Activox XYC100B-P4L User manual

Manufactured & Distributed by
www.InovaLabs.com
Operator’s Manual
FOR USE WITH MODEL:
XYC100B-P4L
®
®

Copyright © 2015 Inova Labs, Inc. All rights reserved.
No part of this document may be reproduced or
transmitted in any form or by any means, electronic,
mechanical, photocopying, recording, or otherwise,
without prior written permission from Inova Labs Inc.
Inova Labs Inc.
3500 Comsouth Drive
Suite 100
Austin, TX 78744 USA
Phone: [phone]
Toll-Free: 1.800.220.0977
www.InovaLabs.com
Represented in Europe by:
QNET BV
Hommerterweg 286
6436 AM Amstenrade
The Netherlands

TABLE OF CONTENTS
Introduction 2
Application/Indications For Use 2
Symbol Descriptions 3
Warnings 3
Contraindications 4
Adverse Events/Hazards 4
Standard Package Contents 5
User Controls 6
Part Names 8
Operating Instructions 9
Battery Life Timetable 12
Battery Recharge Timetable 12
Attach & Remove Nasal Cannula Instructions 13
Repressurization Technology 14
Operating Procedure 14
Normal Operation Indicators 15
Alarm Indicators 16
Carry Case Configuration Instructions 17
Flying With Your POC 17
Routine Cleaning and Maintenance 18
Service Life 19
Technical Support 19
Disposal 19
Specifications 20
Oxygen Concentration Over Altitude and Flow Rate 20
Accessories 21
Warranty 22
EMC Information 26

2
INTRODUCTION
This Operator’s Manual will provide familiarity with the LifeChoice®
Activox®Portable Oxygen Concentrator (POC) model XYC100B-P4L and
its accessories. Be sure to read all of the enclosed information in its entirety
before using the device.
The device is an internally powered, Type BF device when powered by
the Internal Battery and a Class II, Type BF device when connected to the
external AC Power Supply, DC Power Supply or rechargeable External
Battery. The essential performance of the device is to provide oxygen
at a volume that remains within tolerance (the tolerance was defined
based on technical judgment from within the manufacturer’s expertise
in this specific medical application). In addition, the device’s ability to
detect certain error conditions (such as low purity or no breath) and create
an alarm is also considered a part of essential performance.
Operation with the DUO2 Stationary Base Concentrator
The Activox 4L can be purchased as part of the Inova Labs Activox DUO2
system. The system is composed of an Actiovox 4L POC and the DUO2
stationary base concentrator. If your POC came with the Activox DUO2
system, please refer to the Activox DUO2 Operator’s Manual for POC
operating and charging instructions.
The POC and stationary base can be disconnected and used independently
yet it is recommended they be connected. When connected:
•ThePOCandPOCexternalbatterycanbechargedbythestationary
base.
•ThePOCcanbeusedtomutetheaudiblealarmsofthestationarybase.
•ThePOCwillstoresome stationarybaseoperating dataforuse by
service technicians.
•ThePOCwillprovidethetotaloperatinghoursofthestationarybase.
•ThePOCcannotbepowered“on”.
APPLICATION/INDICATIONS FOR USE
This manual applies to the LifeChoice Activox POC XYC100B-P4L.
INDICATIONS FOR USE: The LifeChoice Activox Oxygen Concentrator
is used on a prescriptive basis by adult patients who are diagnosed as
requiring supplemental oxygen. This oxygen concentrator will provide
supplemental, high concentration oxygen to these patients. It is not life-
supporting nor life-sustaining. It may be used continuously in a home,
institution or travel environment. The LifeChoice Activox is also portable.
This device should be used only when prescribed by a physician.

