SERIES 6H DATA SHEET
4- and 8-port PCIe Gen2 HBAs offer broad device compatibility,
scalability, and exibility
Adaptec PCIe Gen2 6Gb/s
SAS and SATA HBA Family
(6405H, 6805H)
e Series 6H family of Adaptec by PMC SAS/
SATA host bus adapters (HBA) oers the ideal
economical solution for customers requiring
high-performance I/O connectivity.
e HBAs connect to hard disk drives (HDDs),
solid-state drives (SSDs), removable media,
and SAS tape drives, and support the migration
of disks from onboard SATA interfaces or other
SATA/SAS I/O controllers.
Flexible, Scalable, Customizable
Using PMC’s PM8001 SAS protocol controller
and a PCIe Gen2 interface, Series 6H HBAs
support both Serial Attached SCSI (SAS) and
Serial ATA (SATA) interfaces to provide the
exibility to use cost-eective, high-capacity
SATA drives and/or high-performance SAS
drives.
Compatibility with a multitude of storage
devices enables system builders to develop
server, storage, and backup solutions tailored
to meet specic customer needs.
Series 6H HBAs also support SAS expanders,
allowing end users to scale-up and design an
optimal price-per-drive solution.
Series 6H HBAs feature a form factor shorter
than low-prole MD2, enabling easy installation
and cable connections in dense server
environments where space is at a premium.
e PCIe x4 bus expands connectivity from
high-end servers into workstation-class and
industrial PC systems. Up to 8 SAS ports allow
for maximum I/O throughput, and the OS
drivers use MSI-X to leverage all available host
CPU cores to achieve maximum performance.
Broad Operating System Support
Extensive operating system support includes
major soware releases for Windows 8,
Windows 7, Windows Server 2012, Windows
2008R2 & SBS 2011, VMware 5.x and Red Hat
Enterprise Linux.
Compatibility, Reliability, and Support
Series 6H HBAs have been extensively tested
with third-party systems and devices to deliver
the utmost in compatibility. ese HBAs are
equipped with both uEFI and legacy BIOS
options as well as a CTRL-A conguration
utility and HII-based BIOS tools.
Series 6H HBAs are backed by a three year
warranty and the company’s technical support
team.
Product Highlights
Designed to meet individual
performance and budget needs
6Gb/s throughput at each port
Supports SAS and SATA HDDs,
SSDs and SAS tape drives
PCIe Gen2 x4 host interface
Shorter than low-prole MD2
form factor
Connectors out the back allow
for easy cable connections
Up to 280,000 IOPS @ 4KB
block size
Up to 1600 MB/s sequential
throughput (64KB blocks)
Support for SAS expanders
supporting up to 128 devices
Enclosure management support
via LED header and SES2/SGPIO
Driver support for Windows,
VMware and Linux

SERIES 6H DATA SHEET
PMC-Sierra, Inc.
1380 Bordeaux Dr.
Sunnyvale, CA 94089 USA
Tel: [phone]
© Copyright PMC-Sierra, Inc. 2013. All rights reserved. PMC, PMC-SIERRA and Adaptec are registered trademarks of PMC-Sierra, Inc. “Adaptec by PMC” is a trademark of PMC-Sierra, Inc.
Other product and company names mentioned herein may be trademarks of their respective owners. For a complete list of PMC-Sierra trademarks, see www.pmc-sierra.com/legal.
DS_Series6H_031313_US Information subject to change without notice.
World Wide Web: www.adaptec.com
Pre-Sales Support: US and Canada: 1 [phone] or [phone] or [email protected]
UK: [phone] or [email protected]
Australia: [phone]
Germany: [phone] or [email protected]
Singapore: [phone]
Adaptec Series 6H Family
Why to buy? Cost effective I/O solution supporting SAS and SATA HDDs, SSDs, removable media, SAS tape drives.
Customer Needs I/O connectivity offers broad compatibility, support for SAS expanders, and enclosure management;
exibility to install SAS and SATA drives.
Features — Four (6405H) or eight (6805H) 6Gb/s ports
— PMC PM8001 SAS protocol controller supports SAS and SATA HDDs, SSDs and SAS tape drives
— Up to 280,000 IOPS at 4KB block size
— Up to 1600 MB/s sequential throughput (64KB blocks)
— Support for SAS expanders
— Enclosure management support via LED header and SES2/SGPIO
— PCIe Gen2 x4 host interface
— Shorter than Low-prole MD2 form factor
Management Utilities Adaptec BIOS Conguration Utility (ACU)
— Legacy conguration utility
— Flashable BIOS support
Adaptec uEFI BIOS Conguration Utility
— HII based conguration utility
— Flashable BIOS support
Operating Systems Windows 8, Windows 7, Windows Server 2012, Windows 2008R2, SBS 2011, Storage Server, Red Hat Enterprise Linux,
VMware. The latest drivers are available at www.adaptec.com/support.
Physical Dimensions 2.535”H x 6.095”L (64mm x 155mm)
Operating Temperature 0°C to 55°C with 200 LFM airow
Operating Current 0.09A@3.3V and 0.7A@12V
Regulatory Certication FCC, C-tick, CE, VCCI, CNS, KCC, UL, BSMI
MTBF 2,000,000 hours at 40°C
Warranty 3 years
Accessories Serial Attached SCSI (SAS) cables (www.adaptec.com/cables)
Adaptec by PMC HBA ASA-6405H ASA-6805H
Order Part Number 2278000-R (Single) 2277900-R (Single)
Form Factor MD2- Low Prole
2.535”H x 6.095”L
MD2- Low Prole
2.535”H x 6.095”L
Ports 4 Internal 8 Internal
Connectors 1 SFF-8087 (Internal) 2 SFF-8087 (Internal)
Host Bus Interface 4-Lane PCIe Gen2 4-Lane PCIe Gen2
Processor PMC PM8001 PMC PM8001
Adaptec PCIe Gen2 6Gb/s
SAS and SATA HBA Family (6405H, 6805H)
