1.0.Introduction
More than just a smart card reader, the ACR100F (CCID) SIMFlash has a built-in flash memory and is
designed for both accessing plug-in (SIM-sized) smart cards and for data or application storage. It is
ideal for GSM solutions such as GSM management software and VoIP applications, electronic
payment systems, e-commerce, home banking, transportation, and computer and network access.
The flash memory acts like any combination of up to three drivers, which may include public, private,
CD-ROM (optional autorun area) and hidden drives, in order to boost security and flexibility when you
store different kinds of software. Aside from its Mass Storage Device Class compatibility, its plug and
play feature is enhanced with its smart card reader now CCID compliant, reducing driver installation
issues.
Document Title Here
Document Title Here Document Title Here [email protected]
www.acs.com.hk
Page 3 of 18
ACR100F (CCID) Reference Manual
Version 3.00 [email protected]
www.acs.com.hk

2.0.Features
USB combo device – works as smart card reader and mass storage
USB 2.0 Hi-Speed interface for flash and USB 1.1 Full-Speed interface for smart card reader
Bus-powered – no need for separate power supply or battery
Plug and play – CCID support brings utmost mobility
With protective USB cap and keychain loop
Smart card reader:
oSupports plug-in (SIM-sized) cards
oSupports ISO 7816 Class A, B and C (5 V, 3 V, 1.8 V) cards
oRead and write all microprocessor cards with T=0, T=1 protocols
oSupports SLE 4418/28/32, SLE 5542 memory cards
oSupports most common memory-based smart cards, including I2C bus protocol cards
(from 1k bits up to 1024k bits) and secure memory cards (Atmel AT88SC153 and
AT88SC1608)
oSupports Spec 11.11-compliant GSM cards
oSupports PPS (Protocol and Parameters Selection)
oShort circuit protection
Flash drive:
oMass Storage Device Class compatible
oBuilt-in 1 GB flash memory (Other memory sizes from 128 MB to 4 GB are available upon
request)
oUp to three partitions (private/security, public and CD-ROM/auto-run, and hidden)
oCompliant with the following international standards: ISO 7816, PC/SC, Microsoft WHQL,
FCC, CE and RoHS
Document Title Here
Document Title Here Document Title Here [email protected]
www.acs.com.hk
Page 4 of 18
ACR100F (CCID) Reference Manual
Version 3.00 [email protected]
www.acs.com.hk

3.0.System Block Diagram.0.System Block Diagram
The USB Hub Controller is the communication interface between the PC and the MCU of the smart
card and flash memory via USB port connection. The 1 GB flash memory is available for the end-user
to use as storage. In Windows Explorer, the device is detected as a removable disk. The ACR100F is
powered from the USB port without other external power supply.
The USB Hub Controller is the communication interface between the PC and the MCU of the smart
card and flash memory via USB port connection. The 1 GB flash memory is available for the end-user
to use as storage. In Windows Explorer, the device is detected as a removable disk. The ACR100F is
powered from the USB port without other external power supply.
1-GB Flash Memory
USB 2.0
Hub
Controller
USB
Interface
Computer
Smart Card
Smart Card
Interface Circuit
Figure 1: ACR100F System Block DiagramFigure 1: ACR100F System Block Diagram
Document Title Here
Document Title Here Document Title Here [email protected]
www.acs.com.hk
Page 5 of 18
ACR100F (CCID) Reference Manual
Version 3.00 [email protected]
www.acs.com.hk

4.0.Power Supply
The ACR100F requires a voltage of 5 V DC, 100 mA regulated power supply. It gets the power supply
from the PC.
4.1. Status LED
Bicolor LED in front of the reader indicates the activation status of the smart card and flash memory
interface.
GREEN LED:
Flashing slowly (turns on 200 ms for every 2 seconds)
Indicates smart card interface part is powered up and in the standby state. Either the smart
card has not been inserted or the smart card has not been powered up (if it is inserted).
Lighting up
Indicates the smart card power is switched on, i.e., the smart card is activated.
RED LED:
Lighting up
Indicates a communication between ACR100F and flash memory.
Document Title Here
Document Title Here Document Title Here [email protected]
www.acs.com.hk
Page 6 of 18
ACR100F (CCID) Reference Manual
Version 3.00 [email protected]
www.acs.com.hk

