ACV Smart Line SLE 130 Assembly instructions

Smart Line SLE - SLE Plus : 661Y2100 • A
EN
FR
NL
ES
IT
DE
PL
RU
INSTALLATION, OPERATING AND
MAINTENANCE INSTRUCTIONS
SLE
130 - 160 - 210 - 240 - 300
SLE Plus
210 - 240 - 300
SMART Line

EN
FR
NL
ES
IT
DE
PL
RU
en
2Smart Line SLE - SLE Plus : 661Y2100 • A
TABLE OF CONTENTS
USER'S GUIDE.............................................................................................5
Control panel ............................................................................................................................................................. 5
APPLIANCE DESCRIPTION........................................................................6
TECHNICAL CHARACTERISTICS..............................................................7
Main characteristics ............................................................................................................................................. 7
Dimensions.................................................................................................................................................................. 7
Heating connections ........................................................................................................................................... 8
Domestic hot water connections.............................................................................................................. 8
Domestic hot water performances.......................................................................................................... 9
Maximum operating conditions................................................................................................................ 9
Electrical characteristics ................................................................................................................................10
INSTALLATION ........................................................................................11
Package contents ................................................................................................................................................. 11
Tools required for the installation........................................................................................................... 11
Safety instructions...............................................................................................................................................12
Connection................................................................................................................................................................14
Connection to the DHW circuit.................................................................................................................15
Connection to the primary circuit..........................................................................................................16
Examples of possible combinations of the SLE and SLE Plus...........................................17
Tank used as electric DHW tank only...................................................................................................18

en
3
EN
FR
NL
ES
IT
DE
PL
RU
Smart Line SLE - SLE Plus : 661Y2100 • A
TABLE OF CONTENTS
STARTING UP ...........................................................................................19
Safety instructions to ll the tank...........................................................................................................19
Filling ..............................................................................................................................................................................20
Checks before starting up.............................................................................................................................22
Starting up .................................................................................................................................................................22
MAINTENANCE........................................................................................23
Periodic checks by the user .........................................................................................................................23
Annual maintenance .........................................................................................................................................23
Draining........................................................................................................................................................................24
Bringing back into service after maintenance .............................................................................25
Fault nding..............................................................................................................................................................26

NOTES
• This manual contains important information with respect to the installation, the starting up
and the maintenance of the hot water tank.
• This manual must be provided to the user, who will read it carefully and keep it in a safe
place.
• The availability of certain models as well as their accessories may vary according to the markets.
• The manufacturer reserves the right to change the technical characteristics and features of
its products without prior notice.
We accept no liability should any damage result from the failure to comply with theinstruc-
tions contained in this technical manual.
Essential instructions forthe safety of persons and the environment
• It is strictly prohibited to bring any modification to the appliance, without
themanufacturer’s prior written approval.
• The appliance must be installed by a qualified installer, in accordance with
applicable regulations.
• The installation must comply with the instructions contained in this manual and
with the regulations applicable to installations.
• Failure to follow the instructions in this manual could result in personal injury or a
risk of environmental pollution.
• The manufacturer declines all liability for any damage caused as a result of
incorrect installation or in the event of the use of appliances or accessories that are
not approved by the manufacturer.
Essential instructions forthecorrect operation oftheinstallation
• In order to ensure that the appliance operates correctly, it is essential to have it
serviced by a certified installer or maintenance contractor every year.
• In case of problem, please contact your installer for advice.
• Faulty parts must only be replaced with genuine parts.
• Our domestic hot water tanks are designed and manufactured exclusively for the
heating and storage of domestic hotwater.
• The domestic hot water heaters must only be heated using hot water in a closed
circuit.
• The part number (N° Art.) and serial number (N° Ser.) of the tank are indicated on
its rating plate and must be provided to ACV in case of warranty claim. Failure to
do so will make the claim void.
EN
FR
NL
ES
IT
DE
PL
RU
en
4Smart Line SLE - SLE Plus : 661Y2100 • A
GENERAL RECOMMENDATIONS

en
5
EN
FR
NL
ES
IT
DE
PL
RU
Smart Line SLE - SLE Plus : 661Y2100 • A
USER'S GUIDE
CONTROL PANEL
Key :
1. Control thermostat [60/90°C] - to set the domestic hot water (DHW) temperature.
2. Manual reset high limit thermostat - to restart the tank after overheating of the primary circuit.
3. Connection plug - to connect the electrical power supply.
4. Thermometer - indicates the temperature of the DHW.
4
1
3
2

