Acrosser Technology AR-B1675 User manual

AR-B1675 User’s Guide
AR-B1675 1
AR-B1675
VIA Mark CoreFusion 800MHz, Half Size ,On Board
SDRAM,VGA,LVDS with One SDRAM SO-DIMM, built in
LAN,CF Type-II
Edition: 2.0
Book Number: AR-B1675-06.11.17

AR-B1675 User’s Guide
AR-B1675 2
@Copyright 2005
All Rights Reserved.
Manual first edition Apr 11, 2006
The information in this document is subject to change without prior
notice in order to improve reliability, design and function and does not
represent a commitment on the part of the manufacturer.
In no event will the manufacturer be liable for direct, indirect, special,
incidental, or consequential damages arising out of the use or inability to
use the product or documentation, even if advised of the possibility of
such damages.
This document contains proprietary information protected by copyright.
All rights are reserved. No part of this manual may be reproduced by
any mechanical, electronic, or other means in any form without prior
written permission of the manufacturer.
Trademarks
AR-B1675 is registered trademarks X-Fire Acrosser, IBM PC is a
registered trademark of International Business Machines Corporation.
Pentium is a registered trademark of Intel Technologies, Inc. Award is
registered trademarks of Award Software International, Inc. Other
product names mentioned herein are used for identification purposes
only and may be trademarks and/or registered trademarks of their
respective companies.

AR-B1675 User’s Guide
AR-B1675 3
Contents
Contents................................................................ 3
Introduction............................................................. 5
1.1 Specifications:........................................................................... 5
1.2 What You Have......................................................................... 6
Installation .............................................................. 7
2.1 AR-B1675’s Layout................................................................... 7
2.2 Power Button Setting................................................................ 9
2.3 CMOS Reset........................................................................... 10
2.4 Jumper description ................................................................. 10
Connection............................................................ 12
3.1 Ultra ATA33 IDE Disk Drive Connector(IDE2)........................ 12
3.2 Serial Ports(COM2) ................................................................ 13
3.3 Keyboard / Mouse Connector(MS_KB1,2)............................. 13
3.4 USB Port Connector(USB1~4)............................................... 14
3.5 Fan Connector (FAN1) ........................................................... 14
3.6 LAN RJ45 Connector (J4)....................................................... 15
3.7 Compact Flash Storage Card Socket(CF1)............................ 15
3.8 VGA Connector(VGA1)........................................................... 16

AR-B1675 User’s Guide
AR-B1675 4
3.9 AUDIO Connector(AUDIO1)................................................... 17
3.10 SDRAM SODIMM Socket (DIMM1)...................................... 17
3.11 8-BIT GPIO Connector(CN1)................................................ 17
3.12 Parallel port(LPT1)................................................................ 18
3.13 LVDS Connector(LVDS1)..................................................... 18
Award BIOS Setup................................................ 20
4.1 Introduction............................................................................. 20
4.2 Starting Setup......................................................................... 20
4.3 Using Setup ............................................................................ 21
4.4 Main Menu.............................................................................. 22
4.5 Advanced BIOS Features....................................................... 25
4.6 PnP/PCI Configuration Setup................................................. 27
4.7 Peripheral................................................................................ 28
4.8 H/W Monitor............................................................................ 29
4.9 Boot……………...…………………………………………………30
4.10 Exit Selecting…………………………………………………….31

AR-B1675 User’s Guide
AR-B1675 5
1
Introduction
1.1 Specifications:
CPU : Onboard VIA Mark CoreFusion 800MHz CPU.
Chipset : VIA VT82C686B South Bridge
RAM memory : Onboard 128M SDRAM and One SDRAM SO-DIMM Socket
support to 1 GB/133MHz.
Display Controller: MARK integrated ProSavage 4 3D/2D Graphic Controller.
Ultra DMA 133 IDE Interface : One PCI Enhance IDE channel.
CompactFlashTM interface : Supports CompactFlashTM Type II socket for
Compact Flash Disk or IBM Micro Drive.
Series ports : Two high-speed 16C550 compatible UARTs ports.COM2 can
also support RS-422/485.
Parallel Port: IEEE-1284 compliant. Supports SPP/EPP/ECP mode.
USB port : Support Four USB 2.0 compatible ports.
Audio Connector: supports Line-in, Line-out, MIC-in.
Digital IO: Supports four digital-in, and four digital-out TTL-level I/O ports.
PS/2 Mouse/Keyboard Connector
Watchdog timer : Time setting form 1 to 4096 second / minute System Reset
generate when CPU did not periodically trigger the timer.
Intel LAN Controller: 1 ports IEEE 802.3u Auto-Negotiation support for
Realtek RTL8100C 10/100BASE-TX Connected to your LAN through RJ45
connector.
Power Consumption : 5V / 2.75A

