ACRITEC B03 Series User manual

IMPORTANT
Thoroughly inspect your product before proceeding with the installation.
The warranty will be void if the product is installed with a conspicuous defect.
CAUTION
To prevent leaks, silicone must be applied on the outside of the shower and not on the inside!
Read all instructions carefully before starting the installation.
Save this manual for future reference.
INSTALLATION MANUAL
B03 Series
Single Threshold Sliding Bypass Door
Updated: 2021/05/14

No.
Name
Qty
No.
Name
Qty
1
Wall profile UR
2 10
Guide block
1
2
Door panel
2 11
Bottom track cover, right
1
3
Wall plug
6 12
Roller cover
4
4
Bumper block
6
13
Roller
4
5
Handle
2
14
M5*16grub screw
4
6
ST4*30 Screw
6
15
Top track cover
2
7
Bottom track cover
1
16
Top track
1
8
Bottom track
1
17
Ø10 cover cap
2
9
ST4*10 Screw
2
PARTS LIST
2

TOOLS AND MATERIALS REQUIRED
DRILL SILICONE
PRECISION KNIFE
MEASURING TAPE MALLET
LEVEL
SCREWDR
PENCIL
SET SQUARE
SCREWS
DRILL BITS: 1/8" / 1/4"
*MASONRY DRILL BIT
3
COMPONENT LIST
Roller
x4
Handle
x2
Cover cap
x2
M5*16 Grub screw
x4
Roller cover
x4
Screw
x2
Screw
x6
Wall plug
x6
2.5mm hex wrench
x1
4mm hex wrench
x1
Top track cover
x2
Bottom track cover
left x1
Bottom track cover
right x1
Bumper block
x6
Guide block
x1

WALL JAMB INSTALLATION
4
TRAY MUST BE 100% LEVEL IN ALL DIRECTIONS
Ensure the shower tray is level in all direction and
is properly sealed to the wall. The wall must be
tiled down to the bottom edge of the tray. Do not
angle up bottom tile.
TRAY MUST BE SEALED FULLY AROUND WHERE
THE TRAY MEETS THE WALL.
IMPORTANT
1. Ensure the top surface of the shower tray on which the enclosure which be installed is level in every
direction.
2. The tiling or other wall finishing should be effectively sealed at the tray edges.
3. Tiles should extend at least to the corners of the tray and a minimum of 2.1m from top of the tray.
6
A1=A2
INSTALLATION SITE
Move the two wall profiles to the installation position. The outer edge of the wall profile is
flush with the shower tray.
After the wall profile is adjusted to be perpendicular to the ground, a line is drawn on the wall
to mark the drilling position. Note: When marking the drilling position, make sure it is in the
center of the aluminum screw hole for easy installation and adjustment. Drill a hole of 06 at
the marking on the wall, and put in the wall plug.
1

CONTINUED
5
Put the top track on the wall and install the door panel:
1. Install the rollers to the door panel;
2. Hang the door panel on the inner groove of the top track;
3. Install the lower slide block on the bottom tracm;
4. Adjust the glass height and ensure glass is level.
2

CONTINUED
6
Adjust gap between guide block and glass.
1. lnstall handle.
2. lnstall grub screw to roller bracket, tigeten and install cover cap.
3. lnstall top/bottom track covers.
4. lnstall roller cap.
3

CONTINUED
7
Apply silicone to inside and outside of the shower enclosure.
Do not use the enclosure for 24 hours after sealing.
4

Acritec Industries Corp.
27049 Gloucester Way
Langley, B.C. V4W 3Y3
Tel: [phone]
Fax: [phone]
Email: [e-mail]
Website: www.acritec.com