5.0.Smart Card Interface
The interface between the ACR100F and the inserted smart card follows the specifications of ISO
7816-3.
5.1. Smart Card Power Supply VCC (C1)
The current consumption of the inserted card must not be higher than 50 mA.
5.2. Programming Voltage VPP (C6)
According to ISO 7816-3, the smart card contact C6 (VPP) supplies the programming voltage to the
smart card. Since all common smart cards in the market are EEPROM based and do not require the
provision of an external programming voltage, the contact C6 (VPP) has been implemented as a
normal control signal in the ACR100F. The electrical specifications of this contact are identical to
those of the signal RST (at contact C2).
5.3. Card Type Selection
The controlling PC has to always select the card type through the proper command sent to the
ACR100F prior to activating the inserted card. This includes both the memory cards and MCU-based
cards. For MCU-based cards, the reader allows to select the preferred protocol, T=0 or T=1, however,
this selection is only accepted and carried out by the reader through the PPS when the card inserted
in the reader supports both protocol types. Whenever a MCU-based card supports only one protocol
type, T=0 or T=1, the reader automatically uses that protocol type, regardless of the protocol type
selected by the application.
5.4. Interface for Microcontroller-Based Cards
For microcontroller-based smart cards, only the contacts C1 (VCC), C2 (RST), C3 (CLK), C5 (GND)
and C7 (I/O) are used. A frequency of 4 MHz is applied to the CLK signal (C3).
5.5. Card Tearing Protection
The ACR100F provides a mechanism to protect the inserted card when it is suddenly withdrawn while
it is powered up. The power supply to the card and the signal lines between the ACR100F and the
card are immediately deactivated when the card is being removed. As a general rule, however, to
avoid any electrical damage, a card should only be removed from the reader while it is powered
down.
Note: The ACR100F never switches on the power supply to the inserted card by itself. This
must explicitly be done by the controlling computer through the proper command sent to the
reader.
Document Title Here
Document Title Here Document Title Here [email protected]
www.acs.com.hk
Page 7 of 18
ACR100F (CCID) Reference Manual
Version 3.00 [email protected]
www.acs.com.hk

6.0.USB Interface
The connection of the ACR100F to a computer through a USB port follows a USB Standard.
6.1. Communication Parameters
The ACR100F is connected to a computer through USB as specified in the USB Specification. The
ACR100F is working in high-speed mode, i.e. 480 Mbps, for the flash memory and USB 1.1 full-speed
mode for smart card interface.
Pin Signal Function
1 VBUS +5 V power supply for the reader
2 D- Differential signal transmits data between ACR100F and PC.
3 D+ Differential signal transmits data between ACR100F and PC.
4 GND Reference voltage level for power supply
6.2. Endpoints
The ACR100F uses the following endpoints to communicate with the host computer:
Control Endpoint 0 For setup and control purposes
Bulk OUT Endpoint 1 For the command to be sent from host to Mass Storage Interface
(data packet size is 64 bytes)
Bulk IN Endpoint 1 For response to be sent from Mass Storage Interface to host (data
packet size is 64 bytes)
Bulk OUT Endpoint 2 For command to be sent from host to CCID Interface (data packet
size is 16 bytes)
Bulk IN Endpoint 2 For response to be sent from CCID Interface to host (data packet
size is 16 bytes)
Document Title Here
Document Title Here Document Title Here [email protected]
www.acs.com.hk
Page 8 of 18
ACR100F (CCID) Reference Manual
Version 3.00 [email protected]
www.acs.com.hk

