AR-B5205 Series User Manual
1
AR-B5205
Intel® Pentium® M/Celeron® M 478-pin Micro-FCPGA PROCESSOR
NETWORKING BOARD
User Manual
Manual Rev.: 1.0
Book Number: AR-B5205-2010.02.09

AR-B5205 Series User Manual
2
Revision
Version Date Author Description
1.0 2010/02/09
Xavier Initial release.

AR-B5205 Series User Manual
3
Copyright 2010
All Rights Reserved.
Manual’s first edition:
For the purpose of improving reliability, design and function, the information in this document is
subject to change without prior notice and does not represent a commitment on the part of the
manufacturer.
In no event will the manufacturer be liable for direct, indirect, special, incidental, or
consequential damages arising out of the use or inability to use the product or documentation, even
if advised of the possibility of such damages.
This document contains proprietary information protected by copyright. All rights are reserved.
No part of this Manual may be reproduced by any mechanical, electronic, or other means in any
form without prior written permission of the manufacturer.
Trademarks
AR-B5205 is a registered trademarks of Acrosser; IBM PC is a registered trademark of the
International Business Machines Corporation; Pentium is a registered trademark of Intel
Technologies Inc; Award is a registered trademark of Award Software International Inc; other
product names mentioned herein are used for identification purposes only and may be trademarks
and/or registered trademarks of their respective companies.

AR-B5205 Series User Manual
4
Table of Contents
1 Introduction ...................................................................5
1.1 Specifications................................................................................................6
1.2 Package Contents.........................................................................................7
2 H/W Information.............................................................9
2.1 Locations - Main Chips and Standard Connectors.....................................9
2.2 Connectors and Jumper Setting ................................................................11
2.3 Connector and Jumper Setting Table........................................................ 12
3 BIos setting..................................................................15
3.1 Main Setup................................................................................................... 16
3.2 Advanced Setup.......................................................................................... 17
3.3 Power Setup................................................................................................18
3.4 PnP/PCI Setup............................................................................................. 19
3.5 Peripheral Setup..........................................................................................20
3.6 PC Health Setup..........................................................................................21
3.7 Boot Setup................................................................................................... 22
3.8 Exit Setup ....................................................................................................23
4 BIOS refreshing, WatchDog, GPIO programming....25
4.1 BIOS Refreshing.......................................................................................... 25
4.2 WatchDog Programming............................................................................. 26
4.3 GPIO Programming.....................................................................................29
5 BYPASS programming ...............................................32
6 Electrical Characteristics ...........................................35
6.1 Basic Electrical Characteristics Table....................................................... 35

AR-B5205 Series User Manual
5
The AR-B5205 is a non-standard platform board special design for Networking microbox and
1U 19”Rackmount system. AR-B5205 uses Intel chipsets 910GMLE and ICH6M support for CPU
Celeron M/Pentium M processors up to 1.8GHz to provide exceptional performance with low power
consumption. The board support up to 2GB DDR2 system memory at 400MHz(default onboard
512MB DDR2), by leveraging the PCI Express technology both provide total of four onboard Intel
82574L PCI-E x1 GbE ports plus two Intel 82541PI PCI GbE ports to maximize network bandwidth.
Among the Ethernet ports, integrated a pair of configurable By-Pass function ensure
continuous operation during power interruption or any unexpected system halt. For Storage
interface, it provides SATA and Compact Flash for Operating system installation or Internet security
applications. Also it features a 9-pin RS-232 serial port, VGA port, and two USB ports for I/O
connectivity. In addition, the PCI slot offers easy expansion of add-on card(AR-R5205 series only),
also a LCD Module(AR-R5205 series only) supplies a good tool for local system management,
maintenance and diagnostics.
AR-B5205 series offer the flexibility, and power efficiency which are ideally for many internet
security applications, such as UTM (Unified Threat Management), WAS (Web Access
Management), VPN and Anti-Spam mail server etc.. System integrators can easily develop their
internet security solutions with Gigabit Ethernet, expandable HDDs, and the convenient modular
design.
AR-B5205 features:
 Intel 910GMLE + ICH6M chipsets support Intel Celeron M/Pentium M.
 2 Memory slots, support 2GB max.
 6 Gigabit Ethernet.
 Console re-direction port.
 Bypass function.
1
INTRODUCTION