AR-B1675 User’s Guide
AR-B1675 6
Operating Temperature : 0°~ 60°C
Dimension: 122mm(W) X 185mm(L)
1.2 What You Have
In addition to this User's Manual, the AR-B1675 package includes the
following items:
AR-B1675 board
Setting Manual
Software utility CD
Serial port wired cable
Audio wired cable
PS/2 Mouse& Keyboard interface Y-cable
Hard disk drive adapter cable
USB port on one bracket cable
Parallel port cable

AR-B1675 User’s Guide
AR-B1675 7
2
Installation
This chapter describes how to install the AR-B1675. At first, the
layout of AR-B1675 is shown, and the unpacking information that you
should be careful is described. The jumpers and switches setting for
the AR-B1675’s configuration
2.1 AR-B1675’s Layout
Top Placement

AR-B1675 User’s Guide
AR-B1675 8
Bottom Placement

AR-B1675 User’s Guide
AR-B1675 9
2.2 Power Button Setting
•CN3 : Power Connector
•PWRON1 : Power Button Connector
•HDLED1 : HardDisk LED Connector
•RST1 : Reset Button Connector
•CN2 : Power ON Pin Header
PIN DESCRIPTION
1 12V
2 GND
3 GND
4 5V
Pin DESCRIPTION
Open Showdown
Short Power ON
Pin DESCRIPTION
1 +5V
2 HD_LED
Pin DESCRIPTION
Open Normal
Short Reset System
Pin DESCRIPTION
1 5VSB
2 GND
3 PS_ON

AR-B1675 User’s Guide
AR-B1675 10
2.3 CMOS Reset
•CMOS1 : CMOS pin header
2.4 Jumper description
•JP2 : Select CF Master or Slave mode
•JP3 : COM1/2 Select RI is 12V/5V or signal
•J2 : Select COM2 is RS232 or RS422/485
CMOS1 DESCRIPTION
1-2 Normal Operation
2-3 Reset CMOS
JP2 DESCRIPTION
Short Master
Open Slave
PIN DESCRIPTION PIN DESCRIPTION
1 12V 2 12V
3 COM_RI1 4 COM_RI2
5 5V 6 5V
7 COM_RI1 8 COM_RI2
9 NRI1 10 NRI2
J2 DESCRIPTION
1-2 RS232
3-4 RS422
5-6 RS485

AR-B1675 User’s Guide
AR-B1675 11
•JP1: Select LCD Voltage
•J1 : Inverter Power Connector
•Kb_key1: Keyboard Lock Connector
•Ms_key1: Mouse Lock Connector
JP1 DESCRIPTION
1-2 +3.3V
2-3 +5V
PIN NO. DESCRIPTION
1 +12V
2 +12V
3 GND
4 BKLTEN
5 GND
6 BKLTCTL
JP1 DESCRIPTION
Short Normal
Open Lock
JP1 DESCRIPTION
Short Normal
Open Lock

AR-B1675 User’s Guide
AR-B1675 12
3
Connection
This chapter describes how to connect peripherals, switches and
indicators to the AR-B1675 board.
3.1 Ultra ATA33 IDE Disk Drive Connector(IDE2)
You can attach two IDE( Integrated Device Electronics) hard disk drives
to the AR-B1675 IDE controller.
IDE 2 : Secondary IDE Connector (44 Pins)
PIN DESCRIPTION PIN DESCRIPTION
1 RESET# 2 GROUND
3 DATA 7 4 DATA 8
5 DATA 6 6 DATA 9
7 DATA 5 8 DATA 10
9 DATA 4 10 DATA 11
11 DATA 3 12 DATA 12
13 DATA 2 14 DATA 13
15 DATA 1 16 DATA 14
17 DATA 0 18 DATA 15
19 GROUND 20 N/C
21 N/C 22 GROUND
23 IOW# 24 GROUND
25 IOR# 26 GROUND
27 N/C 28 BALE
29 N/C 30 GROUND
31 INTERRUPT 32 IOCS16#
33 SA1 34 N/C
35 SA0 36 SA2
37 HDC CS0# 38 HDC CS1#
39 HDD ACTIVE# 40 GROUND
41 +5V LOGIC 42 +5V MOTOR
43 GROUND 44 TYPE

AR-B1675 User’s Guide
AR-B1675 13
3.2 Serial Ports(COM2)
The AR-B1675 offers two high speeds NS16C550 compatible UARTs
with Read/Receive 16 byte FIFO serial ports.
•COM1 : RS-232 Serial port
•COM2: RS-232 with RS-422/485 Serial port(Pin Header)
3.3 Keyboard / Mouse Connector(MS_KB1,KB_MS2)
A PS/2 type connector(MS_KB1)is for easy connection to a keyboard
and PS/2 mouse. The board comes with a Y split PS/2 cable for
keyboard and mouse connection.
•MS_KB1 : Keyboard Mouse PS2 Port
PIN DESCRIPTION PIN DESCRIPTION
1 NDCD 2 NRX
3 NTX 4 NDTR
5 GND 6 NDSR
7 NRTS 8 NCTS
9 NRIA_12V 10 NC
PIN DESCRIPTION PIN DESCRIPTION
1 NDCD 2 NDSR
3 NSIN 4 NRTS
5 NRIB 6 NCTS
7 NSOUT 8 NRI
9 GND 10 GND
11 TX+ 12 TX-
13 RX+ 14 RX-
PIN DESCRIPTION PIN DESCRIPTION
1 KB_DAT 2 MS_DAT
3 GND 4 +5V
5 KB_CLK 6 MS_CLK
7 GND 8 GND

AR-B1675 User’s Guide
AR-B1675 14
•KB_MS1 : Keyboard Mouse JST Port
3.4 USB Port Connector(USB1~4)
The AR-B1675 provides four USB port, four pin header .
•USB1/2/3/4: USB Connector(Pin header)
3.5 Fan Connector (FAN1)
The AR-B1675 provides one connectors for CPU cooling fan.
•FAN1: Fan Connector for CPU
PIN NO. DESCRIPTION
1 +12V
2 +12V
3 GND
4 BKLTEN
5 GND
6 BKLTCTL
PIN DESCRIPTION PIN DESCRIPTION
1 VCC 2 GND
3 USB- 4 USB+
5 USB+ 6 USB-
7 GND 8 VCC
PIN NO. DESCRIPTION
1 FANSP1
2 +5V
3 GNDl

AR-B1675 User’s Guide
AR-B1675 15
3.6 LAN RJ45 Connector (J4)
AR-B1675 is equipped with built-in 10/100Mbps Ethernet Controller. You
can connect it to your LAN through RJ45 LAN connector. The pin
assignments are as following:
•LAN1 : LAN RJ45 Connector
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1 TX+ 5. N/C
2 TX- 6. RX-
3. RX+ 7. N/C
4. N/C 8. N/C
3.7 Compact Flash Storage Card Socket(CF1)
The AR-B1675 configures Compact Flash Storage Card in IDE Mode.
This type II Socket is compatible with IBM Micro Drive.
•CF1 : Compact Flash Storage Card Socket pin assignment
PIN DESCRIPTION PIN DESCRIPTION
1 GROUND 26 CARD DETECT1
2 D3 27 D11
3 D4 28 D12
4 D5 29 D13
5 D6 30 D14
6 D7 31 D15
7 CS1# 32 CS3#
81

