AXIOMTEK NA861 User manual

NA860 series
Network Appliance
User’s Manual

ii
Disclaimers
This manual has been carefully checked and believed to contain accurate information.
Axiomtek Co., Ltd. assumes no responsibility for any infringements of patents or any third
party’s rights, and any liability arising from such use.
Axiomtek does not warrant or assume any legal liability or responsibility for the accuracy,
completeness or usefulness of any information in this document. Axiomtek does not make any
commitment to update the information in this manual.
Axiomtek reserves the right to change or revise this document and/or product at any time
without notice.
No part of this document may be reproduced, stored in a retrieval system, or transmitted, in
any form or by any means, electronic, mechanical, photocopying, recording, or otherwise,
without the prior written permission of Axiomtek Co., Ltd.
CAUTION
If you replace wrong batteries, it causes the danger of explosion. It is recommended by the
manufacturer that you follow the manufacturer’s instructions to only replace the same or
equivalent type of battery, and dispose of used ones.
Copyright 2018 Axiomtek Co., Ltd.
All Rights Reserved
October 2018, Version A2
Printed in Taiwan

iii
Safety Approvals
CE Marking
FCC Class A
FCC Compliance
This equipment has been tested and complies with the limits for a Class A digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. If not installed and used in
accordance with proper instructions, this equipment might generate or radiate radio frequency
energy and cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by one or
more of the following measurers:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver
is connected.
Consult the dealer or an experienced radio/TV technician for help.
Shielded interface cables must be used in order to comply with emission limits.

iv
Safety Precautions
Before getting started, read the following important cautions.
1. Be sure to ground yourself to prevent static charge when installing the internal
components. Use a grounding wrist strap and place all electronic components in any
static-shielded devices. Most electronic components are sensitive to static electrical
charge.
2. Disconnect the power cords from the NA860 Series before making any installation. Be
sure both the system and the external devices are turned OFF. Sudden surge of power
could ruin sensitive components. Make sure the NA860 Series is properly grounded.
3. Do not open the system’s top cover. If opening the cover for maintenance is a must, only
a trained technician is allowed to do so. Integrated circuits on computer boards are
sensitive to static electricity. To avoid damaging chips from electrostatic discharge,
observe the following precautions:
Before handling a board or integrated circuit, touch an unpainted portion of the
system unit chassis for a few seconds. This will help to discharge any static
electricity on your body.
When handling boards and components, wear a wrist-grounding strap, available
from most electronic component stores.
Trademarks Acknowledgments
Axiomtek is a trademark of Axiomtek Co., Ltd.
Windows®is a trademark of Microsoft Corporation.
IBM, PC/AT, PS/2, VGA are trademarks of International Business Machines Corporation.
Intel®and Pentium®are trademarks of Intel Corporation.
AMI is trademark of American Megatrend Inc.
Other brand names and trademarks are the properties and registered brands of their
respective owners.

