OVE ANTIGUA 48 User manual

12015-05-18
Opening
470
[18 1/2]
550
[21 5/8]
CSA Markings
2000
[78 3/4]
1219
[48]
Measures: millimeter [inch]
ANTIGUA 48
2800 Etienne Lenoir, Laval
Quebec H7R 0A3 Canada
Purchase date: _________________________ Product Tracking Reference: ________________________
Questions, problems, missing parts?
Before returning to your retailer, call our customer service department at
1-866-839-2888, 9 a.m. - 5 p.m., EST, Monday - Friday

2
TABLE OF CONTENT
PACKAGE CONTENT.......................................................................................................................................... 4
HARDWARE CONTENT...................................................................................................................................... 5
TOOLS REQUIRED............................................................................................................................................. 5
SAFETY INFORMATION..................................................................................................................................... 6
PREPARATION.................................................................................................................................................... 6
SHOWER REVERSIBILITY.................................................................................................................................. 7
WALL TO WALL MEASURES............................................................................................................................. 7
BASE INSTALLATION GUIDELINES (OPTIONAL)............................................................................................ 8
WALL TRACK INSTALLATION........................................................................................................................... 9
FIXED PANEL AND SUPPORT BAR INSTALLATION...................................................................................... 10
DOOR PANEL INSTALLATION......................................................................................................................... 13
HANDLE INSTALLATION & SEALING.............................................................................................................. 15
CARE AND MAINTENANCE............................................................................................................................. 16
LIMITED 5 YEARS WARRANTY........................................................................................................................ 16

3
PACKAGE CONTENT
B
DE
C
F
G
H
J
M
R
N
Q
U
T
O
P

4
PACKAGE CONTENT
PART# DESCRIPTION QTY CODE
B Wall track 1 99STR2020-WM
C Fixed panel 1 99SG10049-WM
D Support bar’s anchor 2 99SGC0038-WM
E Shower door stopper 1 99SDS0008-WM
F Support bar 1 99SGS0024-WM
G Fixed panel’s bracket 1 99SGC0039-WM
H Door roller 2 99SWE0021-WM
J Door panel 1 99SGD0034-WM
M Door handle 1 99SHA1034-WM
N Fixed panel’s bottom seal strip 1 99SRU0131
O Door bottom seal strip 1 99SRU0132
P Glass panels vertical seal strip 2 99SRU0024
QSliding door guide (with its rubber tting) 1 99SGC2037-WM
R Door panel vertical seal strip 1 99SRU0023
T Decorative end cap 2 99SHW0101-WM
U Decorative track 1 99STR1070-WM
V Hardware content 1 99SHW0068-WM

5
HARDWARE CONTENT
CC
FFEE
AA
GG
BB
Screw
ST4x20mm
2+1
Wall Anchor
ø8x30mm
5+1
Screw
ST5x40mm
2+1
Cap
3x Fitting
3x
TOOLS REQUIRED
Pencil Screwdriver Level
Measuring Tape Silicone Rubber mallet Cutter
Safety glasses
Screw
ST5x30mm
3+1
DD
Screw
ST4x12mm
3+1
HH
Cap
2x
Allen key
2mm & 2.5mm & 4mm & 5mm 5mm Bit socket
Drill with ceramic tile bits
ø3mm (1/8in) & ø8mm (5/16in)

6
Please read and understand this entire manual before attempting to assemble, operate
or install the product.
WARNING
• Distributor is not responsible for any damage to the unit or personal property caused
by improper installation. If you disregard instructional warnings, you will void your
warranty and possibly deal with water damage.
CAUTION
• Carefully remove product from packaging and keep packaging until installation is
complete.
• Inspect all parts for damage; if there is damage to the unit prior to installation,
please contact customer service at the number provided in this guide.
• Install the shower on a oor that is level and able to accommodate the weight of the
unit and an occupant.
• Please, consult local building codes and compliance standards prior to installation
and ensure conformity.
SAFETY INFORMATION
PREPARATION
Before beginning assembly of product, make sure all parts are present. Compare
parts with package contents list and hardware contents list. If any part is missing or
damaged, do not attempt to assemble the product.
Estimated Assembly Time 60min.
Handle the tempered glass with caution! Improperly handling the glass can
cause it to break suddenly in small pieces (never in pointed fragments).
Dot NOT put glass panels on hard surfaces, always work on clean and soft
surface (e.g. towel). Shattering may occur otherwise!
HEAVY PRODUCT! You will need at least two people to install this
unit properly.

