Acuity LITHONIA LIGHTING Aeris Suspend Series User manual

Aeris Suspend
Installation Instructions
Lithonia Lighting Outdoor
OneLithoniaWay, Conyers,GA30012
Phone: [phone] Fax: [phone]
www.lithonia.com
Part Number: RJ5210199 Rev A
Revision Date: 3/4/08
SAVETHESEINSTRUCTIONS
WARNING
To reduce the risk of death, injury or property damage from fire, electric shock, cuts,
abrasions, falling parts, and other hazards:
•Serviceoftheequipmentmustbeperformedbyqualifiedservicepersonnel.
•Installationandmaintenance must be performed bya person familiarwith the construction and
operationofthis product and any hazards involved.All applicable codes and ordinancesmust
befollowed.
•Readthisdocument before installing, servicing, ormaintaining this equipmentor installing a
lamp.These instructions do not coverall installation, service,and maintenance situations.If
your situation is not covered, or if you do not understand these instructions or additional
informationisrequired, contactLithonia Lighting oryourlocalLithonia LIghting Distributor.
•Readandfollowallwarningsandinstructionsprovidedbythe lamp manufacturer.
WARNING
Before installing, servicing, or maintaining this equipment, follow these general precautions.
To reduce the risk of electrocution:
•Makesuretheequipment is properly grounded.
•Alwaysde-energizethe circuit and/or equipment before connecting to,disconnecting
from,orservicingtheequipment.
To reduce the risk of fire:
•Keep material away that can burn from hot lamp.
•Make sure lamps are correctly installed.
•Use supply conductors with a minimum installation temperature rating as specified on
equipment.
To reduce the risk of personal injury from cuts, abrasions, or falling parts:
•Wearglovestopreventcutsorabrasionsfromsharpedgeswhenremoving from carton,
handlingandmaintainingthisequipment.
•Donot use abrasive materials, glasscleaners orother solvents onreflector or lens.
Thesesubstancesmay damage equipment and cause partsto eventually break and
fall.
•Do not install a damaged fixture.
CAUTION: Observelampmanufacturer’srecommendations and restrictions on lamp operation,
including but not limited to ballast type, burning position, replacement and cycling. Use only lamps that
complywithapplicableANSIstandards.
NOTICE: If lamp is marked it contains mercury. Follow disposal laws. See www.lamprecycle.org
Lithonia Lighting, a division of Acuity Brands Lighting, Inc., assumes no responsibility for claims arising out of
improper or careless installation or handling of this product.
IMPORTANTSAFETYINSTRUCTIONS
READ AND FOLLOW ALL SAFETY INSTRUCTIONS!
SAVE THESE INSTRUCTIONS AND DELIVER TO OWNER AFTER INSTALLATION

Aeris Suspend
Installation Instructions
Lithonia Lighting Outdoor
OneLithoniaWay, Conyers,GA30012
Phone: [phone] Fax: [phone]
www.lithonia.com
Part Number: RJ5210199 Rev A
Revision Date: 3/4/08
Tools Required: 9/16" socket wrench with extension. 3/16" and 5/32" allen wrench.
Delivery: Upon receipt of fixture and accessories (packed separately), throughly inspect for any freight damage. All damage should be reported to the delivery carrier.
Compare the catalog description listed on the packing slip with the fixture label on the inside of the housing to be sure you have received the correct merchandise.
1. a) Attach mounting block to the pole by placing the backing plate (#4) inside the pole with
the 3 holed bar stock piece facing out, aligning with the Aeris drill pattern. Place the mounting
block (#3) on the outside of the pole, with the word “Up” towards the top of the pole and facing
outward or away from the pole. Thread the (2) 3/8" diameter hex head bolts (#9) through the
block and pole into the threaded bar stock. (There is no gasket needed) Check plumb and
level of the block and secure bolts tightly with 9/16" wrench or socket.
1. b) Attach pole gasket (#11) to the strut receiver block (#1) and then attach both to the
pole using one 10-24 x 3/4" screw (#12) from the inside of the pole through the top through
the top hole of the bar and pole. The locating pin on the receiver block fits into the second
hole at the top of the pole.
