A B C
A-B-C Switch
Set to match
display
Install Batteries
4 AA Batteries
Rain Gauge Stabilizer
Remove and discard
Connect to My AcuRite with Wi-Fi
SETUP REQUIRES:
• 2.4 GHz Wireless Network
• Phone, Tablet, or Computer with Wi-Fi
• Display set up with 5-in-1 Sensor
Set up your Weather Station 06100M
www.acurite.com
You can congure these settings at any time by pressing
the Gear button.
INSTALL SENSOR BATTERIES
In the 5-in-1 outdoor sensor battery compartment, install four AA alkaline or lithium
batteries. The Display should automatically sync with the sensor and start showing
readings within a minute.
NOTE: In the battery compartment of the sensor, there is a small switch A/B/C switch
that should match the selection on the Display. By default this is “A” and doesn’t need
adjustment.
SETUP REQUIRES:
• Display
• Power Adapter (3 AAA backup batteries recommended)
• 5-in-1 Sensor (may be sold separately)
PLUG IN DISPLAY AND CONFIGURE SETTINGS
Plug in the power adapter. Once the display is powered on, conguration will begin
automatically. Use the Up and Down arrows to select between options, and press the
Gear button to conrm your selections.
1
2
3
• RF Channel (A, B, C;
A recommended)
• Auto DST (ON / OFF)
• 12 or 24 Hour Clock Display
• Clock Hour
• Clock Minute
• Calendar Month
• Calendar Date
• Calendar Year
• Temperature Units (°F / °C)
• Wind Speed Units
(mph, km/h, knots)
• Rainfall Units
(inches / mm)
• Pressure Units
(inHg / hPa)
ADDITIONAL NOTES
The Wi-Fi set up page is available for 30 minutes after the display is powered on. Press the
gear button to re-activate the setup page at any time.
To retain Wi-Fi conguration details, backup batteries are strongly recommended in the
display. The display can be power cycled at any time to clear Wi-Fi credentials.
2
3
4
CONNECT TO DISPLAY WI-FI
Connect to the Wi-Fi signal coming from
your Display using your phone or Wi-Fi com-
patible device.
ACCESS WI-FI SETUP PAGE
Open a web browser on your device. Type
“192.168.4.1” in the address bar and hit
enter to access the AcuRite Wi-Fi display
settings website.
ADD YOUR WI-FI CREDENTIALS
Select your Wi-Fi network name and enter
your network password. Press “Save”. Once
your credentials are successfully entered,
reconnect to your normal Wi-Fi.
SET UP YOUR MY ACURITE ACCOUNT
Download the My AcuRite mobile app or visit
www.myacurite.com to complete setup.
1
MOUNT SENSOR
Find a suitable place to mount
the outdoor sensor:
• At least 5 feet (1.5 meters)
off the ground
• Front solar cell facing south
• Away from heat and humidity
sources
• Level for accurate rain
reporting using bubble level
on top of sensor
Once the sensor is mounted,
remove the rain gauge stabilizer
from sensor.