3
WARNINGS
SYMBOL DESCRIPTIONS
Symbol Description Symbol Description Symbol Description
Caution
Consult
instructions for
use
No smoking
No open flame No oil or grease Do not
disassemble
Temperature
limit
Humidity
limitation Keep dry
This side up Fragile, handle
with care
Compliant with
WEEE
Manufacturer Date of
manufacture
Class II
equipment
Type BF applied
part
Device that
has conductive
contact with
patient
Catalogue
number
CE Marking
of Conformity
Representative
Gas flow Prescription
only Radio frequency
Rechargeable
battery Portable
Oxygen
Concentrator
Connection
Authorized
representative
in the European
Community
Serial number
1. U.S. Federal law restricts this device to sale by or on the order of a physician.
2. It is the responsibility of the patient and/or provider to make back-up
arrangements for an alternative oxygen supply.
3. Availability of an alternate source of oxygen is required in case of power
outage or mechanical failure.
4. The device is to be operated in the approved carry case provided.
5. The device should be located as to avoid pollutants or flames.
6. Portable and mobile RF communications equipment can affect medical
electrical equipment.
7. The device should not be used adjacent to or stacked with other equipment
other than the the Activox DUO2.
8. When traveling by air, the device and External Battery must be transported
as carry-on (not checked) baggage.
9. The device and External Battery contain lithium-ion batteries that are subject
to special shipping regulations. If shipping either the device or External
Battery, notify the shipper that the shipment will contain lithium-ion batteries.
10. In the event of a battery’s cell leaking, do not allow the liquid to come in
contact with the skin or eyes. If contact has been made, wash the affected
area with copious amounts of water and seek medical advice.

4
CONTRAINDICATIONS
1. The device is not intended to be life-sustaining or life-supporting.
2. In certain circumstances, oxygen therapy can be hazardous. Please
seek medical advice before using this device.
3. The device is designed to provide a flow of high purity oxygen
up to 4 LPMeq pulse. The device should only be used by patients
prescribed oxygen therapy within this range.
4. As the device will alarm through audio and visual indicators, patients
who are unable to communicate discomfort, hear, see and/or
understand the alarms may require additional monitoring.
Inova Labs Inc. assumes no liability for persons choosing not to
adhere to manufacturer’s recommendations. Failure to adhere to the
statements below may impair performance of the device and will void
all warranties.
1. DO NOT use oil, grease or petroleum-based products on or near
the device as the use of such products may damage the electronic
components of the device.
2. DO NOT use power supplies or accessories other than those that
came with the device as the use of non-specified accessories may
impair performance.
3. DO NOT allow smoking or open flames within 10 ft. (3 m) of the device
as the device produces enriched oxygen gas which accelerates
combustion.
4. DO NOT operate the device in the accessory bag or any other
enclosed bag as improper ventilation will impair performance.
5. DO NOT submerge or expose the device to liquids as it may
damage the electronic components of the device.
6. DO NOT operate or expose the device to temperatures and humidity
levels outside of the specified operational environment conditions listed
in the Specifications section on page 20. Extreme temperatures and
humidity levels may damage the device.
7. DO NOT press the Control Panel buttons or screen with any hard,
sharp and/or small object as it may damage the surface.
8. DO NOT dismantle, open or shred secondary cells or batteries.
9. DO NOT expose cells or batteries to heat or fire and avoid storage in
direct sunlight.
ADVERSE EVENTS/HAZARDS

5
STANDARD PACKAGE CONTENTS
DC Power Supply
AC Power Supply
Standard 7-Foot (2-meter)
Single Lumen Nasal
Cannula*
Accessory Bag
LifeChoice Activox 4L POC
Model identified on device and
packaging labels. See .
4-Way Carry Case
Use as a backpack, shoulder bag,
waist pack or briefcase
Adjustable Straps
For use with 4-Way Carry Case
7
1
2
5
6
7
3
4
1
2
5
4
6
3
An optional External Battery (not included
in the Standard Package) is available for
purchase.
*Nasal cannula may not be included. Based on international requirements.See
your doctor for compatibility of other accessories (CPAP, BiPAP, etc.).

Alarm Indicator: A red LED will illuminate and an audible signal (tone)
will sound if there is a change in operating status or a condition occurs
that may need response (alarm).
Display Screen: Displays operational indicators. (Reference Display
Screen diagram on page 7.)
Mute Button: Disables audible alarm signals during operation. If an
alarm has been muted, the Mute symbol will appear on the Display
Screen. (Reference Display Screen diagram on page 7.)
CAUTION: Please use the Mute function appropriately as it silences
important audio signals regarding the status of the device.
Navigation Controls: The Plus, Minus, Right Arrow, Left Arrow and OK
buttons enable navigation within operating menus.
Plus/Minus Buttons: Adjust the Pulse Setting (1, 2, 3 or 4 LPMeq).
OK Button: Press once to illuminate the screen. Press and hold
down to display the serial number and hours of operation.
Right/Left Arrow Buttons: Press once to illuminate the screen.
Service personnel will also use these buttons to access maintenance
menus for troubleshooting.
Power Button: To turn on, briefly press the Power Button. To turn off,
press and hold down the Power Button until you hear a tone.
Power Indicator: A green LED will illuminate when the POC is turned
on and in use.
6
Control Panel
USER CONTROLS
Power Indicator
Power Button
Alarm Indicator Navigation Controls
Mute Button Display Screen
4