2. Open doorframe by loosening the (2) captive doorframe screws using 3/16" allen wrench.
3. Unhook safety-restraining cable. Loosen the 10-24 screw at the neck end of the doorframe
1/2 turn.
4. Remove door by sliding the hinge latch up and away from hinge, close door slightly and
lift door assembly off. Set aside for reinstallation.
5. Place the three wires from the fixture through the center hole of the mounting block
assembly, pulling them into the pole. Place the fixture onto the mounting block, being sure
the wires are not pinched.
6. Tighten the locking hex head bolt inside the arm with a 9/16" socket to 20-30 ft. lbs. torque.
Check the mounted assembly to assure proper placement and secured mounting has been
achieved. Install the lamp, being sure it is of the same wattage, source and ANSI code as
indicated on the ballast and fixture label. Screw the lamp into the socket, back it out one
or two turns, and tighten it securely again. This procedure properly seats the lamp in the
socket.
7. Re-install the door asembly by placing hinge of doorframe on fixed hinge rod of fixture.
Slide hinge latch on the doorframe over hinge rod. Tighten 10-24 hinge latch screw. Hook
the safety cable to its proper location. Close the door assembly, and tighten the (2) captive
doorframe screws.
8. Make wire connections, observice proper voltage and polarity. Connect green ground
wire from the fixture to the field ground wire.
9. Attach aluminum rod (#6) using the two 1/4" x 1-1/4" black oxide screws (*8) to the receiver
(#1) on the top of the fixture and to the receiver on the pole using 5/32" allen wrench. Tighten
until head of screw is flush with the receiver block (see diagram for step 1).
OPTICAL ROTATION - WARNING: Burn Risk - Ensure lamp cools before performing maintenance. Assure that the unit is NOT engerized during this procedure.
To rotate: Open door (refer to step 2 per the pole mounted instructions above). Gently lift the optical assembly away from the fixture. Once optical assembly is free from it's
position, rotate to desired direction. Gently place assembly back into the housing, being sure that the holding devices are aligned with the spring clips. Make sure no wires
interfere with this process. Snap reflector into place. Be sure that the optical assembly has not been positioned past the seating position on the spring clips. Re-check seating
position for secured application. Reinstall lamp-- refer to step 6 per the pole mounted instructions above. Close door -- refer to step 7 per the pole mounted instructions above.
To change optical assemblies, follow optical rotation instructions above, except, once the optical asssembly is free from the seating and spring clips, disconnect socket
leads via quick disconnect. Connect the quick disconnect of the new optical assembly with the connector in the unit. Continue optical rotation instructions above.
TB - Tapped Ballast - The tapped ballast will be wired for 277 volt at the factory. To wire a fixture that contains a tapped ballast, first determine correct line voltage. Then
select the proper fixture ballast voltage lead, remove crimped cap and connect to supply voltage lead. The fixture lead marked COM should then be connected to the neutral
supply lead on all multi-voltage fixtures; be sure to cap off all unused fixture leads individually.
TROUBLESHOOTING - If this fixture fails to operate properly, check to make sure: •The correct lamp is properly installed. •The fixture is wired correctly. •The lamp is
not faulty. • The fixture is grounded correctly. •The line voltage at the fixture is correct.
Step 1
Step 2 Step 4 Step 6Step 5
Step 3 Step 7
US. Patent No. D447,590. Canada Patent No. 94324.
Step 1 (see
diagram
below/right)
# DESCRIPTION QTY
1 RECEIVER 2
2 ASTHSG 1
3 ARM MTG ASM 1
4 AST BACKING PLATE ASM 1
5 LOCKWASHER 2
6 ALROD 1
7 SCREW10-24X1/2 1
8 SCREW1/4-20 X 11/4 2
9 BOLT3/8-16X2 2
10 HSGGASKET 1
11 POLEGASKET 1
12 SCREW10-24X3/4 1
Page 1

Aeris Suspend
Installation Instructions
Lithonia Lighting Outdoor
OneLithoniaWay, Conyers,GA30012
Phone: [phone] Fax: [phone]
www.lithonia.com
Part Number: RJ5210199 Rev A
Revision Date: 3/4/08
WBA (Wall Bracket) INSTALLATION CAUTION: APPLY A CONTINUOUS BEAD
OF WEATHER - PROOF CAULKING BETWEEN MOUNTING PLATE AND WALL TO
ENSURE WEATHER - TIGHT INTEGRITY OF ELECTRICAL COMPONENTS.