7
• This instruction is drawn up for an opening from right to left (see illustration B).
• For an installation from left to right (see illustration A), use the same instructions, but switch around the
panels: mirror effect.
SHOWER REVERSIBILITY
A B
WALL TO WALL MEASURES
• Measure the thickness of your tiles on either side before installing the metal tracks. A thicker tile will limit
your space to install the shower panels.
• Make sure to have a tile to tile distance (D) between 1173mm (46 3/16 in) min. and 1188mm (46 3/4 in)
max. (see image).
Make sure to have a distance (D) from the left side tile
to the right side tile:
D Min: 1173mm (46 3/16 in)
D Max: 1188mm (46 3/4 in)
If D < 1173mm (46 3/16 in) you can cut the support
bar to adequate size.
Install the shower head on the door’s side! This will reduce the risk of leaking.

8
BASE INSTALLATION GUIDELINES (OPTIONAL)
1 2
4
Tile Wall
Studs
Drywall
Silicone
5
Shower Base
3
Shower Base
Cement
Floor
Wood shim
Flange
Stud
Drywall
Silicone
Flange

9
1. Ensure the base and wall are leveled. Place the metal track (B) approximately 24mm (15/16in) from the
edge of the base to the center of the metal track. Ensure the metal track (B) is leveled, then mark the holes
clearly on the wall.
2. Remove track and drill pilot holes in the marked locations with a Φ8mm (5/16in) drill bit.
3. Insert the wall anchors (AA) using a rubber mallet until the wall anchors are ush with the wall.
4. Replace and secure the metal track (B) with screws (BB). Do not overtighten.
WALL TRACK INSTALLATION
Φ 8mm
5/16in
Helpful Hint
Do not overtighten!
This may crack the
acrylic or tile walls.
AA
2
3
Helpful Hint
Make sure there
is a support stud
located behind the
drywall, behind the
tracks!
24mm
15/16in
BB
4
B
1

10
1. Insert the xed panel’s bottom seal strip (N) at the base of the xed panel (C). With a cutter, cut the surplus to
adequate size.
2. Insert the xed panel (C) into the metal track (B). Do not fully tighten it as further adjustments may be required.
Note: The wall track (B) allows you to adjust the position of the xed panel (C). Adjusting the depth and/or
giving the xed panel a slight angle allows for precise alignment with the door.
3. Smoothly slide the guide (Q) at the bottom of the xed panel (C) without securing.
4-5. Install the door stopper (E), door rollers (H), xed panel’s bracket (G) and the support bar anthors (D) onto the
support bar (F).
6. Loosely mount the support bar (F) onto xed panel (C) using the brackets (G) and level it.
7. Mark the positions of holes of the sliding door guide (Q).
FIXED PANEL AND SUPPORT BAR INSTALLATION
Q
B
C
C
N
2
3
C
57
Q
6
1
H
E
F
G
D
DCG
4
F

11
1-2. Place the support bar (F) in order to align the bracket (G) in front of the the xed panel’s hole. Position the
support bar in so that distance A and B are the same. Mark the outline of the 2 support bar’s anchors (D) on the wall.
3-4. Completely remove the support bar (F) and the xed panel (C).
5. Drill a pilot hole for the sliding door guide (Q) using a ø3mm (1/8in) drill bit.
6. Install the sliding door guide (Q) with the screw (CC) and the cap (HH).
FIXED PANEL AND SUPPORT BAR INSTALLATION
Φ3mm
1/8in
CC
Q
Helpful Hint
Add a drop of
silicone in the
holes before
inserting the
screws
A
B
A
B2
5
1
4
C
B
6
HH
CD
G
C
CG
F
3
FF

