Acrosser Technology ACM-TGLUE0-A Series User manual

ACM-TGLUE0-Ax
User Manual
Acrosser Technology Co., Ltd.
www.acrosser.com
ACM-TGLUE0-Ax
COM Express Mini Module Type 10
with Intel®Tiger Lake U

ACM-TGLUE0-Ax
2Acrosser Technology Co., Ltd.
To read this User Manual on your smart phone, you will have to install an
APP that can read PDF le format rst. Please nd the APP you prefer from
the APP Market.
Ver: 100
Date: Apr. 11, 2022
Disclaimer
For the purpose of improving reliability, design and function, the information in
this document is subject to change without prior notice and does not represent a
commitment on the part of Acrosser Technology Co., Ltd.
In no event will Acrosser Technology Co., Ltd. be liable for direct, indirect, special,
incidental, or consequential damages arising out of the use or inability to use the
product or documentation, even if advised of the possibility of such damages.
Copyright
This document contains proprietary information protected by copyright. All rights are
reserved. No part of this manual may be reproduced by any mechanical, electronic,
or other means in any form without prior written permission of Acrosser Technology
Co., Ltd.
Trademarks
The product names appear in this manual are for identication purpose only. The
trademarks and product names or brand names appear in this manual are the
property of their respective owners.
Purpose
This document is intended to provide the information about the features and use of
the product.
Audience
The intended audiences are technical personnel, not for general audiences.
WARNING
Danger of explosion if batteries are incorrectly replaced. Always replace the
battery with the same specications. Dispose of used batteries according to the
manufacturer's instructions.
Before running the system, make sure the power cord is rmly plugged into the
socket.
CAUTION
IEC 60417-6042 (2010-11) IEC 60417-6172 (2012-09)
All power cords must be disconnected during product repair.

ACM-TGLUE0-Ax
3
www.acrosser.com
Table of Contents
1. Introduction ...................................................................5
1.1. Specications ............................................................................................................. 5
1.2. Packing List ................................................................................................................ 6
1.3. Block Diagram ............................................................................................................ 7
2. Hardware Information ...................................................8
2.1. Mainboard Layout....................................................................................................... 8
2.2. Row A/B Pin Assignments .......................................................................................... 9
2.3. Board Dimension...................................................................................................... 13
3. BIOS Settings...............................................................15
3.1. Main Setup ............................................................................................................... 15
3.2. Advanced Setup ....................................................................................................... 16
3.2.1. Graphics Conguration ................................................................................. 16
3.2.2. CPU Conguration ........................................................................................ 17
3.2.3. Memory Conguration................................................................................... 18
3.2.4. On-Module H/W Monitor ............................................................................... 19
3.2.4.1. Fan 1 Mode Conguration ............................................................. 19
3.2.5. PCH-FW Conguration ................................................................................. 22
3.2.5.1. Firmware Update Conguration .................................................... 22
3.2.6. On-Module Conguration ............................................................................. 23
3.2.7. Power Management ..................................................................................... 24
3.2.8. BIOS Robot .................................................................................................. 25
3.3. System I/O Setup ..................................................................................................... 26
3.3.1. PCI Express Conguration............................................................................ 26
3.3.2. Storage Conguration .................................................................................. 28
3.3.3. HD Audio Conguration ................................................................................ 29
3.3.4. Digital IO Port Conguration ........................................................................ 30
3.3.5. Legacy Logical Devices Conguration ......................................................... 31
3.3.5.1. Serial Port 1 Conguration ............................................................ 31
3.3.5.2. Serial Port 2 Conguration ............................................................ 32
3.3.6. Serial Port Console Redirection ................................................................... 33
3.4. Security Setup .......................................................................................................... 34
3.4.1. Trusted Computing ....................................................................................... 35
3.4.2. Secure Boot ................................................................................................. 36
3.4.2.1. Key Management .......................................................................... 37

