ACV SMART Line SL Manual

661Y1700 • C
EN
FR
NL
ES
IT
DE
PL
RU
INSTALLATION, OPERATION AND
MAINTENANCE INSTRUCTIONS
SL & SLEW
100 - 130 - 160 - 210 - 240
SMART Line

en
2Smart Line SL - SLE W : 661Y1700 • C
EN
NL
ES
IT
DE
PL
RU
FR
TABLE OF CONTENTS
GENERAL RECOMMENDATIONS...............................................................4
USER'S GUIDE..............................................................................................5
Control Panel (SLEW models only)........................................................................................................... 5
APPLIANCE DESCRIPTION.........................................................................6
Models - SL / SLEW 100 - 130 - 160 - 210 - 240................................................................................................. 6
TECHNICAL CHARACTERISTICS ...............................................................8
Dimensions and Main Characteristics................................................................................................... 8
Electrical Characteristics.................................................................................................................................10
Performance .............................................................................................................................................................12
Maximum Operating Conditions.............................................................................................................12
INSTALLATION.........................................................................................13
Safety Instructions...............................................................................................................................................13
Packing Contents..................................................................................................................................................15
Tools.................................................................................................................................................................................15
Tank Installation : SL 100 / 130 / 160 / 210 / 240.........................................................................16
Tank Installation : SLEW 100 / 130 / 160 / 210 / 240.................................................................17
Connection................................................................................................................................................................18
SLEW tank used as electric DHW tank only.....................................................................................21
Available Kits and Accessories...................................................................................................................21
STARTING UP............................................................................................22
Safety Instructions to Fill the Tank..........................................................................................................22
Filling ..............................................................................................................................................................................23
Checks before Starting up.............................................................................................................................25

en
3
Smart Line SL - SLE W : 661Y1700 • C
EN
FR
NL
ES
IT
DE
PL
RU
TABLE OF CONTENTS
MAINTENANCE ........................................................................................26
Periodic Checks by the User ........................................................................................................................26
Annual Maintenance .........................................................................................................................................26
Draining........................................................................................................................................................................27
Bringing back into Service after Maintenance.............................................................................28
Replacement of the Electric Heating Element (SLEW tank) ..............................................29
Fault Finding.............................................................................................................................................................30

NOTES
• This manual contains important information with respect to the installation, the starting up
and the maintenance of the hot water tank.
• This manual must be provided to the user, who will read it carefully and keep it in a safe
place.
• The availability of certain models as well as their accessories may vary according to the markets.
• The manufacturer reserves the right to change the technical characteristics and features of
its products without prior notice.
We accept no liability should any damage result from the failure to comply with theinstruc-
tions contained in this technical manual.
Essential instructions forthe safety of persons and the environment
• It is strictly prohibited to bring any modification to the appliance, without
themanufacturer’s prior written approval.
• The appliance must be installed by a qualified installer, in accordance with
applicable regulations.
• The installation must comply with the instructions contained in this manual and
with the regulations applicable to installations.
• Failure to follow the instructions in this manual could result in personal injury or a
risk of environmental pollution.
• The manufacturer declines all liability for any damage caused as a result of
incorrect installation or in the event of the use of appliances or accessories that are
not approved by the manufacturer.
Essential instructions forthecorrect operation oftheinstallation
• In order to ensure that the appliance operates correctly, it is essential to have it
serviced by a certified installer or maintenance contractor every year.
• In case of problem, please contact your installer for advice.
• Faulty parts must only be replaced with genuine parts.
• Our domestic hot water tanks are designed and manufactured exclusively for the
heating and storage of domestic hotwater.
• The domestic hot water heaters must only be heated using hot water in a closed
circuit.
• The part number (N° Art.) and serial number (N° Ser.) of the tank are indicated on
its rating plate and must be provided to ACV in case of warranty claim. Failure to
do so will make the claim void.
en
4Smart Line SL - SLE W : 661Y1700 • C
EN
NL
ES
IT
DE
PL
RU
FR
GENERAL RECOMMENDATIONS

en
5
Smart Line SL - SLE W : 661Y1700 • C
EN
FR
NL
ES
IT
DE
PL
RU
Key :
1. Control thermostat [60/90°C] - To set the domestic hot water (DHW) temperature.
2. Fuse FF 12,5 Amp - To provide an electric protection to the appliance.
3. Summer / Winter switch - To activate the heating pump of the installation/deactivate the elec-
trical heating element ( - winter position) or activate the electrical heating element/deactivate
the installation pump ( - summer position).
4. Heating-element-on indicator - The built-in indicator lights when the heating element is acti-
vated ( position of the summer / winter switch).
USER'S GUIDE
CONTROL PANEL SLEW models only
1
2
3
4
Heating
element ON
Heating
element OFF

