life of electrical parts is reduced.
B—There is not an installation clearance
requirement for the back of the oven.
C—Allow at least 1” (2.54 cm) of clearance
around sides of oven.
D—Install combination oven so oven bottom is
at least 3 feet (91.5 cm) above oor.
No metal pans
DO NOT power spray
So...how do I use it? (Electronic / Mechanical Dial)
Heating
1. Open oven door, place food in oven, and close oven door.
2. Select desired power level or use default 100%.
2. Turn time entry knob clockwise to desired time.
• Cooking time can be set up to 10 minutes.
• Oven begins operation and time counts down.
3. When cooking time has elapsed, microwave energy stops and oven
signal sounds.
Interrupting Operation
Open oven door to interrupt operation or turn time entry knob
counterclockwise to “0”.
To resume microwave oven operation, close door, select power level pad,
and turn knob.
Changing Time and Canceling Mistakes
Heating time and power level can be changed at any time while the oven is
operating. Press power level pad or turn knob to desired new setting. To set
cooking time to zero, turn knob counterclockwise to “0” or cycle door open
and closed.
C
A
B
Accelerated Cooking Products
0
1
15
15
30
30
45
45
2:00
1:00 - 2:00
:30
:15
:45
1:30 - 2:30
2
3
4
5
6
7
8
9
10
Menu Guide
20% 50% 70% 100%
20%
70% 100%
50%

 2017 ACP , Inc.
Cedar Rapids, Iowa 52404
Part No. 20120206
Revised 12/2017
For full product documentation visit:
www.acpsolutions.com
Refer to Product Safety Manual for Safety Statements
Complete Owner’s Manual available online
Quick Start Reference Guide
Changing Timer Option
Timer resetting to zero can be set at any time to pause current cook time and power level when door is opened. To
change this option follow the step below.
• With door open press and hold the 100% pad 100% for 5 seconds until beep is heard. Close the door this
changes timer setting to pause current cook time and power level when door is opened.
Timer pausing current cook time and power level can be set at any time to reset to zero and 100% power level when
door is opened. To change this option follow the step below.
• With door open press and hold the 20% pad 20% for 5 seconds until beep is heard. Close the door this
changes timer setting to reset timer to zero and power level to 100% when door is opened.
The switching operation of this microwave oven can cause voltage uctuations on the supply line. The operation of this oven under unfavorable voltage
supply conditions can have adverse e󰀨ects. This device is intended for the connection to a power supply system with a maximum permissible system
impedance Zmax of 0.2 Ohms at the interface point of the user’s supply. The user has to ensure that this device is connected only to a power
supply system which fullls the requirement above. If necessary, the user can ask the public power supply company for the system impedance at
the interface point.