12
1. Place the 2 support bar’s anchors (D) back on their wall mark, then mark their center on the wall.
2-4. Drill a hole on the center marks with a ø8mm (5/16in) drill bit and insert the wall anchors (AA) using a rubber
mallet. Fix the center tting on the support bar’s anchor (D) using the screws (GG).
5-6. Insert the xed panel (C) into the metal track (B). Then x the support bar to xed panel (C) by the xed panel’s
bracket (G).
7. Secure the support bar (F) on their anchors using the provided hex screws. Position the roller stopper (E) in order
to block the door panel (J) from hitting the wall when opening it. Use the Allen key to strongly secure the stopper when
the nal position is found.
FIXED PANEL AND SUPPORT BAR INSTALLATION
Φ8mm
5/16in
2
6
AA
3
B
C
5
1
4
7
D
D
GG
D
E
C
G
F

13
1. Insert the door bottom seal strip (O) onto the door panel (J).
2-3. Install the door panel by its 2 rollers (H) on the support bar (F) and make sure to place the bottom of the
door inside the guide (Q).
4-5. Install the 2 glass panels seal strips (P).Install the door’s vertical seal strip (R) on the closing end.
6. Using silicone, install the decorative track (U) in front of the door panel. Slide the decorative end caps (T)
onto the track.
DOOR PANEL INSTALLATION
T
U
6
12
5
34
C
Q
J
J
OJ
R
J
P
C
J
H

14
1. Remove the cover of the rollers (H) and Loose the screws a little bit.
2. Adjust the level of the glass panel using the eccentric mechanism of the rollers.
3. Tighten the screws and install the cover of the rollers (H).
4-5. Drill the xed panel (C) on 3 positions with a ø3mm (1/8in) drill bit. Level the xed panel (C) and x it with
the ttings (FF), the screw (DD) and the cap (EE).
DOOR PANEL INSTALLATION
1
3
5
2
4
H
H
H
C
Φ3mm
1/8in
FF
EE
DD

15
HANDLE INSTALLATION & SEALING
1. Install the door handle (M) on both sides using Allen keys.
2. Ensure that the door closes tightly and opens smoothly, and that there is a tight connection between the side
glass panels and the frame as well as the support bar.
Apply a clear silicone water sealant around the outside perimeter of any xed shower components (horizontally
between bottom of xed side glass panel and base, as well as vertically between the wall, glass frames, and
any side glass panel).
Allow 24 hours for silicone to dry.
Improper application of silicone sealant may cause your shower to leak.
M
1
2

16
CARE AND MAINTENANCE
For the daily maintenance, use a wet cloth and a soft liquid cleaner.
Never use abrasive cleaners containing some acetone, chlorine or strong bleach, scrapers, metallic brushes,
nor other objects or the products which can graze or tarnish surfaces.
Use a ratchet to strongly tighten any bolts used to support the xed glass panels or doors panel (support bolts
can withstand up to 250 lbf*in of torque).
Check these bolts every 4 months and re-tighten them if necessary.
LIMITED 5 YEARS WARRANTY
This warranty extends only to the original owner lend-user for personal household use only. For commercial
uses, additional limitations may apply.
Distributor warrants your satisfaction with each shower. Should any shower not meet your satisfaction due to
a visual defect, simply return it to your retailer with the original packaging, PRIOR TO INSTALLATION, for a
replacement.
Distributor warrants shower doors to be free from defects in workmanship and materials under normal use and
service for a period of ve (5) years.
Distributor warrants acrylic surface against blistering or cracking and chipping resulting from defect in the
acrylic surface material when used under normal conditions and service for a period of ve (5) years from
purchase date.
Distributor further warrants the structure of the acrylic shell against loss of water through berglass laminate of
the acrylic body as a result of defect in materials and workmanship for a period of ve (5) years from purchase
date.
Distributor warrants, shower hardware (handles, hinges, rubber support clips, metal support bars and wall
tracks) to be free from defects in workmanship and materials under normal use and service for a period of one
(1) year.
Distributor will, at its election, repair, replace, or make appropriate adjustment where distributor optional
inspection discloses any such defects occurring in normal usage within the warrantee periods.
Please note distributor is not responsible for installation or removal costs.
Modication of any shower enclosure components may void the warranty. This warranty does not cover any
claim arising from abuse, misuse, negligence, accident, improper installation or operations on the part of the
purchaser. This warranty is void if the distributor product is subject to alterations, or if repairs where done to the
shower unit.
This warranty does not extend to any plumbing or components installed by dealers, installers or by any party
other than distributor.
Implied warranties, including that of merchantability or tness for a particular purpose, are expressly limited in
duration to the duration of this warranty.
Distributor disclaims any liability for special, incidental or consequential damages.

