Acson international ADB200B2 User manual

CONTENTS
1. NOMENCLATURE ..................................................................................................... 1
2. FEATURES ................................................................................................................ 3
3. PRODUCT LINE-UP .................................................................................................. 4
4. SPECIFICATIONS .................................................................................................... 10
5. OPERATING RANGE .............................................................................................. 131
6. SOUND DATA .......................................................................................................... 132
7. PERFORMANCE TABLES ...................................................................................... 147
8. FAN PERFORMANCE CHARTS ............................................................................. 170
9. OUTLINES AND DIMENSIONS ............................................................................... 195
10. REFRIGERANT CIRCUIT DIAGRAM .................................................................... 213
11. WIRING DIAGRAMS .............................................................................................. 215
12. CONTROLLERS .................................................................................................... 229
13. INSTALLATION ...................................................................................................... 235
14. SERVICING AND MAINTENANCE ........................................................................ 245
15. TROUBLESHOOTING ........................................................................................... 246
16. EXPLODED VIEW AND PARTS LIST ................................................................... 251
This manual supersede ADB-2005

1. NOMENCLATURE
1
ADB 200 BR
Brand
A : Acson
Capacity
200 : 200,000 Btu/h
Series
B : B series
D : D series
Model Type
R : Heatpump
Omitted if Cooling Only
A A
AB
-
Refrigerant
Blank : R22
4 : R407C
Model Name
DB : Ducted Blower
DSB : Double Skin Ducted Blower
Electrical
A : 50Hz/1Ph/220 ~ 240V
F : 50Hz/3Ph/380 ~ 415V
Others
AA : Revision
Type of Connection
B : For Brazed
F : For Flare
Indoor

2
AMC 75 BR
Brand
A : Acson
Capacity
75 : 75,000 Btu/h
Series
B : B series
D : D series
Model Type
R : Heatpump
Omitted if Cooling Only
A A
AB
-
Refrigerant
Blank : R22
4 : R407C
Model Name
MC : Modular Condensing Unit
LC : Single Split Condensing Unit
Electrical
A : 50Hz/1Ph/220 ~ 240V
F : 50Hz/3Ph/380 ~ 415V
Others
AA : Revision
Type of Connection
B : For Brazed
F : For Flare
Outdoor

2. FEATURES
3
EASY MAINTENANCE
The simple design concept has provided the ease of maintenance and servicing. Access to the internal part of
the unit can be from the service panel or other side of the unit by loosening a few screws.
Only for model ADB75/100D with additional service panel from bottom
AIR DISCHARGE ORIENTATION
ADB75-150D models come with standard horizontal air discharge.
ADB200-500 B/D models only come with standard vertical air discharge and they can be converted to horizontal
air discharge at the site. ADB200-500 B/D models with horizontal air discharge are not offered from factory.
ADB600-750B models are offered in vertical and horizontal air discharge as standard by differentiate of
nomenclature.
COMPACT INDOOR UNIT
Indoor models are designed with compact size with twin coil structure. This design is able to provide some
saving in space for installation.
VERSATILITY
Multiple rooms can be cooled together at the same time by using just one unit of fan coil unit.
FRESH AIR INTAKE FOR HEALTHY LIVING
Fresh air can be introduced into the building through the design of fresh air intakes. This will help to improve the
indoor air quality.
SUPERIOR AIR DISTRIBUTION FOR COMFORTABLE LIVING
The conditioned air can be effectively distributed to every corner of the room through the ducting and this
ensure a more pleasant environment for comfort living.
FLEXIBILITY OF AIR SUPPLY
ADB200-750B and ADB125-500D models using belt driven blower such as that the air volume and static re-
quired can be adjusted according to the requirement. This flexibility allows for wider application.
SCROLL COMPRESSOR
All outdoor units are using Scroll compressor which has better energy efficiency and quiet in operation.
SEQUENTIAL CONTROLLER AS STANDARD
This controller is supplied as the standard specification for cooling model where the systems are matching with
two outdoor units and more. The benefit of this controller is capable of part-loading of the system capacity.

