ACV E-Tech W 09 Instruction manual

E-Tech W
Wall mounted electric sealed
system boiler. An economical
alternative to LPG and Oil.
High efficiency electric boilers
36
Available up to 15 kW for single phase supply and,
where available, three phase options up to 36 kW.
The E-Tech W is user and installer-friendly with
simplified maintenance. The control panel can be
rotated to facilitate access to the water connections.
The unit is of a steel body with removable stainless
steel incoloy elements to increase the reliability and the
service life of your installation.
Benefits and Features
• No flue
• Reduced maintenance (no landlord certification)
• Modulating element input
• Can be used in modular formation
• Compatible with Honeywell S-plan and Y-plan wiring
systems
• Built-in control circuit protected by internal 3 amp
MCB
• Removable stainless steel incoloy immersion
elements
• Stove enamelled casing
• Control panel including thermostats, combined
temperature and pressure gauge and on/off switch
• Wall mounting bracket included
• Simple connection to heating systems
• Compatible with wet radiator or underfloor heating
installations
• Ease of installation - the boiler allows direct
connection to a heating system without the need
for a feed and expansion tank
Easy connection to underfloor heating
In contrast with electric underfloor heating, hydraulic
circuits are compatible with multiple-energy systems
(electricity, gas, fuel-oil, heat pump, solar, etc).
This allows the user to adapt to changes in the
market and to opt for alternative sources of energy
as the need arises.
See the ACV multi-energy tanks on page 8.

High efficiency electric boilers 37
Technical Data
E-Tech W 09 E-Tech W 15 E-Tech W 22 E-Tech W 28 28 E-Tech W 36
Single Phase Single Phase Tri-Phase Tri-Phase Tri-Phase
Output kW 4.2 to 8.4 7.2 to 14.4 14.4 to 21.6 21.6 to 28.8 30 to 36
Supply V 230 230 3 x 400 + N 3 x 400 + N 3 x 400 + N
Total capacity Ltrs 13 13 13 13 13
Expansion volume Ltrs 10 10 10 10 10
Heating connections Ø 3/4"3/4"3/4"3/4"3/4"
Weight empty kg 45 45 45 45 45
Primary pressure drop mbar 10 20 45 85 125
Max. operating temp. °C 85 85 85 85 85
Heating element type 2 x 1.4kW 2 x 2.4kW 2 x 2.4kW 2 x 2.4kW 2 x 3kW
Number of elements 33566
Maximum operating pressure Primary: 3 bar
Characteristics
Dimensions
Output
modulation
(example):
E-Tech W 15
7.2 or 14.4 kW
E-Tech W 22
14.4 or 21.6 kW
Temperature (°C)
Output (kW)
Output modulation
The output of the E-Tech W automatically adjusts
to heating demand thanks to the use of a two-
stage thermostat:
• The upper thermostat can be adjusted and
controls the first stage of output.
• The lower thermostat is automatically
regulated 7°C below the setpoint of the upper
thermostat. It controls the second stage of
output.
Characteristics
1. Expansion vessel
2. Casing
3. Primary flow
4. Expansion tank connection
5. Manual reset limit thermostat
6. Pressure switch (low water level)
7. DHW kit connection (optional)
8. Safety valve
9. Primary return
1
2
34
5
6
7
8
9