7
Mute Symbol
INT and EXT
Battery Bars
Flow Setting
Level
Auto Mode Setting
Message Field
Auto Mode Setting: There are two inhalation sensitivity modes on
the device: Active and Rest, which automatically adjust based on your
breathing patterns. The activated Auto Mode setting will appear on the
display.
External Power Symbol: This symbol is displayed only when the unit
is connected to an external power supply (AC or DC).
Flow Setting Level: Represents the selected Pulse Setting (1, 2, 3 or 4
LPMeq). Use the Plus and Minus Buttons to adjust the Pulse Setting up
or down.
INT and EXT Battery Bars: Represent the charging level of the Internal
(INT) and External (EXT) Batteries.
Message Field: Displays the title of an alarm if activated. (Reference
Alarm Indicators section on page 16.)
Mute Symbol: Appears only when the Mute Button has been pressed.
Operating Status Field: This field will indicate if the device is
“Running”, “Charging Internal” or “Charging External”. When the
batteryisfullycharged,“ChargingInternal”or“ChargingExternal”
will disappear from the display.
PULSE-WAVE®Breath Detection Symbol: Appears when a breath is
detected and the device delivers a pulse of oxygen.
Display Screen
PULSE-WAVE Breath
Detection Symbol
Operating Status
Field
External
Power Symbol
Each Battery Bar is divided into 4 segments
that represent 25% charge levels. As the
charge level of the device increases, more
segments will appear until full.
100%
75%
50%
25%
4

8
Fan Inlet Vent
Cannula
Nozzle Fitting
Fan Outlet
Vent
External
Battery Port
Cannula Nozzle Fitting: Connect the nasal cannula to this fitting at the top
of the device.
Charger Port: Connect the AC or DC Power Supply to this port on the
device.
Control Panel: All user controls are located on this panel. (Reference User
Controls section on page 6 for details.)
External Battery Port: Connect the External Battery, if purchased, to this
port. The flat end of the External Battery plug should be facing upwards
when plugging into the port on the device.
Fan Inlet Vent: Cooling air is drawn in through this opening.
Fan Outlet Vent: Processed air is exhausted through this opening.
Nasal Cannula: A standard single lumen nasal cannula or equivalent must
be used with the device to provide oxygen from the concentrator.†The
maximum length recommended for use is 7-feet (2-meter). For a replacement
cannula, please contact your local medical equipment provider. Follow
cleaning and care instructions provided with the nasal cannula.
CAUTION: Use of some accessories and/or service equipment not specified
for use with this oxygen concentrator may impair the performance.
† Nasal cannula may not be included. Based on international requirements. See your doctor for
compatibility of other accessories (CPAP, BiPAP, etc.).
PART NAMES
Control Panel
Charger Port

9
OPERATING INSTRUCTIONS
The LifeChoice Activox POC must be operated and stored in its carry case at
all times.
BEFORE FIRST USE:
1. Fully charge the device. It can take up to 4 hours to reach a full charge
on the Internal Battery. Begin charging by connecting the AC Power
Supply to the Charger Port on the device and an electrical outlet.
2. Verify that the INT Battery Bar, the External Power Symbol and the
message“ChargingInternal”appearonthedisplay.Thisindicatesthat
the system recognizes the external power source and is charging the
Internal Battery.
If an External Battery was purchased, connect it to the External Battery
Port. By design, the External Battery will begin charging after the Internal
Battery has reached a full charge. When connected, the External Battery
Bar,theExternalPowerSymbolandthemessage“ChargingExternal”
appear on the display. It can take up to 2 hours to fully charge the External
Battery.
CAUTION: Never use an external battery that is not authorized by Inova
Labs Inc.
POWERING YOUR POC
The device can be powered from four different sources: (1) Internal
Battery, (2) AC Power Supply, (3) DC Power Supply and (4) External
Battery (optional, sold separately from the Standard Package).
1. Internal Battery: A rechargeable
internal battery is located within
each device. When the device is being
powered from the Internal Battery,
the display will read “Running
Internal” and the INT Battery Bar will
appear.
If not connected to the AC or DC Power Supply, the Internal Battery
will slowly discharge over time even when not in use.
Always check the battery level prior to use to ensure adequate charge
level.
4
Running Internal