EN
FR
NL
ES
IT
DE
PL
RU
en
6Smart Line SLE - SLE Plus : 661Y2100 • A
APPLIANCE DESCRIPTION
MODELS  SLE / SLE Plus
High efficiency storage water tanks, to be installed on the floor. Possibility to heat by transfer fluid
or independently with an optional electric resistance.
1. Manual air bleed valve
2. Polypropylene shell
3. Dip tube
4. Electrical heating element (optional)
5. Outer steel tank (primary circuit)
6. Polypropylene top lid
7. Polyurethane foam insulation
8. Dry well
9. Stainless steel tank (DHW)
10. Polypropylene bottom lid
6
2
1
3
5
4
7
9
8
10

en
7
EN
FR
NL
ES
IT
DE
PL
RU
Smart Line SLE - SLE Plus : 661Y2100 • A
TECHNICAL CHARACTERISTICS
TECHNICAL CHARACTERISTICS
MAIN CHARACTERISTICS
MAIN CHARACTERISTICS
SLE
130
SLE
160
SLE /
SLE Plus
210
SLE /
SLE Plus
240
SLE /
SLE Plus
300
Total capacity L 130 161 203 242 293
Primary circuit capacity (heating) L 55 62 77 78 93
Sanitary circuit capacity L 75 99 126 164 200
Primary uid ow rate L/h 2100 2600 3500 4200 5500
Primary pressure drop mbar 17 22 37 45 51
Tank heating surface m² 1,03 1,26 1,54 1,94 2,29
Empty weight kg 45 54 66 76 87
DIMENSIONS
SLE
130
SLE
160
SLE
210
SLE
240
SLE
300
SLE Plus
210
SLE Plus
240
SLE Plus
300
A (mm) 1025 1225 1495 1740 2045 1495 1740 2050
B (mm) 760 960 1230 1480 1780 1230 1480 1785
C (mm) 235 235 235 235 230 235 235 235
D (mm) 235 235 335 340 405 315 305 340
E (mm) — — — — — 940 1070 1280
F (mm) — — — — — 475 455 525
G (mm) — — 375 375 405 355 345 380
H (mm) — — 235 235 230 235 235 235
A
B
CD
E
FGHG
360
150
565

EN
FR
NL
ES
IT
DE
PL
RU
en
8Smart Line SLE - SLE Plus : 661Y2100 • A
TECHNICAL CHARACTERISTICS
HEATING CONNECTIONS
DOMESTIC HOT WATER CONNECTIONS
1. Heating ow connection (tank loading)
2. Auxiliary heating return
(only SLE Plus)
3. Auxiliary heating return
(only SLE Plus)
4. Heating ow connection / heat pump
(except SLE 130 - 160)
5. Optional electrical heating element connection
6. Heating return connection / heat pump
7. Flow heating circuit
(except SLE 130 - 160)
8. Return heating circuit
(except SLE 130 - 160)
1. Cold water inlet connection
2. Auxiliary connection (DHW)
3. Domestic hot water connection
Connections
dimensions
SLE /
SLE Plus
Heating connection Ø 1" [F]
Optional electrical heating
element connection Ø 1"½ [F]
Connections
dimensions
SLE /
SLE Plus
Cold / hot water
connections Ø 3/4" [M]
Auxiliary
connections Ø 3/4" [F]
1
2
3
4
6
5
7
8
21
3

