Midea PD series User manual

MIDEA
60Hz
PORTABLE
PD SERIES
SINGLE-HOLE

CONTENTS
1. Precaution............................................................................................................................................. 1
1.1 Safety Precaution............................................................................................................................... 1
1.2 Warning............................................................................................................................................... 1
2. Model Lists ........................................................................................................................................... 6
3.Function and control panel.................................................................................................................. 7
3.1 Function.............................................................................................................................................. 7
3.2 Control panel...................................................................................................................................... 8
4. Dimension........................................................................................................................................... 10
5. Refrigerant Cycle Diagram.................................................................................................................11
6. Wiring Diagram................................................................................................................................... 13
7 Electronic function.............................................................................................................................. 14
7.1 Terms and definitions...................................................................................................................... 14
7.2 Electric Control working environment........................................................................................... 14
7.3 Protection function .......................................................................................................................... 14
7.4 Fan-only mode function requirement ............................................................................................ 14
7.5 Cooling mode function requirement.............................................................................................. 14
7.6 Drying mode ..................................................................................................................................... 15
7.7 Heating mode (heater)..................................................................................................................... 16
7.8 Heating mode (heat pump).............................................................................................................. 16
7.9 Sensor malfunction.......................................................................................................................... 17
7.10 Some standard functions synopsis ............................................................................................. 17
8 Installation details............................................................................................................................... 19
8.1 Installation instructions .................................................................................................................. 19
8.2 Care and maintenance..................................................................................................................... 25
9 Basic test procedure........................................................................................................................... 27
9.1 Defective compressor ..................................................................................................................... 27
9.2 Sealed refrigeration system repairs............................................................................................... 29
9.3 Fan motor.......................................................................................................................................... 32
9.4 Capacitor........................................................................................................................................... 32
10 Characteristic of temperature sensor............................................................................................. 34
11 Troubleshooting ................................................................................................................................ 35

1
1. Precaution
1.1 Safety Precaution.
To prevent injury to the user or other people and property damage, the following instructions must
be followed.
Incorrect operation due to ignoring instruction will cause harm or damage.
Before service unit, be sure to read this service manual at first.
1.2 Warning
Installation
Do not use a defective or underrated circuit breaker. Use this appliance on a dedicated circuit.
There is risk of fire or electric shock.
For electrical work, contact the dealer, seller, a qualified electrician, or an Authorized service center.
Do not disassemble or repair the product, there is risk of fire or electric shock.
Always ground the product.
There is risk of fire or electric shock.
Install the panel and the cover of control box securely.
There is risk of fire of electric shock.
Always install a dedicated circuit and breaker.
Improper wiring or installation may cause fore or electric shock.
Use the correctly rated breaker of fuse.
There is risk of fire or electric shock.
Do not modify or extend the power cable.
There is risk of fire or electric shock.
Do not install, remove, or reinstall the unit by yourself(customer).
There is risk of fire, electric shock, explosion, or injury.
Be caution when unpacking and installing the product.
Sharp edges could cause injury, be especially careful of the case edges and the fins on the condenser and
evaporator.
For installation, always contact the dealer or an Authorized service center.
There is risk of fire, electric shock, explosion, or injury.
Do not install the product on a defective installation stand.

2
It may cause injury, accident, or damage to the product.
Be sure the installation area does not deteriorate with age.
If the base collapses, the air conditioner could fall with it, causing property damage, product failure, and
personal injury.
Do not let the air conditioner run for a long time when the humidity is very high and a door or a
window is left open.
Moisture may condense and wet or damage furniture.
Take care to ensure that power cable could not be pulled out or damaged during operation.
There is risk of fire or electric shock.
Do not place anything on the power cable.
There is risk of fire or electric shock.
Do not plug or unplug the power supply plug during operation.
There is risk of fire or electric shock.
Do not touch (operation) the product with wet hands.
There is risk of fire or electric shock.
Do not place a heater or other appliance near the power cable.
There is risk of fire and electric shock.
Do not allow water to run into electric parts.
It may cause fire, failure of the product, or electric shock.
Do not store or use flammable gas or combustible near the product.
There is risk of fire or failure of product.
Do not use the product in a tightly closed space for a long time.
Oxygen deficiency could occur.
When flammable gas leaks, turn off the gas and open a window for ventilation before turn the
product on.
Do not use the telephone or turn switches on or off. There is risk of explosion or fire.
If strange sounds, or small or smoke comes from product. Turn the breaker off or disconnect the
power supply cable.
There is risk of electric shock or fire.
Stop operation and close the window in storm or hurricane. If possible, remove the product from the
window before the hurricane arrives.
There is risk of property damage, failure of product, or electric shock.
Do not open the inlet grill of the product during operation. (Do not touch the electrostatic filter, if the