en
6Smart Line SL - SLE W : 661Y1700 • C
EN
NL
ES
IT
DE
PL
RU
FR
APPLIANCE DESCRIPTION
MODELS  SL / SLEW 100 - 130 - 160 - 210 - 240
SL : Storage water tanks, to be installed on the oor or either vertically or horizontally on the
wall, that work within a heating installation.
SLEW : Storage water tanks, to be installed vertically on the wall, that can work within a heating
installation, or independently as an electric domestic hot water heater. The SLEW tank
is equipped with one 2200 W heating element controlled by the thermostat and by the
Summer/Winter switch on the appliance control panel.
SL 100 - 130 - 160 - 210 - 240
1
2
10
4
5
6
7
8
9
11
12
14
15
13
8
3

en
7
Smart Line SL - SLE W : 661Y1700 • C
EN
FR
NL
ES
IT
DE
PL
RU
APPLIANCE DESCRIPTION
SLEW 100 - 130 - 160 - 210 - 240
1. Auxiliary connection DHW
2. Cold water inlet connection
3. Control thermostat
4. Flow connection (primary circuit)
5. Polyurethane foam insulation
6. Return connection (primary circuit)
7. Outer steel tank (primary circuit)
8. Manual air bleed valve (x 2 - SL Models)
9. Hot water outlet connection
10. Polypropylene top lid
11. Stainless steel tank (DHW)
12. Polypropylene shell
13. Polypropylene bottom lid
14. DHW thermometer
15. Dry well
16. Control panel
17. Electric heating element 2200 W
1
2
4
9
6
7
8
5
10
11
12
13
16
17
14
15
3

en
8Smart Line SL - SLE W : 661Y1700 • C
EN
NL
ES
IT
DE
PL
RU
FR
TECHNICAL CHARACTERISTICS
DIMENSIONS AND MAIN CHARACTERISTICS
Tank dimensions
SL / SLEW
100 130 160 210 240
Amm 865 1,025 1,225 1,497 1,744
Bmm 629 789 989 1,261 1,508
Cmm 365 525 725 997 1,244
Empty weight Kg 49 55 65 75 87
Main characteristics
SL
100 130 160 210 240
Total capacity L 105 130 161 203 242
Primary circuit capacity L 30 31 35 39 42
Primary circuit connection [F] " 1 1 1 1 1/4 1 1/4
DHW connection [M] " 3/4 3/4 3/4 3/4 3/4
Auxiliary DHW loop connection [F] " 3/4 3/4 3/4 3/4 3/4
Primary uid ow rate L/h 2100 2600 3500 4200 5500
Primary pressure drop mbar 17 22 37 45 51
Heating surface area m² 1.03 1.26 1.54 1.94 2.29
Main characteristics
SLEW
100 130 160 210 240
Total capacity L 105 130 161 203 242
Primary circuit capacity L 30 31 35 39 42
Primary circuit connection [F] " 1 1/4 1 1/4 1 1/4 1 1/4 1 1/4
DHW connection [M] " 3/4 3/4 3/4 3/4 3/4
Auxiliary DHW loop connection [F] " 3/4 3/4 3/4 3/4 3/4
Primary uid ow rate L/h 2100 2600 3500 4200 5500
Primary pressure drop mbar 17 22 37 45 51
Heating surface area m² 1.03 1.26 1.54 1.94 2.29

en
9
Smart Line SL - SLE W : 661Y1700 • C
EN
FR
NL
ES
IT
DE
PL
RU
TECHNICAL CHARACTERISTICS
A
B
264
C
360
325
295
145
565
AB
264
C
360
325
295
14
5
565
SL
A
B
264
C
565
360
325
295
145
A
B
264
C
565
360
325
295
14
5
SLEW

en
10 Smart Line SL - SLE W : 661Y1700 • C
EN
NL
ES
IT
DE
PL
RU
FR
TECHNICAL CHARACTERISTICS
Main characteristics SL
100 130 160 210 240
Rated voltage V~ 230 230 230 230 230
Rated frequency Hz 50 50 50 50 50
Max. Amp rating A 6 6 6 6 6
ELECTRICAL CHARACTERISTICS
Wiring diagram
1. 230 Volt supply cord
2. Control thermostat [60/90°C]
3. Manual reset high limit thermostat [96°C max.]
4. Summer / Winter switch
5. Fuse FF 12,5 A
6. Electric heating element
7. Charging pump [option]
8. Heating-element-on indicator
B. Blue
Bk. Black
Br. Brown
G. Grey
Or. Orange
W. White
Y/Gr. Yellow/Green
1
7
Br
Y/Gr
B
Br
B
Br
Y/Gr
BB
B
G
T2S3 T1 N L1
T2 S3T1NL1
SLE W
6
BBk
t
c
1
2
t
2
3
5
4
B
BB
G
G
W
Or
Bk
c1
2
SL
Br
Y/Gr
B
OrOr
Y/Gr
Bk
Bk
N L1
L1 N
t
2
7
SL