7.0.Communication Protocol
ACR100F interfaces with the host via USB connection. It is a compounded device consisting of two
interfaces: Chip Card Interface Device and Mass Storage.
The ACR100F Smart Card Interface shares the same core as the smart card interface of the ACR38
CCID. The Smart Card Interface will be identified as “ACR38-112c” once the reader FW is obtained.
(The command for this will be discussed later on). CCID covers all the protocols required for operating
smart cards and PIN.
The configurations and usage of USB endpoints on ACR100F Smart Card Interface shall follow CCID
Section 3. An overview is summarized below:
1. Control Commands are sent on control pipe (default pipe). These include class-specific
requests and USB standard requests. Commands that are sent on the default pipe report
information back to the host on the default pipe.
2. CCID Events are sent on the interrupt pipe.
3. CCID Commands are sent on BULK-OUT endpoint. Each command sent to smart card
reader has an associated ending response. Some commands can also have intermediate
responses.
4. CCID Responses are sent on BULK-IN endpoint. All commands sent to the smart card reader
have to be sent synchronously. (i.e. bMaxCCIDBusySlots is equal to 1)
The supported CCID features by ACR100F smart card interface are indicated in its Class Descriptor:
Offset Field Size Value Description
0 bLength 1 36h Size of this descriptor, in bytes.
1 bDescriptorTyp
e 1 21h CCID Functional Descriptor type.
2 bcdCCID 2 0100h CCID Specification Release Number in
Binary-Coded decimal.
4 bMaxSlotIndex 1 00h One slot is available
5 bVoltageSuppor
t 1 07h The Smart card reader can supply 1.8V,
3.0V and 5.0V to its slot.
6 dwProtocols 4 00000003h The Smart card reader supports T=0 and
T=1 Protocol
10 dwDefaultClock 4 00000FA0h Default ICC clock frequency is 4MHz
14 dwMaximumClock 4 00000FA0h Maximum supported ICC clock
frequency is 4MHz
18 bNumClockSuppo
rted 1 00h Does not support manual setting of clock
frequency
19 dwDataRate 4 00002A00h Default ICC I/O data rate is 10752 bps
23 dwMaxDataRate 4 0001F808h Maximum supported ICC I/O data rate is
344 kbps
27 bNumDataRatesS
upported 1 00h Does not support manual setting of data
rates
28 dwMaxIFSD 4 00000Feh Maximum IFSD supported by the smart
card reader for protocol T=1 is 254
32 dwSynchProtoco
ls 4 00000000h The Smart card reader does not support
synchronous card
36 dwMechanical 4 00000000h The Smart card reader does not support
special mechanical characteristics
Document Title Here
Document Title Here Document Title Here [email protected]
www.acs.com.hk
Page 9 of 18
ACR100F (CCID) Reference Manual
Version 3.00 [email protected]
www.acs.com.hk

