Acson international A5VR ECO-PLUS Series User manual

Technical Manual
A5VR
CAREFREE SERIES
A5VR030DRM•A5VR035DRM•
A5VR040DRM•A5VR050DRM•
A5VR060DRM•A5VR065DRM•
A5VR070DRM•A5VR080DRM

1 1
A5VR
CAREFREE SERIES
A5VR030DRM•A5VR035DRM•
A5VR040DRM•A5VR050DRM•
A5VR060DRM•A5VR065DRM•
A5VR070DRM•A5VR080DRM
CONTENTS
1.0 NOMENCLATURE P2
1.1 OUTDOOR P2
1.2 INDOOR P2
2.0 APPLICATION INFORMATION P5
2.1 REFRIGERANT CIRCUIT DIAGRAM P5
2.2 INSTALLATION GUIDELINE P6
3.0 ENGINEERING & PHYSICAL DATA P18
4.0 PERFORMANCE CURVE P23
4.1 CAPACITY DROP DIAGRAM P23
5.0 OUTLINE & DIMENSION P27
6.0 WIRING DIAGRAM P34
7.0 SERVICE & MAINTENANCE P38
8.0 TROUBLESHOOTING P41
* All specicaons stated in this technical manual are for Cooling Only unit.
Please contact us for more informaon about Heat Pump unit.

2
NOMENCLATURE
A5VR Carefree series units are most suitable for commercial building, oce room, hotel, which includes
the outdoor units and mul-indoor units. The advantage of this product range is unique outdoor units with
inverter compressor. To meet dierent requirements, there are many indoor units to be chosen: ceiling
concealed, ceiling cassee, wall mounted, ducted blower and ceiling mounted;
Outdoor Units: A5VR-DRM Series
Product range: A5VR030DRM, A5VR035DRM, A5VR040DRM, A5VR050DRM, A5VR060DRM, A5VR065DRM,
A5VR070DRM, A5VR080DRM
Feature: The outdoor units are compact, and elegant design with low noise; the compressor is with advanced
technology of inverter, can meet the stageless energy level adjustment from 50% to 130%;
Nomenclature
A 5 V CC 022 V - 10 R B X A IA E
Applied region (Omied: China, D:Hong Kong, E:Other region)
Brand A: Acson
Refrigerant 5: R410A
V : Design for AVR
ModelCC: Ceiling Concealed
Capacity 022:2200W
Series V: V series
Type of addional heater
10-10X100W electric heater
Omied-no addional heater
Descripon of the unit
Power supply features A:220V~/50Hz
Feature of control, lter, and pump
Air return model
B: rear air return plenum, D: lower air return plenum
Type of connecng pipe
R: right connecng pipe, L: le connecng pipe
Nomenclature
A 5 VR 030 D R M - A BA E
Applied region (Omied: China, D:Hong Kong, E:Other region)
Descripon of the unit
Power supply features A:220V~/50Hz; F:380V/3N~/50Hz
Carefree Series
Type R:Heatpump Omied if cooling only
Series D: D series
Capacity 030:30,000 Btu/h
Model VR: Variable Refrigerant
Refrigerant 5:R410A
Brand A: Acson
Ceiling Concealed Indoor Units: A5VCC-V Series
Product Range: A5VCC022V, A5VCC025V, A5VCC028V, A5VCC032V, A5VCC036V, A5VCC040V, A5VCC045V,
A5VCC050V, A5VCC056V, A5VCC063V, A5VCC071V, A5VCC080V, A5VCC090V, A5VCC100V, A5VCC112V,
A5VCC125V, A5VCC140V, A5VCC160V
Feature: Concealed type, space saving, ESP is mulple;

