Acrosser Technology ACE-B8701 Installation guide

ACE-B8701 Quick Manual
P/N：220010404-G
1
ACE-B8701 Quick Manual V1.0
1.Mainboard illustration (Top Side)
USB1
One RJ45 with two layer USB
connector
DIMM1
DDR2 SODIMM socket
SATA1 & SATA2
Standard 7-pin SATA connector
CF1
Standard CF Card Slot
72 Pins Golden Fingers
General Gaming interface
U73
iButton holder
U6
Chipset VIA VX800
VGA1
D-Sub 15-pin VGA connector
U2
Processor VIA C7 1.5G
BAT1
CR2032 Size Coin Battery
BAT2
CR2032 Size Coin Battery for
AGA/SRAMA
COM1_2 & COM3_4
Dual D-Sub 9-pin RS232
connector
20 Pins Golden Fingers
Work with 72 Pins Golden Fingers

ACE-B8701 Quick Manual
P/N：220010404-G
2
2. Connector and Jumper Setting (Top Side)

ACE-B8701 Quick Manual
P/N：220010404-G
3
CCTALK1
JST connector for ccTalk (Signal
share with COM6).
KM1
JST connector for Keyboard and
Mouse.
SW1
8-bit readable DIP switch.
CN4
JST connector for Case Open
Intrusion logger.
CN3
Pin header for 2 USB ports.
COM6(optional)
Pin header for RS232 port.
JP11
CF Card master/slave select pin
header.
JP13
CF Card Voltage select pin
header.
JPC_2
Bill enable, Coin enable
and Hopper
pre-set pin header.
JBAT3
SRAM A and SRAM B supply
voltage
select from BAT2 or BAT3 pin
header.
JSRAMA & JSRAMB
SRAM A and SRAM B data clear pin
header.
BAT3(optional)
Rechargeable Battery for SRAM
A and SRAM B.
VR1 & VR2
Adjust audio volume.
JPB_1
Select Audio output with/without
amplifier pin header.
JPB_2
Select SPEAKER RIGHT+ connect
to 72 Pins Golden Fingers (B4, B5)
or (A2, B2).
AUDIO1
JST connector for Audio output.
COM3_4
RS232/ccTalk/RS485 output.
LED1
LED for Power & HDD.
SATAPWR1
JST connector for SATA power.
JP20
Reset pin header.
VGA2
Secondary VGA.
FAN1
CPU Fan Connector.
JPA_1 & JPA_2
Select COM1 or COM2 is RS232 or
TTL.
JPA_3
Select COM3 is RS232 or ccTalk.
JPA_5
Select COM4 is RS232 or RS485.
JPA_4
Select COM3 is RS232 or ccTalk.
JPA_6
Select COM4 is RS232 or RS485.
JPA_7
Select COM6 is RS232 or ccTalk.
JBAT1
CMOS clear pin header.

ACE-B8701 Quick Manual
P/N：220010404-G
4
3. Connector and Jumper Setting Table
1. CCTALK1 2. KM1 3. SW1
Pin
Signal
1 DATA
2 COM
3 NC
4 12V
Pin Signal
1 Mouse data
2 Keyboard data
3 GND
4 5V
5 Mouse clock
6 Keyboard clock
Status
Signal
ON GND
OFF 3.3V
4. CN4 5. CN3 6. COM6
Pin
Signal
1 Case open
2 GND
Pin
Signal
Pin
Signal
1 5V 2 5V
3 -USB0
4 -USB2
5 +USB0
6 +USB2
7 GND 8 GND
9 NC 10
GND
Pin
Signal
Pin
Signal
1 -DCD
2 -DSR
3 SIN 4 -RTS
5 SOUT
6 -CTS
7 -DTR
8 -RI
9 GND
10
NC
7. JP11/JP13 8. JPC_2 9. JBAT3/JSRAMA/JSRAMB
JP11
Pin Setting
1-2
Open
Slave
1-2
Close
Master
(default)
JP13
Pin Setting
1-2
Close
5V
2-3
Close
3.3V
(default)
Pin
Status
Setting
1-2
Open Preset is
LOW
Close
(default)
Preset is
HIGH
3-4
Open Preset is
LOW
Close
(default)
Preset is
HIGH
5-6
Open Preset is
LOW
Close
(default)
Preset is
HIGH
JBAT3
JSRAMA
JSRAMB
Pin
Setting
Setting
1-2
close
BAT2
(default)
Normal
(default)
2-3
close
BAT3 Clear
SRAM