Document Title Here
Document Title Here Document Title Here [email protected]
www.acs.com.hk
Page 10 of 18
ACR100F (CCID) Reference Manual
Version 3.00 [email protected]
www.acs.com.hk
Offset Field Size Value Description
40
dwFeatures
4
00010030h The Smart card reader supports the
following features:
Automatic ICC clock frequency
change according to
parameters
Automatic baud rate change
according to frequency and
FI,DI parameters
TPDU level exchange with the
smart card reader
44 dwMaxCCIDMessa
geLength 4 0000010Fh Maximum message length accepted by
the smart card reader is 271 bytes
48 bClassGetRespo
nse 1 00h Insignificant for TPDU level exchanges
49 bClassEnvelope 1 00h Insignificant for TPDU level exchanges
50 wLCDLayout 2 0000h No LCD
52 bPINSupport 1 00h No PIN Verification
53 bMaxCCIDBusySl
ots 1 01h Only 1 slot can be simultaneously busy
7.1. Command to the ACR100F (CCID)
In the normal operation, the ACR100F acts as a slave device with regard to the communication
between a computer and the reader. The communication is carried out in the form of successive
command-response exchanges. The computer transmits a command to the reader and receives a
response from the reader after the command has been executed. A new command can be transmitted
to the ACR100F only after the response to the previous command has been received.
There are two cases where the reader transmits data without having received a command from the
computer, namely, the Reset Message of the reader and the Card Status Message.
7.1.1. CCID Command Pipe Bulk-OUT Messages
The ACR100F shall follow the CCID Bulk-OUT Messages as specified in CCID section 4. In addition,
this specification defines some extended commands for operating additional features. This section
lists the CCID Bulk-OUT Messages to be supported by ACR100F.
7.1.1.1. PC_to_RDR_IccPowerOn
Activate the card slot and return ATR from the card.
Offset Field Size Value Description
0 bMessageTy
pe 1 62h
1 dwLength 4 00000000
h Size of extra bytes of this message
2 bSlot 1 Identifies the slot number for this command
5 bSeq 1 Sequence number for command
6
bPowerSele
ct 1
Voltage that is applied to the ICC
00h – Automatic Voltage Selection
01h – 5 volts
02h – 3 volts
7 abRFU 2 Reserved for future use
The response to this message is the RDR_to_PC_DataBlock message and the data returned is the
Answer To Reset (ATR) data.

Document Title Here
Document Title Here Document Title Here [email protected]
www.acs.com.hk
Page 11 of 18
ACR100F (CCID) Reference Manual
Version 3.00 [email protected]
www.acs.com.hk
7.1.1.2. PC_to_RDR_IccPowerOff
Deactivate the card slot.
Offset Field Si
ze Value Description
0 bMessageType 1 63h
1 dwLength 4 00000000h Size of extra bytes of this message
5 bSlot 1 Identifies the slot number for this
command
6 bSeq 1 Sequence number for command
7 abRFU 3 Reserved for future use
The response to this message is the RDR_to_PC_SlotStatus message.
7.1.1.3. PC_to_RDR_GetSlotStatus
Get current status of the slot.
Offset Field Size Value Description
0 bMessageType 1 65h
1 dwLength 4 00000000h Size of extra bytes of this message
5 bSlot 1 Identifies the slot number for this
command
6 bSeq 1 Sequence number for command
7 abRFU 3 Reserved for future use
The response to this message is the RDR_to_PC_SlotStatus message.
7.1.1.4. PC_to_RDR_XfrBlock
Transfer data block to the ICC.
Offset Field Size Value Description
0 bMessageType 1 6Fh
1 dwLength 4 Size of abData field of this message
5 bSlot 1 Identifies the slot number for this command
6 bSeq 1 Sequence number for command
7 bBWI 1
Used to extend the CCIDs Block Waiting
Timeout for this current transfer. The CCID
will timeout the block after “this number
multiplied by the Block Waiting Time” has
expired.
8 wLevelParameter 2 0000h RFU (TPDU exchange level)
10 abData Byte
array Data block sent to the CCID. Data is sent “as is” to the ICC (TPDU exchange level)
The response to this message is the RDR_to_PC_DataBlock message.
7.1.1.5. PC_to_RDR_GetParameters
Get slot parameters.
Offset Field Size Value Description
0 bMessageType 1 6Ch
1 DwLength 4 00000000
h Size of extra bytes of this message
5 BSlot 1 Identifies the slot number for this
command
6 BSeq 1 Sequence number for command

