ActionTec MegaPlug HPE400T User manual

Note: You do not need to complete this section if you connected the Hub to a
device other than a Computer. This utility can be used to adjust the security
settings of the Hub. For more information,see the User Manual which is located on
the Installation CD-ROM.
Note: An Ethernet port looks similar to a phone port but is slightly larger.
AConnect the Hub to a Device
BInstall the Configuration Utility
Step1Get the MegaPlug
85 Mbps 4-Port Hub from the
Quick Start Kit.
Step4Plug the other end of the
Ethernet Cable into an OPEN
Ethernet Port on your computer
or other device.
Step7Plug the other end into a
Power Outlet.
Do NOTplug the Hub into a power
strip or wall outlet that uses surge
protectionastheHubmaynotwork.
Step1Get the Installation CD
and insert it in the computer’s
CD-ROM Drive.
Flip this Quick Start Guide over to continue NEXT
Step2Get the Gray Ethernet
Cable.
Step3Plug one end of the
Ethernet Cable into any open
Ethernet Port on the back of the
MegaPlug 4-Port Hub.
Step5Get the Power Cord
from the Quick Start Kit.
Step6Plug one end into the AC
In Port located on the back of the
MegaPlug 4-Port Hub.
Questions? Call 1-888-436-0657 (USA) Questions? Call 1-888-436-0657 (USA)
!NOTE: This device requires another HomePlug (MegaPlug) compatible
device connected to your modem or router in order to function.If you
do not have another HomePlug compatible device,you may order one
by visiting www.actiontecstore.com/homeplug

Quick Start Guide
Connect the Hub to a Device
Install the Configuration Utility
B
A
This Quick Start Guide will walk you through the
easy steps to install and set up your MegaPlug™
85 Mbps 4-Port Hub.During this process,we will
show you how to:
You will need the following items:
•MegaPlug™85 Mbps
4-Port Hub
•Gray Ethernet Cable
•Power Cord
•Installation CD
(Note: Each device that needs to
communicate using the power will
need its own MegaPlug adapter) NEXT
Questions? Call 1-888-436-0657 (USA)
Model# HPE400T
Note: If the screen above does not appear,click Start on the taskbar and then
select Run. Type d:/setup (or e:/setup,depending on the drive letter of your CD-
ROM drive),then click OK..
Step2When the“Welcome”
screen appears,click Next.
Step3When the“Choose
Destination Location”screen
appears,click Next.
Step4Please wait until the final
screen appears.Then click Finish.
Part No:0530-0517-000 QS800/1105
NOTE ABOUT SECURITY: If you live in an apartment building or want to
take extra security measures,please see Chapter 3 of the User Manual which
is located on the Installation CD-ROM.
Congratulations! You have successfully installed the MegaPlug
85 Mbps 4-Port Hub.
