ACU-RITE 01129 User manual

Instruction Manual
SAVE THIS MANUAL FOR FUTURE REFERENCE.
Questions? Contact Customer Support at
[phone] or visit www.AcuRite.com.
CONTENTS
Unpacking Instructions ........... 2
Package Contents .................. 2
Product Registration ............... 2
Features & Benets: Sensor..... 2
Features & Benets: Display.... 3
Setup .................................... 5
Sensor Setup ......................... 5
Display Setup ........................ 6
Intelli-Time® Clock .................. 7
Set the Time, Date & Units ...... 7
Placement Guidelines ............. 8
Using the Weather Forecaster... 9
Backlight Settings..................10
USB Charging.......................11
Troubleshooting ....................12
Care & Maintenance.............13
Replace Intelli-Time® Battery ..13
Specications........................14
FCC Information ...................14
Customer Support .................15
Warranty..............................15
Alarm Clock Weather Station
model 01129

2
Congratulations on your new AcuRite product. To ensure the best
possible product performance, please read this manual in its entirety
and retain it for future reference.
Unpacking Instructions
Remove the protective lm that is applied to the LCD screen prior to using this
product. Locate the tab and peel off to remove.
Package Contents
1. Display
2. Outdoor Sensor
3. Power Adapter
4. Instruction Manual
Features & Benets
4
3
2
1
5
OUTDOOR SENSOR
1. Integrated Hanger
For easy placement.
2. Wireless Signal Indicator
Flashes when data is being sent to
the display.
3. Battery Compartment
4. A-B-C Switch
ID code that must match display’s
A-B-C switch to ensure units
synchronize.
5. Battery Compartment Cover
PRODUCT REGISTRATION
Register online to receive 1 year warranty protection
www.AcuRite.com
IMPORTANT PRODUCT MUST BE REGISTERED
TO RECEIVE WARRANTY SERVICE

3
Features & Benets
FRONT OF DISPLAY
1. Current Outdoor Temperature
Arrow icon indicates the direction
temperature is trending.
2. Outdoor Sensor Signal Strength
3. Outdoor Low Temperature Record
Lowest temperature recorded
since midnight.
4. Outdoor High Temperature Record
Highest temperature recorded
since midnight.
5. Date
6. USB Charger
For compatible smartphones.
7. Icon
Indicates display is in auto-dimming
brightness mode (see page 10).
8. Intelli-Time®Clock
Automatically updates itself for
Daylight Saving Time.
9. Alarm ON/OFF Indicator
10. Learning Mode Icon
Disappears after weather forecast
self-calibration is complete.
11. Current Indoor Humidity
Arrow icon indicates the direction
humidity is trending.
12. Humidity Level Icon
Indicates a high, low or ideal
humidity comfort level.
13. Current Indoor Temperature
Arrow icon indicates the direction
temperature is trending.
14. SNOOZE Button
15. 12 to 24 Hour Weather Forecast
Self-Calibrating Forecasting pulls data
from the outdoor sensor to generate
your personal forecast.
16. Outdoor Sensor Low
Battery Indicator
1
2
3
4
5
16 1415
9
11
10
12
13
7 8
6

4
Features & Benets
8
9
7
6
DISPLAY BOTTOM
6. A-B-C Switch
ID code that must match the
sensor's A-B-C switch to ensure
units synchronize.
7. Battery Compartment
8. Intelli-Time® Battery
Compartment
9. Battery Compartment Cover
DISPLAY BACK
1. Alarm ON/OFF Switch
2. Button
For setup and backlight
brightness preferences.
3. SET Button
For setup preferences.
4. Button
For setup and backlight
brightness preferences.
5. Plug-in for Power Adapter
2
3
4
1
5

5
SETUP
Sensor Setup
Set the A-B-C Switch
The A-B-C switch is located inside
the battery compartment. It can
be set to A, B or C. However,
you must select the same letter
choices for both the sensor and
the display in order for the units
to synchronize.
Install or Replace Batteries
AcuRite recommends high quality
alkaline or lithium batteries for
the best product performance.
Heavy duty or rechargeable
batteries are not recommended.
The sensor requires lithium
batteries in low temperature
conditions. Cold temperatures
can cause alkaline batteries
to function improperly. Use
lithium batteries in the sensor for
temperatures below -4ºF / -20ºC.
1. Slide off the battery
compartment cover. Take note
of the A-B-C switch setting
inside the battery compartment
for display setup.
2. Insert 2 x AA batteries into
the battery compartment, as
shown. Follow the polarity
(+/-) diagram in the battery
compartment.
3. Replace the battery cover.
2
1
1A-B-C Switch
Set to match
display
2Install Batteries
2 AA batteries
A B C