3
unit is so equipped.)
There is risk of physical injury, electric shock, or product failure.
When the product is soaked (flooded or submerged), contact an Authorized service center.
There is risk of fire or electric shock.
Be caution that water could not enter the product.
There is risk of fire, electric shock, or product damage.
Ventilate the product from time to time when operating it together with a stove, etc.
There is risk of fire or electric shock.
Turn the main power off when cleaning or maintaining the product.
There is risk of electric shock.
When the product is not be used for a long time, disconnect the power supply plug or turn off the
breaker.
There is risk of product damage or failure, or unintended operation.
Take care to ensure that nobody could step on or fall onto the outdoor unit.
This could result in personal injury and product damage.
Caution
Always check for gas (refrigerant) leakage after installation or repair of product.
Low refrigerant levels may cause failure of product.
Install the drain hose to ensure that water is drained away properly.
A bad connection may cause water leakage.
Keep level even when installing the product.
To avoid vibration of water leakage
Do not install the product where the noise or hot air from the outdoor unit could damage the
neighborhoods.
It may cause a problem for your neighbors.
Use two or more people to lift and transport the product.
Avoid personal injury.
Do not install the product where it will be exposed to sea wind (salt spray) directly.
It may cause corrosion on the product. Corrosion, particularly on the condenser and evaporator fins, could
cause product malfunction or inefficient operation.

4
Operational
Do not expose the skin directly to cool air for long periods of time. (Do not sit in the draft).
This could harm to your health.
Do not use the product for special purposes, such as preserving foods, works of art, etc. It is a
consumer air conditioner, not a precision refrigerant system
There is risk of damage or loss of property.
Do not block the inlet or outlet of air flow.
It may cause product failure.
Use a soft cloth to clean. Do not use harsh detergents, solvents, etc.
There is risk of fire, electric shock, or damage to the plastic parts of the product.
Do not touch the metal parts of the product when removing the air filter. They are very sharp.
There is risk of personal injury.
Do not step on pr put anything on the product. (outdoor units)
There is risk of personal injury and failure of product.
Always insert the filter securely. Clean the filter every two weeks or more often if necessary.
A dirty filter reduces the efficiency of the air conditioner and could cause product malfunction or damage.
Do not insert hands or other object through air inlet or outlet while the product is operated.
There are sharp and moving parts that could cause personal injury.
Do not drink the water drained from the product.
It is not sanitary could cause serious health issues.
Use a firm stool or ladder when cleaning or maintaining the product.
Be careful and avoid personal injury.
Replace the all batteries in the remote control with new ones of the same type. Do not mix old and
new batteries or different types of batteries.
There is risk of fire or explosion.
Do not recharge or disassemble the batteries. Do not dispose of batteries in a fire.
They may burn of explode.
If the liquid from the batteries gets onto your skin or clothes, wash it well with clean water. Do not use
the remote of the batteries have leaked.
The chemical in batteries could cause burns or other health hazards