Tools Required: 3/16" allen wrench, 9/16" socket or wrench.
1. Secure base plate to wall with (4) 1/4" fastener (supplied by others) using the (4) holes
located on the outer corners of the base plate. Check the base plate to confirm that
it is level and plumb in all directions. (See figure 1).
2. Prepare the cover plate by attaching the Aeris mounting block to the cover plate using
(2) 3/8" diameter by 1-1/4" bolts with (2) 3/8" diameter lockwashers by inserting the bolts
and washers into the mounting block through the cover plate and thread into the
threaded steel bar stock. Use a 9/16" socket or wrench and tighten securely (See figure
2). When installing the fixture in the lens down position, place the curved portion of the
cover plate upwards . When installing the fixture in the lens up position (damp location
only), place the straight portion of the cover plate upwards.
3. Check the gasketing(factory installed) on the backside of the cover plate to ensure
that it is in place.
4. Place and tighten (4) 3/8" diameter by 1-1/4" stainless steel hex socket head screws
(requires 3/16" allen wrench) into the threaded opening of the cover plate by turning
approximately 6-7 full turns.
5. To prepare fixture for installation, refer to steps 2 and 3 per pole mounted instructions
on page 1.
6. Pull the wires from the fixture through the mounting block on the cover plate. Place
fixture onto the mounting block, being sure the wires are not being pinched.
7. Tighten the locking hex head bolt inside the arm with a 9/16" socket to 20-30 ft. lbs.
torque.
8. Make wiring connections, being careful to observe proper polarity and grounding.
9. Slide the assembly over the base plate, tighten the top (2) 3/8" x 1-1/4" stainless steel
hex socket head screws until 3/8" to 1/4" of the screw is still visible.
10. Tighten the bottom (2) 3/8" x 1-1/4" stainless steel hex socket head screws until 3/8"
to 1/4" of the screw is still visible.
11. Alternating between the top two and bottom two sets of screws, gently tighten until
snug, (approximately one thread showing on each screw).
12. Continue fixture installation and lamp installation (refer to step 6 per the pole mounted
instructions above).
13. Secure strut receiver to small strut wall mount plate using the 10-24 x 3/4" thread rolling
screw in the top hole on the center of the plate. The locating pin on the receiver should
sit in the second hole on the center of the plate (See Figure 3).
14. Attach aluminum rod using the two 1/4" x 1-1/4" black oxide screws to the receiver
on the top of the fixture and to the receiver on the wall mount plate using 5/32" allen
wrench. Tighten until head of screw is flush with the receiver block.
15. Secure the small strut wall mount plate to wall with two 1/4" fasteners (supplied by
others). Check the plate to confirm that it is level and plumb in all directions (See Figure
4).
Page 2
1/4" black
oxidescrews
Strut
Receiver
3/4" thread
rollingscrew
Figure 3
Figure 4
Figure 2
Aeris Mounting Block
(4) Socket Held Screws
Figure 2
Aeris Mounting Block
(4) Socket Held Screws
Figure 2
Aeris Mounting Block
(4) Socket Held Screws
Figure 1
Seal
By others
To wall
Gasket
(factory installed)
Base Plate
Cover Plate
(4) 1/4” fasteners
(by others)
Silicone
Sealant by
Others
Figure 1
Seal
By others
To wall
Gasket
(factory installed)
Base Plate
Cover Plate
(4) 1/4” fasteners
(by others)
Silicone
Sealant by
Others
Seal
By others
To wall
Gasket
(factory installed)
Base Plate
Cover Plate
(4) 1/4” fasteners
(by others)
Seal
By others
To wall
Gasket
(factory installed)
Base Plate
Cover Plate
(4) 1/4” fasteners
(by others)
Silicone
Sealant by
Others
(4) Socket
Head Screws
Threaded
Steel Bar
Stock
Figure 2