3
Ceiling Cassee Indoor Units: A5VCK-V Series
Product Range: A5VCK028V, A5VCK032V, A5VCK036V, A5VCK040V, A5VCK045V, A5VCK050V, A5VCK056V,
A5VCK063V, A5VCK071V, A5VCK080V, A5VCK090V, A5VCK100V, A5VCK112V, A5VCK125V, A5VCK140V
Feature: 4 ways air supply evenly, streamlined design, in-build high eciency lter;
Nomenclature
A 5 V CK 028 V - 07 A IA E
Applied region (Omied: China, D:Hong Kong, E:Other region)
Descripon of the unit
Power supply features A:220V~/50Hz
Type of addional heater 07-07X100W electric heater
Omied-no addional heater
Series V: V series
Cooling capacity 028: 2800W
Model CK: Ceiling casee
V : Design for AVR
Refrigerant 5:R410A
Brand A: Acson
Wall Mounted Indoor Units: A5VWM-W Series
Product Range: A5VWM022W, A5VWM028W, A5VWM036W, A5VWM045W, A5VWM056W, A5VWM071W
Feature: elegant design, friendly installaon, In-build high eciency and mould proof lter, easy to detach
and clean.
Nomenclature
A 5 V WM 022 W - A IA E
Applied region (Omied: China, D:Hong Kong, E:Other region)
Descripon of the unit
Power supply features A:220V~/50Hz
Series W: W series
Capacity 022: 2200W
Model WM: Wall mounted
V : Design for AVR
Refrigerant 5:R410A
Brand A: Acson

4
Ceiling Mounted Indoor Units: A5VCM-V Series
Product Range: A5VCM056V, A5VCM071V, A5VCM112V, A5VCM125V
Feature: elegant design, friendly installaon;
Nomenclature
A 5 V CM 056 V - A IA E
Applied region (Omied: China, D:Hong Kong, E:Other region)
Descripon of the unit
Power supply features A:220V~/50Hz
Series V: V series
Cooling capacity 056: 5600W
Model CM: Ceiling Mounted
V : Design for AVR
Refrigerant 5:R410A
Brand A: Acson
Ducted Blower Indoors Units: A5VDB-V Series
Product Range: A5VDB125V, A5VDB140V, A5VDB224V
Feature:
Installed above ceiling with air supply duct working, meet the requirement for long distance air supply;
Nomenclature
A 5 V DB 125 V - A IA E
Applied region (Omied: China, D:Hong Kong, E:Other region)
Descripon of the unit
Power supply features A:220V~/50Hz
Series V: V series
Cooling capacity 125: 12500W
Model DB: Ducted Blower
V : Design for AVR
Refrigerant 5:R410A
Brand A: Acson

5
APPLICATION INFORMATION
2.1 Refrigerant Circuit Diagram
A5VR030/035/040/050/060/065/070/080DRM System Diagram
Circulatory system of refrigeraon and heang systems
Filter
Filter Filter
Electronic
expansion valve
Heat
exchanger Service valve
Service valve
Compressor
Oil separator
Four-way valve
Low-pressor sensor
Hairline tube
Shut-o valve
Shut-o valve
Electromagnec valve
Cool Flow
Warm Flow
High-pressure sensor
Gas-liquid separator
High-voltage switch
Single valve

6
Space for installaon of outdoor units
Single outdoor unit can be installed in one place, and mulple outdoor units can be installed together in one
larger place. Please reserve the minimum installaon space, the units may not operate properly if the space
is smaller than required.
2.2.1 An obstacle exists at the air intake side:
No obstacle exists at upper side
a. Single unit installaon
• Only one obstacle exists at the air intake side (see Figure 1)
• Obstacles exist at the both sides (see Figure 2)
b. Group units installaon (more than two units)
• Obstacles exist at the both sides (see Figure 3)
Obstacle exists at upper side
a. Single unit installaon
• One obstacle exists at the air intake side (see Figure 4)
• Obstacles exist at the air intake ,le and right side (see Figure 5)
b. Group units installaon (more than two units)
• Obstacles exist at the air intake ,le and right side (see Figure 6)
2.2 Installaon Guideline (Outdoor Clearance)
Figure 1 Figure 2 Figure 3

7
2.2.2 Obstacle exists at the air exhaust side
No obstacle exists at upper side
a. Single unit installaon (see Figure 7)
b. Group units installaon (more than two units) (see Figure 8)
• Obstacle exists at upper side
a. Single unit installaon (see Figure 9)
Figure 7 Figure 8 Figure 9
Figure 4 Figure 5 Figure 6