5
Warning
-Do not use means to accelerate the defrosting process or to clean, other than those recommended by the
manufacturer.
-The appliance shall be stored in a room without continuously operating ignition sources (for example:
open flames, an operating gas appliance or an operating electric heater).
-Do not pierce or burn.
-Be aware that the refrigerants may not contain an odour.
-Appliance should be installed, operated and stored in a room with a floor area larger than 12 m2.
-Compliance with national gas regulations shall be observed.
-Keep ventilation openings clear of obstruction.
-The appliance shall be stored so as to prevent mechanical damage from occurring.
-A warning that the appliance shall be stored in a well-ventilated area where the room size corresponds to
the room area as specified for operation.
-Any person who is involved with working on or breaking into a refrigerant circuit should hold a current
valid certificate from an industry-accredited assessment authority, which authorises their competence to
handle refrigerants safely in accordance with an industry recognised assessment specification.
-Servicing shall only be performed as recommended by the equipment manufacturer. Maintenance and
repair requiring the assistance of other skilled personnel shall be carried out under the supervision of the
person competent in the use of flammable refrigerants.

6
2. Model Lists
ON/OFF
Capacity
units
10K
MPPDB-10CRN8-BCG8
10K
MPPDB-10HRN8-BCG8

7
3.Function and control panel
3.1 Function
※Operation mode: Cooling, Heating, Dry, Fan and Auto.
※ION (optional)
※Auto swing function.
※Timer function.
※Flexible installation kit.
※No bucket design.
※LED display.
※Sleep mode.
※Follow me function.(Optional)
※Washable filter.
※Self-diagnosis and auto-protection function.
※Anti-freezing control in cooling or drying mode. Prevent the water being freezed on evaporator by
sensing the evaporator pipe temperature in cooling or drying mode.
※Auto-restart. When the power supply is interrupted and then restore, the air conditioners automatically
restore the previous function setting.
※Time Delay Safety. Restarting is for approx. 3 minutes.

8
3.2 Control panel
MPPDB-10CRN8-BCG8, MPPDB-10HRN8-BCG8
(1) POWER button
Power switch on/off
(2) SLEEP button
Used to initiate the SLEEP operation.
(3) FAN/ION button (ION is optional)
Control the fan speed. Press to select the fan speed in four steps-LOW, MED, HI and AUTO.
The fan speed indicator light illuminates under different fan settings except AUTO speed. When select
AUTO fan speed, all the fan indicator lights turn dark. NOTE: Press this button for 3 seconds to initiate ION
feature. The ion generator is energized and will help to remove pollen and impurities from the air, and trap
them in the filter. Press it for 3 seconds again to stop the ION feature.
(4) UP (+) and DOWN (-) button
Used to adjust (increasing/decreasing) temperature settings (1 ℃/2 ℉increments) in a range of 17℃(62
℉) to 30 ℃(88℉) or the TIMER setting in a range of 0~24hrs.
NOTE: The control is capable of displaying temperature in degrees Fahrenheit or degrees Celsius. To
convert from one to the other, press and hold the Up and Down buttons at the same time, for 3 seconds.
(5) MODE select button
Select the appropriate operating mode. Each time you press the button, a mode is selected in a sequence
that goes from AUTO, COOL, DRY, FAN and HEAT (cooling only models without). The mode indicator
light illuminates under the different mode settings.
(6) TIMER button
Used to initiate the AUTO ON start time and AUTO OFF stop time program, in conjuction with the
(+)&(-) buttons. The timer on/off indicator light illuminates under the timer on/off settings.
(7) SWING button
(Applicable to the models with auto swing feature only)
Use to initiate the Auto swing feature when the operation is ON, press the SWING button can stop the

9
louver at the desired angle.
(8) LED Display
Show the set temperature in "℃" or "℉" and the Auto-timer settings. While on DRY and FAN modes, it
shows the room temperature.
Error codes:
E1- Room temperature sensor error-Unplug the unit and plug it back in. If error repeats, call for service.
E2- Evaporator temperature sensor error- Unplug the unit and plug it back in. If error repeats, call for
service.
E3- Condenser temperature sensor error- Unplug the unit and plug it back in. If error repeats, call for
service
E4- Display panel communication error- Unplug the unit and plug it back in. If error repeats, call for service.
EC- Refrigerant leakage detection malfunction- Unplug the unit and plug it back in. If error repeats, call for
service.
P1-Bottom tray is full - Connect the drain hose and drain the collected water away. If protection repeats,
call for service.
NOTE: When more than one codes occur, the priority of the code display order is:
EC—E4—E3—E2—E1—P1
(9) FOLLOW ME/TEMP SENSING feature(optional)
NOTE: This feature can be activated from the remote control ONLY. The remote control serves as a
remote thermostat allowing for the precise temperature control at its location.
To activate the Follow Me/Temp Sensing feature, point the remote control towards the unit and press the
Follow Me/Temp Sensing button. The remote display is actual temperature at its location. The remote
control will send this signal to the air conditioner every 3 minutes interval until press the Follow Me/Temp
Sensing button again. If the unit does not receive the Follow Me /Temp Sensing signal during any 7
minutes interval, the unit will beep to indicate the Follow Me/Temp Sensing mode has ended.