3. PRODUCT LINE UP
4
ADB
W/out Control
With Contactor
U1.4 PCB
U1_SB125
Sequential Controller
SLM3
LCD Sequential Controller
Local (w/out DOL)
CE Mark
Without Marking
TXV
Capillary Tube
Without Expansion Device
With air filter
W/out Air Filter
Horizontal & Changeable
Horizontal & Not Changeable
Vertical as Standard
Vertical & Changeable
Rivet "Made In Malaysia"
Very High Static
FBAH X X X X X
FBAI X XXXX X X
FBAG X X X X X
FBAI X XXXX X X
FBAC X X X X X
FBAE X XXXX X X
FBAC X X X X X
FBAE X XXXX X X
FBAG X X X X X
FBAI X XXXX X X
FBAC X X X X X
FBAE X XXXX X X
FBAC X X X X X
FBAE X XXXX X X
FBAG X X X X X
FBAI X XXXX X X
FBAC X X X X X
FBAD X XXXX X X
FBAF X X X X X
FBAGXXXXXXX
FBAC X X X X X
FBAE X X X X X
Others
Classification
Air DischargeFilter
Refrigerant
Control
HandsetControl
Marking
500B4
600B4
750B5
Nomenclature
COOLING MODEL
200B2
250B2
300B2
300B3
350B3
400B4
450B3

5
ADB
W/out Control
With Contactor
U1.4 PCB
U1_SB125
Sequential Controller
SLM3
LCD Sequential Controller
Local (w/out DOL)
CE Mark
Without Marking
TXV
Cap. Tube & Check Valve
Withour Expansion Device
With air filter
W/out Air Filter
Horizontal & Changeable
Horizontal & Not Changeable
Vertical & Changeable
Rivet "Made In Malaysia"
Very High Static
ABAE X X X X X X
ABAG X X X X X X X
ABAE X X X X X X
ABAG X X X X X X X
FBAE X X X X X X X
FBAF X X X X X X X X
FBHBXXXXXXXX
FBAAXXXXXXX
FBHAXXXXXXXX
FBAE X X X X X X X
FBHBXXXXXXXX
FBACXXXXXXX
FBHAXXXXXXXX
200D2 FBAF X X X X X X X
250D2 FBAF X X X X X X X
300D2 FBAF X X X X X X X
400D4 FBAF X X X X X X X
500D4 FBAF X X X X X X X
100D
75D
COOLING MODEL
150D2
150D1
125D2
125D
Classification
Refrigerant
Control
Control Air Discharge OthersFilter
Nomenclature
MarkingHandset

6
ADSB
Handset
W/out Control
With Contactor
W/out Contactor
Sequential Controller
LCD Wired Handset
CE Mark
Without Marking
TXV
Capillary Tube
Without Expansion Device
With air filter
W/out Air Filter
Horizontal & Changeable
Horizontal & Not Changeable
Vertical as Standard
Vertical & Changeable
Rivet "Made In Malaysia"
Very High Static
200B2 FBAD X X X X X X X
250B2 FBAD X X X X X X X
300B3 FBAD X X X X X X X
350B3 FBAD X X X X X X X
400B4 FBAD X X X X X X X
500B4 FBAD X X X X X X X
Air Discharge
Classification
OthersControl Marking
Nomenclature
Filter
COOLING MODEL
Refrigerant
Control

7
AMC
ALC
With Togami Contactor
With Chint Contactor
Without Contactor
With HP/LP
CE Mark
ETL
Without Marking
Scroll-Copeland
Scroll Maneurop
Reciprocating-Maneurop
Reciprocating Bristol
Reciproacating-Copeland
TXV
Capillary Tube
Bi-Flow TXV
Without Expansion Device
Centrifugal Fan
Rivet "Made In Malaysia"
With Accumulator
Phase Sequencer
Gold Fin (NA549)
FBAPXXXX X X
FBARXXXX XX
FBASXXXX XX
FBAHXXXX X X
FBAIXXXX XX
FBAJXXXX XX
FBARXXXX X X
FBAWXXXX XX
FBATXXXX XX
FBAYXXXX XX
FBAKXXXX X X
FBAMXXXX XX
FBAPXXXX XX
With Togami Contactor
With Chint Contactor
Without Contactor
With HP/LP
CE Mark
ETL
Without Marking
Scroll-Copeland
Scroll Maneurop
Reciprocating-Maneurop
Reciprocating Bristol
Reciproacating-Copeland
TXV
Capillary Tube
Bi-Flow TXV
Without Expansion Device
Centrifugal Fan
Rivet "Made In Malaysia"
With Accumulator
Phase Sequencer
Gold Fin (NA549)
FFFEXXXX X
FFFF X X X X X
FFFGXXXX XX
COOLING MODEL
Marking
Nomenclature
150C
125B
100B
100C
Expansion DeviceCompressorControl
Classification
Others
COOLING
MODEL
61C
Classification
Nomenclature
Control Marking Compressor Expansion Device Others

