Carrier ASBFE600BA User manual

OWNER’S MANUAL
INDOOR UNIT OUTDOOR UNIT
Thank you very much for purchasing CARRIER Air Conditioner. Please read this
owner’s manual carefully before using your Air Conditioner.
PN PE630728

2
CONTENTS
TECHNICAL SPECIFICATIONS 3
PRECAUTIONS FOR SAFETY 4
CAUTIONS ABOUT INSTALLATION 5
CAUTIONS ABOUT OPERATION 6-7
MAINTENANCE 8-9
AIR CONDITIONER CONTROLLER 10-16
TROUBLESHOOTING GUIDE 17

3
TECHNICAL SPECIFICATIONS

4
I. PRECAUTIONS FOR SAFETY
Do not attempt to install the unit by yourself.
This unit requires a qualified installer.
This air conditioner must be connected Ground the unit without fail.
to the main power supply by means of a
circuit breaker.

5
II. PRECAUTIONS ON INSTALLATION
Lay the drain hose for perfect draining. Make sure to connect the air
conditioner to an exclusive power
supply of rated circuit breaker and
voltage.
Do not install the unit in an area where Consider the weight of the unit in
inflammable gases could leak constructing & selecting materials
for the sub-base.

6
III. PRECAUTIONS ON OPERATION
When cleaning the unit, make sure to turn Do not put anything on the outdoor
off the main switch unit nor step into it. It may topple
and cause an injury.
Ensure that the air outlet or inlet of the If you will not use the airconditioner
outdoor unit is not blocked. for a long time, operate it at FAN
mode for at least two hours to dry
the inside of the unit and then turn it
off. Remove the battery of the
remote and turn off the main switch.

7
III. PRECAUTIONS ON OPERATION (CONTD.)
Do not use benzene, alcohol, thinner, Do not insert fingers and sticks in to
for cleaning the unit. Use water, the air outlet and air inlet to avoid
mild soap and soft cloth instead. injury.
If the unit does not operate normally, immediately
turn off the air conditioner and the main circuit
breaker. Contact your nearest service center.

8
IV. MAINTENANCE
Check that the air filter is installed Check that the air outlet & inlet of
before turning ON the unit indoor and outdoor units are not
blocked.
Do not clean the coil with vacuum cleaner. Use vacuum cleaner or pressurized
It can damage the coil. water to clean the air filter.

9
IV. MAINTENANCE (CONTD.)
Dry the filter under sunshade.

10
V. AIR CONDITIONER CONTROLLER
V1. The following features can be operated by the buttons on the Display unit.
V2.1 Power on/off
Press POWER button to turn ON the air conditioner or vice versa. When turned
ON, it will operate according to the last setting made by the user.
V2.2 Fan
Press FAN button to select desired fan speed (HIGH, MED, LOW or AUTO).
The LCD display will show the status by blinking for 5 seconds.
Auto fan speed
When the fan speed is set to AUTO, the AUTO LED on the Display unit will
be lit. Speed is adjusted automatically according to the difference between the
room temperature and setting temperature.
•If the difference is 3°C or more, fan speed is set to HIGH.
•If the difference is 2°C, fan speed is set to MED.
•If the difference is 1°C or less, fan speed is set to LOW.
V2.3 Operating mode
By pressing the MODE button, the air conditioner can be set to FAN or COOL.

11
V. AIR CONDITIONER CONTROLLER (CONT’D.)
V2.3.1 Fan
If the system is in FAN mode, the FAN LED on the Display unit will be lit.
The system will operate as the fan only. The TEMP∆and TEMP∇buttons
are not used.
V2.3.2 Cool
If the system is set to COOL mode, the COOL LED on the Display unit will
be lit. The system will operate as the air conditioner. The compressor will
•operate if room temperature is higher than set TEMP +1°
•stop if room temperature is less than set TEMP
However, there is a 3-minute delay protection on the compressor each time it stops.
V2.4 Temperature setting
Temperature can be set from 18 - 30°C by pressing TEMP∆or TEMP∇
button. The LCD Display will show the set temperature.
V2.5 Sweep
Press SWEEP button to turn the sweep motor ON or OFF.