2. AC Power Supply: This power supply allows the device to be powered
and charged from a standard 100-240 VAC,
50/60 Hz electrical outlet. When using this
option, power from the AC outlet powers
the unit and recharges the Internal and/
or External Battery. The External Power
symbol will also appear on the display
screen when connected to this power
supply.
NOTE: Using an AC Power Supply that is not specified by Inova Labs
may damage the device and will void all warranties.
3. DC Power Supply: This power supply can be connected from the
device to a vehicle’s (car, boat, motor home,
etc.) standard 12 VDC outlet. When the system is
connected to this option, power from the vehicle
battery powers the device and recharges the
Internal and/or External Battery. The External
Power symbol will also appear on the display
screen when connected to this power supply.
NOTE: The 12 VDC outlets in some vehicles will not provide sufficient
current to operate the device and charge the battery at the same time.
Verify that a DC outlet can provide at least 10 amps at 12 VDC. Car
auxiliary power varies significantly; therefore, the rate of charging will
vary. It is recommended that the vehicle be turned on before plugging
the DC Power Supply into the device.
4. External Battery: This power supply connects directly into the device’s
External Battery Port. When the system is connected
tothisoption,thedisplaywillread“RunningExternal”
and the EXT Battery Bar will appear. The External
Battery is maintenance-
free and replacements can
be purchased from your
equipment provider.
INTERNAL BATTERY CHARGING
1. Connect the device to either an AC or DC Power Supply and corresponding
charger to a suitable outlet.
2. Verify that the INT Battery Bar, the External Power Symbol and the
message“ChargingInternal”appearonthescreen.
3. It can take a fully discharged Internal Battery up to 4 hours to reach a
full charge. Refer to the INT Battery Bar on the display screen to check
the charging progress. Each segment in the Battery Bar represents 25%.
When the Internal Batteryisfullycharged,themessage“Charging
Internal”willdisappearfromthedisplayscreen.
10
OPERATING
INSTRUCTIONS
continued
4
Running External

11
NOTE: It is recommended to
recharge the Internal Battery,
even if only partially depleted
as often as possible. The Internal
Battery cannot be overcharged,
so it is okay to leave the device
plugged into an external power
supply continuously.
EXTERNAL BATTERY CHARGING
1. Connect the External Battery to the External Battery Port. The flat
end of the External Battery plug should be facing upwards when
plugging into the port on the device. Then connect the device to
either an AC or DC Power Supply and corresponding charger to a
suitable outlet. To prolong battery life and maintain communication
with the POC, it is recommended to charge the External Battery when
you charge the Internal Battery.
2. Verify that the EXT Battery Bar, the External Power Symbol and the
message“ChargingExternal”appearonthedisplay.
NOTE: By design, the Internal Battery will charge first. The External
Battery will not start charging until the Internal Battery is full charged.
NOTE: If the External Battery Bar doesn’t illuminate after the
Internal Battery charge is
complete, the External Battery isn’t
communicating with the POC. To
enable communication: a) Power
off the POC and connect the POC
to the AC or DC charger. b) Use
two fingers to push and hold
downboththe“MUTE”and“OK”
buttons at the same time; When the
External Battery Bar starts flashing,
immediately release the buttons. If
communication is established, the External Battery Bar will appear, the
External Battery will begin charging and Charging EXT will appear. If
this procedure doesn’t work for you, please call Inova Labs Customer
Care at 512.617.1744 for assistance.
3. It can take up to 2 hours for a fully discharged External Battery
to reach a full charge. Refer to the EXT Battery Bar on the display
screen to check the charging progress. Each segment in the Battery
Bar represents 25%. When the External Battery is fully charged,
themessage“ChargingExternal”willdisappearfromthedisplay
screen.
NOTE: By design, the External Battery will power the device when
plugged in. Once the External Battery depletes, the device will
switch to Internal Battery power. If both the Internal and External
batteries are fully discharged, it can take up to 6 hours to achieve
a full charge in both batteries.
OPERATING
INSTRUCTIONS
continued

