ACTi MNR-320P User manual

Quick Installation Guide
MNR-320P
MNR-330P
16-Channel Transportation Standalone NVR

2 Quick Installation Guide
Thank you for purchasing ACTi Transportation Standalone Network Video
Recorder (MNR). This guide contains all the information you need to quickly set
up the MNR system via local display interface.
For detailed instructions on installation and operation, please search for the
product manuals on the http://www.acti.com/downloadcenter.
The items below are required for installation:
• Monitor (with HDMI or VGA input and the cable)
• USB mouse
• USB keyboard
• Network cameras
• Network cables
• POE switch
• OneACTi-certied2.5-inchSATAharddisk
Findthecertieddiskmodelsathttp://www.acti.com/hddselector
This package includes the following items:
MNR Unit x 1 GPS Antenna x 1 TerminalBlockx2
Disk Screws Warranty Card x 1 Quick Installation Guide x 1
UNPACK
1
BEFORE YOU START

Quick Installation Guide 3
REAR PANEL
1 2 3 4 5 6
7 8 9
1 Ground Screw
2 Power Connector
3 Power Source Switch
5 Audio Line In
6 Audio Out
7 Power Over Ethernet Ports
8 Terminal Block Connector
9 Antenna Connectors
(optional)
FRONT PANEL
1 USB Ports * 6 Hard Disk Activity LED
7 Power Button
8 GPS Antenna Connector
9 Hard Disk Bay
10
Reset Button
11
I/O Ports
1 2 3 4 5 6 7
9
11
8
10
AT A GLANCE
2
MNR-320P: USB 2.0 x 3, USB 3.0 x 1
MNR-330P: USB 2.0 x2, USB 3.0 x2
2 HDMI Port
3 VGA Port
4 LAN Ports
5 Power LED
4 Audio Mic In
P: Standard power outlet source
V: Vehicle power source

4 Quick Installation Guide
MAKE SURE THE UNIT IS NOT CONNECTED TO POWER before installing the
hard disk.
Step 1
Loosenthetwo(2)
thumbscrews.
Step 2
Pull out the tray.
Step 4
Secure the disk using the
four (4) supplied screws.
Step 5
Slide the tray back into
the slot.
Step 3
Mount the disk on the
tray.
INSTALL THE GPS MODULE
4
INSTALL THE HARD DISK
3
Step 6
Tightenthetwo(2)
thumbscrews to secure
the tray.
Step 1
Attach the GPS module
connector to the antenna
connector on the MNR.
Step 2
Tighten the connectors
to secure the GPS
antenna.
The GPS antenna is bundled with the MNR package.
Step 3
Place the GPS antenna on
aatsurface.

Quick Installation Guide 5
CONNECT THE DEVICES
5
The example below displays a local network consisting of an MNR, network
cameras and required peripherals.
Power Source
Network
Camera
Network
Camera
MNR
USB Devices
Monitor
1. Use at least four (4) screws appropriate for the surface where you will install
the MNR in the vehicle.
2.Install the network camera(s).
3. Connect the camera(s) to the PoE port of the MNR using network cables.
NOTE: The total power budget of the MNR is 30.8 watts. Note that if there are four (4)
cameras connected, each PoE port provides 7 watts power to the camera. Check the
cameraspecicationstoensurethecamerapowerinputmatchestheMNR.
4. Connect the USB devices and other optional input/output devices to the
MNR.
5.Connect the MNR to the power source.
INSTALL OPTIONAL MODULES
Tofulllcertainprojectrequirements,contactACTisalesrepresentativesto
purchase the following optional modules:
• Wireless Module - provides Wi-Fi connectivity
• 3G / 4G Module - provides 3G / 4G connectivity
Refer to the instructions in the Installation Guide to install the optional
modules and use the software utilities provided to complete the initial setup.
4

6 Quick Installation Guide
1. On the front panel, press the POWER SWITCH to turn on the MNR.
2.On the Windows logonscreen,type“123456”toentertheWindowssystem.
NOTE: To assign a static IP address to the MNR, after entering Windows operating
system,congurethenetworksettingsinWindows Network and Sharing Center.
START UP
6
INITIALIZE THE HARD DISK
7
After installing the hard disk, use the Windows Disk Management to initialize
the disk to enable MNR to save the video recordings.
1. In Windows Search Box, search and
enter “Computer Management”.
2.Select Disk Management. The Initialize Disk pop-up window will appear.
3. Select GPT as the partition style, and then click OK.
4. Right-click on the initialized disk
and select New Simple Volume.