8
b. Group units installaon (more than two units)(see Figure 10)
2.2.3 Obstacles exist at the air exhaust and intake side
Model 1: The height of obstacle at intake side is absolute ,when the obstacle at exhaust side is higher than
units.
• No obstacle exists at upper side
a. Single unit installaon (see Figure 11)
b. Group units installaon (more than two units)(see Figure 12)
Figure 10
Figure 11 Figure 12

9
• Obstacles exist at upper side
a. Single unit installaon (see Figure 13)
The relaon of H, A, L is as follows:
LA
L ≤ H
0 < L ≤ 1/2H 750
1/2H < L ≤ H 1000
H < L The seng of foundaon is L ≤ H
Seal the boom of foundaon to prevent the exhausted air from crossing the unit.
b. Group units installaon (more than two units)(see Figure 14)
The relaon of H, A, L is as follows:
LA
L ≤ H
0 < L ≤ 1/2H 1000
1/2H < L ≤ H 1250
H < L The seng of foundaon is L ≤ H
Seal the boom of foundaon to prevent the exhausted air from crossing the unit,
Only install two units in the way.
Figure 13 Figure 14

10
Model 2: The height of obstacle at intake side is absolute ,when the obstacle at exhaust side is lower than
units.
• No obstacle exists at upper side
a. Single unit installaon (see Figure 15)
L ≤ H
b. Group units installaon (more than two units)(see Figure 16)
The relaon of H, A, L is as follows:
LA
0 < L ≤ 1/2H 250
1/2H < L ≤ H 300
• Obstacles exist at upper side
a. Single unit installaon (see Figure 17)
The relaon of H, A, L is as follows:
LA
L ≤ H
0 < L ≤ 1/2H 120
1/2H < L ≤ H 200
H < L The seng of foundaon is L ≤ H
Figure 15 Figure 16

11
Seal the boom of foundaon to prevent the exhausted air from crossing the unit,
Only install two units in the way.
2.2.4 Double-layer Installaon
• An obstacle exists at the air exhaust side (see Figure 19)
Seal opening A to prevent the exhausted air from crossing the unit. The drainage construcon space
required for the upper outdoor unit is about 100 mm. Water generated from the outdoor unit at the upper
layer cannot be directly drained to the outdoor unit at the lower layer. The overlaid units cannot exceed 2.
• An obstacle exists at the air intake side (see Figure 20)
Seal opening A to prevent the exhausted air from crossing the unit. The drainage pipe construcon space
required for the upper outdoor unit is about 100 mm. The overlaid units cannot exceed 2.
Figure 17 Figure 18
Seal the boom of foundaon to prevent the exhausted air from crossing the unit.
b. Group units installaon (more than two units)(see Figure 18)
The relaon of H, A, L is as follows:
LA
L ≤ H
0 < L ≤ 1/2H 250
1/2H < L ≤ H 300
H < L The seng of foundaon is L ≤ H

12
2.2.5 Mul-lined group installaon (In the roof, etc.)
• Mul-lined single installaon (see Figure 21)
• Mul-lined group installaon (more than two units a group)(see Figure 22)
The relaon of H, A, L is as follows:
LA
L ≤ H
0 < L ≤ 1/2H 250
1/2H < L ≤ H 300
H < L Can not be installed
Figure 21 Figure 22
Figure 19 Figure 20