In the event the power supply is interrupted to the device when the AC or DC
Power Supply is connected, a two-second audible alarm will sound and the
compressors will transition from external to battery power.
NOTE: If the POC is powered off and either the AC or DC Power
Supply is connected, the internal fans will continue to operate until the
temperature inside the unit is sufficiently cooled.
12
OPERATING
INSTRUCTIONS
continued
* Hours are approximate and based on a given average breaths per minute use rate. Breathing
faster or slower than nominal can decrease or increase battery run time. As batteries age, charge
times and runtimes may change.
BATTERY LIFE TIMETABLE
Battery Type
Pulse Setting
1 LPMeq 2 LPMeq 3 LPMeq 4 LPMeq
Internal Battery* 10.25 Hours 8.25 Hours 5 Hours 4 Hours
External Battery* 4.75 Hours 3.75 Hours 2.75 Hours 2.25 Hours
BATTERY RECHARGE TIMETABLE
Battery Type Hours
Internal Battery* 4
External Battery* 2

13
ATTACH AND REMOVE NASAL CANNULA INSTRUCTIONS
The Cannula Nozzle Fitting on the Activox POC rotates to reduce
the risk of a kinked cannula. To ensure proper functioning of the
Fitting, refer to the following instructions for correct attachment and
removal of the cannula.
Attaching the Cannula:
1. Align the Cannula Nozzle Fitting to
the up-right position. Cannula Nozzle
Fitting is at the 90° position
2. Install the Cannula Adapter by
rotating and pressing (in the same
motion) onto the Fitting with the
Fitting in the upright position. Press
down to fully seal the connection and
test with a light pull. Note: To ease
Cannula removal, the Adapter should
not be advanced past the fourth rib of
the Fitting.
Removing the Cannula:
1. Put the Fitting in the vertical position
and grasp the Cannula Adapter as
close to the Fitting tip as possible.
2. Remove by squeezing and rotating
straight up on the Cannula Adapter as
shown. Twist and pull. Do NOT yank
the hose abruptly and do NOT pull
any direction but UP or risk breaking
the Fitting.

14
OPERATING PROCEDURE
1. Position the device so that the Fan Inlet Vent and Fan Outlet Vent are
not obstructed and in a well-ventilated space.
2. Briefly press the Power Button to
turn the device on. The Display
Screen and green Power Indicator
will illuminate. This indicates that
the device is powered on, ready for
use, and the settings may now be
changed.
NOTE: After powering on the device, allow 3 minutes for the system
to reach stated performance. If used routinely, the Pulse Setting last
used will appear on the display after powering on.
3. Use the Plus/Minus Buttons to select
the Pulse Setting prescribed by your
doctor (1, 2, 3 or 4). To change a
setting at any time, use the Plus and
Minus buttons.
4. Place the nasal cannula onto the Cannula Nozzle Fitting on the
device and the cannula prongs into your nasal passages and
breathe normally. When the device senses inhalation, oxygen is
supplied through the cannula. The duration and size of the pulse
is dependent upon the Pulse Setting selected.
NOTE: The device utilizes PULSE-WAVE Delivery which delivers
oxygen congruent with your inhalation rate. Because this type of
delivery is very gentle, you may not feel the pulse of oxygen.
To verify that oxygen is being delivered, reference the symbol
next to your selected Pulse Setting on the display. This symbol will
flash every time a breath is detected.
5. Check to make sure the batteries are fully
charged before venturing out with the
device.
6. To turn the device off, press and hold the
Power Button until you hear an audible tone.
REPRESSURIZATION TECHNOLOGY
If the unit has not been used for a period of one or more days, it will
automatically re-pressurize itself. During this time, you may hear the
compressors running for a few seconds. There is no action required
on your part, this feature is intended to prolong the life of the device.