v
Table of Contents
Disclaimers.....................................................................................................ii
Safety Approvals...........................................................................................iii
Safety Precautions........................................................................................iv
Chapter 1 Introduction............................................. 1
1.1 General Description............................................................................1
1.2 Features...............................................................................................1
1.3 Specifications......................................................................................2
1.4 Dimensions and Outlines ...................................................................5
1.5 I/O Outlets............................................................................................7
1.5.1 Front Panel.................................................................................................. 7
1.5.2 Rear Panel ................................................................................................ 10
Chapter 2 Hardware and Installation .................... 13
2.1 Check List..........................................................................................13
2.2 Board Layout.....................................................................................14
2.3 Jumper Settings for SBC8A860 .......................................................16
2.3.1CMOS Clear Jumper (JP3)....................................................................... 16
2.4 Jumper Settings for AX93341...........................................................17
2.4.1 TACT Switch Selection (JP1).................................................................... 17
2.5 Connectors........................................................................................18
2.5.1 FAN Connector (FAN1~FAN6).................................................................. 19
2.5.2 ATX +12V CPU Power Connector (CN1、CN2)....................................... 19
2.5.3 Front Panel Bezel Connector (CN6) ......................................................... 19
2.5.4 ATX Power Connector (CN7).................................................................... 20
2.5.5 LAN Connector(CN9)................................................................................ 21
2.5.6 MINI PCIe SLOT (CN11)........................................................................... 22
2.5.7 LAN Connector (CN12)............................................................................. 23
2.5.8 Digitial Input/Output Connector (CN14) .................................................... 24
2.5.9 I/O board connector (CN15)...................................................................... 24
2.5.10 LAN Connector (CN20)............................................................................. 25
2.5.11 VGA Connector (VGA1)............................................................................. 26
2.5.12 LCM Power Connector (LCM1)................................................................. 26
2.5.13 Serial Port Connector (COM1,COM2)....................................................... 27
2.5.14 USB 2.0Connectors (USB1, USB2).......................................................... 27
2.5.15 Serial ATA Connectors (SSATA1~SSATA4) .............................................. 27
2.5.16 Serial ATA Connectors (SATA1~SATA4) ................................................... 28
2.5.17 ATX 4 Pin 12V In Connector (ATX1)......................................................... 28

vi
2.5.18 PMBUS Connector (PMBUS1).................................................................. 28
2.6 Hardware Installation........................................................................29
2.6.1 Installing the CPU...................................................................................... 29
2.6.2 Install the Memory..................................................................................... 32
2.6.3 Install the Expansion Slot (optional).......................................................... 33
Chapter 3 AMI BIOS Setup Utility .......................... 35
3.1 Starting...............................................................................................35
3.2 Navigation Keys ................................................................................35
3.3 Main Menu..........................................................................................37
3.4 Advanced Menu.................................................................................38
3.5 Platform Configuration .....................................................................55
3.6 Socket Configuration........................................................................60
3.7 Security Menu....................................................................................62
3.8 Boot Menu..........................................................................................63
3.9 Save & Exit Menu ..............................................................................65
Appendix A LAN Bypass Configuration .................... 69
About LAN Bypass.......................................................................................69
LAN Bypass Register Configuration ..........................................................70
Appendix B WDT Timer for System Reset ................ 73
WDT (Watchdog Timer) ...............................................................................73
Appendix C LAN Module Expansion ......................... 75
Appendix D Warning ................................................. 83

NA860 Series User’s Manual
Introduction 1
Chapter 1
Introduction
This chapter contains general information and detailed specifications of the NA860 Series
Network Appliance Server. It contains the following sections:
General Description
Features
Specifications
Dimensions and Outlines
I/O Outlets
1.1 General Description
The NA860 is a 2U rack mountable network security hardware platform for VPN, firewall and
other network security applications. It supports next generation Intel®dual LGA3647 Socket
Intel Skylake sever processors and Intel®C62x chipset with twelve DDR4 2400 RDIMM
memory up to 384GB.
For storing event log data, the NA860 utilizes two 2.5” SATA HDD. For greater flexibility and
easier maintenance, the NA860 has eight front-accessible expansion slots that allow
developers to configure different LAN modules based on their solution requirements.
The NA860 is designed especially for enterprise sized business. NA860 not only provides high
performance processor, memory, storage interface and LAN connection, but also includes
outstanding management capability.
1.2 Features
Intel® Dual Xeon processor Scalable Family (Skylake-SP) Socket LGA3647
Twelve DIMM Socket support RDIMM DDR4 2400 max up to 384GB.
Supports eight LAN modules expansion
Supports BIOS redirected to COM port
Supports two 2.5” SATA HDD (hot swappable)
Suitable for VPN, network bandwidth controller, firewall applications
Supports redundant power