13
2.2 Installaon Guideline (Cable size)
Carefree Series Outdoor Units
Model A5VR
030DRM
A5VR
035DRM
A5VR
040DRM
A5VR
050DRM
A5VR
050DRM(3)
A5VR
060DRM
A5VR
060DRM(3)
A5VR
065DRM
A5VR
070DRM
A5VR
080DRM
Power Supply 220V~/50Hz 380V/3N
~/50Hz
220V
~/50Hz
380V/3N
~/50Hz
220V
~/50Hz 380V/3N~/50Hz
Maximum Operang
Current (A) 23.9 24.3 24.6 34.3 16.1 34.3 16.1 34.3 18.7 18.7
Cable
Intersecon
Surface(mm2)4 4 4 6 4 6 4 6 4 4
Quanes 3 3 3 3 53535 5
Note:
• The lead-in posion of power cable must be provided a short circuit device with a sucient capacity. This device has a contact separaon of 3 mm at least.
• All cable shall be connected and xed ghtly, and connecng wires must be xed on the line card.
• All wires must not touch the refrigerant pipes and compressors, motors and other moving parts, and all the conducng wires must undergo safety measures to
prevent water, dust, corrosion, vibraon and rodents.
• All above intersecon surface of power wires are minimum requirements. The actual specicaons Inuenced by radiaon, temperature, length etc, please
adjust it according to the related electric manual.
Ceiling Concealed Indoor Units
Model A5VCC
022V
A5VCC025V
A5VCC028V
A5VCC032V
A5VCC036V
A5VCC040V
A5VCC045V
A5VCC050V
A5VCC056V
A5VCC
063V
A5VCC
071V
Power Supply 220V~/50Hz
Cable
Intersecon
Surface(mm2)
Normal 1.5
Electrical heater 1.5 2.5
Quanes 3
Model A5VCC
080V
A5VCC
090V
A5VCC
100V
A5VCC
112V
A5VCC
125V
A5VCC
140V
A5VCC
160V
Power Supply 220V~/50Hz
Cable
Intersecon
Surface(mm2)
Normal 1.5
Electrical heater 2.5 4
Quanes 3
Note:
• The lead-in posion of power cable must be provided a short circuit device with a sucient capacity. This device has a contact separaon of 3 mm at least.
• All cable shall be connected and xed ghtly, and connecng wires must be xed on the line card.
• All wires must not touch the refrigerant pipes and compressors, motors and other moving parts, and all the conducng wires must undergo safety measures to
prevent water, dust, corrosion, vibraon and rodents.
• All above intersecon surface of power wires are minimum requirements. The actual specicaons Inuenced by radiaon, temperature, length etc, please
adjust it according to the related electric manual.

14
Ceiling Cassette Indoor Units
Model A5VCK
028V
A5VCK
032V
A5VCK
036V
A5VCK
040V
A5VCK
045V
A5VCK
050V
A5VCK
056V
A5VCK
063V
A5VCK
071V
Power Supply 220V~/50Hz
Cable
Intersecon
Surface(mm2)
Normal 1.5
Electrical heater 2.5
Quanes 3
Model A5VCK
080V
A5VCK
090V
A5VCK
100V
A5VCK
112V
A5VCK
125V
A5VCK
140V
Power Supply 220V~/50Hz
Cable
Intersecon
Surface(mm2)
Normal 1.5
Electrical heater 4
Quanes 3
Note:
• The lead-in posion of power cable must be provided a short circuit device with a sucient capacity. This device has a contact separaon of 3 mm at least.
• All cable shall be connected and xed ghtly, and connecng wires must be xed on the line card.
• All wires must not touch the refrigerant pipes and compressors, motors and other moving parts, and all the conducng wires must undergo safety measures to
prevent water, dust, corrosion, vibraon and rodents.
• All above intersecon surface of power wires are minimum requirements. The actual specicaons Inuenced by radiaon, temperature, length etc, please
adjust it according to the related electric manual.
Wall Mounted Indoor Units
Model A5VWM022W A5VWM028W A5VWM036W A5VWM045W A5VWM056W A5VWM071W
Power Supply 220V~/50Hz
Cable
Intersecon
Surface(mm2)1.5
Quanes 3
Note:
• The lead-in posion of power cable must be provided a short circuit device with a sucient capacity. This device has a contact separaon of 3 mm at least.
• All cable shall be connected and xed ghtly, and connecng wires must be xed on the line card.
• All wires must not touch the refrigerant pipes and compressors, motors and other moving parts, and all the conducng wires must undergo safety measures to
prevent water, dust, corrosion, vibraon and rodents.
• All above intersecon surface of power wires are minimum requirements. The actual specicaons Inuenced by radiaon, temperature, length etc, please
adjust it according to the related electric manual.