ACM-TGLUE0-Ax
4Acrosser Technology Co., Ltd.
3.5. Boot Setup ............................................................................................................... 38
3.6. Save & Exit Setup..................................................................................................... 39
4. Drivers Installation ......................................................40
4.1. Driver Download and Installation.............................................................................. 40
5. Appendix ......................................................................42
5.1. I/O Information.......................................................................................................... 42
5.1.1. I/O Address Map ........................................................................................... 42
5.1.2. Memory Address Map ................................................................................... 43
5.1.3. Large Memory Address Map ........................................................................ 43
5.1.4. IRQ Mapping Chart ...................................................................................... 44
6. FAQ ...............................................................................55
Q 1. Where can I nd the serial number of this product? ................................................. 55

ACM-TGLUE0-Ax
5
www.acrosser.com
1. Introduction
ACM-TGLUE0-A0 (Intel 11 Core i7-1185GRE ) +16GB RAM
ACM-TGLUE0-A1 (Intel 11 Core i7-1187G7E ) +16GB RAM
ACM-TGLUE0-A2 (Intel 11 Core i5-1145G7E ) +16GB RAM
ACM-TGLUE0-A3 (Intel 11 Core i3-1115G4E ) +8GB RAM
1.1. Specifications
CPU • 11th Generation Intel®Core™Processor Family
(formerly Tiger Lake UP3)
Chipset • Intel®SoC
GPU • Intel®Irix XE Graphic Intel®UHD Graphics for 11th
Gen processor
Display • 1x eDP 1x DDI port
BIOS • AMI UEFI
Memory • Onboard LPDDR4x 4266 memory 8GB (A3 only)/
16GB
Storage • Onboard PCIe NVMe SSD 64GB
GbE Ethernet • 1x Intel I225LM GbE Lan, supports PXE Boot
SATA • 2x SATA III (6.0Gb/s)
USB • 8x USB2.0
• 2x USB3.2 Gen2
Audio • 1x Intel High Denition Audio
Serial Port • 2x wire UART (Only TX & RX)
GPIO • 8 bit
Expansion • 4x PCI Express 3.0 lanes
4 PCIe x1
I2C
LPC
SMBus
OS Support • Windows 10
• Linux Kernel 64-bit
Watchdog Timer • Software programmable 0~255 seconds, 0 = disable
timer.
Power Mode • AT/ATX Mode (by jumper setting)

ACM-TGLUE0-Ax
6Acrosser Technology Co., Ltd.
Operating Temperature • ACM-TGLUE0-A0 (i7-1185GRE -40°C~85°C)
• ACM-TGLUE0-A1 (i7-1187G7E 0°C ~ 60°C)
• ACM-TGLUE0-A2 (i5-1145G7E 0°C ~ 60°C)
• ACM-TGLUE0-A3 (i3-1115G4E 0°C ~ 60°C)
Dimension • 84 mm x 55 mm (3.31" x 2.17") COM Express type 10
Safety • CE, FCC Class A
1.2. Packing List
Check if the following items are included in the package.
Item Q’ty
�ACM-TGLUE0 1
�CPU Cooler 1

ACM-TGLUE0-Ax
7
www.acrosser.com
1.3. Block Diagram

ACM-TGLUE0-Ax
8Acrosser Technology Co., Ltd.
2. Hardware Information
2.1. Mainboard Layout
Top View

ACM-TGLUE0-Ax
9
www.acrosser.com
Bottom View
2.2. Row A/B Pin Assignments
Pin # Row A Pin # Row B
A1 GND (FIXED) B1 GND (FIXED)
A2 GBE0_MDI3- B2 GBE0_ACT#
A3 GBE0_MDI3+ B3 LPC_FRAME#
A4 GBE0_LINK100# B4 LPC_AD0
A5 GBE0_LINK1000# B5 LPC_AD1
A6 GBE0_MDI2- B6 LPC_AD2
A7 GBE0_MDI2+ B7 LPC_AD3
A8 GBE0_LINK# B8 N.C.
A9 GBE0_MDI1- B9 N.C.
A10 GBE0_MDI1+ B10 LPC_CLK
A11 GND (FIXED) B11 GND (FIXED)
A12 GBE0_MDI0- B12 PWRBTN#
A13 GBE0_MDI0+ B13 SMB_CK
A14 N.C. B14 SMB_DAT
A15 SUS_S3# B15 SMB_ALERT#

