ACV BNE Series Assembly instructions

EN • 1
664Y1200.B
ENGLISHFRANCAISNEDERLANDSESPAÑOL
Installation, operating and
maintenance Instructions
BNE 1 - BNE 2 - BNE 3

EN • 2
664Y1200.B
ENGLISHFRANCAISNEDERLANDSESPAÑOL
INDEX
INTRODUCTION
Who should read these instructions 3
Symbols 3
Applicable standards 3
Important notes 3
USER GUIDE
Use of the boiler 4
Burner shutdown 5
DESCRIPTION
General description 5
Operating principle 5
Design characteristics 5
Boiler views and key to parts 6
TECHNICAL CHARACTERISTICS
General 7
Operating condition limits 7
Dimensions 7
Domestic hot water performance 7
General characteristics 7
INSTALLATION
Boiler room 8
Chimney connections 8
Fuel oil supply 8
Heating connection 9
Domestic hot water connection 9
Electrical connections 10
BURNER CHARACTERISTICS
Description of the burner 11
Regulation parameter 12
Burner dimension 12
COMMISSIONING AND MAINTENANCE
Filling domestic hot water and heating circuits 13
Using the boiler for the first time 13
Recommendation 13
Maintaining the boiler 13
Maintenance of safety equipment 14
Draining the boiler 14
SPARE PARTS See at the end of this manual

EN • 3
664Y1200.B
ENGLISHFRANCAISNEDERLANDSESPAÑOL
INTRODUCTION
WHO SHOULD READ THESE INSTRUCTIONS
These instructions should be read by:
- the specifying engineer
- the installer
- the user
- the service engineer
SYMBOLS
The following symbols are used in these instructions:
APPLICABLE STANDARDS
The products described in this document have been certified at
European level (European Directive 92/42/EEC “Efficiency”). They
have also been awarded the Belgian “OPTIMAZ” label (for oil-fired
boilers).
IMPORTANT NOTES
These instructions are an integral part of the equipment to which
they relate and must be handed to the user.
The product must be installed and serviced by qualified engineers in
accordance with the regulations in force.
ACV declines all liability for any damage caused as a result of
installation or in the event of the use of appliances or accessories
that are not specified by ACV.
Failure to follow the instructions describing test
operations and procedures may cause injury to
persons or a risk of environmental pollution.
N.B. :
ACV reserves the right to change the technical characteristics and
specification of its products without notice.
Essential instruction for correct
operation of the installation.
Danger of burning.
Danger of electrocution.
Essential instruction for the safety
of persons and the environment.