NA860 Series User’s Manual
2 Introduction
1.3 Specifications
System
System CPU
Intel Dual ®Xeon® Processor Scalable Family (Skylake-SP)
Intel Single ®Xeon® Processor Scalable Family (Skylake-SP)-NA861

System Chipset
Intel®C621
System Memory
Twelve DIMM Socket support DDR4 RDIMM 2400 max up to 384GB.
Six DIMM Socket support DDR4 RDIMM 2400 max up to 192GB (NA861)
BIOS
AMI 256Mbit PnP Flash BIOS with function of BIOS redirected to COM port
HDD Tray
Two 2.5” Trays for SATA HDD, support hot swappable.
LAN
The default is two 10/100/1000Mbps LAN ports(Intel® i210AT) Expandable up to 66
LAN ports via 8 expendable LAN modules (Dual CPUs only).
LAN module
Limitation: Single CPU only supports 4 LAN modules (Slot 1~4)
Note: NA860 can support total 8 slots of LAN module, but for LAN Bypass feature can
be supported 5 slots only.

NA860 Series User’s Manual
Introduction 3
SSD
1 x mSATA
2 x 2.5HDD hot swappable
I/O Interface for NA860
AX93341:One console RJ-type connector, Two USB3.0 connectors and 2 gigabyte
LAN ports ,1 x 4 LED for Power、HDD、GPIO1/GPIO2,TACT switchx1 (Default is HW
reset)
8 x LAN modules (optional)up to 66 LAN ports (Dual CPUs only)
1X LCM module
I/O Interface for NA861
AX93345:One console RJ-type connector, Two USB2.0 connectors and 2 gigabyte
LAN ports ,1 x 4 LED for Power、HDD、GPIO1/GPIO2,TACT switchx1 (Default is HW
reset)
4 x LAN modules (optional)up to 34 LAN ports
1X LCM module
Watchdog Timer
One for System Reset: 255 levels, 1-255 sec
LAN bypass: 7 levels, 1-64 sec for each slot
Note: NA860 can support total 8 slots of LAN module, but for LAN Bypass feature
can be supported 5 slots only.
Hardware Monitoring
Controller Nuvoton NCT6102D & NCT7802Y
CPU temperature, system temperature, power and fan speed detection
Expansion Slot
One PCI Express Mini Card socket
Two PCI Express*8 Slot through AX96709 riser card(optional) NA860 Only
Graphics
One VGA port
Power Supply
800W Redundant Power Supply-NA860
400W Redundant Power Supply or Single Power Supply-NA861
OS Compatibility
Linux Kernel
Mechanical/Environmental
Form Factor
2U rack mount-NA860
1U rack mount-NA861
LED
Power, HDD, GPIO LEDs and LAN bypass LEDs depend on LAN module.
Operation Temperature
0°C ~ 40°C (32°F ~ 104°F)
Humidity
10% - 95% RH, non-condensing

NA860 Series User’s Manual
4 Introduction
Chassis Material
Steel
Dimensions
88mm (3.46”) (H) x 430mm (16.92”) (W) x 562mm (”) (D) NA860
44 mm (1.73") (H) x 430 mm (16.92”) (W) x 561 mm (22") (D) NA861
Certificate
FCC class A / CE class A
Note: All specifications and images are subject to change without notice.

NA860 Series User’s Manual
Introduction 5
1.4 Dimensions and Outlines
The following diagram shows you dimensions and outlines of the NA860 Series.
Default: 2 LAN ports / Expandable up to 66 LAN ports

NA860 Series User’s Manual
6 Introduction
The following diagram shows you dimensions and outlines of the NA861 Series.
Default: 2 LAN ports / Expandable up to 34 LAN ports

NA860 Series User’s Manual
Introduction 7
1.5 I/O Outlets
Locate front and rear panel I/O outlets on the NA860 Series server to connect serial and
Ethernet interface devices.
1.5.1 Front Panel (NA860/NA861)
LAN modules
LCM
Console
USB3.0
2x2.5 HDD
2xMgmt port
LAN modules
LCM Console 2xMgmt port
USB2.0X2

