ACS A1214 Expert User manual

Ultrasonic flaw detector А1214 EXPERT
Operation Manual
1
ACOUSTIC
CONTROL
SYSTEMS
ULTRASONIC
FLAW DETECTOR
Acoustic Control Systems – ACS Group
Saarbrücken, Germany 2019
А1214
EXPERT
OPERATION MANUAL

Ultrasonic flaw detector А1214 EXPERT
Operation Manual
2
ACOUSTIC
CONTROL
SYSTEMS

Ultrasonic flaw detector А1214 EXPERT
Operation Manual
3
ACOUSTIC
CONTROL
SYSTEMS
CONTENTS
1 DESCRIPTION AND OPERATION............................................................................................................................6
1.1 INTENDED USE..................................................................................................................................................................6
1.1.1 Intended use and area of application .................................................................................................................................6
1.1.2 Operating conditions......................................................................................................................................................................6
1.2 TECHNICAL SPECIFICATIONS ..................................................................................................................................6
1.2.1 Main parameters.................................................................................................................................................................................6
1.3 DESIGN AND OPERATION .........................................................................................................................................8
1.3.1 Design .........................................................................................................................................................................................................8
1.3.2 Transducers............................................................................................................................................................................................9
1.3.3 Interface....................................................................................................................................................................................................9
1.3.4 Operation modes..............................................................................................................................................................................9
1.3.5 Display of information on the screen ................................................................................................................................10
1.3.6 Keyboard ..................................................................................................................................................................................................11
1.3.7 Working with icons ..........................................................................................................................................................................13
2 INTENDED USE..............................................................................................................................................................14
2.1 OPERATING LIMITATIONS..........................................................................................................................................14
2.2 PREPARING THE DEVICE FOR USE .....................................................................................................................14
2.2.1 Turning the instrument On/Off..............................................................................................................................................14

Ultrasonic flaw detector А1214 EXPERT
Operation Manual
4
ACOUSTIC
CONTROL
SYSTEMS
2.2.2 Selecting the transducer............................................................................................................................................................14
2.3 OPERATING MODES.....................................................................................................................................................16
2.3.1 SETTING mode ....................................................................................................................................................................................16
2.3.2 FLAW DETECTOR mode.............................................................................................................................................................46
2.3.3 The STOP mode.................................................................................................................................................................................51
2.4 Surface preparation for measurements...........................................................................................................56
3 TECHNICAL MAINTENANCE....................................................................................................................................57
3.1 ELECTRIC POWER SUPPLY AND POWER CONSUMPTION.....................................................................57
3.1.1 Checking the power source .......................................................................................................................................................57
3.1.2 Checking of the power adapter.............................................................................................................................................57
3.2 REGULAR MAINTENANCE.........................................................................................................................................57
3.3 MALFUNCTIONS .............................................................................................................................................................57
4 STORAGE .........................................................................................................................................................................58
5 TRANSPORTATION ......................................................................................................................................................59
APPENDIX A.......................................................................................................................................................................60