10
4. Dimension
Unit Dimension
W(mm)
H(mm)
D(mm)
small body
454
700
365
big body
467
765
397

11
5. Refrigerant Cycle Diagram
The figure below is a brief description of the important components and their function in what is called
the refrigeration system.
(1) This will help to understand the refrigeration cycle and the flow of the refrigerant in the cooling cycle.
LIQ UID S ID E
GAS S IDE
E VA PO RA TOR CO N DEN SER
CO MP RES S OR
CAP ILIA RY T UBE

12
(2).This figure below is fit for Heat Pump Unit.
LIQ U ID S ID E
G A S S ID E
H E AT
E X C H A N G E
(E V A P O R A T O R )
H E AT
E X C H A N G E
(C O N D E N SE R )
C O M P R ES S O R
C H E C K V A LV E
(H e atin g M od el only)
C A P IL IA R Y T U B E
R E V E R S IN G V A LV E
(H e atin g M od el only)
C O O L IN G
H E AT IN G
A C C U M U L AT O R

13
6. Wiring Diagram
MPPDB-10CRN8-BCG8, MPPDB-10HRN8-BCG8

14
7 Electronic function
7.1 Terms and definitions
TC: Temperature of evaporator (T2).
TA: Temperature of indoor ambient (T1).
TS: The set temperature.
TE: Temperature of condenser (T3)
7.2 Electric Control working environment
Input voltage: 187~264V for 50Hz models
7.3 Protection function
7.3.1 The compressor functions protection with a delay of three minutes.
7.3.2 Sensor protection at open or short circuit.
7.3.3 Evaporator anti-icing protection in cooling mode.
7.4 Fan-only mode function requirement
7.4.1. The compressor and outdoor fan are OFF in Fan-only mode (except P1 protection).
7.4.2. The speed of indoor fan can be optionally chosen as High/Mid/Low.
7.4.3. The TS can’t be controlled, and the LED displays as T1.
7.4.4. The TIMER function is valid in the fan-only mode.
7.5 Cooling mode function requirement
7.5.1. The speed of indoor fan can be optionally selected as High/Mid/Low.
7.5.2. The outdoor fan will be turned on as soon as the unit being on cooling mode.
The operation of outdoor fan is according to the compare of TA and TS when the water level is
below to switch 1. If not, the outdoor fan doesn’t work.
7.5.3. The compressor operates as below:

15
7.5.2.1 If TA﹥TS+1℃, the outdoor fan operates. After 15 seconds, the compressor operates.
7.5.2.2 The compressor is on, if TA≤TS, this compressor will stop. If the outdoor fan operates for 3
minutes at least, it will stop after delaying for 5 seconds.
7.5.3. When the unit is off, the compressor stops at first, and the indoor/outdoor fan will stop after
delaying for 5seconds. (If it operates in heating mode, the outdoor fan will be off delaying for 30
seconds).
7.5.4. The TIMER function is valid in cooling mode.
7.6 Drying mode
7.6.1. The unit operates in drying mode. If TA>13℃, outdoor fan turns on, and then the compressor
operates after 15 seconds later.
7.6.1.1 When TA<13℃, the compressor stops working. And the outdoor fan will stop delaying for 5
seconds until it operates for 3minutest.
7.6.1.2 When TA≥14℃, the outdoor fan operates, and the compressor will restart to operate after
15seconds.
7.6.2. The speed can’t be controlled in drying mode, and the indoor fan motor operates at low speed.
(T A -T s)℃
+1
0
C om presso r on
O peration conditon
C om presso r off
TA ℃
15
13
C om pressor o n
O peration conditon
C om pressor off
14