8
AMC
With Contactor
Without Contactor
With 24Vac Control Circuit
With HP/LP
CE Mark
ETL
Without Marking
Scroll-Copeland
Scroll Maneurop
Reciprocating-Maneurop
Reciprocating Bristol
Reciproacating-Copeland
TXV
Capillary Tube
Without Expansion Device
Centrifugal Fan
Rivet "Made In Malaysia"
With Accumulator
With Type Brazed Ball Valve
Phase Protector
Gold Fin (NA549)
FBAFXXXX X X
FBAGXXXX XX
FBAHXXXX XX
FCAAXXXX X X
FCABXXXX XXX
FBAFXXXX X X
FBAGXXXX XX
FBAHXXXX XX
FCAAXXXX X X
FCABXXXX XXX
FBAFXXXX X X
FBAGXXXX XX
FBAHXXXX XX
FCAAXXXX X X
FCABXXXX XXX
FBAGXXXX X X
FBAH X X X X X X X
FBAIXXX X XXX
FCAAXXXX X XX
FCABXXXX XXX
FCACXXX X XXXX
200D2 FBAA X X X X X X
250D2 FBAA X X X X X X
300D2 FBAA X X X X X X
Expansion
Device
Compressor OthersControl
COOLING MODEL
75D
100D
125D
150D
Nomenclature
Classification
Marking

9
A4MC
With Contactor
W/out Contactor with Auto HP/LP
W/out Contactor With Manual HP/LP
With HP/LP
Local (w/out DOL)
CE Mark
ETL
Without Marking
Scroll-Copeland
Scroll Maneurop
Reciprocating-Maneurop
Reciprocating Bristol
Reciproacating-Copeland
TXV
Capillary Tube
Without Expansion Device
Centrifugal Fan
For Sequential Controller
With Accumulator
With Type Brazed Ball Valve
Gold Fin (NA549)
FBAAXXXX XX
FBACXXXX XXX
FCAAXXXX XXX
FCABXXXX XXXXX
FBAAXXXX XX
FBACXXXX XXX
FCAAXXXX XXX
FCABXXXX XXXXX
FBAAXXXX XX
FBACXXXX XXX
FCAAXXXX XXX
FCABXXXX XXXXX
FBAAXXXX XX
FBACXXXX XXX
FCAAXXXX XXX
FCABXXXX XXXXX
Classification
Nomenclature
Control Marking Compressor Expansion
Device Others
COOLING MODEL
75D
125D
100D
150D

4. SPECIFICATIONS
1) ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.
2) ALL UNITS ARE BEING TESTED AND COMPLY TO ARI210/240-94
3) NOMINAL COOLING AND HEATING CAPACITY ARE BASED ON THE CONDITIONS BELOW :
COOLING - 26.7°C DB / 19.4°C WB INDOOR AND 35°C DB / 23.9°C WB OUTDOOR
4) SOUND PRESSURE LEVEL ARE ACCORDING TO JIS B 8615 STANDARD. POSITION OF THE MEASUREMENT POINT IS 1m IN FRONT AND 1m BELOW THE UNIT.
10
GENERAL DATA - COOLING ONLY (R22)
B SERIES
AMC100B x 2 AMC100C x 2
Btu/h 200,000 200,000
W58,600 58,600
W21,130 20,850
A39.8 41.2
V/Ph/Hz 380~415 / 3 / 50 380~415 / 3 / 50
R22 R22
CONTROL
HIGH l/s / cfm
Pa / in.wg
dBA
HEIGHT mm/in
WIDTH mm/in
DEPTH mm/in
HEIGHT mm/in
WIDTH mm/in
DEPTH mm/in
kg/lb
mm/in
l/s / cfm 3304 / 7000 3304 / 7000
dBA 65 76
HEIGHT mm/in 946 / 37.24 971.4 / 38.24
WIDTH mm/in 1116 / 43.93 1393 / 54.84
DEPTH mm/in 939 / 36.96 500 / 19.68
HEIGHT mm/in 1132 / 44.57 1158 / 45.59
WIDTH mm/in 1282 / 50.47 1507 / 59.33
DEPTH mm/in 1112 / 43.78 664 / 26.14
kg/lb 164 / 361 178 / 392
BRAZING BRAZING
LIQUID mm/in 15.88 /
⅝
15.88 /
⅝
GAS mm/in 28.58 / 1
⅛
28.58 / 1
⅛
kg/lb 7.60 (x2) / 16.76 (x2) 7.00 (x2) / 15.43 (x2)
180 / 396
25.40 / 1.00
945 / 37.20
1894 / 74.56
980 / 38.58
1154 / 45.43
2052 / 80.79
1188 / 46.77
ADB200B2
WIRED CONTROL
3021 / 6400
158.2 / 0.64
61
NOMINAL RUNNING CURRENT
POWER SOURCE
REFRIGERANT TYPE
SOUND PRESSURE LEVEL
OPERATION
AIR FLOW
EXTERNAL STATIC PRESSURE
OUTDOOR UNIT
INDOOR UNIT
NOMINAL CAPACITY
NOMINAL TOTAL INPUT POWER
SOUND PRESSURE LEVEL
UNIT WEIGHT
REFRIGERANT CHARGE
AIR FLOW
UNIT WEIGHT
PIPE CONNECTION
UNIT DIMENSION
INDOOR UNIT
MODEL
SIZE
PACKING DIMENSION
UNIT DIMENSION
PACKING DIMENSION
TYPE
OUTDOOR UNIT
CONDENSATE DRAIN SIZE