12
COMPRESSOR
LOW FAN
4 Min. 8 Min.
8 Min.
ON
OFF
ON
OFF
V. AIR CONDITIONER CONTROLLER (CONT’D.)
V.3 The system can be controlled using the LCD Remote unit (OPTIONAL
ITEM)
V3.1 LCD type remote (OPTIONAL ITEM)
The following features can be accessed using the LCD type remote.
V3.1.1 Power ON/OFF
V3.1.2 FAN
V3.1.3 Operating mode: Press the MODE button on the LCD type remote, to
operate the air conditioner in FAN, COOL or DRY modes.
FAN – no cooling. Use this mode when no further cooling is needed
COOL – normal comfort cooling. Use this mode when temperature in the
room needs to be reduced
DRY – dehumidified cooling. Use this on extremely humid days to
eliminate moisture quickly. As soon as satisfactory humidity level is
reached, it is recommended to switch back to COOL mode.
3.1.4 Temperature set
t
V3.1.5 Sweep: set swee
V3.1.6 Sleep :
Pressing SLEEP button to activate sleep function. SLEEP LED on the
Display unit will be lit. The set temperature will be automatically
increased up 1°C after one hour and another 1°C in the second hour.

13
V. AIR CONDITIONER CONTROLLER (CONT’D.)
While the system is in SLEEP mode:
•Pressing the SLEEP button again cancels the sleep function.
•Pressing the TEMP button will increase the set temperature by
1°C from the last setting.
•And unit is turned off or power failure occurs, the SLEEP
function is cancelled.
V3.1.7 Setting the Clock on the Remote Unit:
•Press button until the Display shows blinking,
•Press button to set the time,
•Press SEND button.
NOTE: If no button is pressed within 10 seconds, LCD display will
return to show setting temperature and no data will be transmitted.
V3.1.8 Auto Start: The air conditioner can be programmed to turn on
at a pre-set time.
•Press button until the display shows blinking ON,
•Press button to set the timer-on,
•Press SEND button.
To cancel this function
•Press button until the display shows blinking ON,
•Press CANCEL button.
NOTE: If no button is pressed within 10 seconds, LCD display will
return to show setting temperature and no data will be transmitted.
V3.1.9 Auto Stop : The air conditioner can be programmed to turn off at a
pre-set time.
•Press button until the display shows blinking OFF,
•Press button to set the timer-off,
•Press SEND button.

14
V. AIR CONDITIONER CONTROLLER (CONT’D.)
To cancel this function
•Press button until the display shows blinking OFF,
•Press CANCEL button.
NOTE: If no button is pressed within 10 seconds, LCD display will
return to show setting temperature and no data will be transmitted.
V3.2 Compressor delay protection
Each time the compressor shuts off there is a 3-minute time delay before it
restarts. If power is interrupted, the control system delays compressor
operation from 3-4 minutes in random manner. This ensures that air
conditioning compressors in the building do not start simultaneously.
V3.3 Changing temperature display from °
°°
°C to °
°°
°F
Default temperature display is in °C.
Temperature display can be set to °F by pressing TEMP ∆and TEMP∇
buttons at the same time for 5 seconds while the system is turned on.
To change display back to °C, press TEMP ∆and TEMP∇again.
V4.5 Self-Diagnostic Function
The control system comes with a self-diagnostic function.
If a malfunction is detected, the LED Display will show the following alarms:
blinking if the room sensor is open or short circuited .
blinking if the freeze sensor is open or short circuited.

15
TROUBLESHOOTING GUIDE
PROBLEM POSSIBLE CAUSES SOLUTION
Unit does not start Circuit breaker tripped Reset only once. Should
the unit trip again do not
attempt to reset it again.
Contact your Carrier
service center for
assistance.
Unit does not cool properly. a. Air filter is dirty
b. Thermostat setting is too
high
c. Unit on dry mode
d. Unit on sleep mode
a. Clean air filter.
b. Reset to desired
temperature.
c. Switch the setting into
cool mode
d. Press sleep button
Condensate dripping into
the room
Dirty drain pan and
clogged drain line Clean the drain pan and drain line.
No signal output from air
conditioner controller Controller’s battery is weak Replace controller with new battery of the same
specs.
Concepcion Carrier Air Conditioning Company
Web Site: www.carrier.com.ph