Ultrasonic flaw detector А1214 EXPERT
Operation Manual
5
ACOUSTIC
CONTROL
SYSTEMS
2.2.2 Selecting the transducer............................................................................................................................................................14
2.3 OPERATING MODES.....................................................................................................................................................16
2.3.1 SETTING mode ....................................................................................................................................................................................16
2.3.2 FLAW DETECTOR mode.............................................................................................................................................................46
2.3.3 The STOP mode.................................................................................................................................................................................51
2.4 Surface preparation for measurements...........................................................................................................56
3 TECHNICAL MAINTENANCE....................................................................................................................................57
3.1 ELECTRIC POWER SUPPLY AND POWER CONSUMPTION.....................................................................57
3.1.1 Checking the power source .......................................................................................................................................................57
3.1.2 Checking of the power adapter.............................................................................................................................................57
3.2 REGULAR MAINTENANCE.........................................................................................................................................57
3.3 MALFUNCTIONS .............................................................................................................................................................57
4 STORAGE .........................................................................................................................................................................58
5 TRANSPORTATION ......................................................................................................................................................59
APPENDIX A.......................................................................................................................................................................60
The current operation manual (hereinafter referred to as “Operation Manual”) includes in-
formation on the technical specifications, design and operation of the А1214 EXPERT Ultrasonic
Flaw Detectors (hereinafter referred to as “flaw detector” or “instrument”) and their operation
principle, as well as information on the proper use of the instrument.
Please carefully read the operation manual prior to starting to work with the device.
Only properly trained personnel who carefully read the operation manual, and knows the
general principles of the theory of ultrasonic vibrations should be allowed to work with the device.
For proper ultrasonic testing the following preparatory works shall be performed: the control
tasks shall be defined, the testing schemes and the transducer shall be selected, and the inspec-
tion conditions of the given materials shall be evaluated and etc.
During the production of the instrument some modifications can be introduced to it due
to the constant improvement of its reliability and serviceability. They do not affect the technical
specifications of the instrument. Some of the modifications may not be described in current
revision of the Operation Manual.
Manufacturer:
ACS-Solutions GmbH
Science Park 2
66123 Saarbrucken, Germany
Phone: [phone]
Fax: [phone]
Е-mail: [e-mail]
Website: www.acs-international.com

Ultrasonic flaw detector А1214 EXPERT
Operation Manual
6
ACOUSTIC
CONTROL
SYSTEMS
1.1.1 Intended use and area of application
The instrument is a portable general-purpose ultrasonic device.
The instrument is designed for searching, evaluation and localization of various discontinuities, defects and irregularities
in different objects made of metal and plastic.
The flaw detector allows generation, registration and recording of time realizations of pulse ultrasonic signals in its memory.
A color TFT display indicates the ultrasonic signals in form of A-Scans. The instrument provides both manual and automatic
measurement of time intervals, signal amplitudes as well as automatic determination of locations of the flaws.
1.1.2 Operating conditions
The instrument is designed to operate under the following conditions:
- temperature from - 30 to +55 ˚С;
- relative air humidity up to 95 % at + 35 ˚С upper temperature limit.
DESCRIPTION
AND OPERATION
1.1 INTENDED USE
1
Name of the parameter Value
Ultrasonic reconstruction range from 500 to 14,999 m/s
Operating frequencies of transducers from 0.5 to 15.0 MHz
Tuning range of amplification (gain) of the receiving transducer (gain regulation range) from 0 to 100 dB
Gain deviation ±1.0 dB
Measurement range of the time intervals at frequency 2.5 MHz from 0 to 1 900 µs
Limits of permissible absolute measurement errors of the time intervals, where Тmeas. – mea-
sured value of time interval ±(0.1+0.0001·Тmeas.)
Table 1
1.2 TECHNICAL SPECIFICATIONS
1.2.1 Main parameters of the device
The main technical specifications of the instrument are presented in the Table 1.
▼

Ultrasonic flaw detector А1214 EXPERT
Operation Manual
7
ACOUSTIC
CONTROL
SYSTEMS
1
Table 1
Parameter Value
Measurement range of the depth of the flaw location (steel) with straight beam transducers:
transducer S3568 2.5A0D10CL
transducer D1771 4.0A0D12CL
from 7 to 6,000 mm
from 2 to 3,000 mm
Limits of permissible absolute measurement error of the depth of the flaw location (steel) with
the straight beam transducers, where H is the measured depth of the flaw location in mm ±(0.02·H+1.00)
Measurement ranges of the flaw locations (steel) with angle beam transducers:
transducer S5182 2.5А65D12CS
transducer S5096 5.0А70D6CS
from 2 to 1,300 mm
from 2 to 500 mm
Limits of permissible absolute measurement errors of the flaw locations (steel) with angle
beam transducers:
Depth, where H is the measured depth of the flaw location in mm
Length over the surface, where L is the measured length over the surface to the flaw in mm
±(0.03·H+1.00)
±(0.03·L+1.00)
Power supply specifications
Power supply source battery
Rated supply voltage of the battery unit 11.1V
Period of continuous operation of the instrument powered from the battery under normal cli-
matic conditions, min. 18.0 hours
Overall dimensions of the electronic unit 260×166×80 mm
Maximum weight of the electronic unit 1.8
Mean time between failures 18 000 hours
Average service life, min. 5 years
Operating conditions:
– air temperature
– relative air humidity at 35°С, max.
from – 30 to 55 ºC
95%
▼