EN • 4
664Y1200.B
ENGLISHFRANCAISNEDERLANDSESPAÑOL
USER GUIDE
fig. 1 : Control panel
Max
Min
Max
Min
1
8
1
7
1
6
1
5
1
4
1
3
1
2
1
1
1
0
9
8
7
6
5
4
3
2
1
2
4
2
3
2
2
2
1
2
0
1
9
GRASSLIN
GRASSLIN
I
O
1345 8762
USE OF THE BOILER
To ensure that your system operates correctly, please
have it serviced annually by a qualified engineer;
servicing should be completed before the start of the
heating season.
Starting the burner:
in normal operation the burner starts automatically if
the temperature of the boiler is below the set point.
Before carrying out any work on the boiler, isolate it
from the electrical supply at the switch on the external
control box.
Also move the main switch on the control panel to
“OFF”.
• You should familiarise yourself with the control panel
(fig. 1)
The user must not attempt to gain access to the
components inside the control panel.
1. Main switch
Use this switch to turn the boiler on and off.
2. Summer/Winter switch
Use this switch to start and stop the heating pump.
3. Energy selection switch
This is used to switch the heating pump and the burner off (or on).
It is used to switch a 2.4 kW resistor on (or off) for the provision of
hot water.
4. Indicator lamp of the heating element
This lamp indicates that the heating element is energised.
5. Time clock
This allows the boiler to be limited ON and OFF operates on a 24
hour sequence. Around the outside of the clock there are a number
of white tabs, these allow 15 minute switching periods. To set the
time clock simply push outwards the number of tabs required for
ON period.
Remember : TAB IN = BNE OFF
TAB OUT = BNE ON
6. Hot water temperature control thermostat
In hot water mode, the temperature of the hot water can be adjusted
from 60 to 80°C.
7. Thermostat-pressure gauge
This gauge shows the temperature of the boiler and the pressure in
the primary heating circuit. The temperature must not exceed 90°C.
If it rises above this point, turn off the boiler and check the settings
on the thermostat. If the problem persists, call a technician.
The pressure must not fall below 1 bar. If it does fall below this point,
look up the section entitled “Gauge pressure of the heating installation”
in this section below.
8. Heating temperature control thermostat
n “Winter” position the boiler temperature can be set to between 60
and 90°C.
It is advisable to set this thermostat 10°C above the hot water
thermostat setting.
Pump operation:
The pump is controlled by a reset high limit thermostat, which is
located at the rear of the boiler. This is pre-set at 45°C. When the
boiler starts up, it delays the activation of the boiler pump, there by
preventing any risk of corrosion in the combustion chamber.
Gauge pressure of the heating system
Your system must be fitted with a heating safety valve calibrated to
3 bars.
Ensure that the system is always under water pressure. When the
system is cold and the air inside it has been vented, the gauge
must indicate a pressure between 0.5 and 1.5 bar depending on the
height of the building.
To add water: (fig. 9 page 9)
• Open the filling valve (5).
• Close the valve properly after filling.
• Vent the system in order to obtain an accurate reading of the
pressure inside the heating circuit.
Safety valves (heating circuit) (fig. 9 page 9 - item 2)
If water is found to be escaping from one of the safety valves, stop
the boiler and contact your installer for advice.
A monthly test is recommended:
Lift the lever on the drain cock for a few seconds to ensure that the
safety valve is working correctly.
If there is a problem after this short test, please
contact your installer for advice.

EN • 5
664Y1200.B
ENGLISHFRANCAISNEDERLANDSESPAÑOL
The water escaping from the safety valve can
be extremely hot and cause serious burns.
Safety group (hot water circuit)
It is normal for water to escape from the safety group each time the
hot water tank is heated. A hot water expansion vessel may reduce
or even prevent this escape. (fig. 10 page 9 - item. 6)
A monthly test is recommended:
Lift the lever on the drain cock for a few seconds to ensure that the
safety valve is working correctly.
If there is a problem after this short test, please
contact your installer for advice.
The water escaping from the safety group can
be extremely hot and cause serious burns.
BURNER SHUTDOWN
If the burner is not working:
1. The burner indicator lamp lights up.
2. Press the burner reset button (fig. 2) on the burner. Turn the boiler
off for several seconds at the main switch, then restart the boiler.
fig. 2
3. If the burner still does not work, remove the boiler front panel
and reset the high limit thermostat on the top of the boiler body
(fig. 3).
fig. 3
4. If the anomaly persists, please contact your installer.
USER GUIDE DESCRIPTION
GENERAL DESCRIPTION
• Combined boiler and water heater (heating and domestic hot water).
• Hot water generated by an indirect storage system.
• Equipment required: a water connection kit for the heating circuit
supply (optional).
• The control panel contains a main switch, a Summer/Winter
switch, an energy selection switch, an indicator lamp, an
optimiser, a hot water control thermostat, a thermostat-pressure
gauge and a heating control thermostat.
• The boiler may be connected directly to the chimney using a B23
chimney connection.
• BNE 1 Model : Outputs in the range 20 to 25 kW.
• BNE 2 Model : Outputs in the range 28 to 36 kW.
• BNE 3 Model : Outputs in the range 36,5 to 51 kW .
OPERATING PRINCIPLE
Two thermostats are used to adjust the temperature settings for the
heating and hot water. The addition of the hot water priority device
incorporated in the wiring ensures an ample supply of hot water.
A manual reset high limit thermostat locks the burner if the boiler
temperature exceeds 103°C.
In summer, when heating is not required, the heating pump and
burner can be switched off and a 2.4 kW resistor used for the hot
water requirements. (BEWARE : The water heating efficiency will be
lower than that with the oil burner).
DESIGN CHARACTERISTICS
Outer body
The outer body which holds the primary water is made from STW 22
heavy gauge steel.
Flue ways
The boiler’s flue ways can be accessed from the front and include
a set of removable turbulators, in either stainless steel or chrome,
which have been specially designed to provide the optimum
combustion efficiency.
Combustion chamber
The boiler features a large, water-cooled combustion chamber to
guarantee a good flame.
Removable burner chamber plate
The chamber plate is fitted on a hinge (left or right) and made from
STW 22 steel. It is protected from the flame by a ceramic fibre padding
and a vermiculite brick.
Insulation
The boiler body is fully insulated by rigid polyurethane foam with
a high thermal insulation coefficient, sprayed on without the use
of CFCs.