en
11
Smart Line SL - SLE W : 661Y1700 • C
EN
FR
NL
ES
IT
DE
PL
RU
TECHNICAL CHARACTERISTICS
Main characteristics SLEW
100 130 160 210 240
Rated voltage V~ 230 230 230 230 230
Rated frequency Hz 50 50 50 50 50
Electrical consumption with
electrical heating element W2,200 2,200 2,200 2,200 2,200
Rated current with electrical
heating element A10 10 10 10 10
c
2 1
t
t
L1 PE N
M
T1
T2
Br Bk
Or
W
B
Y/Gr
B
Y/Gr
B
B
Gr Br
BB
Bk B
Bk
7
3
2
4
5
6
230 V ~50Hz
B
Y/Gr
Br
1
8
SLEW

en
12 Smart Line SL - SLE W : 661Y1700 • C
EN
NL
ES
IT
DE
PL
RU
FR
TECHNICAL CHARACTERISTICS
MAXIMUM OPERATING CONDITIONS
Maximum Service Pressure [tank full of water]
- Primary circuit :..................................................3 bar
- DHW water circuit : ......................................8.6 bar
Maximum Temperature
- Maximum DHW temperature : ....................90°C
Supply Pressure (DHW circuit)
- Max. 6 bar without requiring a pressure reducing valve
Water Quality
- Chlorides < 150 mg/L (304 Stainless steel)
< 2000 mg/L (Duplex)
- 6 ≤ pH ≤ 8
- If the water hardness is > 20°fH, the installation of a water softener is recommended.
PERFORMANCE
DHW performance* SL / SLEW
100 130 160 210 240
Peak ow at 40 °C L/10' 236 321 406 547 700
Peak ow at 60 °C L/10' 117 161 209 272 337
Peak ow at 40 °C L/60' 784 1,063 1,349 1,820 2,319
Peak ow at 60 °C L/60' 384 549 689 913 1,165
Constant ow at 40 °C L/h 658 890 1,132 1,527 1,943
Constant ow at 60 °C L/h 320 465 576 769 994
Power drawn kW 23 31 39 53 68
Initial heating time Minutes 24 22 22 20 20
SLEW ONLY
Heating time with the 2.2 kW
heating element from 10 to 60°C 2 h 43' 3 h 27' 4 h 20' 5 h 37' 6 h 37'
Conditions: Primary circuit temp.: 85°C, water supply temp.: 10°C

SAFETY INSTRUCTIONS
General remark
• Connections (electrical, hydraulic) must be carried out in accordance with
applicable standards and regulations.
• If the water drawing off point is far from the tank, installing an auxiliary DHW loop
can allow to get hot water more quickly at all times.
Essential instructions forthecorrect operation oftheinstallation
• The tank must be installed in a dry and protected area.
• Install the appliance to ensure easy access at all times.
• To avoid any risk of corrosion, connect the stainless steel tank directly to the earth.
• Make sure to install a pressure reducing valve set at 4.5 bar in the DHW circuit if the
supply pressure is higher than 6 bar.
• On the DHW circuit, install an approved safety group, comprised of a safety valve
set at 7 bar, a check valve and a stop valve.
• Make sure that the outlet of the safety unit goes directly to the sewer to avoid any
potential damage.
• Do not install the safety group above the tank to avoid water discharge on to the
tank.
en
13
Smart Line SL - SLE W : 661Y1700 • C
EN
FR
NL
ES
IT
DE
PL
RU
en
13
INSTALLATION

Essential instructions forthe safety of persons and the environment
• Hot water can burn!
In the event of small amounts of hot water repeatedly being drawn off, a
stratification effect can develop in the tank. The upper hot water layer may then
reach very high temperatures.
• ACV recommends using apre-set thermostatic mixing valve in order to provide
hot water at a maximum of 60°C.
• Water heated to wash clothes, dishes and for other uses can cause serious burns.
• In order to avoid exposure to extremely hot water that can cause serious burns,
never leave children, old people, disabled or handicapped people in the bath
orshower alone.
• Never allow young children to turn on the hot water or fill their own bath.
• Adjust the water temperature in accordance with usage and plumbing regulations.
•
The risk of developing bacteria exists, including “Legionella pneumophila”,
ifaminimum temperature of 60°C is not maintained in both the DHW tank andthe
hot water distribution network.
Essential instructions for the electrical safety
• Only an approved installer is authorized to carry out the electrical connections.
• Install a 2-way switch and a fuse or circuit breaker of the recommended rating
outside the appliance, so as to be able to shut power down when servicing the
appliance or before performing any operation on it.
• Shut down external electrical supply of the appliance before performing any
operation on the electrical circuit.
• This appliance is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge,
unless supervised or unless they have been given instruction concerning the use
of the appliance by a person responsible for their safety.
en
14 Smart Line SL - SLE W : 661Y1700 • C
EN
NL
ES
IT
DE
PL
RU
FR
INSTALLATION