15
NORMAL OPERATION INDICATORS
During normal operation, the Control Panel and Display Screen
should appear as described below:
OPERATION DESCRIPTION
Active or Rest Mode
Activitated
Theword“ActiveMode”or“RestMode”willappearnexttoyourselected
pulsesetting.If“ActiveMode”isdisplayeditmeansyourbreathrateistypical
foranactiveuser.If“RestMode”isdisplayeditmeansyourbreathrateis
slower than your normal active breath rate.
Alarm Muted
The audible alarm signal will be muted and the Mute symbol will
display on screen. The red alarm LED will remain illuminated on the
Control Panel and the alarm title will remain on the display.
Breath Detected
The PULSE-WAVE Breath Detection Symbol will flash as you breathe. This
is confirmation the device is delivering a dose of oxygen with each inhaled
breath.
If you stop breathing through the nasal cannula (mouth breathing), the unit
will begin delivering doses of oxygen automatically without the PULSE-
WAVEsymbol.After75seconds,theunitwillprovidea“NOBREATH
DETECTED”alarmandwillcontinuetoautomaticallyprovidedosesof
oxygen until normal breathing resumes. When the unit detects normal
breathing,the“NOBREATHDETECTED”alarmwillceaseandthePULSE-
WAVE symbol will indicate detection of your breath.
Charging Status
The following messages will appear on the display depending on the battery
being used or charged.
“ChargingInternal”meanstheInternalBatteryischarging.
“ChargingExternal”meanstheExternalBatteryischarging.
“RunningInternal”meanstheInternalBatteryisinuse.
“RunningExternal”meanstheExternalBatteryisinuse.
NOTE: By design, the device will preserve the Internal Battery charge as
long as possible. This means that the External Battery will deplete before the
Internal Battery and the Internal Battery will charge before the External Battery
when connected.
Connected to Activox DUO2 When the device is connected to the Activox DUO2 stationary base, the Display
Screenwillshowthemessage“ConnectedtoActivoxDUO2”.
Power Interruption
The device will emit a two second audible tone if the AC or DC Power is
interrupted or intentionally unplugged. The unit will automatically switch
to battery operation. If the power was not intentionally removed, check all
connections between the unit and the power source to ensure all are secure
and firmly plugged in. If the power indicator icon does not show on the
display, switch to another power source (AC or DC) or source of oxygen and
contact your equipment provider.
Powered On The Power Indicator is illuminated green and the Display Screen is on.
Setting Selected “1”,“2”,“3”or“4”willappearunder“Setting”ontheDisplayScreen.

16
ALARM INDICATORS
The device will alarm to inform you of conditions that may require
your attention or action. Each alarm will trigger:
• A repeating audible tone (<1 second ON, <2 seconds OFF)
• Illuminated red Alarm Indicator on the Control Panel
• Alarm title displayed in the Message Field (unless noted
differently below)
ALARM TITLE DESCRIPTION & CORRECTIVE ACTION
Low Battery
This alarm is triggered when the Internal Battery has approximately
5% charge remaining. A countdown timer of the final 180 seconds will
appearonthescreenandan“X”willappearovertheINTBatteryBar.
Connect the device to the AC or DC Power Supply. Ensure all your
chargerconnectionsaresecureandthemessage“ChargingInternal”
and the External Power symbol appear on the display. The device will
begin charging and the alarm should stop. If the alarm persists, switch to
another source of oxygen and call your equipment provider.
Low Oxygen Purity
This alarm can be triggered when the oxygen purity falls below 82%.
This can occur if you are breathing at a high breath rate that exceeds
the oxygen production capacity of the device or if the device requires
sieve bed replacement. Take slow deep breaths until your breath rate
recovers.This allows the device time to restore purity levels. If the alarm
stops, the device is safe to use. If the alarm persists for an extended
period of time after you have recovered your breath, change to another
source of oxygen and contact your equipment provider.
No Breath Detected
This alarm can be triggered by a kinked cannula, unattached cannula
or shallow and/or mouth breathing. Check the cannula connection and
hose for kinks and fix if found. If the cannula was not impaired and is also
attached properly, the alarm could be caused by shallow and/or mouth
breathing. Breathe deeply through your nasal cannula and the alarm
should stop. If the alarm persists, switch to another source of oxygen and
contact your equipment provider.
High Temperature
This alarm is triggered when the internal temperature of the device
exceeds 140°F (63°C). When this alarm is activated, the device will
power off and the audible alarm will cease. The red Alarm Indicator and
the alarm title remain until the device sufficiently cools. Move the device
away from any potential heat source and change to another source of
oxygen. After allowing sufficient time to cool, turn on the device. If the
alarm persists, continue to use another source of oxygen and contact
your equipment provider.
Reset Required
This alarm can be triggered when the device experiences a sudden
spike in current from an external power supply. The Display Screen
will be blank when this alarm is activated. Follow the Electronic Reset
directions on page 18 to reset the device to default factory settings. If the
alarm continues immediately after the reset, switch to another source of
oxygen and contact your equipment provider.