ACM-TGLUE0-Ax
10 Acrosser Technology Co., Ltd.
Pin # Row A Pin # Row B
A16 SATA0_TX+ B16 SATA1_TX+
A17 SATA0_TX- B17 SATA1_TX-
A18 SUS_S4# B18 SUS_STAT#
A19 SATA0_RX+ B19 SATA1_RX+
A20 SATA0_RX- B20 SATA1_RX-
A21 GND (FIXED) B21 GND (FIXED)
A22 USB3_RXN0 B22 USB3_TXN0
A23 USB3_RXP0 B23 USB3_TXP0
A24 SUS_S4# B24 PWR_OK
A25 USB3_RX1_N B25 USB3_TX1_N
A26 USB3_RX1_P B26 USB3_TX1_P
A27 BATLOW# B27 WDT
A28 ATA_ACT# B28 N.C.
A29 AC_SYNC B29 N.C.
A30 AC_RST# B30 AC_SDIN0
A31 GND (FIXED) B31 GND (FIXED)
A32 AC_BITCLK B32 SPKR
A33 AC_SDOUT B33 I2C_CK
A34 BIOS_DIS0# B34 I2C_DAT
A35 THRMTRIP# B35 THRM#
A36 USB6- B36 USB7-
A37 USB6+ B37 USB7+
A38 USB_6_7_OC# B38 USB_4_5_OC#
A39 USB4- B39 USB5-
A40 USB4+ B40 USB5+
A41 GND (FIXED) B41 GND (FIXED)
A42 USB2- B42 USB3-
A43 USB2+ B43 USB3+
A44 USB_2_3_OC# B44 USB_0_1_OC#
A45 USB0- B45 USB1-
A46 USB0+ B46 USB1+
A47 VCC_RTC B47 N.C.
A48 N.C. B48 N.C.
A49 N.C. B49 SYS_RESET#

ACM-TGLUE0-Ax
11
www.acrosser.com
Pin # Row A Pin # Row B
A50 LPC_SERIRQ B50 CB_RESET#
A51 GND (FIXED) B51 GND (FIXED)
A52 N.C. B52 N.C.
A53 N.C. B53 N.C.
A54 GPI0 B54 GPO1
A55 N.C. B55 N.C.
A56 N.C. B56 N.C.
A57 GND B57 GPO2
A58 PCIE_TX3+ B58 PCIE_RX3+
A59 PCIE_TX3- B59 PCIE_RX3-
A60 GND (FIXED) B60 GND (FIXED)
A61 PCIE_TX2+ B61 PCIE_RX2+
A62 PCIE_TX2- B62 PCIE_RX2-
A63 GPI1 B63 GPO3
A64 PCIE_TX1+ B64 PCIE_RX1+
A65 PCIE_TX1- B65 PCIE_RX1-
A66 GND B66 WAKE0#
A67 GPI2 B67 WAKE1#
A68 PCIE_TX0+ B68 PCIE_RX0+
A69 PCIE_TX0- B69 PCIE_RX0-
A70 GND (FIXED) B70 GND (FIXED)
A71 EDP_TX2_P B71 DDI0_PAIR0+
A72 EDP_TX2_N B72 DDI0_PAIR0-
A73 EDP_TX1_P B73 DDI0_PAIR1+
A74 EDP_TX1_N B74 DDI0_PAIR1-
A75 EDP_TX0_P B75 DDI0_PAIR2+
A76 EDP_TX0_N B76 DDI0_PAIR2-
A77 EDP_VDDEN B77 N.C.
A78 N.C. B78 N.C.
A79 N.C. B79 EDP_BKLTEN
A80 GND (FIXED) B80 GND (FIXED)
A81 EDP_TX3_P B81 DDI0_PAIR3+
A82 EDP_TX3_N B82 DDI0_PAIR3-
A83 EDP_AUXP B83 EDP_BKLT_CTRL