EN • 6
664Y1200.B
ENGLISHFRANCAISNEDERLANDSESPAÑOL
DESCRIPTION
BOILER VIEWS AND KEY TO PARTS
1. Cold water inlet
2. Hot water thermostat pocket
3. Hot water outlet
4. Steel outer tank
5. Stainless steel inner tank
6. Heating return
7. Chimney connection
8. Heating outlet
9. Heating circuit drain cock
10. Combustion chamber
11. Steel base
12. Exchanger (flue ways)
13. Burner
14. Flame inspection window
15. Left-right removable burner chamber plate
16. Heating element
17. Polyurethane foam insulation
18. Front panel
19. Control panel
20. Heating circuit aire vent
fig. 4
1
11
19
16
13
20 2 3
6
7
8
8
4
10
9
17
15
14
18
5
12
Casing
The boiler is covered with a steel casing that has been stove
enamelled at 220°C after scouring and phosphating.
Storage exchanger
The inner hot water tank with integrated heating surface is made
of stainless steel that has been fully argon welded using the TIG
(Tungsten Insert Gas) method.
Heating element
The heating element, made entirely of stainless steel, is mounted
on a flange.

EN • 7
664Y1200.B
ENGLISHFRANCAISNEDERLANDSESPAÑOL
TECHNICAL CHARACTERISTICS
GENERAL
The appliances are supplied fully assembled, tested and packed
standing on a timber transport base with impact protection strips
and wrapped in heat-shrunk plastic film. When the appliance arrives,
remove the packaging and check that no parts have been damaged
in transit.
Refer to the dimensions and weights listed below for handling
purposes:
DIMENSIONS
OPERATING CONDITION LIMITS
Maximum service pressure (tank filled with water)
- Heating circuit: 3 bar
- Hot water circuit: 10 bar
Test pressure (tank filled with water)
- Heating circuit: 4.5 bar
- Hot water circuit: 13 bar
Operating temperature
- Maximum temperature: 90°C
A
J
Ø D
G
B
L
C
K
F
H
I
DOMESTIC HOT WATER PERFORMANCE BNE 1 BNE 2 BNE 3
Operating conditions at 80 °C
Peak flow at 40°C (ΔT = 30 °C) L/10’ 311 311 311
Continuous delivery at 40°C (ΔT = 30 °C) L/h 716.4 898.8 898.8
GENERAL CHARACTERISTICS BNE 1 BNE 2 BNE 3
Input kW 22/28 30/41 40/57
Output kW 20/25 28/36 36.5/51
Hydraulic pressure loss mbar 20.0 25.5 30.0
Pressure loss of the flue gas circuit mbar 0.15 0.17 0.15
Total capacity L184 186 248
Heating circuit capacity L64 66 128
Hot water connection (male) Ø3/4” 3/4” 3/4”
Heating connection (female) Ø1” 1” 1” 1/4
Hot water tank heat exchange surface m21.1 1.1 1.1
A mm B mm C mm D Ø mm F mm G mm H mm I mm J mm K mm L mm Kg (*)
BNE 1 590 1505 640 130 463 260 615 1390 270 300 700 204
BNE 2 590 1570 640 130 526 260 680 1450 270 300 700 222
BNE 3 690 1610 740 150 564 260 715 1475 270 350 800 283
(*) The weights shown are drained weights.