16
7.6.3. The TIMER function is valid in drying mode.
7.7 Heating mode (heater)
7.7.1. The speed of indoor fan can be optionally chosen as High/Mid/Low.
The compressor and outdoor fan keep on stop (except P1 protection)
7.7.2. In heating mode, the heater will operate according to the difference between TA and TS.
Electric heater operates as below.
7.7.2.1. When TA﹤TS, the indoor fan operates firstly, and then the heater operates after 4 seconds.
7.7.2.2. If TA﹥TS＋1℃, the heater stops. Then the heater turns off after 10 seconds.
When the unit is off in heating mode, the indoor fan motor stops delaying for 10 seconds
7.7.3. The TIMER function is valid in heating mode.
7.8 Heating mode (heat pump)
7.8.1. When TA≤TS+5℃, compressor operates; When TA﹥TS＋6℃, compressor stops.
When TA ﹤5℃, heat pump mode is invalid, and water pump/indoor motor/outdoor
motor/compressor/ shaded pole motor stop; When TA≥6℃, heat pump mode resumes to be valid.
7.8.2. At non-defrosting situation, shaded pole motor always stops ; Compressor operates; Outdoor motor
is on at high speed. Then outdoor motor stops at a delay of 30s when compressor is off. When unit
is change to others mode(non-heating mode), Four-way valve shuts off at a delay of 2 minutes than
compressor.
7.8.3. Condition of entering into defrosting mode: when the operation time of TE(TC) (TE(TC)≤2℃
continuous) is up to 40minutes.
Defrosting motion: 1) Compressor operates; Four-way valve and indoor /up outdoor motor shut
off(down outdoor fan is still on at low speed).
(T A -T s)℃
+1
0H eater on
O peration conditon
H eater off

17
2) When TE(TC)﹥40℃or time is more than 7 minutes, up outdoor motor is on at high speed until
defrosting is over.
7.8.4 When meeting one of conditions as below, unit finishes defrosting motion.
1) The time of defrosting is up to 10 minutes.
2) TE(TC)≥50℃
7.8.5 Finishing defrosting motion: Outdoor motor is on, and compressor is off.
7.8.6 Compressor delay protection is invalid when unit entering into or finishing defrosting motion.
7.8.7 In heat pump mode, compressor/indoor motor/outdoor motor shut off immediately when water full
protection is on.
7.8.8 The TIMER function is valid in heat pump mode.
7.9 Sensor malfunction
Malfunction display:
When the malfunction happened at the same time, the priority is EC>E4> E3> E2> E1>P1
7.10 Some standard functions synopsis
7.10.1. Timer function
When the unit is on, press the Timer button will initiate the Auto-off stop program, the TIMER OFF
indicator light illuminates. Press the UP or down button to select the desired time. Press the TIMER button
again within 5 seconds, the Auto-on start program is initiated. And the TIMER ON indicator light illuminates.
Press the up or down button to select the desired Auto-on start time. When the unit is off, press the Timer
button to initiate the Auto-on start program, press it again within five seconds will initiate the Auto-off stop
program. Press or hold the UP or DOWN button to change the Auto time by 0.5 hour increments, The
system will automatically revert back to display the previous temperature setting if there is no operation in
a five seconds period.
LED display
Stand for
E2
T2 sensor malfunction
E1
T1 sensor malfunction
E4
Communication malfunction for display board and PCB
E3
T3 sensor malfunction
EC
Refrigerant leakage detection
P1
Water full protection

18
7.10.2. Sleep function
Press this button, the selected temperature will increase (cooling) or decrease (heating) by 1℃/2 ℉30
minutes. The temperature will then increase (cooling) or decrease (heating) by another 1℃/2℉after an
additional 30 minutes. This new temperature will be maintained for 7 hours before it returns to the originally
seting temperature. This ends the Sleep mode and the unit will continue to operate as originally
programmed.