Quick Installation Guide 7
1. On Windows Destop, double-click
to enter the NVR interface.
2.Input the default account and password
to log in.
Account: admin
Password: 123456
“123456”isthedefaultpasswordoftheNVR
administrator’s user account. For security reasons,
please remember to change it.
8
LOGIN
Forrst-timeuse,followtheInstallationWizardtostartconguringthesettings
orskipthisprocessandmanuallycongurethesettingsintheSetup page.
5.Follow the wizard to create the disk volume, assign the drive letter and
volumelabel.Repeatsteps4and5tocreateothervolumes,asneeded.

8 Quick Installation Guide
On the NVR screen, click the Setup button to go to the Setup page. Then
click the Users tab. By default, there is an Administrator group wherein all
permission levels are enabled. To limit NVR access for a certain group of users,
create user groups.
1. Select User Groups, click Add to start adding a new user group.
2.Input group ID and click Apply.
3. ConguretheusergroupPersmissions and click Apply.
9
CREATE USER GROUPS

Quick Installation Guide 9
ADD USERS
10
After creating user groups, create individual users.
1. On the left panel, click the Users title bar, click Add to start adding a new
user.
2.Input the user’s Account, Password, Email address and select its User Group,
and then click Apply.
SELECT STORAGE DRIVES
11
Select the disk where the MNR will save the recordings.
1. On the Setup page, click the Storage tab.
2.On Disk Drive List, select a storage drive.
3. Click Apply.

10 Quick Installation Guide
1. On the Setup page, click the Devices tab.
2.Click Add.
3. Choose a search method based on your network environment and camera
brand.
To Search Cameras in the Local Area Network (LAN)
• Click Hybrid Search to auto-search the network for ACTi cameras.
• Click Search ONVIF Cameras to search for ONVIF-compliant cameras of
any brand.
To Add Cameras Manually
1. Click Add Camera Manually.
2.Fill in Media Type, Protocol, IP
Address, HTTP Port, Account
and Password.
3. Click “Get Device Settings”and
then “Apply”.
Tondthecameras,input
the Account and Password,
and then click to start
searching.
Select the camera(s), then
click Apply to add the
cameras.
12
ADD CAMERAS

Quick Installation Guide 11
1. On the Setup page, click the Devices tab.
2.Choose the camera from the Camera list on the left panel.
3. Select Basic, Video, PTZ, or Preset Tourtabtocongurerelatedsettings.
NOTE: The available tabs vary depending on the camera model.
Note
If you have any
question during the
system installation,
please feel free to
contact our engineers
via ACTi Customer
Help Desk platform at
http://www.acti.com/
CHD.
CONFIGURE CAMERA SETTINGS
13
SET RECORDING SCHEDULE
14
The recording service automatically starts full-time recording for a newly added
camera. You can modify the recording schedule to suit your needs.
1. On the Setup page, click the Schedule tab.
2.Select the camera from the Camera list on the left panel..
3. Choose a recording mode: or
• Schedule Recording: Records video continuously during the scheduled
session.
• Event Recording:Recordsvideobasedonspecictriggerssuchaswhen
motion is detected by the camera.
4. Dragonthetimetabletodenethetimesession.
5.Click Apply.

12 Quick Installation Guide
Add new view Set as default view
Layout styles Video Stream Save view
15
CUSTOMIZE LIVE VIEW
1. Click the View button to go the Live View page.
2.From the Camera list, drag a channel to a layout window. Repeat this process
to add other channels.
3. On the View Toolbar, click to save the layout style and channel view.
4. Type a view group.
5.To set the current view as the default, click .
16
VIEW AND RECORD
To check live streaming of all channels, go to Live View page,
double-click on on the Camera list.
To check the recording, go to the Playback page, and then select
(double-click) a view from the View List or a camera from the Camera
list. Drag on the time bar to see the recorded video.

www.acti.com
Due to continuous product improvements, some contents may have
changed from the time this documentation was printed. You can download
the latest user documentation, which shall prevail over the printed version
provided in the package, from http://www.acti.com/downloadcenter .
V.2016.10.28