Ultrasonic flaw detector А1214 EXPERT
Operation Manual
8
ACOUSTIC
CONTROL
SYSTEMS
1.3.1 Design
The flaw detector includes an electronic unit to which the removable piezoelectric transducers (PTs) are connected via cables.
1.3 DESIGN AND OPERATION
Figure 1
11.3.1.1 Electronic unit
The electronic unit provides the generation of electrical impulses for excitation of the piezoelectric transducer,
amplification of the signals received from the PT. The electronic unit generates and processes measurement results
and provides their display in digitalized form, records data into nonvolatile instrument’s memory and allows their
transfer to the external PC.
The external design of the electronic unit is presented in the Figure 1.
The instrument is controlled by means of a membrane keyboard. The display and LEDs on the housing of the
device indicate the signals, measurement results and state of the instrument.
The PT is connected via coaxial cables (included in the delivery kit) by means of the LEMO
connectors.
The instrument is powered from the battery unit or a power adaptor included in the de-
livery kit.
1.3.1.2 Power adapter
The power adapter provides external power supply of the instrument and charging of the
battery unit from AC mains (15 V).
The charge time depends on the depletion of the accumulator unit; it can last up to 3
hours. The instrument can be operated during charging of the battery.
Always connect the cable of the power adapter to the electronic unit first, then connect
the network cable to the power adapter, and then connect the network cable to the AC mains
to prevent damage of the instrument.

Ultrasonic flaw detector А1214 EXPERT
Operation Manual
9
ACOUSTIC
CONTROL
SYSTEMS
Figure 3
Figure 2
1
1.3.2 Transducers
The flaw detector is designed to operate with single crystal and double-crystal PTs with operating frequencies from 0.5
to 15.0 MHz.
Two cable types are used with the instrument depending on the type of the transducer. Hence, two connection ways of
the PT exist:
Single crystal transducers (S type) shall be connected via LEMO-LEMO single cable to the unmarked connector (Figure 2).
Double-crystal transducers (D type) shall be connected via LEMO-LEMO double cable. The connector marked with a red
dot is used for connection of the transmitting piezoelectric element, and the unmarked connector for the receiving piezoelectric
element (Figure 3).
1.3.3 Interface
The instrument has an intuitive interface. The content-addressable icon menu in different modes, names and schematic
indications of the keys allow quick understanding of instrument operation.
The display continuously indicates all information required for on-line inspection.
The library of configurations facilitates work with the instrument. The user can assign a unique name to each configuration.
Consequently, the user can adjust the instrument to be operated under different conditions and for inspection of various objects
in a good time. Then the only recourse the user has is to select the configuration from the list.
All settings of the device shall be saved if the instrument is switched off, stored without the battery unit or if the battery
unit goes dead.
1.3.4 Operation modes
The main operation modes of the instrument are as follows: FLAW DETECTOR, provided additionally are STOP and SETTINGS modes.
In the operating mode the instrument generates the sounding impulses, amplifies the received echo signals and displays
them, as well as performs measurements.
In the STOP mode the user can stop (freeze) the signal realizations (snapshots) displayed on the screen, record them into
Red
Red

Ultrasonic flaw detector А1214 EXPERT
Operation Manual
10
ACOUSTIC
CONTROL
SYSTEMS
1
Figure 4
Name of the of the configuration
Current date and time
Indicator of the accumulator
charge level
Menu of icons
Panel of measurement results
Measuring cursor
Marker
Display area of signal
First strobe
the memory, as well as view and delete saved snapshots.
In the SETTING mode the user can select and configure the parameters of the instrument settings. Always start working
with a new testing object in this mode.
1.3.5 Display of information on the screen
A color TFT display (640х480) indicates the measurement results and service information required to control the instrument.
The workspace of the screen is divided into several functional areas in each mode. In the Figure 4 the display in the FLAW
DETECTOR operating mode is shown.