ACE-B8701 Quick Manual
P/N：220010404-G
5
10. BAT3 11. VR1/VR2 12. JPB_1/JPB_2
Pin
Signal
1 GND
2 3.3V
Adjust volume level by turning VR
clockwise
JPB_1 JPB_2
Pin Setting Setting
1-3,
2-4
close
Audio Out
with
Amplifier
(default)
SPEAKER
RIGHT+
connect to 72
Pins Golden
Fingers(B5, B4)
(default)
3-5,
4-6
close
Audio Out
without
Amplifier
SPEAKER
RIGHT+
connect to 72
Pins Golden
Fingers(A2, B2)
13. AUDIO1 14. COM3_4 15. LED1
Pin
Signal
1 SPEAKER
RIGHT+
2 GND
3 SPEAKER
LEFT+
4 GND
COM3
COM4
Pin
RS232
ccTalk
RS485
1 -DCD
12V -
2 SIN Data Data+
3 SOUT
- Data-
4 -DTR
- -
5 GND
GND
-
6 -DSR
- -
7 -RTS
- -
8 -CTS
- -
9 -RI - -
LED Signal
Green
HDD
Red Power
16. SATAPWR1 17. JP20 18. VGA2
Pin
Signal
1 12V
2 GND
3 3.3V
4 5V
Pin
Signal
1 Reset
2 GND
Pin
Signal
Pin
Signal
1 RED 2 GND
3 GREEN
4 GND
5 BLUE 6 GND
7 VSYNC
8 SCL
9 HSYNC
10
SDA

ACE-B8701 Quick Manual
P/N：220010404-G
6
19. FAN1 20. JPA_1/JPA_2/JPA_3/JPA_5
Pin Signal
1 GND
2 12V
3 NC
JPA_1 &
JPA_2 JPA_3 JPA_5
Pin Setting Setting Setting
1-2, 4-5, 7-8, 10-11,
13-14, 16-17, 19-20,
22-23 Close
TTL
Output
ccTalk
output
RS485
output
2-3, 5-6, 8-9, 11-12,
14-15, 17-18, 20-21,
23-24 Close
RS232 output
(default)
RS232 output
(default)
RS232 output
(default)
21. JPA_4/JPA_6/JPA_7 22. JBAT1
JPA_4 JPA_6 JPA_7
Pin Setting Setting Setting
1-3, 2-4
Close
RS232 (default)
RS232 (default)
RS232
3-5, 4-6
Close
ccTalk RS485 ccTalk (default)
Pin Setting
1-2
Close Normal (default)
2-3
Close Clear COMS

ACE-B8701 Quick Manual
P/N：220010404-G
7
72 Pins Golden Finger
I: TTL Input
I.I: Isolated Input
O.D: Open Drain Output
A.O: Audio Output
Component Side Solder Side
I/O TYPE
Port/Bit Function Pin
Function Port/Bit I/O TYPE
1
A.O SPEAKER
RIGHT+
2 Audio GND
A.O SPEAKER
LEFT +
3 Audio GND
I.I B0 Button 1 4 Audio GND
I.I
B1 Button 2 5 SPEAKER
RIGHT+
A.O
I.I B2 Button 3 6 Door SW2 A1 I
I.I B3 Button 4 7 Door SW3 A2 I
I.I B4 Button 5 8 Door SW4 A3 I
I.I B5 Button 6 9 Door SW5 A4 I
I.I B6 Button 7 10
Touch-Cal
Key-Lock D3 I.I
I.I B7 Button 8 11
Spare Key-Lock D4 I.I
I.I C0 Button 9 12
Coin-En I0 O.D
I.I C1 Button10 13
Bill-En I1 O.D
14
I.I D0 Dissolve
Key-Lock 15
Button 15 C6 I.I
I.I C2 Button11 16
Button 16 C7 I.I
I A0 Door SW1 17
I.I E0 Coin-In Signal A
18
Button 12 C3 I.I
I.I E2 Bill-In 19
Coin-In Signal B E1 I.I
I.I D1 OM Key-Lock 20
Setup Key-Lock
(Hand Pay) D2 I.I
I.I C5 Button 14 21
Button 13 C4 I.I
GND 22
Hopper Sensor E3 I.I
O.D H7 Spare Meter1 23
Lamp13 G4 O.D
O.D H0 Key-In Meter 24
Hand-Pay Meter1
H5 O.D
O.D H1 Bill-In Meter 25
Hand-Pay Meter2
H6 O.D

ACE-B8701 Quick Manual
P/N：220010404-G
8
Component Side Solder Side
I/O TYPE
Port/Bit Function Pin
Function Port/Bit I/O TYPE
O.D. H2 Coin-In Meter 26
Lamp14 G5 O.D.
O.D. H3 Pay-Out Meter 27
Lamp15 G6 O.D.
O.D. H4 Key-Out Meter 28
Lamp16 G7 O.D.
O.D. F0 Lamp1 29
Lamp7 F6 O.D.
O.D. F1 Lamp2 30
Lamp8 F7 O.D.
O.D. F2 Lamp3 31
Lamp9 G0 O.D.
O.D. F3 Lamp4 32
Lamp10 G1 O.D.
O.D. F4 Lamp5 33
Lamp11 G2 O.D.
O.D. F5 Tower Lamp6 34
Tower Lamp12 G3 O.D.
GND 35
GND
GND 36
GND
20 Pins Golden Finger
Component Side Solder Side
I/O TYPE Port/Bit
Function Pin
Function Port/Bit I/O TYPE
GND 1 GND
GND 2 GND
+5V 3 +5V
+5V 4 +5V
+12V 5 +12V
+12V 6 +12V
O.D. I2 Hopper SSR 7
8
GND 9 GND
GND 10
GND