AR-B5205 Series User Manual
6
1.1Specifications
Item Description
General
CPU 1. Onboard Celeron M 600MHz 512KB L2 Cache.
2. Onboard Celeron M 1GHz zero L2 cache.
3. Support socket type Intel Celeron M and Pentium M CPU.
Memory Two SO-DIMM socket support dual channel DDRII 400 SDRAM up to 2GB.
BIOS AWARD, Support Console re-direction.
Chipsets Intel 910GMLE + ICH6M.
Watchdog Timer Software programmable 1~255 Seconds.
Network Interface
Ethernet 4 x Intel 82574L (10/100/1000Mbps) (L1~L4).
2 x Intel 82541PI (10/100/1000Mbps) (L5~L6).
LAN by-Pass LAN1 and LAN2 support by-pass function.
I/O
Front panel HDD/Power LED: Green/Yellow.
6 LAN LED: Link/Act & Speed.
Rear panel 1. Power Inlet.
2. USBx2.
3. 6 x RJ45 Gbps LAN.
4. Reset Button.
5. HDD/Power LED (Green/Yellow).
6. Com port(RS-232).
Internal I/O
1. 4xUSB 2.0.
2. Mini-PCI.
3. PS/2 Keyboard and mouse connector.
4. GPIO: 8-bit GPIO, 1 x GND, 1 x 3.3V/5V jumper selectable.
Storage
Compact Flash 1 x Compact Flash socket(Master mode), Support UDMA.
SATA 2 x SATA interface.
Mechanical
Dimension 180 X 180mm.
Operating
Temperature 0~45
o
C (32~104
o
F).
Storage
Temperature -20~80
o
C (-4~176
o
F).
Relative Humidity 0 to 90% @ 40°C, non-condensing (95% @ 40°C, Non-Condensing by
request).
Power Input DC12V single power input.
EMC & Safety
EMC CE, FCC Class A.

AR-B5205 Series User Manual
7
1.2Package Contents
Check if the following items are included in the package.
 Quick Manual.
 AR-B50205.
 1 x Software Utility CD.

AR-B5205 Series User Manual
8
Block Diagram
81801FBM
(ICH6M)
SATA x2
SATA
82541PI x2
USB 2.0 x6
USB
PCI SLOT
RS232
miniPCI SLOT
CF Card Slot
PATA
GPIO
PCI BUS
FWH 8Mbits
82574L x4
Super I/O
LPC BUS
W83627EFG
BRIDGE
SOUTH
PCI Express
KB/MS
(BIOS)
(COM2)
RS232
For LCMFor console
redirection
(COM1)
LAN1 & LAN2 support BYPASS
82910GMLE
HOST BUS
NORTH
CRT OUT
DMI
BRIDGE
Intel Pentium M processr
DDR2 SO-DIMM x2
Intel Celeron M processr
FSB400/479-ball uFCBGA
FSB400/478-pin uFCPGA

AR-B5205 Series User Manual
9
This chapter describes the installation of AR-B5205. At first, it shows the function diagram and
the layout of AR-B5205. It then describes the unpacking information which you should understand,
as well as the jumper/switch settings for the AR-B5205 configuration
2.1 Locations - Main Chips and Standard Connectors
(Topside)
2
H/W INFORMATION
BAT1
Battery Connector
USB1
USB connector
CPU
Intel Celeron M /Pentium M CPU
PCI Ethernet Controller IC x 2
Intel Ethernet controller 82541PI
FAN1 & FAN2
FAN connector
PCI EXPRESS Ethernet Controller IC x
4
Intel Ethernet controller 82574L
North Bridge
Intel 915GME
PCI1
PCI Slot
DDR2SODIMM1
Connector for DDR2 SDRAM
Super I/O Controller
Winbond W3627EHG
2LAN1~2LAN3
RJ45 connector for LAN1~LAN6
South Bridge
Intel Integrated Control Hub（ICH6M）
COM1
RS232
SATA1 & SATA2
Connector for SATA Hard Disk