en
9
EN
FR
NL
ES
IT
DE
PL
RU
Smart Line SLE - SLE Plus : 661Y2100 • A
TECHNICAL CHARACTERISTICS
DOMESTIC HOT WATER PERFORMANCES
DHW performance :
Heating source = External boiler
connected to tank *
SLE
130
SLE
160
SLE /
SLE Plus
210
SLE /
SLE Plus
240
SLE /
SLE Plus
300
Peak ow at 40°C [∆T = 30K] L/10' 236 321 406 547 800
60°C [∆T = 50K] L/10' 117 161 209 272 370
Constant ow at 40°C [∆T = 30K] L/h 658 890 1132 1527 2100
60°C [∆T = 50K] L/h 320 465 576 769 970
Peak ow 1st hour at 40°C [∆T = 30K] L/60' 784 1063 1349 1820 2360
60°C [∆T = 50K] L/60' 384 549 689 913 1100
Maximum absorbed power kW 23 31 39 53 68
Reheat time Minutes 22 22 20 20 22
* Conditions : Primary circuit temperature : 85°C, water intake temperature : 10°C
MAXIMUM OPERATING CONDITIONS
Maximum Service Pressure [tank full of water]
- Primary circuit : .................................................3 bar
- DHW water circuit : ......................................8,6 bar
Maximum Temperature
- Maximum DHW temperature : ....................90°C
Supply Pressure (DHW circuit)
- Max. 6 bar without requiring a pressure reducing valve
Water Quality
- Chlorides < 150 mg/L
- 6 ≤ pH ≤ 8
- If the water hardness is > 20°fH, the installation of a water softener is recommended.

EN
FR
NL
ES
IT
DE
PL
RU
en
10 Smart Line SLE - SLE Plus : 661Y2100 • A
TECHNICAL CHARACTERISTICS
ELECTRICAL CHARACTERISTICS
Main characteristics SLE / SLE Plus
Rated voltage V~ 230
Rated frequency Hz 50
Optional heating element
The models SLE / SLE Plus can be installed with a self- controlled heating element with built-
in control safety thermostats. The control thermostat of the tank can not control the heating
element. To be mounted with an external box with a switch and a circuit breaker - not included
in the delivery.
Volt Amp Power Code
1 x 230 V 13 3 kW 10800081
3 x 400 V + N 4.4 3 kW 10800082
1 x 230 V 26 6 kW 10800083
3 x 400 V + N 8.8 6 kW 10800084
Wiring diagram
1. Manual reset high limit thermostat
2. Control thermostat [60/90°C]
Bk. Black
Br. Brown
Or. Orange
R. Red
W. White
Y/Gr. Yellow/Green
1
Y/Gr
Br
Y/Gr
R
W
Or
Bk
T2S3 T1 NL1
T2 S3T1NL1
t
2
c
1
2
t
c
1
L
N/C
N/O

en
11
EN
FR
NL
ES
IT
DE
PL
RU
Smart Line SLE - SLE Plus : 661Y2100 • A
INSTALLATION
PACKAGE CONTENTS
The appliances are delivered assembled, tested and packed.
At product reception and after removal of packaging,
check the package contents and that the appliance is
free of damages.
Contents packaging :
• A domestic hot water tank.
• A technical manual
TOOLS REQUIRED FOR THE INSTALLATION
General remarks
Make sure to place the rating plate on the outer casing of the tank, so that it is easily
accessible and readable.
The manufacturer reserves the right to change the technical characteristics and
features of its products without prior notice.
The availability of certain models as well as their accessories may vary according to
the markets.

SAFETY INSTRUCTIONS
General remark
• Connections (electrical, hydraulic) must be carried out in accordance with
applicable standards and regulations.
• If the water drawing off point is far from the tank, installing an auxiliary DHW loop
can allow to get hot water more quickly at all times.
Essential instructions forthecorrect operation oftheinstallation
• The tank must be installed in a dry and protected area.
• Install the appliance to ensure easy access at all times.
• To avoid any risk of corrosion, connect the stainless steel tank directly to the earth.
• Make sure to install a pressure reducing valve set at 4.5 bar in the DHW circuit if the
supply pressure is higher than 6 bar.
• On the DHW circuit, install an approved safety group, comprised of a safety valve
set at 7 bar, a check valve and a stop valve.
• Make sure that the outlet of the safety unit goes directly to the sewer to avoid any
potential damage.
• Do not install the safety group above the tank to avoid water discharge on to the
tank.
EN
FR
NL
ES
IT
DE
PL
RU
en
12 Smart Line SLE - SLE Plus : 661Y2100 • A
INSTALLATION