11
1) ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.
2) ALL UNITS ARE BEING TESTED AND COMPLY TO ARI210/240-94
3) NOMINAL COOLING AND HEATING CAPACITY ARE BASED ON THE CONDITIONS BELOW :
COOLING - 26.7°C DB / 19.4°C WB INDOOR AND 35°C DB / 23.9°C WB OUTDOOR
4) SOUND PRESSURE LEVEL ARE ACCORDING TO JIS B 8615 STANDARD. POSITION OF THE MEASUREMENT POINT IS 1m IN FRONT AND 1m BELOW THE UNIT.
GENERAL DATA - COOLING ONLY (R22)
B SERIES
Btu/h
W
W
A
V/Ph/Hz
CONTROL
HIGH l/s / cfm
Pa / in.wg
dBA
HEIGHT mm/in
WIDTH mm/in
DEPTH mm/in
HEIGHT mm/in
WIDTH mm/in
DEPTH mm/in
kg/lb
mm/in
l/s / cfm
dBA
HEIGHT mm/in
WIDTH mm/in
DEPTH mm/in
HEIGHT mm/in
WIDTH mm/in
DEPTH mm/in
kg/lb
LIQUID mm/in
GAS mm/in
kg/lb
UNIT DIMENSION
INDOOR UNIT
MODEL
SIZE
PACKING DIMENSION
UNIT DIMENSION
PACKING DIMENSION
TYPE
OUTDOOR UNIT
CONDENSATE DRAIN SIZE
SOUND PRESSURE LEVEL
UNIT WEIGHT
REFRIGERANT CHARGE
AIR FLOW
UNIT WEIGHT
PIPE CONNECTION
OUTDOOR UNIT
INDOOR UNIT
NOMINAL CAPACITY
NOMINAL TOTAL INPUT POWER
NOMINAL RUNNING CURRENT
POWER SOURCE
REFRIGERANT TYPE
SOUND PRESSURE LEVEL
OPERATION
AIR FLOW
EXTERNAL STATIC PRESSURE
ADB250B2
AMC125B x 2
250,000
73,250
25,146
45.4
380~415 / 3 / 50
R22
WIRED CONTROL
3776 / 8000
417.2 / 1.67
63
1291 / 50.82
1866 / 73.46
1199 / 47.20
1506 / 59.29
2034 / 80.08
1412 / 55.59
250 / 551
25.40 / 1.00
3304 / 7000
65
946 / 37.24
1116 / 43.93
939 / 36.96
1132 / 44.57
1282 / 50.47
1112 / 43.78
7.95 (x2) / 17.53 (x2)
169 / 372
BRAZING
15.88 /
⅝
34.92 / 1
⅜

12
1) ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.
2) ALL UNITS ARE BEING TESTED AND COMPLY TO ARI210/240-94
3) NOMINAL COOLING AND HEATING CAPACITY ARE BASED ON THE CONDITIONS BELOW :
COOLING - 26.7°C DB / 19.4°C WB INDOOR AND 35°C DB / 23.9°C WB OUTDOOR
4) SOUND PRESSURE LEVEL ARE ACCORDING TO JIS B 8615 STANDARD. POSITION OF THE MEASUREMENT POINT IS 1m IN FRONT AND 1m BELOW THE UNIT.
GENERAL DATA - COOLING ONLY (R22)
B SERIES
Btu/h
W
W
A
V/Ph/Hz
CONTROL
HIGH l/s / cfm
Pa / in.wg
dBA
HEIGHT mm/in
WIDTH mm/in
DEPTH mm/in
HEIGHT mm/in
WIDTH mm/in
DEPTH mm/in
kg/lb
mm/in
l/s / cfm
dBA
HEIGHT mm/in
WIDTH mm/in
DEPTH mm/in
HEIGHT mm/in
WIDTH mm/in
DEPTH mm/in
kg/lb
LIQUID mm/in
GAS mm/in
kg/lb 10.10 (x2) / 22.27 (x2)
227 / 500
BRAZING
15.88 /
⅝
34.92 / 1
⅜
1291 / 50.82
1199 / 47.20
1866 / 73.46
346 / 762
1412 / 55.59
WIRED CONTROL
4248 / 9000
325.4 / 1.31
66
1227 / 48.31
1282 / 50.47
1112 / 43.78
25.40 / 1.00
5475 / 11600
74
1041 / 40.98
1116 / 43.93
939 / 36.96
ADB300B2
AMC150C x 2
1506 / 59.29
2034 / 80.08
300,000
87,900
34,460
59.1
380~415 / 3 / 50
R22
NOMINAL RUNNING CURRENT
POWER SOURCE
REFRIGERANT TYPE
SOUND PRESSURE LEVEL
OPERATION
EXTERNAL STATIC PRESSURE
AIR FLOW
OUTDOOR UNIT
INDOOR UNIT
NOMINAL CAPACITY
NOMINAL TOTAL INPUT POWER
SOUND PRESSURE LEVEL
UNIT WEIGHT
REFRIGERANT CHARGE
AIR FLOW
UNIT WEIGHT
PIPE CONNECTION
UNIT DIMENSION
INDOOR UNIT
MODEL
SIZE
PACKING DIMENSION
UNIT DIMENSION
PACKING DIMENSION
TYPE
OUTDOOR UNIT
CONDENSATE DRAIN SIZE

13
1) ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.
2) ALL UNITS ARE BEING TESTED AND COMPLY TO ARI210/240-94
3) NOMINAL COOLING AND HEATING CAPACITY ARE BASED ON THE CONDITIONS BELOW :
COOLING - 26.7°C DB / 19.4°C WB INDOOR AND 35°C DB / 23.9°C WB OUTDOOR
4) SOUND PRESSURE LEVEL ARE ACCORDING TO JIS B 8615 STANDARD. POSITION OF THE MEASUREMENT POINT IS 1m IN FRONT AND 1m BELOW THE UNIT.
GENERAL DATA - COOLING ONLY (R22)
B SERIES
AMC100B x 3 AMC100C x 3
Btu/h 300,000 300,000
W87,900 87,900
W31,600 31,180
A59.2 61.4
V/Ph/Hz 380~415 / 3 / 50 380~415 / 3 / 50
R22 R22
CONTROL
HIGH l/s / cfm
Pa / in.wg
dBA
HEIGHT mm/in
WIDTH mm/in
DEPTH mm/in
HEIGHT mm/in
WIDTH mm/in
DEPTH mm/in
kg/lb
mm/in
l/s / cfm 3304 / 7000 3304 / 7000
dBA 65 76
HEIGHT mm/in 946 / 37.24 971.4 / 38.24
WIDTH mm/in 1116 / 43.93 1393 / 54.84
DEPTH mm/in 939 / 36.96 500 / 19.68
HEIGHT mm/in 1132 / 44.57 1158 / 45.59
WIDTH mm/in 1282 / 50.47 1507 / 59.33
DEPTH mm/in 1112 / 43.78 664 / 26.14
kg/lb 164 / 361 178 / 392
BRAZING BRAZING
LIQUID mm/in 15.88 /
⅝
15.88 /
⅝
GAS mm/in 28.58 / 1
⅛
28.58 / 1
⅛
kg/lb 7.60 (x3) / 16.76 (x3) 7.00 (x3) / 15.43 (x3)
2034 / 80.08
1412 / 55.59
MODEL
OUTDOOR UNIT
REFRIGERANT CHARGE
AIR FLOW
UNIT WEIGHT
INDOOR UNIT
SOUND PRESSURE LEVEL
PIPE CONNECTION
UNIT DIMENSION
OPERATION
OUTDOOR UNIT
NOMINAL CAPACITY
NOMINAL TOTAL INPUT POWER
25.40 / 1.00
NOMINAL RUNNING CURRENT
POWER SOURCE
REFRIGERANT TYPE
INDOOR UNIT
EXTERNAL STATIC PRESSURE
346 / 762
1506 / 59.29
AIR FLOW
1291 / 50.82
SIZE
PACKING DIMENSION
UNIT DIMENSION
PACKING DIMENSION
TYPE
CONDENSATE DRAIN SIZE
SOUND PRESSURE LEVEL
UNIT WEIGHT
1866 / 73.46
1199 / 47.20
4248 / 9000
ADB300B3
66
325.4 / 1.31
WIRED CONTROL

14
1) ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.
2) ALL UNITS ARE BEING TESTED AND COMPLY TO ARI210/240-94
3) NOMINAL COOLING AND HEATING CAPACITY ARE BASED ON THE CONDITIONS BELOW :
COOLING - 26.7°C DB / 19.4°C WB INDOOR AND 35°C DB / 23.9°C WB OUTDOOR
4) SOUND PRESSURE LEVEL ARE ACCORDING TO JIS B 8615 STANDARD. POSITION OF THE MEASUREMENT POINT IS 1m IN FRONT AND 1m BELOW THE UNIT.
GENERAL DATA - COOLING ONLY (R22)
B SERIES
AMC100B x 1 AMC125B x 2
Btu/h
W
W
A
V/Ph/Hz
CONTROL
HIGH l/s / cfm
Pa / in.wg
dBA
HEIGHT mm/in
WIDTH mm/in
DEPTH mm/in
HEIGHT mm/in
WIDTH mm/in
DEPTH mm/in
kg/lb
mm/in
l/s / cfm 3304 / 7000 3304 / 7000
dBA 65 65
HEIGHT mm/in 946 / 37.24 946 / 37.24
WIDTH mm/in 1116 / 43.93 1116 / 43.93
DEPTH mm/in 939 / 36.96 939 / 36.96
HEIGHT mm/in 1132 / 44.57 1132 / 44.57
WIDTH mm/in 1282 / 50.47 1282 / 50.47
DEPTH mm/in 1112 / 43.78 1112 / 43.78
kg/lb 164 / 361 169 / 372
BRAZING BRAZING
LIQUID mm/in 15.88 /
⅝
15.88 /
⅝
GAS mm/in 28.58 / 1
⅛
34.92 / 1
⅜
kg/lb 7.60 / 16.76 7.95 (x2) / 17.53 (x2)
66
1546 / 60.86
25.40 / 1.00
1766 / 69.53
2279 / 89.72
1412 / 55.59
440 / 970
2122 / 83.54
1199 / 47.20
ADB350B3
WIRED CONTROL
4956 / 10500
289.9 / 1.16
350,000
102,550
380~415 / 3 / 50
R22
35,486
64.9
NOMINAL RUNNING CURRENT
POWER SOURCE
REFRIGERANT TYPE
SOUND PRESSURE LEVEL
OPERATION
EXTERNAL STATIC PRESSURE
AIR FLOW
OUTDOOR UNIT
INDOOR UNIT
NOMINAL CAPACITY
NOMINAL TOTAL INPUT POWER
SOUND PRESSURE LEVEL
UNIT WEIGHT
REFRIGERANT CHARGE
AIR FLOW
UNIT WEIGHT
PIPE CONNECTION
UNIT DIMENSION
INDOOR UNIT
MODEL
SIZE
PACKING DIMENSION
UNIT DIMENSION
PACKING DIMENSION
TYPE
OUTDOOR UNIT
CONDENSATE DRAIN SIZE

15
1) ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.
2) ALL UNITS ARE BEING TESTED AND COMPLY TO ARI210/240-94
3) NOMINAL COOLING AND HEATING CAPACITY ARE BASED ON THE CONDITIONS BELOW :
COOLING - 26.7°C DB / 19.4°C WB INDOOR AND 35°C DB / 23.9°C WB OUTDOOR
4) SOUND PRESSURE LEVEL ARE ACCORDING TO JIS B 8615 STANDARD. POSITION OF THE MEASUREMENT POINT IS 1m IN FRONT AND 1m BELOW THE UNIT.
GENERAL DATA - COOLING ONLY (R22)
B SERIES
AMC100B x 4 AMC100C x 4
Btu/h 400,000 400,000
W117,200 117,200
W41,635 41,075
A78.2 81.1
V/Ph/Hz 380~415 / 3 / 50 380~415 / 3 / 50
R22 R22
CONTROL
HIGH l/s / cfm
Pa / in.wg
dBA
HEIGHT mm/in
WIDTH mm/in
DEPTH mm/in
HEIGHT mm/in
WIDTH mm/in
DEPTH mm/in
kg/lb
mm/in
l/s / cfm 3304 / 7000 3304 / 7000
dBA 65 76
HEIGHT mm/in 946 / 37.24 971.4 / 38.24
WIDTH mm/in 1116 / 43.93 1393 / 54.84
DEPTH mm/in 939 / 36.96 500 / 19.68
HEIGHT mm/in 1132 / 44.57 1158 / 45.59
WIDTH mm/in 1282 / 50.47 1507 / 59.33
DEPTH mm/in 1112 / 43.78 664 / 26.14
kg/lb 164 / 361 178 / 392
BRAZING BRAZING
LIQUID mm/in 15.88 /
⅝
15.88 /
⅝
GAS mm/in 28.58 / 1
⅛
28.58 / 1
⅛
kg/lb 7.60 (x4) / 16.76 (x4) 7.00 (x4) / 15.43 (x4)
UNIT DIMENSION
INDOOR UNIT
MODEL
SIZE
PACKING DIMENSION
UNIT DIMENSION
PACKING DIMENSION
TYPE
OUTDOOR UNIT
CONDENSATE DRAIN SIZE
SOUND PRESSURE LEVEL
UNIT WEIGHT
REFRIGERANT CHARGE
AIR FLOW
UNIT WEIGHT
PIPE CONNECTION
OUTDOOR UNIT
INDOOR UNIT
NOMINAL CAPACITY
NOMINAL TOTAL INPUT POWER
NOMINAL RUNNING CURRENT
POWER SOURCE
REFRIGERANT TYPE
SOUND PRESSURE LEVEL
OPERATION
EXTERNAL STATIC PRESSURE
AIR FLOW
ADB400B4
WIRED CONTROL
5664 / 12000
356.7 / 1.43
66
1546 / 60.86
2274 / 89.52
1466 / 57.71
25.40 / 1.00
1766 / 69.53
2431 / 95.81
1684 / 66.3
330 / 727