AR-B5205 Series User Manual
10
(Bottom side)
MPCI1
Mini-PCI Slot
CF1
Slot for Compact Flash
DDR2SODIMM2
Connector for DDR2 SDRAM

AR-B5205 Series User Manual
11
2.2 Connectors and Jumper Setting
2.2.1 Locations (Top side)
LED2~LED7 (Right to Left)
LED indicator for LAN1~LAN6
(Right to Left)
CN8
Connector for Power Switch
CN7
CPLD Program Interface
ATX_12V1
Connector for Regular ATX 4 pin 12V
Input
USB2 & USB3
Each Connector for 2 ports USB
CN5
LCM module interface
LED1
LED indicator for Power On and
Hard Disk
JP3
RTC Reset
JP5
CPU Core Selection - Banias or
Dothan
KBMS1
PS/2 Keyboard and Mouse Connector
VGA1
VGA1 is for CRT output
CN3
Power Supply for SATA Hard Disk
RST_BTN1
Reset Bottom for System Reset
GPIO1
Connector For General Purpose I/O
LED0
The same function with LED1
JP4
GPIO Power Level Switch
PWR1
Power connector forAdapter
POWER-IN

AR-B5205 Series User Manual
12
2.3 Connector and Jumper Setting Table
2.3.1 LED2~LED7 (Right to Left) 2.3.2 CN7-CPLD Program Interface
COLOR SIGNAL
GREEN LINK/ACT
GREEN/YELLOW
100/1000
PIN
SIGNAL
1 3.3V
2 TDO
3 TDI
4 NC
5 NC
6 TMS
7 GND
8 CLK
2.3.3 USB2&USB3-Each Connector for Two Ports
2.3.4 LED1-Indicator for Power-On and Hard
Disk
PIN
SIGNAL
PIN
SIGNAL
1
5V 2
5V
3
-USB_L
4
-USB_R
5
+USB_L
6
+USB_R
7
GND 8
GND
9
GND 10
GND
COLOR
SIGNAL
GREEN
POWER
YELLOW
HARD DISK
2.3.5 JP5-CPU Core Selection – Banias or
Dothan 2.3.6 VGA1-VGA1 is for CRT output
STATUS
DESCRIPTION
CLOSE
BANIAS
OPEN DOTHAN
PIN
SIGNAL
PIN
SIGNAL
1 RED 2 GND
3 GREEN
4 GND
5 BLUE 6 GND
7 V-SYNC
8 I2C CLOCK
9 H-SYNC
10 I2C DATA

AR-B5205 Series User Manual
13
2.3.7 RST_BTN1-Bottom for System Reset 2.3.8 LED0-The Same Function as LED1
S
TATUS
F
UNCTION
Push then Release
System Reset
COLOR
SIGNAL
GREEN
POWER
YELLOW
HARD DISK
2.3.9 PWR1-Connector for Power Input 2.3.10 CN8-Connector for Power Switch
PIN
SIGNAL
UP SIDE 12V
BOTTOM SIDE
GND
S
TATUS
SIGNAL
CLOSE
TURN-ON
OPEN
TURN-OFF
2.3.11 ATX_12V1-Connector for Regular ATX
4-pin 12V Input 2.3.12 CN5-LCM Module Interface
PIN
SIGNAL
RIGHT SIDE
12V
LEFT SIDE
GND
PIN
SIGNAL
1 RESET
2 5V
3 DATA OUT
4 DATA IN
5 RTS
6 CTS
7 GND