EN • 8
664Y1200.B
ENGLISHFRANCAISNEDERLANDSESPAÑOL
BOILER ROOM
Important
• Never obstruct the ventilation.
• Do not store inflammable products in the boiler room.
• Avoid storing corrosive products such as paint, solvents, chlorine,
salt, soap or other cleaning products near the boiler.
Accessibility
The boiler room should be big enough to allow easy access to the
boiler. Minimum clearances around the boiler (mm):
- at the front 500
- at the rear 150
- at the sides 100
- above 300
Ventilation
The boiler room must have both low- and high- level ventilation
(see fig. 5).
The user must ensure that the boiler room ventilation complies
with current local regulations.
By way of information, the table below gives the minimum
ventilation requirements according to Belgian regulations.
A. High-level ventilation
B. Low-level ventilation
C. Draught stabiliser
D. Flame inspection window
E. Height of lined chimney
F. Chimney diameter
A
B
D
F
E
C
BNE 1 BNE 2 BNE 3
Ventilation
Fresh air supply min. m3/h 50.0 72 102
High-level ventilation (A) dm2150 150 150
Low-level ventilation (B) dm2150 150 170
Base
The base on which the boiler will be mounted must be made from
noncombustible materials.
CHIMNEY CONNECTIONS
IMPORTANT
The boiler must be installed by a qualified engineer
in accordance with the local standards and codes of
practice.
The diameter of the chimney must not be less than the
diameter of the boiler’s chimney reducer.
Chimney connector type: B23 (fig.5)
The chimney must be connected to the boiler by means of a metal
pipe rising at an angle from the boiler to the chimney.
A chimney connector is required.
fig. 5 : Boiler ventilation and B23 chimney connector
Important note:
The above table is shown by way of indication only as
regulations vary from country to country.
The high output of our boilers means that the flue
gases are at a low temperature.
The attendant risk of condensation may cause damage
to some chimneys.To avoid this risk we strongly advise
that you line the chimney.
Please contact your installer for any further informa-
tion.
BNE 1 BNE 2 BNE 3
Chimney
E = 5 m Ø min. F mm 130 143 170
E = 10 m Ø min. F mm 130 130 143
E = 15 m Ø min. F mm 130 130 130
INSTALLATION
Height H Ø 8 mm Ø 10 mm
0 m L = 35 m L = 100 m
0.5 m L = 30 m L = 100 m
1.0 m L = 25 m L = 100 m
1.5 m L = 20 m L = 90 m
2.0 m L = 15 m L = 70 m
3.0 m L = 8 m L = 30 m
3.5 m L = 6 m L = 20 m
Two-pipe installation (fig. 7)
Height H Ø 8 mm Ø 10 mm
0,5 m L = 10 m L = 20 m
1.0 m L = 20 m L = 40 m
1.5 m L = 40 m L = 80 m
2.0 m L = 60 m L = 100 m
FUEL OIL SUPPLY
Single-pipe installation (fig. 6)
H
max 4m
L1
L1
L1
H
H
max 4m
fig. 6 fig. 7