en
15
Smart Line SL - SLE W : 661Y1700 • C
EN
FR
NL
ES
IT
DE
PL
RU
INSTALLATION
Package
• One SL/SLEW hot water tank.
• One multilingual Installation, Operation and Maintenance Instructions.
• One wall-mounting kit with support and ow diverter
PACKING CONTENTS
All appliances are delivered, tested and packaged separately.
General Remark
• The hot water tank may be installed either on the floor or on a wall using the
provided wall-mounting kit (depending on the model).
Essential instructions for the correct operation of the installation
• When hung on a wall, the SLEW models must be assembled with the heating
element to the bottom (DHW pipes to the bottom).
• In horizontal configuration, the peak output and the first hour continuous output
will be reduced. In this case, we recommend to oversize the tank.
TOOLS

en
16 Smart Line SL - SLE W : 661Y1700 • C
EN
NL
ES
IT
DE
PL
RU
FR
INSTALLATION
TANK INSTALLATION : SL 100 / 130 / 160 / 210 / 240
Floor mounting
Vertical wall hung position : domestic water connections at the bottom side
12
Horizontal wall hung position : domestic water connections on the right side
12

en
17
Smart Line SL - SLE W : 661Y1700 • C
EN
FR
NL
ES
IT
DE
PL
RU
INSTALLATION
TANK INSTALLATION : SLEW 100 / 130 / 160 / 210 / 240
Vertical wall hung position : domestic water connections at the bottom side
SLEW
SLEW

1 2 3 4
5
67
8
9
11
10
12
Horizontal installation Vertical installation
Cold water
Hot water
CONNECTION
Essential instructions forthe safety of persons and the environment
• Refer to the safety instructions for the installation. Failure to comply with these
instructions can result in damages to the installation, severe injuries or death.
• Hot water can burn! ACV recommends using a pre- set thermostatic mixing valve
in order to provide hot water at a maximum of 60°C.
Essential instructions forthecorrect operation oftheinstallation
• The filling circuit of the DHW tank must be equipped with a safety group,
comprised at least of a stop valve, a check valve, a safety valve set at 7 bar, and
possibly, an expansion vessel of the appropriate size. Make sure that the circuit
between the tank and the safety valve is always open.
• The third DHW tank connection, if any, can be used for the auxiliary DHW loop.
If the connection is not used, replace the protective plug by a brass plug of the
appropriate size.
General remarks
• In certain countries the domestic kits must be approved.
• The circuit illustrations are basic principle diagrams only.
CONNECTION TO THE DHW CIRCUIT (Typical wall installation)
Key
1. Filling valve
2. Pressure reducing valve (set at 4.5 bar)
3. Check valve
4. Stop valve
5. DHW expansion vessel
6. Pressure gauge
7. Safety valve (set at 7 bar)
8. Drain valve
9. Grounding
10. Stop valve
11. Thermostatic mixing valve
12. Hot water outlet
en
18 Smart Line SL - SLE W : 661Y1700 • C
EN
NL
ES
IT
DE
PL
RU
FR
INSTALLATION

1
10
11
2 3
4
8
5
9
10
7
6
1234
5
46
9
8
Cold water
Hot water
CONNECTION TO THE DHW CIRCUIT (Typical floor installation)
Key
1. Filling valve
2. Pressure reducing valve (set at 4.5 bar)
3. Check valve
4. Expansion vessel
5. Safety valve (set at 7 bar)
6. Drain valve
7. Hot water outlet
8. Pressure gauge
9. Grounding
10. Stop valve
11. Thermostatic mixing valve
CONNECTION TO THE PRIMARY CIRCUIT Typical floor installation
Key
1. Primary circuit filling valve
2. Charging pump
3. Check valve
4. Primary circuit stop valve
5. Expansion vessel
6. Pressure gauge
7. Safety valve (set at 3 bar)
8. Drain valve
9. Stop valve
en
19
Smart Line SL - SLE W : 661Y1700 • C
EN
FR
NL
ES
IT
DE
PL
RU
INSTALLATION

Horizontal installation
Vertical installation
5
67
2 3 41
8
94
Cold water
Hot water
CONNECTION TO THE PRIMARY CIRCUIT Typical wall installation
Key
1. Primary circuit filling valve
2. Charging pump
3. Check valve
4. Primary circuit stop valve
5. Expansion vessel
6. Pressure gauge
7. Safety valve (set at 3 bar)
8. Drain valve
9. Stop valve
en
20 Smart Line SL - SLE W : 661Y1700 • C
EN
NL
ES
IT
DE
PL
RU
FR
INSTALLATION