6
Display Setup
Set the A-B-C Switch
Locate the A-B-C switch inside
the battery compartment. Set
the A-B-C switch to A, B or C.
You must select the same letter
choices for both the display and
the sensor in order for the units
to synchronize.
Plug in Power Adapter
For the best performance, plug
in the power adapter as the main
power source for this product.
Install or Replace Backup
Batteries (optional)
1. Remove the battery
compartment cover.
2. Insert 2 x AAA alkaline
batteries into the battery
compartment, as shown.
Follow the polarity
(+/-) diagram in the battery
compartment.
3. Replace the battery cover.
2
3
1
A B C
IMPORTANT: Batteries are a backup power source to preserve records in the event of a
power outage. Power adapter recommended as the primary power source to enjoy the full
functionality of the product.
2Plug in Power
Adapter
1A-B-C Switch
Set to match
sensor
Install Backup
Batteries (optional)
2 AAA alkaline
batteries
3
PLEASE DISPOSE OF OLD OR DEFECTIVE BATTERIES IN AN ENVIRONMENTALLY SAFE
WAY AND IN ACCORDANCE WITH YOUR LOCAL LAWS AND REGULATIONS.
BATTERY SAFETY: Clean the battery contacts and also those of the device prior to battery installation. Remove batteries from equipment that will not be
used for an extended period of time. Follow the polarity (+/-) diagram in the battery compartment. Promptly remove dead batteries from the device. Dispose of used
batteries properly. Only batteries of the same or equivalent type as recommended are to be used. DO NOT incinerate used batteries. DO NOT dispose of batteries in fire,
as batteries may explode or leak. DO NOT mix old and new batteries or types of batteries (alkaline/standard). DO NOT use rechargeable batteries. DO NOT recharge
non-rechargeable batteries. DO NOT short-circuit the supply terminals.

7
Intelli-Time®Clock
Intelli-Time products are pre-programmed with the correct time and date.
Intelli-Time technology instructs the time and date to set themselves. All you
need to do is select your Time Zone and Daylight Saving Time preferences. The
clock will then automatically set itself and change for Daylight Saving Time.
Set the Time, Date & Units
Press and HOLD the "SET" button, located on the back of the display until
"SELECT TIME ZONE" appears, to enter SET MODE. Once in SET MODE, the
preference you are currently setting will ash on the display.
To adjust the currently selected (ashing) item, press and release the " " or
" " buttons (press and HOLD to fast adjust).
To save your adjustments, press and release the "SET" button to adjust the next
preference. The preference set order is as follows:
TIME ZONE (PST MST CST EST AST HAT AKT NST)
AUTO DST (ON or OFF)*
CLOCK HOUR
CLOCK MINUTE
CALENDAR MONTH
CALENDAR DATE
CALENDAR YEAR
TEMPERATURE UNITS (ºF or ºC)
*If you live in an area that observes Daylight Saving Time, DST should be set
to ON, even if it is not currently Daylight Saving Time.
You will automatically exit SET MODE if no buttons are pressed for 5 seconds.
Enter SET MODE at any time by pressing and holding the "SET" button until
"SELECT TIME ZONE" appears on the display.
Set the Alarm Time
To set the alarm time, press and RELEASE the "SET" button to enter ALARM SET
MODE.
To adjust the currently selected (ashing) item, press and release the " " or
" " buttons (press and HOLD to fast adjust).
To save your adjustments, press and release the “SET” button to adjust the next
preference. The preference set order is as follows:
ALARM CLOCK HOUR (Please note AM/PM indicator)
ALARM CLOCK MINUTE
You will automatically exit ALARM SET MODE if no buttons are pressed for
5 seconds. Enter ALARM SET MODE at any time by pressing and RELEASING
the "SET" button.
Enable the alarm by switching the ON/OFF switch (located on the side of the
display) to ON.