16
1) ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.
2) ALL UNITS ARE BEING TESTED AND COMPLY TO ARI210/240-94
3) NOMINAL COOLING AND HEATING CAPACITY ARE BASED ON THE CONDITIONS BELOW :
COOLING - 26.7°C DB / 19.4°C WB INDOOR AND 35°C DB / 23.9°C WB OUTDOOR
4) SOUND PRESSURE LEVEL ARE ACCORDING TO JIS B 8615 STANDARD. POSITION OF THE MEASUREMENT POINT IS 1m IN FRONT AND 1m BELOW THE UNIT.
GENERAL DATA - COOLING ONLY (R22)
B SERIES
Btu/h
W
W
A
V/Ph/Hz
CONTROL
HIGH l/s / cfm
Pa / in.wg
dBA
HEIGHT mm/in
WIDTH mm/in
DEPTH mm/in
HEIGHT mm/in
WIDTH mm/in
DEPTH mm/in
kg/lb
mm/in
l/s / cfm
dBA
HEIGHT mm/in
WIDTH mm/in
DEPTH mm/in
HEIGHT mm/in
WIDTH mm/in
DEPTH mm/in
kg/lb
LIQUID mm/in
GAS mm/in
kg/lb
NOMINAL RUNNING CURRENT
POWER SOURCE
REFRIGERANT TYPE
SOUND PRESSURE LEVEL
OPERATION
EXTERNAL STATIC PRESSURE
AIR FLOW
INDOOR UNIT
PACKING DIMENSION
UNIT WEIGHT
OUTDOOR UNIT
INDOOR UNIT
NOMINAL CAPACITY
NOMINAL TOTAL INPUT POWER
MODEL
REFRIGERANT CHARGE
AIR FLOW
UNIT WEIGHT
PIPE CONNECTION
SIZE
UNIT DIMENSION
PACKING DIMENSION
TYPE
OUTDOOR UNIT
CONDENSATE DRAIN SIZE
SOUND PRESSURE LEVEL
6372 / 13500
364.6 / 1.46
68
UNIT DIMENSION
1112 / 43.78
10.10 (x3) / 22.27 (x3)
34.92 / 1
⅜
ADB450B3
AMC150C x 3
450,000
131,850
227 / 500
BRAZING
15.88 /
⅝
1282 / 50.47
1684 / 66.3
1227 / 48.31
5475 / 11600
74
1041 / 40.98
1116 / 43.93
939 / 36.96
25.40 / 1.00
339 / 747
2431 / 95.81
53,010
90.5
380~415 / 3 / 50
R22
1546 / 60.86
2274 / 89.52
1466 / 57.71
1766 / 69.53
WIRED CONTROL