Document Title Here
Document Title Here Document Title Here [email protected]
www.acs.com.hk
Page 12 of 18
ACR100F (CCID) Reference Manual
Version 3.00 [email protected]
www.acs.com.hk
Offset Field Size Value Description
7 AbRFU 3 Reserved for future use
The response to this message is the RDR_to_PC_Parameters message.
7.1.1.6. PC_to_RDR_ResetParameters
Reset slot parameters to default value.
Offset Field Size Value Description
0 bMessageType 1 6Dh
1 DwLength 4 0000000
0h Size of extra bytes of this message
5 BSlot 1 Identifies the slot number for this
command
6 BSeq 1 Sequence number for command
7 AbRFU 3 Reserved for future use
The response to this message is the RDR_to_PC_Parameters message.
7.1.1.7. PC_to_RDR_SetParameters
Set slot parameters.
Offset Field Size Value Description
0 bMessageType 1 61h
1 dwLength 4 Size of extra bytes of this message
5 bSlot 1 Identifies the slot number for this command
6 bSeq 1 Sequence number for command
7
bProtocolNum
1
Specifies what protocol data structure follows.
00h = Structure for protocol T=0
01h = Structure for protocol T=1
The following values are reserved for future
use.
80h = Structure for 2-wire protocol
81h = Structure for 3-wire protocol
82h = Structure for I2C protocol
8 abRFU 2 Reserved for future use
10 abProtocolDat
aStructure Byte
array Protocol Data Structure
Protocol Data Structure for Protocol T=0 (dwLength=00000005h)
Offset Field Size Value Description
10
bmFindexDinde
x 1
B7-4 – FI – Index into the table 7 in ISO/IEC
7816-3:1997 selecting a clock rate conversion
factor
B3-0 – DI - Index into the table 8 in
ISO/IEC 7816-3:1997 selecting a baud rate
conversion factor
11 bmTCCKST0 1 B0 – 0b, B7-2 – 000000b B1 – Convention used (b1=0 for direct, b1=1
for inverse) Note: The CCID ignores this bit.
12 bGuardTimeT0 1 Extra Guardtime between two characters. Add 0 to 254 etu to the normal guardtime of
12 etu. FFh is the same as 00h.
13 bWaitingInteg
erT0 1 WI for T=0 used to define WWT

Document Title Here
Document Title Here Document Title Here [email protected]
www.acs.com.hk
Page 13 of 18
ACR100F (CCID) Reference Manual
Version 3.00 [email protected]
www.acs.com.hk
Offset Field Size Value Description
14 bClockStop 1
ICC Clock Stop Support
00h = Stopping the Clock is not allowed
01h = Stop with Clock signal Low
02h = Stop with Clock signal High
03h = Stop with Clock either High or Low
Protocol Data Structure for Protocol T=1 (dwLength=00000007h)
Offset Field Size Value Description
10
bmFindexDin
dex 1
B7-4 – FI – Index into the table 7 in ISO/IEC
7816-3:1997 selecting a clock rate conversion
factor
B3-0 – DI - Index into the table 8 in
ISO/IEC 7816-3:1997 selecting a baud rate
conversion factor
11
BmTCCKST1
1
B7-2 – 000100b
B0 – Checksum type (b0=0 for LRC, b0=1 for
CRC)
B1 – Convention used (b1=0 for direct, b1=1 for
inverse) Note: The CCID ignores this bit.
12 BGuardTimeT
1 1 Extra Guardtime (0 to 254 etu between two
characters). If value is FFh, then guardtime is
reduced by 1 etu.
13 BwaitingInt
egerT1 1 B7-4 = BWI values 0-9 valid
B3-0 = CWI values 0-Fh valid
14
bClockStop
1
ICC Clock Stop Support
00h = Stopping the Clock is not allowed
01h = Stop with Clock signal Low
02h = Stop with Clock signal High
03h = Stop with Clock either High or Low
15 bIFSC 1 Size of negotiated IFSC
16 bNadValue 1 00h Only support NAD = 00h
The response to this message is the RDR_to_PC_Parameters message.
7.1.2. CCID Bulk-IN Messages
The Bulk-IN messages are used in response to the Bulk-OUT messages. ACR100F shall follow the
CCID Bulk-IN Messages as specified in section 4. This section lists the CCID Bulk-IN Messages to
be supported by ACR100F.
7.1.2.1. RDR_to_PC_DataBlock
This message is sent by the smart card reader in response to PC_to_RDR_IccPowerOn,
PC_to_RDR_XfrBlock and PC_to_RDR_Secure messages.
Offset Field Size Value Description
0 bMessageType 1 80h Indicates that a data block is being sent from
the CCID
1 dwLength 4 Size of extra bytes of this message
5 bSlot 1 Same value as in Bulk-OUT message
6 bSeq 1 Same value as in Bulk-OUT message
7 bStatus 1 Slot status register as defined in CCID section
4.2.1
8 bError 1 Slot error register as defined in CCID section
4.2.1 and this specification section 5.2.8
9 bChainParame
ter 1 00h RFU (TPDU exchange level)
10 abData Byte
array This field contains the data returned by the CCID

