PRODUCT INFORMATION BOOKLET
Metrix-i
[972-0004] Document Reference: MTX_I_PIB_EN_1.2
Distribution Date: October 30th, 2014
Adamson Systems Engineering | Metrix-i Product Information Booklet Page 2
© 2014 Adamson Systems Engineering. All rights reserved. No part of this publication may be reproduced or transmitted in
any form or by any means without the express written consent of the publisher
Important Operating Instructions - Notication of instructions that must be strictly
followed to ensure proper use of the product.
Warning - Indication of a potential risk of harm to an individual or possibility of
damage to the product.
Symbols
Congratulations on your purchase of the Adamson Systems Engineering Metrix-i line array enclosure.
Included in your shipment should be: 1x Metrix-i enclosure
All products manufactured by Adamson Systems Engineering are inspected before packaging and shipping and should arrive
free from technical and visual defects. After opening the shipping container, check for any damage. If found, please notify
your Adamson representative immediately. The consignee should then initiate a damage claim with the shipping agent. Be
sure to save all contents and packing materials to be inspected by the carrier.
Read this document thoroughly and completely to become familiar with the product. Also read the product manual containing
vital information regarding proper use and safety limits of this product. All accompanying documentation can also be ob-
tained by contacting your Adamson representative, or through the website at http://www.adamsonsystems.com/.
We are always improving our products and technology, and as such, Adamson Systems Engineering reserves the right to
change the contents of its documents without prior notice. Please refer to Adamson Systems Engineering’s website for up to
date documentation.
General Information
Adamson Systems Engineering | Metrix-i Product Information Booklet Page 3
Safety Instructions
1. Read this document completely.
2. Follow all safety instructions and heed all warnings indicated by the appropriate signal.
3. This product is not to be modied.
4. This product is only to be used in conjunction with equipment or accessories authorized by Adamson Systems Engineer-
ing. Using unauthorized items is prohibited as this allows risk of hazardous accidents and/or personal injury.
5. Read the accompanying user manual before using the product. Follow all instructions regarding use of approved acces-
sories.
6. Before suspending this product, read the accompanying user manual’s rigging section.
7. Do not expose this product to extreme environmental conditions, such as excessive heat, moisture or rain for prolonged
periods of time.
8. Do not store or transport this product on an unstable surface.
9. When transporting this product, please carry by using the handles, or use the approved transportation accessories.
10. Maintain all documentation shipped with the product. Record any service to the product in the maintenance section, and
if re-selling the product, include these documents in the transaction.
11. The maintenance section of this document is to be followed exactly.
Please read the Metrix User Manual for proper use of this loudspeaker product.
Please read the rigging section of the Metrix User Manual for proper rigging techniques and safety limits.
Use Blueprint AV™ to determine proper rigging information.
Proper Use
Rigging
Adamson Systems Engineering | Metrix-i Product Information Booklet Page 4
Metrix
Frequency Range (+/- 3dB) 95 Hz - 18 kHz
Nominal Directivity (-6 dB) H x V 120° x 5°
Maximum Peak SPL** 136.5 dB
Components LF ND8-LM 8” Kevlar Neodymium Driver
Components HF B&C DE800 3” Diaphragm / 1.4” Exit Compres-
sion Driver
Nominal Impedance LF 16 Ω
Nominal Impedance HF 16 Ω
Power Handling (AES / Peak) LF 250 / 1000 W
Power Handling (AES / Peak) HF 110 / 440 W
Rigging AIR™ Revolving Disc System (Touring) or EIR™
Plate System (Install)
Connection 2x Speakon™ NL8
Height Front (mm / in) 217 / 8.56
Width (mm / in) 540 / 21.25
Depth (mm / in) 420 / 16.5
Weight (kg / lbs) 24.2 / 53.5 (-t), 19.7 / 43.5 (-i)
Processing Lake, XTA
The Adamson Metrix is an ultra compact 2-way true line
source array enclosure which provides unmatched clarity
for speech reinforcement and medium SPL for smaller to
mid-size venue installations, or for use as an underhang-,
side-, front- or balcony ll enclosure in larger installations.
The Metrix offers lightning fast rigging and multiple uses
for applications of all sizes. The Metrix line is available
with AIR™ laser cut steel touring rigging (-t), or with EIR™
installation rigging (-i) with reduced weight and cost.
Similar to the high-end SpekTrix True Line Source Array
Series, the Metrix houses the Adamson ND8-LM 8” Kev-
lar neodymium low-mid frequency driver optimized for
this 2-way enclosure, and B&C’s DE800 1.4” HF com-
pression driver with an Adamson patented high frequen-
cy wave shaping chamber. The result is clear, clean high
end, with a full and warm mid-range.
The Metrix system makes for an impeccable main P.A
system for smaller touring applications such as for the-
atre & dance companies, when used in conjunction with
the Metrix double 15” sub woofer, as well as a front, side,
or stage-ll speaker for full-sized touring applications.
Specications
540 mm / 21.25 in
420 mm / 16.5 in
207 mm / 8.56 in
**12 dB crest factor pink noise at 1m, free eld, using specied processing and amplication
Adamson Systems Engineering | Metrix-i Product Information Booklet Page 5
EC Declaration of Conformity
ADAMSON SYSTEMS ENGINEERING, INC.
1401 Scugog Line 6, Port Perry (ON), L9L 1B2, Canada
Declares that the product:
972-0004 Metrix-i
Is in conformance with all applicable essential requirements of the Directives:
2006/42/EC: Machinery Directive (relevant to the rigging system of the loudspeaker)
2006/95/EC: Low Voltage Directive
It has been designed to comply with the relevant sections of the following standards and technical specications:
Harmonised Standards
EN ISO 12100 (11/2010) Safety of Machinery
EN 60065 (10/2011): Audio, Video and Similar Electronic
Apparatus – Safety Requirements
Further Standards and Regulations
DIN EN 1993-1 Eurocode 3 (12/2010), Design of Steel Structures
DIN 18800 (11/1990), Steel Structures
DIN EN 1999-1 Eurocode 9 (05/2010), Design of Aluminium Structures
DIN 4113 (9/2002), Aluminium constructions
BGV C1 (04/1998), German Accident-Prevention Regulation for Staging and Production
Facilties for the Entertainment Industry
The Technical File is maintained at:
ADAMSON EUROPE GMBH
Billstr. 173, 20539 Hamburg, Germany
Contact person and authorized representative:
Jochen Sommer (Director of European Operations)
------------------------------------------------
Brock Adamson (President & CEO)
Established at Port Perry, ON. CA - October 30th, 2014
Adamson Systems Engineering | Metrix-i Product Information Booklet Page 6
MAINTENANCE RECORD Serial Number: #________________________________________
Date Service Record Technician
Maintenance
Adamson Systems Engineering products should be regularly inspected to ensure proper performance
and safety. Please refer to the Metrix User Manual for detailed instructions.
Only perform repair work using the Metrix-i Service Kit [945-0031]
Any other repair work is not authorized and will void the warranty. Please contact an Adamson representa-
tive for further information.
Adamson Systems Engineering | Metrix-i Product Information Booklet Page 7
MAINTENANCE RECORD Serial Number: #________________________________________
Date Service Record Technician
Maintenance
Metrix-i
2 way line source enclosure [972-0004]
LF - 1x 8” ND8-LM [940-0017]
HF - 1x 3” DE800 [140-0009]
EIR™ installation rigging plate system
www.adamsonsystems.com
www.facebook.com/adamsonsystems
CANADA: 905-982-0520
UNITED STATES: 952-892-6003
EUROPE: +49 40 7699 9959 0