15
Ducted Blower Indoor Units
Model A5VDB125V A5VDB140V A5VDB224V
Power Supply 220V~/50Hz 380V/3N~/50Hz
Cable
Intersecon
Surface(mm2)Normal 1.5 2.5
Quanes 3 5
Note:
• The lead-in posion of power cable must be provided a short circuit device with a sucient capacity. This device has a contact separaon of 3 mm at least.
• All cable shall be connected and xed ghtly, and connecng wires must be xed on the line card.
• All wires must not touch the refrigerant pipes and compressors, motors and other moving parts, and all the conducng wires must undergo safety measures to
prevent water, dust, corrosion, vibraon and rodents.
• All above intersecon surface of power wires are minimum requirements. The actual specicaons Inuenced by radiaon, temperature, length etc, please
adjust it according to the related electric manual.
Ceiling Mounted Indoor Units
Model A5VCM056V A5VCM071V A5VCM112V A5VCM125V
Power Supply 220V~/50Hz
Cable
Intersecon
Surface(mm2)Normal 1.5
Quanes 3
Note:
• The lead-in posion of power cable must be provided a short circuit device with a sucient capacity. This device has a contact separaon of 3 mm at least.
• All cable shall be connected and xed ghtly, and connecng wires must be xed on the line card.
• All wires must not touch the refrigerant pipes and compressors, motors and other moving parts, and all the conducng wires must undergo safety measures to
prevent water, dust, corrosion, vibraon and rodents.
• All above intersecon surface of power wires are minimum requirements. The actual specicaons Inuenced by radiaon, temperature, length etc, please
adjust it according to the related electric manual.

16
2.2 Installaon Guideline (Refrigerant Piping)
Refrigerant piping length limitations
Pipe Parts
Pipe
Length
Total length Actual length
A5VR030DRM ≤80m L1+L2+...
+Li+a+b+…+i
A5VR040~A5VR080DRM ≤120m
Longest pipe length
Actual length
A5VR030DRM ≤50m
L1+L2+... +Li+i
A5VR040~A5VR080DRM ≤75m
Equivalent
length
A5VR030DRM ≤60m
A5VR040~A5VR080DRM ≤85m
Equivalent length from rst bifurcaon/refnet to furthest piping secon ≤20m L2+... +Li+i
Height
dierence
Maximum height dierence between indoor units and outdoor units ≤20m -
Maximum height dierence between the indoor units ≤15m -
Bifurcaon/Refnet
Height dierence between
indoor units and outdoor units
Height dierence between
the indoor units

17
Equivalent length refers to the elbow and other parts of the tube with consideraon to the pressure lost aer
the conversion length.
The formula is as follows:
Equivalent length = actual length of pipe + number of elbows x Equivalent length of various elbows
The length of each branch is 0.5m, with the equivalent length of the elbow as follows:
Diameter
Equivalent length
Diameter
Equivalent length
Elbow(m) Elbow(m)
φ9.52 0.18 φ28.6 0.50
φ12.7 0.20 φ31.8 0.55
φ15.88 0.25 φ34.9 0.60
φ19.05 0.35 φ38.1 0.65
φ22.23 0.40
φ41.3 0.70
φ25.4 0.45
Note:
The equivalent length of elbow in the table above aims to fulll installaon standards: the pipe bending radius of curvature is R ≥ 3.5D (D for the pipe diameter),
about ≥ 3/4 of the original diameter before the pipe bending deformaon. If the elbow bending radius does not meet the above installaon standards, the
equivalent length is to be calculated separately (the smaller the bending radius, the longer the equivalent length).
• Maximum number of outdoor units that are compable with the outdoor unit models:
Outdoor unit Maximum number of
outdoor units
A5VR030DRM 5
A5VR035DRM 6
A5VR040DRM 6
A5VR050DRM 8
A5VR060DRM 9
A5VR065DRM 11
A5VR070DRM 11
A5VR080DRM 13