Document Title Here
Document Title Here Document Title Here [email protected]
www.acs.com.hk
Page 14 of 18
ACR100F (CCID) Reference Manual
Version 3.00 [email protected]
www.acs.com.hk
7.1.2.2. RDR_to_PC_SlotStatus
This message is sent by the smart card reader in response to PC_to_RDR_IccPowerOff,
PC_to_RDR_GetSlotStatus, PC_to_RDR_Abort messages and Class specific ABORT request.
Offset Field Size Value Description
0 bMessageTy
pe 1 81h
1 dwLength 4 0000000
0h Size of extra bytes of this message
5 bSlot 1 Same value as in Bulk-OUT message
6 bSeq 1 Same value as in Bulk-OUT message
7 bStatus 1 Slot status register as defined in CCID section
4.2.1
8 bError 1 Slot error register as defined in CCID section
4.2.1 and this specification section 5.2.8
9 bClockStat
us 1
value =
00h Clock running
01h Clock stopped in state L
02h Clock stopped in state H
03h Clock stopped in an unknown state
All other values are RFU.

Document Title Here
Document Title Here Document Title Here [email protected]
www.acs.com.hk
Page 15 of 18
ACR100F (CCID) Reference Manual
Version 3.00 [email protected]
www.acs.com.hk
7.1.2.3. RDR_to_PC_Parameters
This message is sent by the smart card reader in response to PC_to_RDR_GetParameters,
PC_to_RDR_ResetParameters and PC_to_RDR_SetParameters messages.
Offset Field Siz
e Value Description
0 bMessageType 1 82h
1 dwLength 4 Size of extra bytes of this message
5 bSlot 1 Same value as in Bulk-OUT message
6 bSeq 1 Same value as in Bulk-OUT message
7 bStatus 1 Slot status register as defined in CCID section
4.2.1
8 bError 1 Slot error register as defined in CCID section
4.2.1 and this specification section 5.2.8
9
bProtocolNum
1
Specifies what protocol data structure follows.
00h = Structure for protocol T=0
01h = Structure for protocol T=1
The following values are reserved for future
use.
80h = Structure for 2-wire protocol
81h = Structure for 3-wire protocol
82h = Structure for I2C protocol
10
abProtocolData
Structure Byt
e
arra
y
Protocol Data Structure as summarized in
section 5.2.3.
7.1.3. Commands Accessed via PC_to_RDR_XfrBlock
7.1.3.1. GET_READER_INFORMATION
This command returns relevant information about the particular smart card reader model and the
current operating status such as the firmware revision number, the maximum data length of a
command and response, the supported card types, and whether a card is inserted and powered up or
not.
Note: This command can only be used after the logical smart card reader communication has
been established using the SCardConnect( ) API. For details of ScardConnect( ) API,
please refer to PC/SC specification.
Pseudo-APDU
CLA INS P1 P2 Lc
FF H09
H00 H00 H10 H
Command format (abData field in the PC_to_RDR_XfrBlock)
Response data format (abData field in the RDR_to_PC_DataBlock)
FIRMWARE MAX
_C MAX _R C_TY PE C_SE L C_ST AT