Essential instructions forthe safety of persons and the environment
• Hot water can burn!
In the event of small amounts of hot water repeatedly being drawn off, a
stratification effect can develop in the tank. The upper hot water layer may then
reach very high temperatures.
• ACV recommends using apre-set thermostatic mixing valve in order to provide
hot water at a maximum of 60°C.
• Water heated to wash clothes, dishes and for other uses can cause serious burns.
• In order to avoid exposure to extremely hot water that can cause serious burns,
never leave children, old people, disabled or handicapped people in the bath
orshower alone.
• Never allow young children to turn on the hot water or fill their own bath.
• Adjust the water temperature in accordance with usage and plumbing regulations.
•
The risk of developing bacteria exists, including “Legionella pneumophila”,
ifaminimum temperature of 60°C is not maintained in both the DHW tank andthe
hot water distribution network.
Essential instructions for the electrical safety
• Only an approved installer is authorized to carry out the electrical connections.
• Install a 2-way switch and a fuse or circuit breaker of the recommended rating
outside the appliance, so as to be able to shut power down when servicing the
appliance or before performing any operation on it.
• Shut down external electrical supply of the appliance before performing any
operation on the electrical circuit.
• This appliance is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge,
unless supervised or unless they have been given instruction concerning the use
of the appliance by a person responsible for their safety.
en
13
EN
FR
NL
ES
IT
DE
PL
RU
Smart Line SLE - SLE Plus : 661Y2100 • A
INSTALLATION

1 2 3 4
5
67
8
9
11
10
12
Horizontal installation Vertical installation
Cold water
Hot water
CONNECTION
Essential instructions forthe safety of persons and the environment
• Refer to the safety instructions for the installation. Failure to comply with these
instructions can result in damages to the installation, severe injuries or death.
• Hot water can burn! ACV recommends using a pre- set thermostatic mixing valve
in order to provide hot water at a maximum of 60°C.
Essential instructions forthecorrect operation oftheinstallation
• The filling circuit of the DHW tank must be equipped with a safety group,
comprised at least of a stop valve, a check valve, a safety valve set at 7 bar, and
possibly, an expansion vessel of the appropriate size. Make sure that the circuit
between the tank and the safety valve is always open.
• The third DHW tank connection, if any, can be used for the auxiliary DHW loop.
If the connection is not used, replace the protective plug by a brass plug of the
appropriate size.
General remarks
• In certain countries the domestic kits must be approved.
• The circuit illustrations are basic principle diagrams only.
CONNECTION TO THE DHW CIRCUIT (Typical wall installation)
Key
1. Filling valve
2. Pressure reducing valve (set at 4.5 bar)
3. Check valve
4. Stop valve
5. DHW expansion vessel
6. Pressure gauge
7. Safety valve (set at 7 bar)
8. Drain valve
9. Grounding
10. Stop valve
11. Thermostatic mixing valve
12. Hot water outlet
EN
FR
NL
ES
IT
DE
PL
RU
en
14 Smart Line SLE - SLE Plus : 661Y2100 • A
INSTALLATION
• To protect the primary circuit when the stop valves are closed, a safety valve and
expansion vessel are imperative between the tank and the stop vales.

en
15
EN
FR
NL
ES
IT
DE
PL
RU
Smart Line SLE - SLE Plus : 661Y2100 • A
INSTALLATION
CONNECTION TO THE DHW CIRCUIT
1. Filling valve
2. Pressure reducing valve (set at 4.5 bar)
3. Check valve
4. DHW expansion vessel
5. Safety valve (set at 7 bar)
6. Drain valve
7. Draw-o tap
8. Pressure gauge
9. Grounding
10. Stop valve
11. Thermostatic mixing valve
12. Air vent
Cold water
Hot water
Domestic hot water kit (option)
1. Thermostatic mixing valve
2. Mixed water outlet - Ø 3/4" [M]
3. DHW expansion vessel connection - Ø 3/4" [M]
4. Safety unit (7 bar)
5. Outlet hot water tank - Ø 3/4" [F]
6. Inlet cold water tank - Ø 3/4" [F]
7. Cold water inlet - Ø 3/4" [M]
8. Drain connection - Ø 1" [M]
2
7
1
5 6
3 4
8
The drain connection 8must be connected to the sewer system to avoid hot water
projections on the top cover of the tank.
1
10
23
4
8
5
9
10
7
6
11
2
7
1
5 6
3 4
8
12