18
Carefree Series Outdoor Units
Model A5VR030
DRM
A5VR035
DRM
A5VR040
DRM
A5VR
050DRM
A5VR
050DRM(3)
A5VR
060DRM
A5VR
060DRM(3)
A5VR065
DRM
A5VR070
DRM
A5VR080
DRM
Cooling capacity (kW) 8.0 10.0 11.2 14.0 15.5 16.0 18.0 20.0 22.4
Heang capacity (kW) 9.0 11.2 12.5 16.0 18.0 18.0 20.0 22.4 24.0
Power 220V~/50Hz 380V/3N
~/50Hz
220V
~/50Hz
380V/3N
~/50Hz
220V
~/50Hz 380V/3N~/50Hz
Noise dB(A) 54 55 55 57 59 59 62
W×D×H(mm) 900*320*782 900*320*1222 900*320*1354
Weight (kg) 71 76 102 110 107 110 107 120 128 128
Power consumpon
in cooling (kW) 2.34 3.12 3.2 4.24 3.70 4.69 4.40 5.29 5.40 6.59
Ampere in cooling (A) 11.9 15.2 15.3 20.3 7.4 23.0 8.0 27.0 9.6 11.9
Power consumpon
in heang (kW) 2.32 2.66 3.25 4.36 3.90 4.84 4.20 5.16 5.70 6.00
Ampere in heang (A) 11.8 13.0 16.1 20.6 7.6 24.0 7.8 26.3 10.1 10.5
Max.indoors-quanty 56 6 8 9 11 11 13
Refrigerant R410A
Connecng
Pipe
gas expanded copper tube
liquid expanded copper tube
LiquidΦ(mm(in)) 9.52 (3/8”) 9.52 (3/8”)
GasΦ(mm(in)) 15.88 (5/8”) 19.05 (3/4”)
Note:
1. Cooling condion: Indoor D/W bulb Temp. 27/19°C,outdoor temperature: D/W bulb Temp.35/24°C;
2. Heang condion: Indoor D/W bulb Temp. 20/15°C,outdoor temperature: D/W bulb Temp.7/6°C;
3. The noise level is tested in the incomplete anechoic lab under the standard refrigeraon condion and got from the average values from three points, 1 meter
in front of the unit, 1 meter from two sides of the unit and half of the unit height plus I meter. The real noise value in operaon may be a lile higher than the
tested value due to the inuence of the actual environment;
4. The width is just for the unit, not including the width of boom edge.
ENGINEERING & PHYSICAL DATA

19
Ceiling Concealed Indoor Units
Model A5VCC
022V
A5VCC
025V
A5VCC
028V
A5VCC
032V
A5VCC
036V
A5VCC
040V
A5VCC
045V
A5VCC
050V
A5VCC
056V
Cooling capacity (kW) 2200 2500 2800 3200 3600 4000 4500 5000 5600
Heang capacity (kW) 2500 2800 3200 3600 4000 4500 5000 5600 6300
Power 220V~/50Hz
Sound level dB(A) 29 31 32 34 37
W×D×H(mm) 900*599*199
Weight (kg) 26 26 27 28 28
Power input(W) 43 47 57 62 96
Fan number 2
Air ow H: m³/h 430 600 630 730 900
ESP(Pa) 10Pa ,(0/30Pa adjustable)
Drain Φ(mm(in)) 20.5(4/5”)
Protecon An-freezing, overload
Pump head 700
Connecng
Pipe
gas expanded copper tube
liquid expanded copper tube
LiquidΦ(mm(in)) 6.35 (1/4”)
GasΦ(mm(in)) 9.52 (3/8”) 12.7 (1/2”)
Model A5VCC
063V
A5VCC
071V
A5VCC
080V
A5VCC
090V
A5VCC
100V
A5VCC
112V
A5VCC
125V
A5VCC
140V
A5VCC
160V
Cooling capacity (kW) 6300 7100 8000 9000 10000 11200 12500 14000 16000
Heang capacity (kW) 7100 8000 9000 10000 11200 12500 14000 16000 18000
Power 220V~/50Hz
Sound level dB(A) 37 40 43 46 47 49
W×D×H(mm) 1100*599*199 1384*490*250 1734*490*250 1994*490*250
Weight (kg) 33 33 30 41 47
Power input(W) 98 138 157 210 246 276 377
Fan number 3 2 3 4
Air ow H: m³/h 1050 1200 1200 1400 1700 1900 1900 2500
ESP(Pa) 10Pa ,(0/30Pa adjustable) 30(15) 50(30)
Drain Φ(mm(in)) 20.5(4/5”) R3/4
Protecon An-freezing, overload
Pump head 700
Connecng
Pipe
gas expanded copper tube
liquid expanded copper tube
LiquidΦ(mm(in)) 9.52 (3/8”)
GasΦ(mm(in)) 15.88 (5/8”)