17
CARRY CASE CONFIGURATION INSTRUCTIONS
The Carry Case can be configured as a shoulder bag, backpack, waist
pack or briefcase using the adjustable straps and/or briefcase handle.
Below are instructions for configuring the backpack.
BACKPACK
1. Adjust each strap to make sure they are the same length.
2. Unfold the snaps that are tucked into the mesh pocket on the
backside of the Carry Case.
3. Attach one strap to the top left and bottom right snaps on the Carry
Case making sure the shoulder pad is near the top clip.
4. Attach the second strap to the top right and bottom left snaps on the
Carry Case making sure the shoulder strap is near the top clip.
5. Forman“X”withthestrapsatthetopandslidearmsintotheconfiguration
as if putting on a backpack. Assistance may be required with this step.
6. Adjust straps as needed. Assistance may be required with this step.
The LifeChoice Activox POC is approved by the FAA for use on
commercialaircraft.TheFAA-approvedPOClistshows “Inova Labs
LifeChoice Activox.”Thisapprovalislistedasapartofthelabelingonthe
bottom panel of the device. As every airline has specific information
required for traveling with oxygen you should review your airline’s
specific requirements in addition to following the instructions below.
1. Two weeks prior to your trip, verify that the Internal and, if purchased,
External Battery runtimes will provide you with enough battery life
for the trip. Typically, airlines require you to have enough battery life
for 1.5 times the flying duration.
2. Fully charge the Internal and, if purchased, External Battery within
24 hours of a trip. Keep the device connected to a power supply until
you leave.
3. Pack all required accessories (AC and DC Power Supplies,
Operator’s Manual, small extension cord, etc.)
4. Download and complete a Physician Statement from your airline’s website
or from www.inovalabs.com/resources/traveling-with-oxygen/. Bring the
signed and completed Physician Statement to the airport and be ready to
provide it to the airline if requested.
FLYING WITH YOUR POC

18
ROUTINE CLEANING AND MAINTENANCE
The device was designed to minimize the amount of routine
maintenance that is required. There are no end-user repairable parts.
Aside from the preventative maintenance outlined below, all other
maintenance must be performed by qualified service personnel.
Fan Inlet Vent Cleaning: There is one inlet
vent located on the right side (facing the
unit) of the device. The carrying case for
the unit has mesh material corresponding
to the location of the Fan Inlet Vent. You
should visually check to ensure that there
is no buildup of lint, hair or other materials
that could obstruct the flow of air into the unit’s
fan inlet vent. At least once a month inspect
the grille of the intake vent and if it appears
dirty, use a dry cotton swab (Q-Tip or similar)
to clean it.
Device and Carrying Case Cleaning: If it is necessary to clean the
deviceand/or carrying case,use only warmwater andamild liquiddish
detergent. Dampen a cloth in the solution and carefully wipe the
outside surfaces of the device and/or carrying case. Allow sufficient
time to dry before placing the device back in the case.
CAUTION: DO NOT use alcohol, solvents, polishes or any oily
substances as they may be flammable. DO NOT stick cotton swab into
vent while POC or fan is running. This will cause damage
Nasal Cannula Inspection: At least once a week, visually inspect
the nasal cannula. Make sure there are no kinks or obstructions.
Replace as needed with a standard 7-foot. (2-meter) single lumen
nasal cannula from your equipment provider.
Reserve Oxygen Supply: Your local equipment provider should
provide or suggest an alternative source of supplemental oxygen
therapy in case there is a mechanical failure or power outage.
Electronic Reset: If the Display Screen does not appear as described
on page 7 or the Reset Required alarm is activated, follow the steps
below to reset the device to default factory settings:
1. Check that the unit has at least 25% (1 bar) charge on the battery
or plug into an external power source.
2. With the device off, press and hold down
the Power button. The screen display will
start flashing. In 10-15 seconds, the unit will
beep one time and the home screen will
appear on the display (see example).
3. Release the Power button. The unit will run for a few seconds and
then turn off.
4. The unit is now reset. If this doesn’t resolve the issue, contact your
equipment provider or Inova Labs.
Activox
Serial Number: PF1234
Runtime: 00:0 Hrs.
Version: 123-456R7.8