NA860 Series User’s Manual
8 Introduction
Front Side I/O
Power /GPO LED1
HDD /GPO LED2
Slot-3Slot-2Slot-1
2.5" HDD Tray(2in1)
Slot-4
Reset Tact Switch Console USB 0/1
LAN1/2
LCM + Key Pad
Slot-5 Slot-6 Slot-7 Slot-8
GPIO LEDs (Green)
The GPIO1 and GPIO2 LEDs are controlled by programmable GPIO. A sample code
will be provided that allow users to define their own function.
HDD LED (Green)
LED flashes when HDD is transmitting or receiving data.
Power LED (Green)
LED flashes when the server is powered on to perform diagnostic tests and proper
operation checking.
Console Port
This is a RJ-type connector console port for command line interface and diagnostic
support by P.O.S.T (Power On Self-Test).
USB Ports
Two USB 3.0 ports supported.
“Reset” Tact Switch (default)
It is for reset the system to reboot your computer instead of turning OFF the power
switch. It is a better way to reboot your system for a longer life of the system’s power
supply, or GPI/power bottom by jumper setting.
Transfer Rate for LAN port
The double-color LED light indicates 10/100/1000Mbps transfer rate.
LED Light Color
Transfer Rate
Dark
10Mbps
Green
100Mbps
Orange
1000Mbps
If the LED is dark and Active/Link LED is lighting on flashing, the transfer rate
should be 10Mbps.
When the green-color LED light is radiating, the transfer rate should be
100Mbps.
When the orange-color LED light is radiating, the transfer rate should be
1000Mbps.
When this LED and Link/Active LED both are dark, no networking devices are
attached.

NA860 Series User’s Manual
Introduction 9
Active/Link LED for LAN Port
The orange LED is on when the LAN port connection is working.
The LED flashes when transmitting or receiving any signals to or from the
appliance.
The LED is dark when the appliance is off.
Note: Optional LAN module LED definition in Appendix C.

NA860 Series User’s Manual
10 Introduction
1.5.2 Rear Panel (N860/NA861)
Fan VGA PSU
Fan
PSU
VGA
Expansion slot

NA860 Series User’s Manual
Introduction 11
Rear Side I/O
System Fan
Redundant Power
VGA Port
CPU1 Fan CPU2 Fan
Expansion Slot
Power Alarm Reset
Power Supply
Redundant power supply; use power cord to connect this power supply to electrical
outlet (AC)and also provide an alarm reset for power supply, when one of power has
damage.
Power Alarm Reset
Alarm reset is used to clear fail status by shorting circuit activities.
Buzzer should alarm if signal goes low.
VGA
This is a standard D-Sub connector commonly used for VGA display.
CPU & System Fan
These are fans for cooling down system& CPU temperature.
Expansion Slot(optional)
Through AX96709 rise card can support 2x PCIEx8 slot.

NA860 Series User’s Manual
12 Introduction
This page is intentionally left blank.

NA860 Series User’s Manual
Hardware and Installation 13
Chapter 2
Hardware and Installation
The NA860 Series are convenient for your various hardware configurations. This chapter will
help you get familiar with the hardware.
2.1 Check List
The package bundled with your NA860 Series should contain the following items:
The NA860 Series network appliance hardware platform
Power cord x2 (redundant power 1+1)
Mounting brackets for rack installation (left/right) x 2
Screw for mounting bracket x4
Plastic stand for stack–up x 4
Console cable (RJ-type connector) x 1 for optional
Passive CPU heat sink x2
Processor Clip x2
If you cannot find this package or any items are missing, please contact Axiomtek distributors
immediately. If you order any optional components, the package might contain those additional
hardware or documents accordingly.

NA860 Series User’s Manual
14 Hardware and Installation
2.2 Board Layout
TOP