FIRMWARE 10 bytes data for firmware version
MAX_C The maximum number of command data bytes.
MAX_R The maximum number of data bytes that can be requested to be transmitted in a
response.
C_TYPE The card types supported by the smart card reader. This data field is a bitmap with
each bit representing a particular card type. A bit set to '1' means the corresponding
card type is supported by the reader and can be selected with the
SELECT_CARD_TYPE command. The bit assignment is as follows:
Byte 1 2
card type F E D C B
A
9 8 7 6 5 4 3 2 1 0
See Appendix A.1 for the correspondence between these bits and the respective card
types.
C_SEL The currently selected card type. A value of 00Hmeans that no card type has been
selected.
C_STAT Indicates whether a card is physically inserted in the reader and whether the card is
powered up:
00H: no card inserted
01H: card inserted, not powered up
03H: card powered up
7.2. Mass Storage
Mass Storage Device Class specifies all the protocols required for data transaction between the Host
(computer) and storage devices. The configurations and usage of USB endpoints on ACR100 shall
follow Mass Storage Class Bulk-Only Transport in Section 3 (Protocol Code) of the USB Mass
Storage Device Specification. This document is available at: www.usb.org.
An overview of this specification is summarized below:
1. Control Commands are sent on control pipe (default pipe). It is shared with the CCID
interface.
2. Data-Out Command Protocol uses the BULK-OUT endpoint to transfer data from the host to
the device.
3. Data-In Command Protocol uses the BULK-IN endpoint to transfer data from the device or to
return status about the device.
Document Title Here
Document Title Here Document Title Here [email protected]
www.acs.com.hk
Page 16 of 18
ACR100F (CCID) Reference Manual
Version 3.00 [email protected]
www.acs.com.hk

Appendix A. Supported Card Types
The following table is a list of the card types returned by GET_READER_INFORMATION corresponding
with the respective card type code:
Card type code Card Type
00HAuto-select T=0 or T=1 communication protocol
01HI2C memory card (1k, 2k, 4k, 8k and 16k bits)
02HI2C memory card (32k, 64k, 128k, 256k, 512k and 1024k bits)
03HAtmel AT88SC153 secure memory card
04HAtmel AT88SC1608 secure memory card
05HInfineon SLE4418 and SLE4428
06HInfineon SLE4432 and SLE4442
07HInfineon SLE4406, SLE4436 and SLE5536
08HInfineon SLE4404
09HAtmel AT88SC101, AT88SC102 and AT88SC1003
0CHMCU-based cards with T=0 communication protocol
0DHMCU-based cards with T=1 communication protocol
Document Title Here
Document Title Here Document Title Here [email protected]
www.acs.com.hk
Page 17 of 18
ACR100F (CCID) Reference Manual
Version 3.00 [email protected]
www.acs.com.hk

Document Title Here
Document Title Here
Document Title Here [email protected]
www.acs.com.hk
Page 18 of 18
ACR100F (CCID) Reference Manual
Version 3.00 [email protected]
www.acs.com.hk
Appendix B. Response Status Codes
The following table is a list of the error codes that may be returned by the ACR38:
Error Code Status
FFHSLOTERROR_CMD_ABORTED
FEHSLOTERROR_ICC_MUTE
FDHSLOTERROR_XFR_PARITY_ERROR
FCHSLOTERROR_XFR_OVERRUN
FBHSLOTERROR_HW_ERROR
F8HSLOTERROR_BAD_ATR_TS
F7HSLOTERROR_BAD_ATR_TCK
F6HSLOTERROR_ICC_PROTOCOL_NOT_SUPPORTED
F5HSLOTERROR_ICC_CLASS_NOT_SUPPORTED
F4HSLOTERROR_PROCEDURE_BYTE_CONFLICE
F3HSLOTERROR_DEACTIVATED_PROTOCOL
F2HSLOTERROR_BUSY_WITH_AUTO_SEQUENCE
E0HSLOTERROR_CMD_SLOT_BUSY