AR-B1675 User’s Guide
AR-B1675 16
8 N/C 33 N/C
9 GROUND 34 IOR#
10 N/C 35 IOW#
11 N/C 36 PULL HIGH
12 N/C 37 IRQ15
13 VCC 38 VCC
14 N/C 39 MASTER/SLAVE
15 N/C 40 N/C
16 N/C 41 RESET#
17 N/C 42 IORDY
18 A2 43 N/C
19 A1 44 PULL HIGH
20 A0 45 ACTIVE#
21 D0 46 PDIAG#
22 D1 47 D8
23 D2 48 D9
24 N/C 49 D10
25 CARD DETECT2 50 GROUND
Note: If IDE2 & CFD1 both in used, CFD1 must be as “Master” & IDE2 is as “Slave”.
3.8 VGA Connector(VGA1)
The AR-B1675 has a built-in 15-pin VGA connector accepting the CRT
monitor
•VGA1 : 15-pin D-Sub Connector
PIN DESCRIPTION PIN DESCRIPTION
1 L_RED 2 L_GREEN
3 L_BLUE 4 MON2PU
5 GND 6 GND
7 GND 8 GND
9 +5V 10 GND
11 MONOPU 12 5VDDCDA
13 HSYNC 14 VSYNC
15 5VDDCCL

AR-B1675 User’s Guide
AR-B1675 17
3.9 AUDIO Connector(AUDIO1)
•AUDIO1 : Audio Pin Header
3.10 SDRAM SODIMM Socket (DIMM1)
There are one 144-pin SDRAM DIMM slots to accept 3.3V. The max Memory
size is 1GB.
•DIMM1
3.11 8-BIT GPIO Connector(CN1)
•CN1: 4 BIT Input/Output GPIO Connector
PIN DESCRIPTION PIN DESCRIPTION
1 LINE OUT R 2 LINE OUT L
3 GND 4 GND
5 LINE IN R 6 LINE IN L
7 MIC IN 8 GND
9 GND 10 GND
PIN DESCRIPTION PIN DESCRIPTION
1 GND 2 +5V
3 DIOI0 4 DIOO0
5 DIOI1 6 DIOO1
7 DIOI2 8 DIOO2
9 DIOI3 10 DIOO3

AR-B1675 User’s Guide
AR-B1675 18
3.12 Parallel port(LPT1)
This port is usually connected to a printer. The AR-B1675 cludes an on-board
parallel port.
•LPT1: Parallel Port Connector
3.13 LVDS Connector(LVDS1)
•LVDS1 : LVDS Interface Connector
PIN DESCRIPTION PIN DESCRIPTION
1 STB- 14 AFD-
2 PD0 15 ERR-
3 PD1 16 INIT-
4 PD2 17 SLIN-
5 PD3 18 GND
6 PD4 19 GND
7 PD5 20 GND
8 PD6 21 GND
9 PD7 22 GND
10 ACK- 23 GND
11 BUSY 24 GND
12 PE 25 GND
13 SLCT 26 X

AR-B1675 User’s Guide
AR-B1675 19
PIN DESCRIPTION PIN DESCRIPTION
1 LCDVDD 2 GND
3 TRXEC- 4 TRXEC+
5 GND 6 TRXE2-
7 TRXE2+ 8 GND
9 TRXE1- 10 TRXE1+
11 NC 12 NC
13 TRXE0+ 14 TRXE0-
15 GND 16 TRXOC+
17 TRXOC- 18 GND
19 TRXO2+ 20 TRXO2-
21 NC 22 TRXO1+
23 TRXO1- 24 NC
25 TRXO0+ 26 TRXO0-
27 NC 28 NC
29 LCDVDD 30 LCDVDD

AR-B1675 User’s Guide
AR-B1675 20
4
Award BIOS Setup
4.1 Introduction
This chapter discusses the Setup program built into the BIOS. The
Setup program allows users to configure the system. This configuration
is then stored in battery-backed CMOS RAM so that it retains the Setup
information while the power is off.
4.2 Starting Setup
The BIOS is immediately active when you turn on the computer. While
the BIOS is in control, the Setup program can be activated in one of two
ways:
1. By pressing <Del> immediately after switching the system on, or
2. By pressing the <Del> key when the following message appears
briefly at the bottom of the screen during the POST (Power On Self-
Test).
Press DEL to enter SETUP.
If the message disappears before you respond and you still wish to enter
Setup, restart the system to try again by turning it OFF then ON or
pressing the "RESET" button on the system case. You may also restart
by simultaneously pressing <Ctrl>, <Alt>, and <Delete> keys. If you do
not press the keys at the correct time and the system does not boot, an
error message will be displayed and you will again be asked to...
PRESS F1 TO CONTINUE, DEL TO ENTER SETUP