17
1) ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.
2) ALL UNITS ARE BEING TESTED AND COMPLY TO ARI210/240-94
3) NOMINAL COOLING AND HEATING CAPACITY ARE BASED ON THE CONDITIONS BELOW :
COOLING - 26.7°C DB / 19.4°C WB INDOOR AND 35°C DB / 23.9°C WB OUTDOOR
4) SOUND PRESSURE LEVEL ARE ACCORDING TO JIS B 8615 STANDARD. POSITION OF THE MEASUREMENT POINT IS 1m IN FRONT AND 1m BELOW THE UNIT.
GENERAL DATA - COOLING ONLY (R22)
B SERIES
Btu/h
W
W
A
V/Ph/Hz
CONTROL
HIGH l/s / cfm
Pa / in.wg
dBA
HEIGHT mm/in
WIDTH mm/in
DEPTH mm/in
HEIGHT mm/in
WIDTH mm/in
DEPTH mm/in
kg/lb
mm/in
l/s / cfm
dBA
HEIGHT mm/in
WIDTH mm/in
DEPTH mm/in
HEIGHT mm/in
WIDTH mm/in
DEPTH mm/in
kg/lb
LIQUID mm/in
GAS mm/in
kg/lb 7.95 (x4) / 17.53 (x4)
169 / 372
BRAZING
15.88 /
⅝
34.92 / 1
⅜
939 / 36.96
1132 / 44.57
1282 / 50.47
1112 / 43.78
3304 / 7000
65
946 / 37.24
1116 / 43.93
2431 / 95.81
1684 / 66.3
350 / 771
25.40 / 1.00
1546 / 60.86
2274 / 89.52
1466 / 57.71
1766 / 69.53
WIRED CONTROL
7080 / 15000
393.7 / 1.58
68
51,587
92.9
380~415 / 3 / 50
R22
ADB500B4
AMC125B x 4
500,000
146,500
UNIT DIMENSION
INDOOR UNIT
MODEL
SIZE
PACKING DIMENSION
UNIT DIMENSION
PACKING DIMENSION
TYPE
OUTDOOR UNIT
CONDENSATE DRAIN SIZE
SOUND PRESSURE LEVEL
UNIT WEIGHT
REFRIGERANT CHARGE
AIR FLOW
UNIT WEIGHT
PIPE CONNECTION
OUTDOOR UNIT
INDOOR UNIT
NOMINAL CAPACITY
NOMINAL TOTAL INPUT POWER
NOMINAL RUNNING CURRENT
POWER SOURCE
REFRIGERANT TYPE
SOUND PRESSURE LEVEL
OPERATION
EXTERNAL STATIC PRESSURE
AIR FLOW

18
1) ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.
2) ALL UNITS ARE BEING TESTED AND COMPLY TO ARI210/240-94
3) NOMINAL COOLING AND HEATING CAPACITY ARE BASED ON THE CONDITIONS BELOW :
COOLING - 26.7°C DB / 19.4°C WB INDOOR AND 35°C DB / 23.9°C WB OUTDOOR
4) SOUND PRESSURE LEVEL ARE ACCORDING TO JIS B 8615 STANDARD. POSITION OF THE MEASUREMENT POINT IS 1m IN FRONT AND 1m BELOW THE UNIT.
GENERAL DATA - COOLING ONLY (R22)
B SERIES
Btu/h
W
W
A
V/Ph/Hz
CONTROL
HIGH l/s / cfm
Pa / in.wg
dBA
HEIGHT mm/in
WIDTH mm/in
DEPTH mm/in
HEIGHT mm/in
WIDTH mm/in
DEPTH mm/in
kg/lb
mm/in
l/s / cfm
dBA
HEIGHT mm/in
WIDTH mm/in
DEPTH mm/in
HEIGHT mm/in
WIDTH mm/in
DEPTH mm/in
kg/lb
LIQUID mm/in
GAS mm/in
kg/lb
NOMINAL RUNNING CURRENT
POWER SOURCE
REFRIGERANT TYPE
SOUND PRESSURE LEVEL
OPERATION
EXTERNAL STATIC PRESSURE
AIR FLOW
OUTDOOR UNIT
INDOOR UNIT
NOMINAL CAPACITY
NOMINAL TOTAL INPUT POWER
SOUND PRESSURE LEVEL
UNIT WEIGHT
REFRIGERANT CHARGE
AIR FLOW
UNIT WEIGHT
PIPE CONNECTION
UNIT DIMENSION
INDOOR UNIT
MODEL
SIZE
PACKING DIMENSION
UNIT DIMENSION
PACKING DIMENSION
TYPE
OUTDOOR UNIT
CONDENSATE DRAIN SIZE
ADB600B4
AMC150C x 4
600,000
175,800
73,820
125.4
380~415 / 3 / 50
R22
WIRED CONTROL
8496 / 18000
514.9 / 2.07
70
1977.8 / 77.86
2274 / 89.52
1905 / 75.00
2135 / 84.06
2399 / 94.45
2005 / 78.94
999 / 2202
25.40 / 1.00
5475 / 11600
74
1041 / 40.98
1116 / 43.93
939 / 36.96
1227 / 48.31
1282 / 50.47
1112 / 43.78
10.10 (x4) / 22.27 (x4)
227 / 500
BRAZING
15.88 /
⅝
34.92 / 1
⅜