AR-B5205 Series User Manual
14
2.3.13 JP2-RTC power and reset 2.3.14 KBMS1-PS/2 Keyboard and Mouse
Connector
S
TATUS
FUNCTION
1-2 CLOSE
NORMAL
(DEFAULT)
2-3 CLOSE
RTC RESET
PIN
SIGNAL
PIN
SIGNA
L
1 MS DATA
4 5V
2 KB DATA
5 MS CLOCK
3 GND 6 KB CLOCK
2.3.15 CN3-Power Supply for SATA Hard Disk 2.3.16 GPIO1-Connector For General Purpose
I/O
PIN
SIGNAL
1 12V
2 GND
3 3.3V
4 5V
PIN
SIGNAL
PIN
SIGNAL
1 V_GPIO
2 GND
3 GPIO0
4 GPIO4
5 GPIO1
6 GPIO5
7 GPIO2
8 GPIO6
9 GPIO3
10
GPIO7
2.3.17 JP4-GPIO Power Level Switch
S
TATUS
F
UNCTION
1-2 CLOSE
5V
(DEFAULT)
2-3 CLOSE
3.3V

AR-B5205 Series User Manual
15
This chapter describes the BIOS menu displays and explains how to perform common tasks
needed to get the system up and running. It also gives detailed explanation of the elements found
in each of the BIOS menu displays. The following topics are covered:
 Main Setup
 Advanced Setup
 Power Setup
 PnP/PCI Setup
 Peripheral Setup
 PC Health
 Boot Setup
 Exit
Once you enter the BIOS CMOS setup utility, you can use the control keys that listed at the
bottom of the menu to select the desired value in each item.
3
BIOS SETTING

AR-B5205 Series User Manual
16
3.1 Main Setup
Option Choice Description
Date Setup N/A To set the system date. Note that the ‘Day’ automatically
changes when you set the date.
Time Setup N/A To set the system time.
IDE Channel 0
Master/Slave N/A Press <Enter> to view the IDE device’s information and related parameters.
Halt On
All Errors,
No Errors,
All, But
keyboard.
To select the situation in which you want the BIOS to stop
the POST process and notify you.

AR-B5205 Series User Manual
17
3.2 Advanced Setup
Option Choice Description
Quick Power On
Self Test Enabled
Disabled
This category speeds up Power On Self Test (POST) after you
have powered up the computer. If it is set to Enabled
, BIOS will
shorten or skip some check items during POST.
Full Screen Logo
Show Enabled Disabled Select Enabled to show the OEM full screen logo if you
have
add-in BIOS.
Boot Display CRT To set the display device.
DVMT mode FIXED DVMT
Both
To set the mode of Dynamic Video Memory Technology
(DVMT).
DVMT/FIXED
Memory Size
64MB
128MB
224MB To set the shared memory size for DVMT.

AR-B5205 Series User Manual
18
3.3 Power Setup

AR-B5205 Series User Manual
19
3.4 PnP/PCI Setup
Option Choice Description
Reset
Configuration
Data
Enabled
Disabled
Normally, you leave this field Disabled. Select Enabled
to
reset Extended Sy
stem Configuration Data (ESCD) when you
exit setup. If you have installed a new add-
on and the system
reconfiguration has caused such a serious conflict, then
the
operating system can not boot.
Resources
Controlled By Auto(ESCD) Manual
The Award Plug and
Play BIOS has the capacity to
automatically configure
all of the boot and Plug and Play
compatible devices. However, this
capability means
absolutely nothing unless you are using a Plug and Play
operating system such as Windows 95. If you set this field to
“manual,” then you may
choose specific resources by going
into each of the submenus.
IRQ Resources N/A When resources are controlled manually, assign a type
to
each system interrupt,depending on the type of the
device
that uses the interrupt.

AR-B5205 Series User Manual
20
3.5 Peripheral Setup
Option Choice Description
Onboard Serial Port 1
Onboard Serial Port 2
Serial Port 1: 3F8 / IRQ4
Serial Port 2: 2F8 / IRQ3
Select an address and the
corresponding
interrupt for each serial port.
USB Device setting Press Enter Press <Enter> to Enabled/Disabled USB
controllers and view device’s information.
OnChip IDE Device N/A Press <Enter> to Enabled/Disabled
IDE/SATA controllers or set parameters.