8
Display Placement
Place display in a dry area free of dirt and dust. To help ensure an
accurate indoor temperature measurement, be sure to place the
display away from heat sources or vents.
Outdoor Sensor Placement
Sensor must be placed outside to observe outdoor conditions.
Sensor is water resistant and is designed for general outdoor use,
however, to extend its life place the sensor in an area protected
from direct weather elements.
Hang the sensor using the integrated hang holes or hanger, or by
using string (not included) to hang it from a suitable location, like a
well covered tree branch. The best location is 4 to 8 feet above the
ground with permanent shade and plenty of fresh air to circulate
around the sensor.
Placement for Maximum Accuracy
AcuRite sensors are sensitive to surrounding environmental conditions. Proper
placement of both the display and outdoor sensor are critical to the accuracy
and performance of this product.
Important Placement Guidelines
• To ensure accurate temperature measurement, place units out of direct
sunlight and away from any heat sources or vents.
• Display and outdoor sensor must be within 330 ft (100 m) of each other.
• To maximize wireless range, place units away from large metallic items, thick
walls, metal surfaces, or other objects that may limit wireless communication.
• To prevent wireless interference, place both units at least 3 ft (.9 m) away
from electronic devices (TV, computer, microwave, radio, etc.).
Setup is Complete
The sensor will now synchronize with the display. It may take a few minutes for
synchronization to complete.
TV 3
(100 meters)
(330 feet maximum)
(.9 m)
AT
LEAST
APART

9
OPERATION
View the complete list of icons at www.AcuRite.com/acurite-icons
Using the Weather Forecaster
Learning Mode
Self-Calibrating Forecasting use a unique algorithm to analyze changes in
pressure over a time period (called Learning Mode) to determine your altitude.
After 14 days, the Learning Mode icon disappears from the display screen. At
this point, the self-calibrated pressure is tuned in to your location and the unit is
ready for superior weather prediction.
Weather Forecast
AcuRite’s patented Self-Calibrating Forecasting provides your personal forecast
of weather conditions for the next 12 to 24 hours by collecting data from
the sensor in your backyard. It generates a forecast with pinpoint accuracy -
personalized for your exact location.
STORM
DEVELOPING
(Flashing)
SNOW
LIKELY LIGHT RAIN LIKELY PARTLY CLOUDY SUNNYCLOUDY
Weather Trend
Subtle variations in barometric pressure greatly impact the weather. This
weather forecaster displays an arrow icon under the forecast to indicate the
direction the pressure is trending (FALLING, STEADY, or RISING).

10
Humidity Level Icon
The Humidity Level Icon easily conveys a low, high or ideal indoor humidity
level for your home and health:
Learn more at http://www.acurite.com/humidity-health
LOW Humidity Level
Humidity is
low relative to
temperature.
Makes for a
DRY environment.
OK Humidity Level
Humidity is
OK relative to
temperature.
Makes for an
IDEAL environment.
HIGH Humidity Level
Humidity is
high relative to
temperature.
Makes for a HUMID
environment.
LOW
OK
HIGH
Alarm Clock SNOOZE
The alarm clock will sound, increasing in volume over a 2 minute period. When
the alarm is sounding, press the "SNOOZE" button to activate the SNOOZE
function for 10 minutes. The SNOOZE function can be activated up to 10 times.
Backlight Settings
This alarm clock's color display features 6 different lighting settings: 100%
(High), 70%, 50% (Medium), 30%, 10% and 5% (Low) brightness.
When the display is powered with the power adapter, the backlight remains
on at 100% brightness by default. Press the "SNOOZE" button at any time to
momentarily light the display at 100% brightness. After 5 seconds, the display
will return to the user-selected brightness setting.
Manually adjust the backlight brightness by pressing and releasing the " "
or " " buttons when not in SET MODE or ALARM SET MODE. Press the
" " button a sixth time to enter "AUTO DIM" mode. " " will appear to the
left of the clock.
AUTO DIM MODE: Automatically adjusts display brightness based on time of day.
7:00 a.m. - 9:00 p.m. = 100% brightness
9:01 p.m. - 6:59 a.m.= 5% brightness