EN • 9
664Y1200.B
ENGLISHFRANCAISNEDERLANDSESPAÑOL
INSTALLATION
ACV water kit
ACV can supply an optional
pre-assembled water kit.
This kit comprises:
• A pump;
• A 3-way manual valve. This
valve can be power-operated
if required;
• Connection pipes that can be
used to connect a second
heating circuit;
• Two isolating valves;
• Connectors for the right- or
efthand mounting of the
expansion vessel, the safety
valve with pressure gauge and
the fill valve.
The expansion vessel is not
included.
Drain
The drain cock and safety valve must be connected to the building
drain.
HEATING CONNECTION
Typical single-circuit connection
1. 3-way power-operated mixer valve
2. Safety valve calibrated to 3 bar, with pressure gauge
3. Pump
4. Non-return valve
5. System filling valve
6. Expansion vessel
7. Room thermostat
8. Heating circuit isolating valve
9. Drain cock
fig. 8 : Kit hydraulique ACV
DOMESTIC HOT WATER CONNECTION
Pressure reducing valve
If the mains water pressure exceeds 6 bar, a pressure reducing valve
calibrated to 4.5 bar must be installed.
Safety group
The safety group of the water tank must be approved by ACV and
calibrated to 7 bar; the group’s valve discharge must be connected
to the drain.
Domestic hot water expansion vessel
Installing a hot water expansion vessel will prevent any risk of excess
pressure due to water hammer or pressure fluctuations.
Domestic hot water circulation
If the water tank is a long way from the point of use, installing a
closed recirculation circuit can ensure a faster hot water drawoff at
any time.
Typical domestic hot water connection
fig. 10 : Domestic hot water circuit connection
7
3
10
11
8
45
6
9
5
2
1
IMPORTANT
As a safety measure, we strongly advise the
installation of a thermostatic mixer to prevent
any risk of burning to persons.
Optional accessories
Safety group Ø 3/4”
Pressure reducing valve Ø 3/4“
Thermostatic mixer Ø 3/4”
Expansion vessel 5 litres
1. Safety group
2. Pressure reducing valve
3. Thermostatic mixer
4. Hot water pump
5. Non-return valve
6. Hot water expansion vessel
7. Cold water supply tap
8. Drawoff tap
9. Drain cock
10. Air vent
11. Isolating valve
fig. 9 : Heating circuit connection
1
4
8
3
2
5
6
7
9

EN • 10
664Y1200.B
ENGLISHFRANCAISNEDERLANDSESPAÑOL
INSTALLATION
ELECTRICAL CONNECTIONS
Power supply principle
The boiler operates on a single-phase supply of 230 V/50 Hz.
You should install a control box with main switch and 6A fuses
externally to the boiler to allow the boiler to be isolated from the
supply for servicing and repairs.
Statutory compliance
The installation must comply with your local standards and codes
of practice.
Safety
The stainless steel if present water tank must be provided with a
separate earth.
The boiler must be isolated from the electrical supply
before any work is carried out on it.
The heating element consists of two 2.4 kW electrical
resistors.
One of these two resistors is wired and used as the main
resistor. The other resistor is not used, and serves only
as a back-up if the first resistor becomes faulty.
The two resistors must never be connected to operate
together, as this will damage the internal wiring of the
boiler.
Wiring diagram key
1. Main switch
2. Hot water control thermostat
3. Time clock
4. Heating control thermostat (60/90°C)
5. Manual reset high-limit thermostat (103°C max.)
6. Heating element indicator lamp
7. Energy selection switch
8. Burner
9. Pump
10. Room thermostat
(optional)
11. Summer/Winter switch
B. Blue
Bk. Black
Br. Brown
G. Grey
Or. Orange
Pk. Pink
R. Red
V. Violet
W. White
Wiring diagram of the boiler
t
L1
NBBB
RRRR
RPk V V
Gr
T1 T2
t
t
S3 B4
M
C
1
2C
1
2
C
1
2
Gr
WBkBkW
GrGr
Or Or
Or
Or
Br
Or Or
Br
B
Or
B
B
B
B
B
Gr
R
127
3 4 5
6
9
8
11 10
L1 T1NT2S3B4
230 V ~ 50Hz
M
10
9

EN • 11
664Y1200.B
ENGLISHFRANCAISNEDERLANDSESPAÑOL
BURNER CHARACTERISTICS
DESCRIPTION OF THE BURNER
This new generation of fuel oil burners comply with current
requirements in terms of performance and the cleanliness of
combustion gases.
The burner is fitted with the finest quality components reflecting the
latest developments in technology and the fuel-oil is pre-heated.
Components :
• “Landis & Gyr” relay
• “A.E.G.” motor
• “Suntec” pump
• “May & Christe” transformer
• “Danfoss” fuel-oil preheater
Advantages
• Simple to install, it is fitted with a safety switch and a new burner
suspension system.
• A special key is provided with the burner for any maintenance
work needed.
• The burner air pressure adapts to the pressure in the combustion
chamber.
• An automatic stop check valve stops the airflow when the boiler is
turned off, preventing it from cooling.
• Silent and very reliable operation.
• Adapts to the depth of the boiler with the adjustable nozzle
clamp.
• Three air-regulation points to ensure the optimum air/fuel oil
mixture.
- The air is pre-regulated upstream;
- primary regulation;
- combustion head regulation.
Pump - nozzle connection pipe
Throat
Nozzle line adjuster screw
Louver
High voltage transformer
Electrical valve
Motor
Fuel oil pump
Burner reset
Control relay
Capacitor motor
Burner socket

EN • 12
664Y1200.B
ENGLISHFRANCAISNEDERLANDSESPAÑOL
REGULATION PARAMENTER BNE 1 BNE 2 BNE 3
Type of burner BM R 31 BM R 31 BM R 51
Power kW 23.0 30.0 49.0
Electrical power W150 150 150
Nozzle gal/h 0.50 0.75 1.25
Nozzle angle 60° 60° 60°
Fuel oil rate of flow Kg/h 1.94 2.53 4.13
Pump pressure bar 13.5 10.5 10
Flue gas index 0.6 0.6 0.6
Louver regulation 3 4.5 4
Combustion head regulation 2 1 2
Weight Kg 12 12 12
BURNER CHARACTERISTICS
fig. 11 :
Electrode distance
fig. 12 :
Combustion head
adjuster screw
fig. 13 :
Air flow adjuster screw
(precision adjustment)
fig. 14 fig. 16fig. 15
BURNER DIMENSION A mm B mm C mm D mm E mm F mm G Ø mm L Ø mm LK Ø mm
BM R 31 240 270 215 280 60-130 M 8 80 85 140-165
BM R 51 240 270 215 280 60-130 M 8 80 85 140-165

EN • 13
664Y1200.B
ENGLISHFRANCAISNEDERLANDSESPAÑOL
COMMISSIONING AND MAINTENANCE
FILLING THE DOMESTIC HOT WATER AND
HEATING CIRCUITS
IMPORTANT
It is essential to fill the domestic hot water circuit
before the heating circuit.
1. Open valves 7 and 8 to fill the domestic hot water circuit and
pressurise it. (fig. 17 page 13)
2. Open valves 4, 5 and 8 to fill the heating circuit and make sure
the pressure does not exceed 2 bars. (fig. 18 page 13)
3. Venting the air from the installation and the boiler.
4. Once you have vented the system, return the pressure to static
pressure plus 0.5 bar.
Height of the heating system:
• 10 m Heating circuit pressure = 1,5 bar
• 15 m  Heating circuit pressure = 2 bar
USING THE BOILER FOR THE FIRST TIME
1. Check the fuel oil supply connection and ensure that it is free
from leaks.
2. Check the electrical connection of the boiler and the boiler room
ventilation, and ensure that the flue gas discharge pipes and the
burner chamber plate are properly gas tight.
3. Set the boiler thermostat to between 60 and 90°C.
4. Place the Summer/Winter switch to the required position.
5. Place the main switch to “ON”.
6. Carry out the necessary venting operations, measurements and
settings.
RECOMMENDATION
It is compulsory to have the boiler serviced once a year. Boiler
servicing and checking must be carried out by a qualified engineer.
MAINTAINING THE BOILER (fig. 19)
1. Isolate the boiler from the electrical supply at the switch on the
external control box and close the fuel oil supply valve.
2. Place the main switch on the control panel to “OFF”.
3. Remove the boiler front panel (1).
4. Loosen the two nuts to open the burner chamber plate (2).
5. Remove the stainless-steel turbulators (3).
6. Brush the flue ways, clean the chamber and vacuum up any soot
deposits.
7. Check the insulation of the burner chamber plate (4).
8. Before reassembling, clean the burner combustion head (5).
9. Check that the thermostats and safety valves are working
correctly.
1
2
35
4
fig. 19
7
3
10
11
8
45
6
9
5
2
1
fig. 17 : Domestic hot water circuit connection
1
4
8
3
2
5
6
7
9
fig. 18 : Heating circuit connection

EN • 14
664Y1200.B
ENGLISHFRANCAISNEDERLANDSESPAÑOL
COMMISSIONING AND MAINTENANCE
MAINTENANCE OF SAFETY EQUIPMENT
- Check that all thermostats and safety devicesoperate correctly:
the boiler thermostat and the manual reset high-limit thermostat
(103°C).
- Check the heating circuit safety valves.
DRAINING THE BOILER
The water draining from the drain cock is
very hot and can cause serious burns.
Keep all persons away from running
hot water.
Draining the heating circuit (fig. 20)
1. Place the main switch on the control panel to “OFF”, isolate the
boiler from the electrical power supply at the switch in the external
control box.
2. Close the isolating valves (8) in the heating circuit.
3. Connect a flexible tube to the drain cock (9).
4. Open the drain cock (9) to drain the heating circuit.
Draining the hot water circuit (fig. 21)
1. Place the main switch on the control panel to “OFF”, isolate the
boiler from the electrical power supply at the switch in the external
control box.
2. Reduce the pressure in the heating circuit until the pressure
gauge reads zero.
3. Close the valve (7et 11).
4. Open the drain cock 9 first, then 10.
5. Allow the hot water circuit to discharge to the drain.
The drain cock (9) must be at ground level for the
circuit to drain fully.
fig. 21 : Domestic hot water circuit connection
7
3
10
11
8
45
6
9
5
2
1
fig. 20 : Heating circuit connection
1
4
8
3
2
5
6
7
9

N° BNE 1 BNE 2 BNE 3
A01 21471384 21471385 21471386
A02 21472384 21472385 21472386
A03 21473384 21473385 21473386
A04 21474384 21474385 21474386
A05 21475384 21475384 21475386
A06 21477384 21477384 21477386
A07 30465156 30465157 30465158
A08 2147P380 2147P381 2147P382
A04
A01
A02
A06
A03
A05
A07
A08

BNE 1 BNE 2 BNE 3
24614110 24614110 24614111
54766014 54766014 54766014
54766013 54766013 54766013
54442045 54442045 54442045
54764021 54764021 54764021
54441008 54441008 54441008
54766001 54766001 54766001
ON / OFF

BNE 1 BNE 2 BNE 3
54764010 54764010 54764010
54428182 54428182 54428182
49410280 49410280 49410280
50423008 50423008 50423008
55426001 55426001 55426001
47405252 47405252 47405252
63438001 63438001 63438001

BNE 1 BNE 2 BNE 3
49410045 49410045 49410045
47438008 47438008 47438008
47405004 47405004 47405004
47405005 47405005 47405005
50423097 50423097 50423098
51701001 51701002 51701003
237E0009 237E0009 23860600