17
Date de l’achat: _______________________ Numéroderéférence du produit:______________________
Questions, problèmes ou pièces manquantes?
Avant de retourner le produit à votre détaillant, contactez notre service à la clientèle au
1-866-839-2888, du lundi au vendredi de 9h00 à 17h00 HNE.
2800 Etienne Lenoir, Laval
Quebec H7R 0A3 Canada
Ouverture
470
[18 1/2]
550
[21 5/8]
Marques CSA
2000
[78 3/4]
1219
[48]
Mesures: millimètres [pouces]
ANTIGUA 48
2015-05-18

18
TABLE DES MATIÈRES
CONTENU DE L’EMBALLAGE ......................................................................................................................... 20
QUINCAILLERIE FOURNIE .............................................................................................................................. 21
OUTILS REQUIS ............................................................................................................................................... 21
INFORMATION SUR LA SÉCURITÉ ................................................................................................................. 22
PRÉPARATION ................................................................................................................................................. 22
CETTE DOUCHE EST RÉVERSIBLE ............................................................................................................... 23
MESURES MUR À MUR.................................................................................................................................... 23
GUIDE D’INSTALLATION DE LA BASE (OPTIONNEL) ................................................................................. 24
INSTALLATION DES RAILS MURAUX ............................................................................................................. 25
INSTALLATION DU PANNEAU FIXE ET DE LA BARRE DE SOUTIEN........................................................... 26
INSTALLATION DE LA PORTE ........................................................................................................................ 29
INSTALLATION DE LA POIGNÉE ET SCELLAGE ........................................................................................... 31
TRAITEMENT ET ENTRETIEN ......................................................................................................................... 32
GARANTIE LIMITÉE DE 5 ANS ........................................................................................................................ 32

19
CONTENU DE L’EMBALLAGE
B
DE
C
F
G
H
J
M
R
N
Q
U
T
O
P

20
CONTENU DE L’EMBALLAGE
# DE PIÈCE DESCRIPTION QUANTITÉ CODE
B Rail mural 1 99STR2020-WM
CPanneau xe 1 99SG10049-WM
D Ancrages pour barre de support 2 99SGC0038-WM
E Buttées pour roues 1 99SDS0008-WM
F Barre de support 1 99SGS0024-WM
GRaccords pour panneau xe 1 99SGC0039-WM
H Roues de la porte 2 99SWE0021-WM
J Panneau de la porte 1 99SGD0034-WM
M Poignée de la porte 1 99SHA1034-WM
NJoint d’étanchéité du bas du panneau xe 1 99SRU0131
O Joint d’étanchéité du bas de la porte 1 99SRU0132
P Joints d’étanchéités verticaux des panneaux de verre 2 99SRU0024
QGuide de porte (avec joint) 1 99SGC2037-WM
R Joint d’étanchéité de fermeture de la porte 1 99SRU0023
T Embouts du rail décoratif 2 99SHW0101-WM
U Rail décoratif 1 99STR1070-WM
V Quincaillerie fournie 1 99SHW0068-WM
Table of contents
Languages:
Other OVE Bathroom Fixture manuals
Popular Bathroom Fixture manuals by other brands

Signature Hardware
Signature Hardware OCALA 948060 manual

newform
newform THERMO EASY 70400E instructions

Tenzo
Tenzo HC-305 Installation manual & users guide

Mira
Mira Select Flex quick start guide

Durovin Bathrooms
Durovin Bathrooms Ravenna 17-2 DR04-L installation manual

Decor Star
Decor Star PL-020-SS manual

Noro
Noro STAR H instruction manual

Helvex
Helvex Piura PIU-100 installation guide

Hans Grohe
Hans Grohe Vernis Blend Vario 26270 Series Assembly instructions

CRISTINA
CRISTINA ITALY CRIIT165 installation instructions

antoniolupi
antoniolupi DAFNE quick start guide

Northwest Territory
Northwest Territory KMT160704SW owner's manual