EN
FR
NL
ES
IT
DE
PL
RU
en
16 Smart Line SLE - SLE Plus : 661Y2100 • A
INSTALLATION
CONNECTION TO THE PRIMARY CIRCUIT
1. Primary circuit lling valve
2. Charging pump
3. Check valve
4. Primary circuit stop valve
5. Expansion vessel
6. Pressure gauge
7. Safety valve (set at 3 bar)
8. Drain valve
9. Stop valve
Cold water
Hot water
1 2 3 4
85
9
7
6
4

en
17
EN
FR
NL
ES
IT
DE
PL
RU
Smart Line SLE - SLE Plus : 661Y2100 • A
INSTALLATION
EXAMPLES OF POSSIBLE COMBINATIONS OF THE SLE AND SLE PLUS
SLE Plus combined with a heat pump and floor heating system.
SLE 210 / 240 / 300 combined with a boiler and floor heating system.
Prestige

EN
FR
NL
ES
IT
DE
PL
RU
en
18 Smart Line SLE - SLE Plus : 661Y2100 • A
INSTALLATION
TANK USED AS ELECTRIC DHW TANK ONLY
Do not power the heating element if the outside tank is not filled and bled.
1. System lling valve
2. Safety valve (set at 3 bar)
3. Expansion vessel
4. Isolation valve, heating system
5. Pressure gauge
Essential instruction for the correct operation of the installation
• Connections must be carried out in accordance with applicable standards and
regulations.
4
1
2
3
5
Plug all unused
connections
Plug all unused
connections

SAFETY INSTRUCTIONS TO FILL THE TANK
Essential instructions forthe safety of persons and the environment
• The DHW tank must always be filled and pressurised before filling and pressurising
the primary circuit.
• Do not use vehicle antifreeze. This can causeserious injury or death, or damage
facilities.
• If antifreeze is needed in the primary circuit, it must comply with Public
Hygiene Regulations and must be non-toxic. A food-grade Propylene Glycol is
recommended. It must be diluted according to the ratio recommended in the local
regulations.
• Consult the manufacturer to determine the compatibility of the antifreeze with the
tank's construction materials.
Essential instructions forthecorrect operation oftheinstallation
• Before bringing the tank into service, check the connections to avoid any risk
ofleaks during filling.
• Only use drinking water to check that the DHW tank is watertight. The on-site
testpressure must not exceed a pressure surge of 8,6 bar.
• Using antifreeze in the primary circuit will lead to a reduction in the heating
performance. The higher the concentration of antifreeze in the circuit, the lower
the performance.
en
19
EN
FR
NL
ES
IT
DE
PL
RU
Smart Line SLE - SLE Plus : 661Y2100 • A
STARTING UP

FILLING THE DHW TANK Figure 1
General remark
• Connect the safety valve outlet to the sewer.
1. To fill the tank, open a hot water tap (2) located at the highest point of the installation. It
enables to bleed the air from the installation.
2. Open the filling valve (1) and the stop valves (3) to fill the DHW tank.
3. Close the hot water tap (2), after the water flow has stabilised and the air has been
completely evacuated.
4. Check all the connections of the installation for leaks.
FILLING THE PRIMARY CIRCUIT Figure 2
General remark
• If the tank is used within a heating installation, refer to the heating boiler manual.
1. Check that the drain valve (3) of your primary circuit is tightly closed.
2. Open the stop valves (1) and (2) of the primary circuit connected to the heating boiler.
3. Open the air bleed valve (4) located on the top of the hot water tank.
4. When the air is eliminated, close the airbleed valve (4). Make sure the air bleed valve is tight.
FILLING
Essential instructions forthecorrect operation oftheinstallation
• The DHW tank must always be filled and pressurised before filling and pressurising
the primary circuit.
1. Check that the drain valve (3) of your primary circuit is tightly closed.
2. Open the stop valves (1) and (2) of the primary circuit connected to the heating boiler.
3. Open the air bleed valve (4) located on the top of the hot water tank.
4. Connect the filling pipe to the valve (3) and open the valve to start filling the heating circuit.
5. Once the system is bled from air, close the airbleed valve (4). Make sure the air bleed valve
is tight.
6. Once the desired pressure is reached, close the valve (3) and disconnect the filling pipe from
the valve (3).
EN
FR
NL
ES
IT
DE
PL
RU
en
20 Smart Line SLE - SLE Plus : 661Y2100 • A
STARTING UP