ACM-TGLUE0-Ax
12 Acrosser Technology Co., Ltd.
Pin # Row A Pin # Row B
A84 EDP_AUXN B84 VCC_5V_SBY
A85 GPI3 B85 VCC_5V_SBY
A86 N.C. B86 VCC_5V_SBY
A87 EDP_HPD B87 VCC_5V_SBY
A88 PCIE0_CK_REF+ B88 BISO_DIS1#
A89 PCIE0_CK_REF- B89 DDI0_HPD
A90 GND (FIXED) B90 GND (FIXED)
A91 SPI_POWER B91 N.C.
A92 SPI_MISO B92 N.C.
A93 GPO0 B93 N.C.
A94 SPI_CLK B94 N.C.
A95 SPI_MOSI B95 DDI0_DDC_AUX_SEL
A96 GND B96 N.C.
A97 TYPE10# (Pull down 47k ohm to GND) B97 SPI_CS#
A98 RS1_TX B98 DDI0_AUX_DP
A99 RS1_RX B99 DDI0_AUX_DN
A100 GND (FIXED) B100 GND (FIXED)
A101 RS2_TX B101 FAN_PWMOUT
A102 RS2_RX B102 FAN_TACHIN
A103 LID# B103 SLEEP#
A104 VCC_12V B104 VCC_12V
A105 VCC_12V B105 VCC_12V
A106 VCC_12V B106 VCC_12V
A107 VCC_12V B107 VCC_12V
A108 VCC_12V B108 VCC_12V
A109 VCC_12V B109 VCC_12V
A110 GND (FIXED) B110 GND (FIXED)

ACM-TGLUE0-Ax
13
www.acrosser.com
2.3. Board Dimension
(Unit: mm)

ACM-TGLUE0-Ax
14 Acrosser Technology Co., Ltd.

ACM-TGLUE0-Ax
15
www.acrosser.com
3. BIOS Settings
The AMI BIOS ROM has a pre-installed Setup program that allows users to modify
basic system congurations, which is stored in the battery-backed CMOS RAM and
BIOS NVRAM so that the information is retained when the power is turned off.
To enter BIOS Setup, press <Del> or <F2> immediately while your computer is
powering up.
The function for each interface can be found below.
• Main – Date and time can be set here. Press <Tab> to switch between date
elements
• Advanced – Enable/ Disable boot option for legacy network devices
• System I/O – For conguring PCI Express settings
• Security – The setup administrator password can be set here
• Boot – Enable/ Disable Quiet Boot option
• Save & Exit –Save your changes and exit the program
3.1. Main Setup

ACM-TGLUE0-Ax
16 Acrosser Technology Co., Ltd.
3.2. Advanced Setup
3.2.1. Graphics Configuration
• VBT Select
Select VBT for GOP Driver.

ACM-TGLUE0-Ax
17
www.acrosser.com
3.2.2. CPU Configuration
• Active Processor Cores
Number of cores to enable in each processor package.
• Turbo Mode
Enable/Disable processor Turbo Mode (requires EMTTM enabled too). AUTO means
enabled.
• Hyper-Threading
Enable or Disable Hyper-Threading Technology.
• Intel(R) SpeedStep(tm)
Allows more than two frequency ranges to be supported.
• Intel (VMX) Virtualization Technology
When enabled, a VMM can utilize the additional hardware capabilities provided by
Vanderpool Technology.

ACM-TGLUE0-Ax
18 Acrosser Technology Co., Ltd.
3.2.3. Memory Configuration
Note: In-Band ECC Support availability depends on CPU.
• In-Band ECC Support
Enable/Disable In-Band ECC. Either the IBECC or the TME can be enabled.
• In-Band ECC Error Injection
By enabling this Error Injection feature, the user acknowledges the security risks.
Enabling Error Injection allows attackers who have access to the Host Operating
System to inject IBECC errors that can cause unintended memory corruption and
enable the leak of security data in the BIOS stolen memory regions.
• In-Band ECC Operation Mode
0: Functional Mode protects requests based on the address range,
1: Makes all requests non-protected and ignore range checks,
2: Makes all requests protected and ignore range checks

ACM-TGLUE0-Ax
19
www.acrosser.com
3.2.4. On-Module H/W Monitor
3.2.4.1. Fan 1 Mode Configuration
Fan 1: Full Mode

ACM-TGLUE0-Ax
20 Acrosser Technology Co., Ltd.
• FAN 1
Smart Fan Mode Select.
• PWM signal
Select output PWM of inverting or non-inverting signal.
Fan 1: Manual Mode by PWM
• Manual Setting
Set Fan at xed Duty-Cycle
Min = 0 Max = 100
Please input Dec number:
