ACS TVA-080 User manual

Technical manual BA 0318
Signal converter
TVA – 080 / 100 / 120 / 180 / 200 / 220
Isolation amplifier – active
for galvanic isolation, conversion and
adjustment of electrical standard signals
Evaluable input signals
 Direct voltage 0...10V / 0...1V / -5...+5V / -0,5...+0,5V
 Direct current 0...20mA / 4...20mA / -10…+10mA
 Pulse frequency modulated (PFM) current signal 90...520Hz
Output signals
 Direct voltage 0…10V / 2…10V – simultaneous outputs
 Direct current 0…20mA / 4…20mA - simultaneous outputs
Signal adjustment of zero value and amplification – optional
Single or double channel version – optional
Integrated measurand transducer supply – optional
Space saving safe isolation with 4kV~
Wide range power supply from 20 to 253V AC and DC
L a u t e r b a c h s t r . 5 7 – 84307 E g g e n f e l d e n – G e r m a n y
Tel: [phone] – F a x : + 4 9 8 7 2 1 / 9 6 6 8 - 30
i n f o @ a c s - c o n t r o l s ys t e m . d e – w w w . a c s - c o n t r o l s ys t e m . d e

TVA – 080 / 100 / 120 / 180 / 200 / 220
page 2 of 8
Index
Order code .................................................................................................................... 2
Application ................................................................................................................... 3
Function ........................................................................................................................ 3
Safety notes .................................................................................................................. 4
Installation .................................................................................................................... 4
Maintenance ................................................................................................................. 4
Repair ............................................................................................................................ 4
Electrical connection ................................................................................................ 5 / 6
Operation and display elements ................................................................................... 7
Technical data ............................................................................................................... 8
Order code
TVA – 080 – U0 Version single channel device, adjustable
TVA – 100 – U0 Version single channel device, adjustable, with measurand transducer supply
TVA – 180 – AB – U0 Version single channel device, fix adjusted
TVA – 120 – AB – U0 Version single channel device, fix adjusted, with measurand transducer supply
Input
code no. A
Output
code no. B
0…10V
1
0…10V
1
0…20mA
2
0…20mA
2
4…20mA
3
4…20mA
3
90…520Hz – PFM
P
special range
Y
special range
Y
TVA – 200 – U0 Version double channel device, adjustable, with measurand transducer supply
TVA – 220 – ABCD – U0 Version double channel device, fix adjusted, with measurand transducer supply
Input 1
order no. A
Input 2
order no. B
Output 1
order no. C
Output 2
order no. D
0…10V
1
0…10V
1
0…10V
1
0…10V
1
0…20mA
2
0…20mA
2
0…20mA
2
0…20mA
2
4…20mA
3
4…20mA
3
4…20mA
3
4…20mA
3
special
Y
special
Y
special
Y
special
Y
TVA –
080 – U0
TVA –
180 – U0
TVA –
100 – U0
TVA –
120 – U0
TVA –
200 – U0
TVA –
220 – U0
Fix adjusted version
x
x
x
Adjustable version
x
x
x
Measurand transducer supply
x
x
x
x
Single channel version
x
x
x
x
Double channel version
x
x

TVA – 080 / 100 / 120 / 180 / 200 / 220
page 3 of 8
Application
The active isolation amplifier of the series TVA is used, dependent on version, for galvanic isolation of electrical
standard signals 0..10V / 0..1V / -5..+5V / -0,5..+0,5V / 0..20mA / 4..20mA / -10..+10mA or a pulse frequency
modulated (PFM) current signal 90...520Hz or for convert it into another standard signal or to adjust the signals
in the zero value and/or end value resp. amplification.
A galvanic isolation is sometimes the only possibility at error generating ground loops, unwished signal
overlapping and potential problems.
Thus, a current flow between more signal current circuits that distort the signal is avoided.
The free configurable resp. fix signal conversion, dependent on version, allows the flexible adaption of different
systems among each other, e.g. for connection of a 2-wire-measurand transducer with a current signal 4...20mA
to the input 0...10V of a SPS control.
The adjustable version is suitable, if sections, e.g. 5...14mA of a standard signal 4...20mA at the input should
amplified to a complete standard signal e.g. 4...20mA or e.g. for zero value adjustment of a fix adjusted
measurand transducer e.g. because of a position dependent zero value shifting.
At the versions TVA – 200 – U0 / TVA – 220 – U0 in one device there can be two electrical signals simultaneous
transmitted separately or one electrical standard signal can be doubled into two separated electrical standard
signals by parallel or series connection.
The signal input for pulse frequency modulated (PFM) current signal 90...520 Hz in combination with
corresponding measurand transducer resp. signaling transmitter is especially suited for long transmission links
of several 1000 m. The special type of the signal makes in insensitive against the negative characteristics of
cables, that occurs only at higher length, like e.g. resistance and inductivity as well as error current through the
isolation.
Function
Measuring principle
Version TVA – 080 – U0 / TVA – 100 – U0 / TVA – 200 – U0 – adjustable version
The connected electrical standard signal 0..10V / 0..1V / -5..+5V / -0,5..+0,5V / 0..20mA / 4..20mA / -10..+10mA
is measured by the evaluation circuit, adjusted according to the front-sided trimmer and transmitted galvanically
isolated to the simultaneous output signals 0...10V and 0...20mA or 2...10V and 4...20mA according to the
settings of the internal configuration switches.
The respective current resp. voltage signals at the output can be used simultaneous. Therefore there are
simultaneous 2 output signals at the single channel versions TVA – 080 – U0 / TVA – 100 – U0 and
simultaneous 4 output signals at the double channel version TVA – 200 – U0 are available.
Examples:
 TVA – 100 – U0 Input signal: 0...10V is converted to output signal: 0...10V / 0...20mA
 TVA – 100 – U0 Input signal: 5...18mA is converted to output signal: 2...10V / 4...20mA
 TVA – 200 – U0 Input signal 1: 0...10V is converted to output signal 1: 0...10V / 0...20mA and
Input signal 2: 4...18mA is converted to output signal 2: 2...10V / 4...20mA
Version TVA – 120 – U0 / TVA – 180 – U0 / TVA – 220 – U0 – fix adjusted version
The connected electrical standard signal 0..10V / 0..20mA / 4..20mA or the pulse frequency modulated (PFM)
current signal 90...520Hz (not for the version TVA – 220 – U0) is transmitted by the evaluation circuit
galvanically isolated to the output signal 0...10V or 0...20mA or 4...20mA.
Examples:
 TVA – 120 – U0 Input signal: 0...10V is converted to output signal: 0...10V
 TVA – 120 – U0 Input signal: 90...520Hz is converted to output signal: 4...20mA
 TVA – 220 – U0 Input signal 1: 0...10V is converted to output signal 1: 0...10V and
Input signal 2: 4...20mA is converted to output signal 2: 0...20mA
Measurand transducer supply
Version TVA – 100 – U0 / TVA – 120 – U0 / TVA – 200 – U0 / TVA – 220 – U0
The integrated measurand transducer supply allows the direct connection and thus the supply of 2-wire and 3-
wire transmitter.
At the versions TVA – 200 – U0 / TVA – 220 – U0 the measurand transducer supply is two times available, one
for each channel separately.
Version TVA – 080 – U0 / TVA – 180 – U0
A measurand transducer supply is not available.

TVA – 080 / 100 / 120 / 180 / 200 / 220
page 4 of 8
Safety notes
Each person that is engaged with inauguration and operation of this device, must have read and
understood this technical manual and especially the safety notes.
Installation, electrical connection, inauguration and operation of the device must be made by a qualified
employee according to the informations in this technical manual and the relevant standards and rules.
The device may only be used within the permitted operation limits that are listed in this technical manual.
Every use besides these limits as agreed can lead to serious dangers.
The device meets the legal requirements of all relevant EC directives.
Installation
The device is conceived for vertical installation on a standard fastening rail acc. to DIN EN 60715 TH 35-7,5
resp. TH 35-15.
DIN EN 60715 TH 35-7,5
DIN EN 60715 TH 35-15
The device must be installed protected against dust and humidity, e.g. in control stations or in a suitable
protection housing with a minimum protection classification IP55 acc. to DIN EN 60529.
The devices must be installed wheather and stroke protected, ideally at places without direct solar radiation.
This is especially important in warm climatic regions.
Maintenance
The device is free of maintenance.
Repair
A repair may only be carried out by the manufacturer. When sending back the device, add a note with the
description of the error and the application.

TVA – 080 / 100 / 120 / 180 / 200 / 220
page 5 of 8
Electrical connection
The electrical connection of the device must be carried out according to the respective country specific
standards. Incorrect installation or adjustment could cause applicationally conditioned risks.
Power supply input, measuring input and signal output channels are safe galvanically isolated from each other.
This is also valid for both measuring input and signal output channels among each other.
Connection of the signaling transmitter resp. measuring transducer – measuring inputs
For the two, three or four-wire connection cable between the isolation amplifier and the signaling transmitter
resp. measuring transducer a standard installation cable or multi-wire cable for measuring intends with a
maximum of 25  per wire can be used.
The use of a shielded signal cable is recommended, if strong electromagnetic influences could happens, e.g.
due to machines or radio equipment. In that case the shielding of the cable should be connected to earth only at
the side of signaling transmitter resp. measuring transducer.
The signal cable should be installed separated from power leading wires.
The connected signaling transmitter resp. measuring transducer can be, dependent on version, powered by the
integrated measuring transducer supply. The supply is overload and short circuit protected.
The maximum values of the inputs at the isolation amplifier (current input maximum 400mA - 30V / voltage input
50V) must not be transgressed. The current input is equipped with a self resetting fuse.
At activation of the fuse the signal current wire must be disconnected for app. 5 seconds.
Terminal occupation
Connection scheme

TVA – 080 / 100 / 120 / 180 / 200 / 220
page 6 of 8
Electrical connection
Connection of the output
For the two-wire connection cable between the isolation amplifier and the connected devices a standard
installation cable or multi-wire cable for measuring intends with a maximum of 25  per wire can be used.
The use of a shielded signal cable is recommended, if strong electromagnetic influences could happens, e.g.
due to machines or radio equipment. In that case the shielding of the cable should be connected to earth only at
the side of the connected device. When connecting a SPS input stage there must be paid attention that mostly
the signal circuit must be connected to earth by connection the minus terminal with measuring earth.
The signal cable should be installed separated from power leading wires.
For inauguration it is suggested, to deactivate all connected control devices, to avoid unwanted control reactions.
Connection of the power supply voltage
Due to the integrated wide range power supply, for connection to supply voltages from 20...253V AC / DC, the
isolation amplifier is suitable for using in all common energy supply networks.
The connection is reverse polarity protected.
A fuse is integrated internally at the power supply circuit. Due to this the installation of a fine protection is not
necessary.
Terminal occupation
Connection scheme

TVA – 080 / 100 / 120 / 180 / 200 / 220
page 7 of 8
Operation and display elements
Function indicator
 ON  green LED  ready status, power supply voltage on
Trimmer
For adjustment of zero and end value per channel. Only available at versions TVA – 080 / 100 / 200.
For an accurate results the adjustment zero value – end value must be proceeded repeatedly with connected signal,
because zero and end value adjustment effects each other.
Configuration switches
The configuration of the input and output signal ranges is made per dip switches inside the housing.
Dangerous voltage
Ensure a safe switching off the supply voltage when opening the housing
For configuration release the upper housing part at top and bottom side behind the terminals by using a screwdriver and pull
it out of the housing. Drop-in pin's avoid a complete pulling out. Following the respective dip switches can be set according to
the desired functions to ON or OFF.
Input signal range channel 1 switcher block SB1
Switch 1, 2, 3 (SB1)  measuring range
switching state S1
switching state S2
switching state S3
measuring range CH 1
OFF
ON
ON
-0,5...+0,5V / -10...+10mA
ON
OFF
OFF
4...20mA
OFF
OFF
ON
0...1V / 0...20mA
OFF
ON
OFF
-5...+5V / -10...+10mA
OFF
OFF
OFF
0...10V / 0...20mA
Input signal range channel 2 switcher block SB3
Switch 1, 2, 3 (SB3)  measuring range
switching state S1
switching state S2
switching state S3
measuring range CH 2
OFF
ON
ON
-0,5...+0,5V / -10...+10mA
ON
OFF
OFF
4...20mA
OFF
OFF
ON
0...1V / 0...20mA
OFF
ON
OFF
-5...+5V / -10...+10mA
OFF
OFF
OFF
0...10V / 0...20mA
Output signal range channel 1 switcher block SB1
Switch 4 (SB1)  signal range
switch
switching state ON
switching state OFF
4
0...10V / 0...20mA
2...10V / 4...20mA
Output signal range channel 2 switcher block SB3
Switch 4 (SB3)  signal range
switch
switching state ON
switching state OFF
4
0...10V / 0...20mA
2...10V / 4...20mA
Channel 2
Trimmer for zero and
end value adjustment
only at version
TVA – 200
Function indicator
1 LED for indication of
ready status
Channel 1
Trimmer for zero and
end value adjustment
only at version
TVA – 080 / 100 / 200
Configuration switch
inside the housing
only at versions
TVA – 080 / 100 / 200

TVA – 080 / 100 / 120 / 180 / 200 / 220
page 8 of 8
Technical data
Auxiliary power supply
Permitted supply voltage: 20 V to 253 V AC / DC 48...62 Hz, reverse polarity protected
Power consumption:  3 VA / 1,5 W (TVA – 080 / 180) resp.  5 VA / 3 W (TVA –100 / 120) resp.
 7 VA / 5 W (TVA – 200 / 220)
Overvoltage category: II acc. to DIN EN 61010-1
Protection classification: II double or reinforced insulation
Isolation voltage: 4kV~ auxiliary power to signal inputs to signal outputs
Galvanic isolation: All supply, input and output channels among each other as well as both input and
output channels from each other are safe galvanically isolated.
Signal input (1x resp. 2x available, depends on version)
Direct voltage: 0…10 V / 0...1 V / -5...+5 V / -0,5...+0,5 V / max. 50V / input resistance 1,1M
Direct current: 0…20mA / 4…20mA / -10...+10mA / max. 400mA at 30V
self-resetting fuse / input resistance 25 + 0,2V
PFM modulated current signal: 90...520 Hz, overlapping current pulse 5mA10%, TPulse=110µs20%
Measurand transducer supply: overload and short circuit protected
 TVA – 100 / 120 3- wire-sensor:  18,7V at 20mA  18,3V at 27,5mA min. 27,5mA / max. 25V
2- wire-sensor:  18,3V at 20mA  17,9V at 27,5mA min. 27,5mA / max. 25V
 TVA – 200 / 220 3- wire-sensor:  17,6V at 20mA  17,5V at 22,5mA min. 22,5mA / max. 25V
2- wire-sensor:  17,3V at 20mA  17,1V at 22,5mA min. 22,5mA / max. 25V
Signal output (1x resp. 2x available, depends on version)
Direct voltage: 0…10 V / 2...10 V, max. 17V, overload and short circuit protected
Permitted load direct voltage:
 TVA – 080 / 100 / 120 / 180 RL  1250 at 10V / RL  2000 at 10V (at simultaneous output Iout with 20mA)
 TVA – 200 / 220 RL  3333 at 10V / RL  6666 at 10V (at simultaneous output Iout with 20mA)
Direct current: 0…20mA / 4…20mA, max. 28mA
Permitted load direct current:
 TVA – 080 / 100 / 120 / 180 RL  880 at 20mA / RL  680 at 20mA (at simultaneous output Uout with 5mA)
 TVA – 200 / 220 RL  570 at 20mA / RL  530 at 20mA (at simultaneous output Uout with 1,5mA)
Adjustment range zero value: –25...+5% of respective nominal measuring range
Adjustment range end value: –5...+45% of respective nominal measuring range
Transmission frequency:  500 Hz
Limit value deviation:  0,2% of factory calibrated measuring range (delivery setting)
Range changing deviation:  2% of respective nominal measuring range
Characteristic deviation:  0,05% of respective nominal measuring range
Temperature deviation:  0,05% / 10 K of respective nominal measuring range
Long term deviation:  0,1% of respective nominal measuring range / year
Influence output load:  0,05% of respective nominal measuring range
Materials
Connection housing: PA – polyamide
Terminal housing: PA – polyamide
Sticker: PE – polyester
Connection terminals
Number: 3 resp. 4 terminal blocks with each 4 terminals, everlasting screws
Connection cross-section: maximum 1 x 2,5 mm or 2 x 1,5 mm
Housing style
Housing: Series installation housing, 22,5mm wide
Weight: 100 g
Environmental conditions
Environmental temperature: Single installation – 40°C...+70°C versions TVA – 080 / 100 / 120 / 180
– 40°C...+60°C versions TVA – 200 / 220
Series installation – 40°C...+60°C versions TVA – 080 / 100 / 120 / 180
– 40°C...+50°C versions TVA – 200 / 220
Climatic classification: 3K3 resp. 3M2 DIN EN 60721-3-3
Protection classification: IP20 DIN EN 60529
EM – compatibility: emission DIN EN 61326-1 operation device class B
immunity DIN EN 61326-1 industrial range
